SoundMax SM-CDM1036 User manual

SM-CDM1036
CD/MP3/WMA–RECEIVER CD/MP3/WMA-РЕСИВЕР
Instruction manual Руководство по эксплуатации

2
Dear customer!
Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully
before connecting, operating and/or adjusting the product and keep the manual for reference in the future.
Table of contents
Table of contents............................................................................................................................2
Important safeguards .....................................................................................................................3
Installation/Connections..................................................................................................................4
Panel controls ................................................................................................................................7
General operations .........................................................................................................................9
CD/MP3 operations....................................................................................................................... 10
MP3 overview .............................................................................................................................. 12
Radio operations .......................................................................................................................... 13
Anti-theft system ......................................................................................................................... 17
Handling compact discs................................................................................................................. 18
Cleaning ..................................................................................................................................... 18
Troubleshooting guide................................................................................................................... 19
Specification................................................................................................................................ 20

3
Important safeguards
• Read carefully through this manual to familiarize yourself with this high-quality sound system.
• Disconnect the vehicle's negative battery terminal while mounting and connecting the unit.
• When replacing the fuse, be sure to use one with an identical amperage rating. Using a fuse with a
higher amperage rating may cause serious damage to the unit.
• DO NOT attempt to disassemble the unit. Laser beams from the optical pickup are dangerous to the
eyes.
• Make sure that pins or other foreign objects do not get inside the unit; they may cause malfunctions, or
create safety hazards such as electrical shock or laser beam exposure.
• If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car
becomes normal before operating the unit.
• DO NOT open covers and do not repair yourself. Consult the dealer or an experienced technician for
help.
• Make sure you disconnect the power supply and aerial if you will not be using the system for a long
period or during a thunderstorm.
• Make sure you disconnect the power supply if the system appears to be working incorrectly, is making
an unusual sound, has a strange smell, has smoke emitting from it or liquids have got inside it. Have a
qualified technician check the system.
• The unit is designed for negative terminal of the battery, which is connected to the vehicle metal.
Please confirm it before installation.
• Do not allow the speaker wires to be shorted together when the unit is switched on. Otherwise it may
overload or burn out the power amplifier.
• Do not install the detachable panel before connecting the wire.

4
Installation/Connections
Parts List
Installation method 1

5
Installation method 2
Detaching the front panel
Replacing the front panel
Precautions

6
Connection diagram
1. Replaceable antenna 5. Output socket (male)
2. Line out (R) 6. Output socket (female)
3. Line out (L) 7. Fuse holder (15A, 0.5A)
4. Screw holes

7
Panel controls
Front panel
1. RESET button
2. POWER button
3. VOL knob (volume)
4. SEL button
5. TA button
6. SCAN button
7. MU button (mute)
8. DSP button
9. MOD button (mode)
10. Infra red sensor
11. BND button (band)
12. /buttons
13. AF button
14. PTY button
15. AMS button Inner panel
16. Number buttons
17. EJECT button
18. Disk slot
19. LCD display
20. RELEASE button
21. LED indicator

8
Remote control
1. POWER button
2. MUTE button
3. SCAN button
4. VOL+/VOL- buttons
5. RDM button
6. ST/AF button
7. D-DN/D-UP buttons
8. /buttons
9. AMS button
10. LOC/DX/PTY button
11. BAND button
12. PLAY/PAUSE button
13. SEL button
14. RPT button
15. MOD button
16. LOUD/TA button
17. INT button
18. DISP button
Installing the Battery
1. Pull out the battery holder while pressing the stopper 1.
2. Put the button-type battery (+) mark upward into the battery holder.
3. Insert the battery holder into the remote control.

9
General operations
Reset the unit
Operating the unit for the first time or after replacing the car battery, you must reset the unit.
Press RELEASE button, then press the RESET button to restore the unit to the original factory settings.
Power button
Press the POWER button to switch the unit on. Press it and hold for 2 seconds to turn the unit off.
Note: After the unit is off, volume level and radio current settings will be memorized, and when you turn
the unit on it will resume the stored status you set.
Volume control
Rotate VOL knob clockwise or VOL+/VOL- buttons to increase the volume level; rotate anticlockwise to
decrease the volume level.
Audio settings adjustment
Press SEL button shortly and repeatedly to select the mode: VOL => BAS => TRE => BAL => FAD. Rotate
the VOL knob to adjust each mode.
Mode selection
Press the MOD button to select the mode: TUNER => DISC.
Mute function
Press the MU button to turn off the sound. Press again to resume.
Clock setting
Press the DISP button on the RC or DSP button on the unit until the clock is shown. Then press and hold
this button, the clock starts blinking. Rotate the knob clockwise to adjust hours and anticlockwise to adjust
minutes.

10
CD/MP3 operations
Discs for playback
This unit can play disc types: CD/CD-R/-RW. Compatible with formats: CDDA/MP3/WMA.
Loading/eject a disc
• Press the RELEASE button on the panel. Insert the disc with the printed side facing upward into the slot.
• Press EJECT button on the inner side to eject the disc.
Playing/pausing playback
• Press PLAY/PAUSE button on the RC or PLAY button on the unit to start playback.
• Press PLAY/PAUSE button on the RC or PLAY button on the unit to pause the playback. Press again to
resume.
Playing the previous/next track
During playback press the /buttons to play the previous/next track.
Choosing 10+, 10- track
Press 10+,10- buttons on the unit or D-DN, D-UP buttons on the RC to jump over 10 tracks. Every 10th
track will play.
For example if you press this button three times, the order of the playing tracks will be as follows:
1=>11=>21=>31.
Fast forward and backward playback
Press and hold the /buttons to hasten the playing in backward or forward direction. Release the button
when the desired location is found.
Repeat playback
During disc playback, press the RPT button shortly to repeat the current track playback. Press again to
cancel.
Random playback
During disc playback, press the RDM button to start random playback of the tracks. Press again to cancel.

11
Intro playback
You can play the beginning of every track for 10 seconds in sequence. Press the INT button to start intro
play. Press again to cancel.
Track number searching
To find the track number:
1. Press the AMS button to open the Track search window.
2. Press SEL button, the LCD will show 000.
3. Rotate the VOL knob clockwise to increase the track number 1 by 1 starting from the first track number.
Rotate anticlockwise to decrease the track number 1 by 1 starting from the last track number.
4. OR If you want to set each figure when the display shows 000 rotate the VOL knob to set the last figure;
press SEL, the second figure will start blinking, rotate the VOL knob to set it; press SEL, the first figure
will start blinking, rotate the VOL knob to set it.
5. Press the SEL button and wait for 3 seconds to start the desired track playback.
File searching
To find the file in the folder:
1. Press the AMS button twice to enter the file search window.
2. Press SEL button. “A” directory will be displayed.
3. Rotate the VOL knob to select another directory.
4. Press the SEL button to enter it. The display will show the first track in this folder.
5. Rotate the VOL knob to select the track.
6. Press the SEL button to start its playback.
File character searching
To find the file name:
1. Press the AMS button three times to enter the file character search window.
2. Press SEL button. The first character “A” will start blinking.
3. Rotate the VOL knob to set the first character or figure.
4. Press SEL button. The second character “A” will start blinking.
5. Repeat 3-4 steps to insert the desired word.
6. Press the SEL button to start its playback.

12
MP3 overview
Notes on MP3
• MP3 is short for MPEG Audio Layer 3 and refers to an audio compression technology standard.
• This product allows playback of MP3 files on CD-ROM, CD-R or CD-RW discs.
• The unit can read MP3 files written in the format compliant with ISO 9660. However it does not support
the MP3 data written by the method of packet write.
• The unit can not read an MP3 file that has a file extension other than “.mp3”.
• If you play a non- MP3 file that has the “.mp3” extension, you may hear some noise.
• In this manual, we refer to what are called “MP3 file” and “folder” in PC terminology as “track” and
“album”, respectively.
• Maximum number of directory level is 8, including the root directory. Maximum number of files and
folders per disc is 256.
• The unit may not play tracks in the order of Track numbers.
• The unit plays only the audio tracks if a disc contains both audio tracks and MP3 files.
• When playing a disc of 8 kbps or “VBR”, the elapsed playing time in the display window will not be
correct and also the intro play may not function properly. “VBR”: Variable Bit Rate.
Notes on creating your own CD-Rs or CD-RWs containing MP3 files
• To enjoy high quality sound, we recommend converting to MP3 files with a sampling frequency of 44.1
kHz and a fixed bit rate o f 128 kbps.
• DO NOT store more than 256 MP3 files per disc.
• For ISO 9660 - compliant format, the maximum allowable depth of nested folders is 8, including the
root directory (folder).
• When CD-R disc is used, playback is possible only for discs, which have been finalized.
• Make sure that when MP3 CD-R or CD-RW is burned that it is formatted as a data disc and NOT as an
audio disc.
• You should not write non-MP3 files or unneeded folders along with MP3 files on the disc otherwise it
takes a long time until the unit starts to play MP3 files.
• With some CD-R or CD-RW media, data may not be properly written depending on their manufacturing
quality. In this case, data may not be reproduced correctly. High quality CD-R or CD-RW disc is
recommended.
• Up to 16 characters are displayed for the name of an Album or a Track. ID3TAG version 1.x is required.
• Note that the unit may not play Tracks in the order that you wrote them to the disc.

13
Radio operations
Note: RDS (Radio Data System) service availability varies with areas. Please understand if RDS service is
not available in you area, the following service is not available, either.
BAND selection
Press the BND button on the panel or the BAND button on the remote control repeatedly to select the
needed radio band in RADIO mode: FM1, FM2, FM3, FM, WM1, WM2.
Auto/Manual tuning
• Manual tuning: Press the /buttons shortly to select a station downward or upward step by step.
• Automatic tuning: Press the /buttons and hold for 2 seconds, the automatic search downward or
upward will start. It will play when finds the station.
Storing stations
You can store up to a total of 30 radio stations in the memory (18 FM, 12 AM), manually or automatically.
To store a station:
• Select a band (if needed).
• Select a station.
• Hold a number button (1-6/М1-М6) which you want store the station for at least 2 seconds.
To recall a station:
• Select a band (if needed).
• Press a number button (1-6/М1-М6) briefly to recall the stored station.
Scanning stations
Select a band. Press the SCAN button to scan all stations stored in the memory of the current band and stay
on each memorized station for about 10 seconds. To stop preset scan, press it again.
Auto memorizing stations
Press and hold the AMS button for more than 3 seconds to activate automatically memory storing function.
The radio automatically selects a station and has it stored in any of the number buttons.
Note: The unit can store up to 6 stations for each band.

14
Loud mode
Press and hold for 3 seconds the LOUD/TA button on the RC to increase bass output.
Stereo mode
Press the ST/AF button on the remote control to select stereo or mono reception for FM radio stations.
Stereo reception is activated when “AF” appears in the display.
Note: You can sometimes improve reception of distant stations by selecting mono mode.
Local/Distant mode
Press the LOC/DX/PTY button on the remote control to switch between Local and Distant (DX) tuning mode.
The unit is set to PTY mode when the PTY button is first pressed. “PTY” appears in the display, and only
local stations are available. The unit is switched to DX mode when the LOC/DX/PTY button is pressed again.
Both distance and local stations can be received.
Radio functions setting
Press and hold for 2 seconds the SEL button to select the setting: TA SEEK => MASK DPI => RETUNE L =>
DSP OFF => LOUD OFF => ESP 12 => MULT OFF => BEEP OFF => SEEK 1 => STEREO => DX.
Rotate the VOL knob to adjust each setting.
a. TA (Traffic Announcement) mode. You can chose TA ALARM or TA SEEK. The function refers to RDS and
may not be available in your region.
To determine what action will the radio take if the newly tuned station does not receive TP (Transport
Program) information for 5 seconds.
There are 2 modes: TA ALARM and TA SEEK.
• TA SEEK: During searching the radio retunes to a different station, which contains TP information.
• TA ALARM: During searching the radio does not retune but beeps will come out.
b. Mask mode
“DPI” is referred to “Different PI (Program Information) with same AF (Alternative Frequency)”.
During AF search, PI stations and non-RDS (Radio Data Station) stations with strong signal will be
masked, in the latter case, the non-RDS stations may cause interference, resulting the real AF to be
masked due to the misjudgment of the radio under interference.
• MASK DPI: To mask only the AF with different PI.
• MASK ALL: To mask both PI and strong signal non-RDS station.

15
c. Retune. You can choose RETUNE S and RETUNE L. The function refers to RDS and may not be available
in your region.
To determine the initial time of automatic TA (Traffic Announcement) search.
d. DSP
Select the equalizer: POP, ROCK, CLASSIC, FLAT, DSP OFF.
e. ESP mode (Electronic Shock Protection)
You can set ESP function 12 or 45.
f. Mult mode. You can choose MULT ON and MULT OFF. The function refers to RDS and may not be
available in your region.
g. Beep. You can enable or disable beep signal when pressing buttons.
h. Seek. You can choose two modes: SEEK 1 and SEEK 2. The function refers to RDS and may not be
available in your region.
i. Stereo/Mono. You can switch to STEREO or MONO mode.
j. DX/Local. You can choose distance or local tuning mode.
TA (Traffic Announcement) function
• Press the TA button on the panel or the LOUD/TA button on the remote control to turn on or turn off the
TA function.
• When TA is enabled, the tuner starts searching the traffic announcement. When it finds it starts
broadcasting with the volume not less then 20.
AF (Alternative Frequencies) function
Press the AF button on the panel or the ST/AF button on the remote control to turn on or turn off the AF
function. If the AF function is activated, the display will show “AF”.
The RDS program will be automatically searched and received. If the RDS signal is week or even no signal,
the unit will search another frequency with this RDS program. Default setting is ON.

16
PTY (Program Type) function
1. Press the PTY button on the panel or the LOC/DX/PTY button on the remote control to show the last
PTY. If no button is pressed during 2 seconds the previous PTY will start to be searched.
2. Press the PTY button on the panel or the LOC/DX/PTY button on the remote control to select the
program type group: MUSIC GROUP => SPEECH GROUP => PTY OFF.
3. When the program type is selected press the digit buttons (1-6/M1-M6) repeatedly to select the
program type according to the table:
Number PTY Music group Number PTY Speech group
1 Rock M 1 Affairs
2 Easy M 2 Sport
3 Classics 3 Culture
4 Jazz M 4 Weather
5 Nation M 5 Social
6 Folk M 6 Travel
4. Searching will start.
5. Press LOC/DX/PTY button again to switch the PTY function off.

17
Anti-theft system
This unit is equipped with a slide-down detachable and mask panel. Panel can be detached
and taken with you, helping to deter theft.
Detaching the front panel
1. Press and hold for 2 seconds the PWR button to turn the power off.
2. Press the REL button on the front panel. The panel will go down.
3. Push the panel to the right and pull it towards you.
4. Place the panel into the case and take it with you when you leave the car.
Attaching the control panel
1. Insert the right side of the control panel into the shaft of the main unit.
Note: the control panel must be attached into the T-Joint.
2. Push the panel to the right and insert the left side.
3. Press the top side of the panel until a “click” sound is heard.
Remove the unit
1. Remove the panel and the trim plate.
2. Insert both T-Keys into hole in front of the set until they lock.
3. Pull out the unit (pic. 1).
Pic. 1

18
Handling compact discs
Dirty, scratched or warped discs may cause skip ping or noise.
Handle the disc only by the edges. To keep clean do not touch its surface.
Discs should be stored in their cases after use to avoid scratches.
Do not expose discs to direct sunlight, high humidity, high temperature or dust.
Prolonged exposure to extreme temperature can wrap the disc (such as leaving the discs in your car during
summertime).
Do not stick or write anything on either side of disc. Sharp writing instruments, or the inks used in some
felt-tip pens, may damage its surface.
DO NOT touch the unlabeled side. DO NOT attach any seal, label or data protection sheet to either side of a
disc.
This unit cannot play 3-inch (8 cm) CDs.
Never insert a 3-inch CD contained in the adapter or an irregularly shaped CD. The unit may not be able to
eject it, resulting in a malfunction.
Cleaning
1. Cleaning the cabinet
Wipe with a soft cloth. If the cabinet is very dampen (not dropping wet) the cloth with a weak solution of
soapy water, and then wipe clean.
2. Cleaning discs
Fingerprints should be carefully wiped from the surface of disc with a soft cloth. Unlike conventional
records, compact discs have no grooves to collect dust and macroscopic dirt, so gently wiping them with a
soft cloth should remove must panicles. Wipe in a straight motion from the center to the edge.
Never use thinner benzine, record cleaner or anti static spray on a compact disc. Such chemicals can
damage its plastic surface.

19
Troubleshooting guide
Symptom Cause Solution
No power The car ignition is not on.
The fuse is blown.
If the power supply is properly
connected to the car accessory switch
the ignition key to "ACC".
Replace the fuse.
Disc cannot be loaded. Presence of CD disc inside the player. Remove the disc in the player then put
a new upward.
Disc cannot be read. Inserting the disc in upside down.
Compact disc is extremely dirty or
defective.
Temperature inside the car is too high.
Insert the compact disc with the label
facing upward.
Clean the disc or try to play a new one.
Cool off until the ambient temperature
returns to normal.
No sound Volume is in minimum.
Wiring is not properly connected.
Adjust volume to a desired level.
Check wiring connection.
The operation keys do
not work.
The built-in microcomputer is not
operating properly due to noise.
Front panel is not properly fix into its
place.
Press the RESET button.
Reinstall the front panel.
Sound skips. The installation angle is more than 30
degrees.
The disc is extremely dirty or defective.
Adjust the installation angle to less
than 30 degrees.
Clean the compact disc/try to play a
new one.
The radio does not
work, the radio station
automatic selection
does not work.
The antenna cable is not connected the
signals are too weak.
Insert the antenna cable firmly select a
station manually.

20
Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General
Power su
pp
l
y
12 V DC
Current consumption max. 14 A
Maximum power output 50 W x 4 channels
Fuse 15 A
Dimensions (L x W x H) 178 x 165 x 50 mm
FM stereo radio
Frequency range 65.0 – 74.0/87.5 – 108.0 MHz
Usable sensitivity 15 dB
AM Section
Frequency range 522 kHz – 1620 kHz
Usable sensitivity 25 dB
Disc player
Usable disc: CD/CD-R/CD-RW
Supported formats CDDA/MP3/WMA
Frequency characteristics: 20 Hz - 20 kHz ±5 dB
Signal to noise ratio: 65 dB
Number of channels: 2 stereo
Line out
Output: 1 V
