SoundScope T Series User manual

filmoscope-lab.com
Specifications:
Power Input 12 VDC
Power Output 15Wpc (4Ω, 10% THD)
10Wpc (4Ω, 0.1% THD)
Performance 0.04% THD (9Wrms, 4 Ω)
0.18% IMD (1Wrms, 4 Ω)
Impedance 4/8Ω
Architecture Class "T"
Efficiency >88% @ 10W, 8Ω
Dynamic Range 102dB
Features:
•Turn-on & turn-off "pop" suppression
•Intelligent short-circuit protection
•Intelligent over-temperature protection
•Connects to any passive 4/8Ωspeakers
•Accepts standard audio line output from any
sound system
Warranty:
This SoundScope product is warranted free from
defects in material and workmanship for one year
from date of purchase. Warranty does not apply to
misuse, abuse, neglect, accident, improper use, etc.
Contact your SoundScope reseller for a Return
Merchandise Authorization.
SoundScope-AmpBox
Class T Digital Audio Amplifier
USER MANUAL

filmoscope-lab.com
Introduction:
Thank you for your purchase of the SoundScope
AmpBox Class T Digital Audio Amplifier.
Don't let the compact size fool you; the AmpBox
amplifier has the heart of a serious performer.
Inside the AmpBox is a proprietary Class T amplifier
circuit, designed to create more efficient and higher
quality audio amplification using digital signal
processing, reducing power wasted as heat, meaning
more music power to your speakers. The resulting
soundstage, tonal balance and sound quality-
combined with a modest price, makes this pint-sized
T-Amp one of the "soundest" audio amplifier
investments you can make!
The AmpBox is remarkably affordable, yet still
delivers a crisp, vibrant signal that compares to
most high-quality linear amplifiers. Perfect for
home or at play applications as the unit operates on
eight AA batteries for portable use or the included
AC adapter can be used to power the AmpBox for
indoor use.
Package Contents:
(1) Class T Digital Audio Amplifier
(1) 12VDC, 2000mA Switching Power Supply
W/Interchangeable US/EU Power Plugs
(1) 3.5mm Coiled Audio Cable (6 inch)
filmoscope-lab.com
Operation:
Function:
1. Power/Volume Control
2. Power Indicator
3. Speaker Terminals
4. Power Input
5. 3.5mm Audio Input
6. Battery Compartment (bottom of unit)
Operation:
I. Attach an audio device such as MP3 player, PC or
CD player to the 3.5mm audio input.
II. Attach two 4 or 8-Ohm speakers to the speaker
terminals. Pay attention to speaker polarity; red to
red (+) and black to black (-).
III. Install 8 "AA" batteries or connect the 12 VDC
power supply.
IV. Turn on the amplifier and set to appropriate
volume level.
V. Enjoy your Class T Digital Audio Amplifier
