Soundstream BX-4EQ User manual

BX-4EQ
4 BAND GRAPHIC EQUALIZER
BASS ENHANCER
,
Owner s Manual
and
Installation Guide
TECHNOLOGIES
R

Congratulations!
CAUTIONS! Prolonged listening at extremely high levels may result in hearing
loss. Even though your car audio system with your new Soundstream BX-4EQ
4 Band Grlaphic Equalizer - Bass Enhancer sounds better than anything you've
ever heard, exercise caution to prevent hearing damage.
- 1 -
Features
Congratulations on purchasingthe SOUND STREAM BX-4EQ. You are nowthe proud owner
of the finestand most accurate4 Band GraphicEqualizer - BassEnhancer & restorationsystem.
Whether your interestis in Beethoven'skettle drums, inMiles Davis' trumpetor in thepercussion
of Rap lyrics,the BX-4EQ willrestore those longlost missing bassnotes, with amazing
accuracy and clarity.
The BX-4EQ isdesigned for dashmounted, which permitsinstant adjustments easily.
Bass Driver: The BX-4EQ containsa Bass Drivercircuit that accuratelyrecreates and injects
Low frequency informationback into thesignal path. Whatthat means ineveryday terms is
that the BX-4EQwill give morebass impact toyour best compactdiscs or evenyour old tapes.
Bass Equalization Circuit:The BX-4EQ hasa unique equalizationcircuit that contoursthe
restored bass toyour speaker systems.
Dash Mount :The BX-4EQ isdesigned for DashMountable, that allowsyou to enjoythe effects
of the BX-4EQwithout having toleave the driversseat.
Bass Maximizer Indicator:Not only doesThe BX-4EQ providegood music toyour ears, butit
also gives yousome visual enjoymentas well. Onthe front panelof the BX-4EQ, there are two
LED indicators thatflashes when thebass maximization circuitis activated.
PFM Subsonic FilterSwitch: This has theability to finetune the bassresponse of anysystem.
Why waste poweron nasty subsonicinformation when thePFM Subsonic FilterSwitch can help
you to cleanthings up?
Bass Output Control:The BX-4EQ hasthe ability toproduce large amountof deep, mind
shattering bass withoutdamaging your speakers.The Bass OutputControl circuit allowsthe
BX-4EQ to maximizethe bass outputof any autosoundaudio system whilerestraining
destructive bursts.
Bass Line LevelMatching: The BX-4EQ has4 Levels ofsignal voltage adjustmentto match
the rest ofthe system seamlessly.

- 2 -
4569
Functions
7
811
12
123
131415
1. Inputs: The inputs of The BX-4EQ use a balanced input circuit to help minimize induced noise.
It is also designed to handle very high signal voltages up to 15 volts.
2. Outputs: These RCA connectors should be connected to the next component after the BX-4EQ
such as a crossover or amplifier. Just remember, the BX-4EQ should go inline before a crossover.
3. Power Connector
7. Para-Bass Controls: These 2 knobs control the Para-Bass functions of the BX-4EQ. The
SWEEP knob allows you to pick the center frequency that you want the BX-4EQ bass restoration
circuit to maximize. The WIDE knob adjusts how wide of a frequency range the BX-4EQ will effect.
8. The PFM Subsonic Filter Switch: The BX-4EQ utilizes a PFM Subsonic Filter Control which
will help with speaker control and amplifier power management. This PFM Subsonic Filter Control
is variable from 35Hz - 80Hz. On most systems, setting the control at 35Hz is fine. If you want
to protect your speaker system even more, you should try a higher frequency. Often a higher
frequency actually sounds louder and cleaner.
4. Master VolumeControl: This is themain control toadjust the outputlevel.
5. Preamp FaderControl: This control adjuststhe volume between the front andrear output in
4-channel systems.
6. Subwoofer Volume Control: This adjusts thelevel of thesubwoofer output.
10

- 3 -
9. Bass Maximizer Indicator: These two LED indicators flash when the bass maximization
circuit is activated.
10. Input Selector Switch: This switch selects the AUX or CD input.
11. FrequencyBand Controls : Adjusts (cut or boost) the level of the three (LOW/ MID/ HIGH)
frequency bands up to +/-18dB
12. Aux Input.
13. Input Grounding Selector: For most systems you can set this switch at the BALANCED
position. In some systems, the source unit may look for a ground through the RCA connectors.
In this event, you should go ahead and change the setting to the UNBALANCED position.
14. Ground Isolation Selector: Occasionally alternator whine may appear in a system
because the source unit and amplifier may use different grounding.Tohelp in this situation,
we have provided alternative grounding selector.
15. Output Voltage: Not all systems are designed the same, some systems are designed
strictly for SPL (Sound Pressure Level) while others are a little more tame. The Bass
Maximizer circuit can either increase or decrease the signal voltage of the Bass Restoration
Circuit. Depending upon your system, you may change this selector switch to a higher or
lower setting to maximize your bass output and protect your speakers.
Power connection
Electronic Connections & Wiring
Red
Orange
Black
B+(12V) : Connect to the car battery or other power source.
REMOTE : Connect to remote activating (12V DC)wire of car stereo or equalizer.
GND : Connect to the car chassis for ground connection.

- 4 -
AMPLIFIER
AMPLIFIER
MIDRANGE
SPEAKERS
SUBWOOFER
Crossover
NOTE: For signal connection, the output RCA connectors should be connected to the
next component after the BX-4EQ, such as a crossover, equalizer, or amplifier. Just
remember, the BX-4EQ should go inline before a crossover.
Signal Connection

- 5 -
Specifications
Maximum Input Level
Maximum Output Level
Frequency Response
Total Harmonic Distortion
Signal to Noise Ratio
Balanced Input Noise Rejection
Input Impedance
Output Impedance
Power Supply
Power draw
Recommend fuse rating
15 V rms
13.5V peak
10Hz - 100KHz ; +/-1dB
0.003%
-130dB
>60dB
10 Kohm
150 Ohms
High headroom PWM
150mA
1 Amp
The bass response in a system is affected by four factors:
(1) The acoustics of the vehicle
(2) The locations of the speakers
(3)The music material
(4) Speakers and speaker enclosures.
Because of the variations in the recording process, we developed BX-4EQ to help restore
any low frequencies lost during the recording process, however, the acoustics of various
environments are different.
The Sweep control allows you to select a center frequency ( the frequency most affected)
between 27 and 63 Hz. The Width control then allows you to control the shape of the filter
centered around the Sweep frequency.
Adjusting the Para-Bass Controls
The BX-4EQ is the most powerful bass component. This device is equipped with several
different Bass Output selections. If you should need to change the settings, Please use
the chart below for guidance. It is recommended : listen to the factory setting before
changing your Bass Output settings.
Setting The Output Voltage
Recommended Settings
Setting
2.5Volt
5Volt
7.5Volt
10Volt
Amplifier Input Voltage
3Volt or less
5Volt or less
7.5Volt or less
Oh My Gosh !!!!!!!!!!!!!!!!!
Minimum Speaker Size
8
10
12

- 6 -
If the Unit does not turn-on, and / or the power indicator LED is NOT
illuminated, do this:
1) Check and make sure that B+ and GND are not reversed
2) Check that all power wires are properly connected and has
the appropriate potential (11- 16 volts)
3) Check that the fuse is intact.
If you experience high audible distortion or low output volume:
4) Check that the input and output levels are set correctly. Input should
match the source and output should match the sensitivity of the next
in-line component.
If you experience whining or engine noises:
5) Verify that the GND connection is secure, the conductor (wire) is not too
thin and unnecessarily long.
6) Check that the B+ wire is not too thin and unnecessarily long.
7) Change the power source; try taking power from a different point.
Trouble Shooting Guide
