Southern CM487200TX User manual
For assistance with assembly contact:
Southern Enterprises Inc.
Customer Service 1-800-633-5096
www.seifurniturestore.com
Page 1
CM487200TX
Javu Wine Storage Console
Assembly Instructions
A Quantity
of 1
Left Side Frame
B Quantity
of 1
Right Side Frame
CQuantity
of 2
Wine Frame
DQuantity
of 1
Back Frame
EQuantity
of 1
Top Frame
F Quantity
of 1
Bottom Frame
G Quantity
of 1
Long Metal Tube
H Quantity
of 2
Iron Frame
J Quantity
of 2
Metal Frame
Page 2
Javu Wine Storage Console
Parts List
Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like
carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing.
Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
Using the incorrect hardware will cause damage.
K Quantity
of 2
Left Metal Tube
L Quantity
of 2
Right Metal Tube
MQuantity
of 2
Short Metal Tube
NQuantity
of 6
Cup Holder
OQuantity
of 1
Large Wood Shelf Panel
P Quantity
of 2
Wood Shelf Panel
Q Quantity
of 2
Large Wicker Basket
R Quantity
of 3
Small Wicker Basket
S Quantity
of 5
Basket Bottom Panel
Page 3
1 Quantity
of 2
Long Bolt ：Ø1/4”×1-1/4” L
2 Quantity
of 8
Bolt ：Ø1/4”×1” L
3Quantity
of 46
Short Bolt ：Ø1/4”×1/2” L
4Quantity
of 1
Allen Wrench
5 Quantity
of 14
Wood Screw: 4.0×1/2” L
6 Quantity
of 2
Long Wood Screw ：4.0×1” L
7 Quantity
of 2
Wall Anchor
8 Quantity
of 2
Wall Brackets
9 Quantity
of 2
Plastic Strap
Care and Cleaning Instructions:
Before using, wipe with a clean, dry cloth.
Periodically apply furniture wax to renew
the finish.Avoid rubbing or scratching the
surface with rough or abrasive objects.
For replacement parts or questions, please
Call SEI customer service at 1-800-633-5096
Assembly Tool Required
No.2 Phillips Screwdriver (Not Included)
Tool ist: 3/16" Drill Bit, Drill, Tape Measure and Pencil.
Page 4
Figure 1
.
Attach Back Frame (D) onto
bothSide Frame (A & B).
Insert 2pcs Long Bolt (1) through
holes on Back Frame (D) to attach
Back Frame (D) to both Side Frame
(A & B), tighten by usingAllen
Wrench (4).
Figure 2
Attach Long Metal Tube (G) onto
bothSide Frame (A & B).
Insert 2pcs Short Bolt (3) through
holes on Long Metal Tube (G) to
attach Long Metal Tube (G) to
bothSide Frame (A & B), tighten by
using Allen Wrench (4).
Page 5
Javu Wine Storage Console
Assembly Instructions
Figure 3
Slowly push 2pcs Iron Frame(H) to
Back Frame (D) & Long Metal
Tube(G) by hands
Insert 4pcs Short Bolt (3) through
holes on Iron Frame(H) to attach Iron
Frame(H) to Back Frame (D) & Long
Metal Tube(G) byAllen Wrench (4).
Figure 4
Slowly push the Large Wood Shelf
Panel (O) onto the Back Frame (D) &
Long Metal Tube(G) by hand
Insert 6pcs Wood Screw (5) through
holes on Back Frame (D) & Long
Metal Tube(G) to attach Large Wood
Shelf Panel (O) onto Back Frame (D)
& Long Metal Tube(G) by Tool
Required - No.2 Phillips Screwdriver
(Not Included).
Page 6
Figure 5
Push Cup Holders(N) onto Top
Frame(E) by hands
Insert 12pcs Short Bolt (3) through
holes on 6pcs Cup Holders(N) to
attach Cup Holders(N) to Top
Frame(E) by Allen Wrench (4).
Figure 6
Slowly push Top Frame(E) to
bothSide Frame (A & B).
Insert 4pcs Short Bolt (3) through
holes on Top Frame(E) to attach Top
Frame(E) to bothSide Frame (A & B),
tighten by using Allen Wrench (4).
Page 7
Figure 7
Slowly push 2pcs Short Metal
Tube(M) to Long Metal Tube (G) &
Top Frame(E) by hands
Insert 4pcs Short Bolt (3) through
holes on Short Metal Tube(M) to
attach Short Metal Tube(M) to Long
Metal Tube (G) & Top Frame(E) by
Allen Wrench (4).
Figure 8
Slowly push Bottom Frame(F) to
bothSide Frame (A & B).
Insert 4pcs Short Bolt (3) through
holes on Bottom Frame(F) to attach
Bottom Frame(F) to bothSide Frame
(A & B), tighten by usingAllen
Wrench (4).
.
Page 8
Figure 9
Slowly push Wine Frame(C) onto
both Frame (E & F) by hands
Insert 2pc Short Bolt (3) through
holes on Wine Frame(C) to attach
Wine Frame(C) to Top Frame (E) by
Allen Wrench (4)
Insert 2pc Bolt (2) through holes on
Bottom Frame(F) to attach Wine
Frame(C) to Bottom Frame (F), by
Allen Wrench (4).
But now 2pcs Bolts (2) can not be
completely locked.
Page 9
Figure 10
Slowly push Wine Frame(C) onto
both Frame (E & F) by hands
Insert 2pc Short Bolt (3) through
holes on Wine Frame(C) to attach
Wine Frame(C) to Top Frame (E) by
Allen Wrench (4)
Insert 2pc Bolt (2) through holes on
Bottom Frame(F) to attach Wine
Frame(C) to Bottom Frame (F) by
Allen Wrench (4)
Now 2pcs Bolts (2) can be
completely locked of Step 9 byAllen
Wrench (4).
Page 10
Figure 11
Slowly push 2pcs Metal Frame(J) to
both Side Frame (B & C) and Wine
Frame( C) by hands
Insert 4pcs Bolt (1) through holes on
Metal Frame(J) to attach Metal
Frame(J) to both Side Frame (B & C)
by Allen Wrench (4)
Figure 12
Slowly push 2pcs Wood Shelf Panel
(P) onto the Metal Frames (J) by
hand
Page 11
Figure 13
Insert 6pcs Wood Screw (5) through
holes on Back Frame (D) & Long
Metal Tube(G) to attach Large Wood
Shelf Panel (O) onto Back Frame (D)
& Long Metal Tube(G) by Tool
Required - No.2 Phillips Screwdriver
(Not Included).
Figure 14
Insert 4pcs Short Bolt (3) through
holes on Right Metal Tube (L) to
attach 2pcs Right Metal Tube (L) to
Right Side Frame (B) and Wine
Frame (C) by Allen Wrench (4)
Insert 4pcs Short Bolt (3) through
holes on Left Metal Tube (K) to
attach 2pcs Left Metal Tube (K) to
Left Side Frame (A) and Wine Frame
(C) by Allen Wrench (4)
Page 12
Figure 15
Please slide one side of Basket
Bottom Panel (S) all the way down
into the bottom of Wicker Basket (Q)
by hand.
Figure 16
Then slowly push the other side of
Basket Bottom Panel (S) into the
bottom of Wicker Basket (Q) by
hand.
Figure 17
Please slide one side of Basket
Bottom Panel (S) all the way down
into the bottom of Wicker Basket (R)
by hand.
Figure 18
Then slowly push the other side of
Basket Bottom Panel (S) into the
bottom of Wicker Basket (R) by
hand.
Page 13
Figure 19
Put the 2pcs complete baskets (Q)
onto the Bottom Frame (F) as
shown.
Put the 3pcs complete Baskets (R)
onto the Top Frame(E) as shown
Figure 20
Find a desired location. Mark 2
locations for screws on wall
One screw (for each unit) must be
attached directly into a wall stud.
Wall anchor is not needed when
mounting to wall stud.
Drill one of the marking 3/16" hole
(for each unit).
Page 14
Figure 21
Insert Plastic Anchors (7) into the
holes on wall as shown.(When doing
this, you will need a hammer to help
you)
Figure 22
Using the Phillips head screwdriver,
install Screw (6) through holes on
Wall Brackets (8) into Wall Anchors
to attach Wall Brackets (8) onto Wall
Anchors (6).
Page 15
Figure 23
Move this item close to the fastened
wall brackets and tie in brackets and
side frame with Plastic Straps (9) as
shown in diagram.
Check to make sure the strap is
securely laced and locked to the
brackets.
Figure 24
Now your Javu Wine Storage
Console is ready to use
Page 16
Please immediately examine this product carefully. Any request for missing parts or damage replacement must be
received within 90 days of your receipt of the product. Replacement, if available, will be honored within this time
frame.Parts will not be available for items arriving fully assembled. We do not recommend modifying product(s) and
we are not responsible for any damages due to product modification(s).
If damages or missing parts are not
reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise.
Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time
if you have product issues or email us at service@seidal.com. Please ask for customer service representative for
issues involving damages or replacement parts. Please ask for technical assistance representative for any issues
with product and assembly/construction.
Please contact the retailer that you purchased from for returns.
