SpaEquip LE04 User manual

User Manual
PRODUCT #:
LE04
ITEM:
Pro Salon Spa Table from Living Earth
Crafts
BRAND:
Living Earth Crafts
SOURCE FOR PURCHASE:
SpaEquip Inc.
211 Wappo Ave
Calistoga, CA 94515
[phone]
www.spaequip.com
FEATURES:
This Pro Salon model features full electronic control of table height, head panel and leg panel tilts. It incorporates the
LEC Quiettech motor/hydraulic system that is smoother, quieter and more reliable. Includes an 8-button hand control,
heavy duty foot pedal, Strata 4" Memory Foam with rounded corners, hard maple wood construction with louvered
cabinet, and half round neck roll. Choose from a variety of base cabinet styles - the base cabinet includes a power outlet
and can accommodate a hot towel cabinet or other electrical device. ADA compliant with low height range. Some models
shown here with Stain, Flexible Armrest and Manicure Arms upgrades. PivotPerfect Side Arms or Manicure Arms
upgrade available in 30" and 32" widths only. Lifting capacity is 650 lbs. Oversized item - ships by Truck.
SPECIFICATIONS:
Dimensions: 73"(185cm) L x 30"(76cm)W x 25 - 37" (63-94cm)H; also available in 28"(70cm) or 32"(81cm)
widths. Base Cabinet is 51"L x 25.5"W
Electrical: 110V AC, 2.4 Amps
Suggested Outlet: Recessed Quad Outlet under table, not to exceed 2" High
Plumbing: None
Notes: None
Warranty: LET:Limited lifetime warranty on the frame. 3 years on foam and vinyl. 2 years on motors &
controls
Certifications: UL, cUL, CE
Country of Origin: United States
Installed By: SpaEquip (if setup is included with order) or Client
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 1 of 15

OPERATION MANUAL
PRO SALON™
MULTI-PURPOSE LIFT TABLE
Classic
Traditional
Contemporary
Cuvée
For tables manufactured
January 2007 forward
[phone] [phone]
Fax: [phone]
Rev.D – September 2007
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 2 of 15

Operation manual – Pro Salon
04/30/10
1
OPERATION MANUAL
Living Earth Crafts
Pro Salon Electric Hydraulic Lift
Your new Living Earth Crafts Serenity Pro Salon Hydraulic Lift table is an
electronically operated table. This manual will assist you in operating and caring for
your new table.
Section 1: IMPORTANT SAFETY INSTRUCTIONS ...................................... page 2-3
.
Section 2: OPERATING INSTRUCTIONS
Standard Equipment .......................................................................page 4
Optional Accessories.................................................................. page 5-7
Section 3: MAINTENANCE............................................................................ page 8-9
Section 4: TROUBLE SHOOTING ..................................................................page 10
Section 5: TECHNICAL PROBLEMS ..............................................................page 11
Section 6: WARRANTY ...................................................................................page 12
Section 7: SPECIFICATIONS ..........................................................................page 13
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 3 of 15

Operation manual – Pro Salon
04/30/10
2
Section 1
PROSALON TABLE
IMPORTANT SAFETY INSTRUCTIONS
FOR COMMERCIAL USE ONLY
When using an electrical furnishing, basic precautions should always be followed,
including the following:
Read all instructions before using the PROSALON TABLE.
DANGER- To reduce the risk of electrical shock:
1) Always unplug this furnishing from the electrical outlet before cleaning.
WARNING- To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Unplug from outlet before putting on or taking off parts.
2. Close supervision is necessary when this furnishing is used by, or near
children, invalids, or disabled persons.
3. Use this furnishing only for its intended use as described in these instructions.
Do not use attachments not recommended by the manufacturer.
4. Never use this furnishing if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water. Return the
furnishing to a service center for examination and repair.
5. Keep the cord away from heated surfaces.
6. Never operate the furnishing with the air openings blocked. Keep the air
openings free of lint, hair and the like.
7. Never drop or insert any object into any opening.
8. Do not use outdoors.
9. Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
10. To disconnect, turn all controls to the off position, then remove plug from
outlet.
11. WARNING, MOVABLE PARTS- Risk of Injury- Keep children away from
extended Table Lift, Back Support or Leg Support.
12. CAUTION: To reduce the risk of electrical shock, this furnishing has a
polarized plug (one blade wider than the other). This plug will fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If
it still does not fit, contact a qualified electrician to install the proper outlet. Do
not change the plug in any way.
13. Make certain that the cord and plug are maintained in good condition and are
not allowed to become damaged while in use. Avoid positioning the cord in the
traffic lane and it is always kept out of the way. Take this furnishing out of
service immediately if the cord or plug becomes damaged in any way.
14. If this furnishing is not in use, the cord needs to be rolled up and stored out of
the way to avoid damage.
SAVE THESE INSTRUCTIONS
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 4 of 15

Operation manual – Pro Salon
04/30/10
3
Section 1, Continued
IMPORTANT SAFETY INSTRUCTIONS
Pro Salon Electric Hydraulic Lift
CAUTION!
When lowering any section of the table, make sure that no supplies or any part of
yours or your client’s body is between the top of your table and its base. This could
result in injury, or could damage your table as well as the item. It is recommended
that you always return your table top to the lowest flat position to avoid leaving the
base exposed. By doing so, you will minimize the possibility of damage to your table
by unequal weight distribution such as sitting on the leg section while raised.
When lowering the table height, be sure there are no foreign obstacles are
underneath your table that could obstruct it from lowering completely. This could
damage your table.
1. Maximum weight lifting capacity of 500 lbs, maximum load limit for the back and
leg section 100 lbs each.
2. Never set anything under the table frame.
3. Never operate your table on an uneven surface. Adjust the leveling feet so that
your table is stable.
4. Never operate your table with unequally distributed weight such as sitting on the
foot or head section while raising or lowering it.
5. Never raise the head or foot section with a client in the prone position (face down).
6. Never use or store your table in a wet or very humid environment. Water and
excessive moisture can damage the wood cabinet and electrical components.
Evidence of exposure to water or moisture will void your warranty.
7. If you have purchased the Flexible Armrest Option, never use the Armrests as
handholds or body support mechanisms, especially when setting clients on or off
the table.
8. Never attempt to use the foot lift section to support concentrated weight such as
sitting or standing.
SAVE THESE INSTRUCTIONS
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 5 of 15

Operation manual – Pro Salon
04/30/10
4
Section 2
OPERATING YOUR TABLE
Pro Salon Electric Hydraulic Lift
Use of Hand Control:
With your new Pro Salon table, you can
1. Raise or lower the head section independently
2. Raise or lower the leg section independently
3. Raise or lower the entire table top
On your hand set control, you will notice three rows of
controls. The darkened section of the image is the
area where adjustment will occur.
Push left of the image – movement will be “up”.
Push right of the image – movement will be “down”.
LOCATION OF BUTTON FUNCTION
FIRST Row of Control Raise or lower the head section
SECOND Row of Control Raise or lower the table height
THIRD Row of Control Raise or lower leg section
You can also push 2 or more of the Control functions at the same time for quick
adjustment of all desired sections, simultaneously.
OPTION: Hands Free Foot Control: If you have ordered the Hands Free Foot
Control, you can adjust the back tilt, foot section, and height of the table –
keeping your hands sanitary for treatments.
The LEFT control adjusts the height of the table.
The CENTER control adjusts the back tilt section.
The RIGHT control adjusts the leg tilt section.
Use of Foot Control:
The foot pedal controls the raising or lowering of the entire table. The left side raises
the table and the right side lowers it.
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 6 of 15

Operation manual – Pro Salon
04/30/10
5
Section 2 - Continued
OPERATING YOUR TABLE
Pro Salon Electric Hydraulic Lift
OPTION: Flex Armrest.Applies only to tables purchased with this option.
The optional flexible armrest on your Living Earth Crafts table features a positive
lock design. A locking mechanism ensures that the armrests do not unexpectedly
pull out during use. At first the armrests will be a bit tight to remove. This is
normal. Allow time to let the components “fit in”, and they will loosen over time.
1. Install the Flex Armrests. Installing the armrests can be done with the
table in any position, however, it may be easiest when the table top is in the
flat position. Line up the entry posts with the side grommet holes. Push the
tips into the holes until a click can be heard. If the armrest is pushed in too
far, pull it back slightly and the lock will engage. Test the locked position by
giving it a light pull. It should give resistance.
2. Remove the Flex Armrests. Removing the armrests can be done with the
table in any position, however, it may be easiest when the table top is in the
flat position. Grasp the armrest near the entry posts and remove one end at
a time with a sharp pull. This operation takes some effort, however this
ensures that the rest will not release during use.
Servicing of Double Insulated Products- This is a double-insulated product, with
two systems of insulation instead of grounding. No grounding means is provided on a
double-insulated product, nor is a means for grounding to be added to the product.
Servicing a double-insulated product requires extreme care and knowledge of the
system, and is to be done only by qualified service personnel. Replacement parts for
a double-insulated product must be identical to the parts they replace.
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 7 of 15

Operation manual – Pro Salon
04/30/10
6
IMPORTANT SAFETY INSTRUCTIONS
ROLLING CASTER / WHEEL OPTION
If you have ordered the optional Rolling Caster Wheels, it is
important that you read this section.
To engage the wheels on your table: Lower the table to the lowest position. Your
table is ready to be rolled to its desired location.
To disengage the wheels on your table: From the lowest position raise the table 1
or more inches. Your table is now ready for use.
FAILURE TO DISENGAGE THE WHEELS WHEN CLIENT IS GETTING ON OR
OFF THE TABLE COULD RESULT IN INJURY. KEEP WHEELS DISENGAGED AT
ALL TIMES WHEN A CLIENT IS ENTERING ONTO OR EXITING FROM THE
TABLE, AS WELL AS WHILE THE CLIENT IS ON THE TABLE.
CAUTION: Wheels are intended for use on smooth surfaces only. Tables with wheels
are not intended to roll over thresholds, cords or other obstacles. Tables with wheels
are not intended for use on stairs. Rolling your table over obstacles can damage your
table as well as the obstacle. Rolling your table over cords can be very dangerous as
this can damage the insulation inside the cord.
Be very careful when rolling your table near walls or doors as damage can occur to
the wall or door as well as the table.
Living Earth Crafts will not be responsible for damage to your table or other
objects damaged by misuse of wheels.
Failure to use the wheels except as described above could damage your table and
void your warranty.
Damage to table frame caused by misuse will not be covered under warranty.
Trained personnel at our factory will assess any frame damage or warranty issues
resulting from the use of wheels.
SAVE THESE INSTRUCTIONS
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 8 of 15

Operation manual – Pro Salon
04/30/10
7
IMPORTANT SAFETY INSTRUCTIONS
PIVOT PERFECT SIDE ARMS OR MANICURE ARMS
If you have ordered the optional Pivot Perfect Side Arms or
Manicure Arms, it is important that you read this section.
•Patent Pending Pivot Perfect ™ Side Arms with or without Manicure Bowls
–These one-of-a-kind armrests pivot in close to the body for a snug-in-fit
and maximum comfort.
–Manicure bowls are covered with comfortable foam cushions that swing
away for access to manicure bowls. When closed, the arms are a
comfortable armrest.
–Easy to remove, lightweight – yet can support the weight of the client
leaning on them while exiting the chair.
SAFETY PRECAUTIONS:
Be aware that when your Pivot Perfect Side Arms are swung in over the table top, you
need to use caution when lifting the leg section to avoid pinching your client’s body
between the table top and the side arms. To avoid possible injury to your client and
damage to your table, stop lifting the leg section before your client’s body touches the
bottom of the side arms. Similarly, avoid lifting the leg section into the bottom of the
armrests as you may tear the vinyl.
When rotating your Pivot Armrests in, take precautions to avoid contact between the
armrest and the leg section. The result of this collision could be injury to your client or
damage to your table and arms. Stop rotating your side arms in before contact is
made with your table.
SAVE THESE INSTRUCTIONS
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 9 of 15

Operation manual – Pro Salon
04/30/10
8
Section 3
MAINTENANCE
Pro Salon Electric Hydraulic Lift
Your new Pro Salon table is relatively maintenance free. However, to ensure that
your table will continue to function properly and keep its appearance, we recommend
the following:
1. VINYL: After each and every treatment on your table, clean thoroughly, removing
all oil residue. This and other residues may cause the vinyl to dry out and become
brittle. We recommend using the product ViraGuard® (sold by Living Earth Crafts)
which also disinfects. Spray the vinyl and rub gently with a soft cloth. A solution
of 1 part mild detergent (such as liquid dishwashing detergent) to 10 parts warm
water may also be used. Simple Green is another alternative. A more thorough
cleaning is recommended on a weekly basis.
Use caution when attempting to remove stains as you could damage your vinyl.
Any stains should be treated immediately with a solution of 1 part alcohol to 10
parts water. Restore the luster to the spot with a light application of spray furniture
wax.
CAUTION!
DO NOT USE ACETONE, PAINT THINNER, BLEACH,
ARMOR ALL TYPE OR INDUSTRIAL CLEANERS.
These will damage the vinyl’s protective coating.
2. To maintain the wood finish and retouch scratches, use a high quality furniture
wax.
3. The stainless steel legs should be cleaned and lubricated often. Clean and
lubricate with a petroleum based lubricant such as WD-40. This will help to
maintain smooth raising and lowering of your table. This should be done at least
every 3 months and more often if table is used often. To clean, raise the table to
its highest height position. Spray WD-40 onto clean, then, with a lint-free cloth,
wipe the legs from top to bottom several times. Check to see if any foreign
material is stuck on surface. (WD-40 applied thick and left a minute will help
loosen most common materials. Wipe clean.) To lubricate, raise table to its highest
position. Lubricate well on the exposed leg and raise and lower the table 2-3 times
to distribute the lubricant. Wipe off excess at leg bottom.
DO NOT USE soap and water for cleaning the legs.
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 10 of 15

Operation manual – Pro Salon
04/30/10
9
Section 3 - Continued
MAINTENANCE
Pro Salon Electric Hydraulic Lift
4. It is recommended that at the same time you lubricate the leg shafts, you should
also check the leveling feet to be sure the table is level and stable.
The “level or balance” of your table is very important, both during the initial set up
and on a routine basis. The balance of the table is adjusted with the leveling feet,
located on the bottom of each leg. You will need (2) open end wrenches – ½” and
9/16”.
Begin by taking a visual inspection of the flat bottom foot of each leg. Notice two
hex nuts on each leveling foot. The upper hex nut is adjustable and secures the
leveling foot in place, while the lower nut is stationary, and allows you to raise and
lower each leveling foot independent of each other. This is necessary as floors
and carpet may not be 100% level or flat. The most common symptom of an
unbalanced table is unusual rocking of the entire bed. To determine which foot to
adjust, attempt to “rock” your table. If your table rocks, the leg that is “off the
ground” is the one that will need adjusting. Once your diagnosis has been made,
proceed as follows:
a. Raise table height to approximately 6 inches off the floor.
b. Using a clean, lint free cloth, grab the silver extrusion (leg) to prevent it from
moving during the adjustment.
c. Loosen the upper hex nut until it no longer touches the upper leg.
d. Raise or lower the entire foot as necessary on the lower hex nut.
Counterclockwise will lower the overall height; clockwise will raise the
overall height. Continue with the adjustment of the lower hex nut until the
black round foot is completely flat to the ground and the table no longer
rocks.
e. To lock into place, reposition the upper hex nut so that is secure and tight
against the upper leg.
f. Test all legs to ensure that the upper hex nut is tight against the upper leg
and secure in place.
5. If this furnishing is taken out of service, the electrical cord needs to be rolled up and
placed inside the table to avoid damage while in storage.
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 11 of 15

Operation manual – Pro Salon
04/30/10
10
Section 4
TROUBLE SHOOTING
Pro Salon Electric Hydraulic Lift
If you are experiencing technical difficulties with your Pro Salon, we ask that you
perform these trouble shooting techniques prior to contacting Living Earth Crafts.
SYMPTOM: Table does not raise or lower:
1. Check to make sure the outlet in your room is receiving power. This can be
done by plugging in a hairdryer or small appliance and turning it on.
2. If you have a dimmer in the room, make sure the dimmer switch is turned to full
power, then retest your table.
3. Check the fuse or circuit breaker box for blown fuse or tripped circuit breaker.
4. Check to make sure both the hand and foot controls are securely plugged into
the junction box of the table. The light on the hand set control should be “on”.
SYMPTOM: Table does not operate in accordance to the functions on the hand-set
control:
1. Check to make sure that the hand set control is plugged into the receptacle
nearest the power cord in the black junction box, located under the table in the
cabinet area. (Note: the foot pedal can be plugged into either of the next two
sockets.)
2. Check to make sure the hand control is securely plugged into the junction box
of the table.
SYMPTOM: Table is unstable after moving it to a new location:
1. See Section 3: Maintenance, #4.
+If your table does not raise and lower evenly, the hydraulic system may need
repair. Refer to Section 5, Technical Problems, and call Living Earth Crafts.
+If only one or two of the functions on the top works, even though the controls are
plugged in properly, the junction box may be faulty. Do not attempt to repair it. Refer
to Section 5, Technical Problems, and call Living Earth Crafts.
If you are unable to resolve the problem with your table, please refer to Section 5,
Technical Problems, and contact Living Earth Crafts.
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 12 of 15

Operation manual – Pro Salon
04/30/10
11
Section 5
TECHNICAL PROBLEMS
Pro Salon Electric Hydraulic Lift
With proper maintenance, your Living Earth Crafts table is designed to give you years
of trouble free operation. If you should have a problem with your table, do not attempt
to repair the table yourself. This will void the 2-year warranty that covers your table
against defects in material and workmanship. It covers repairs only if you follow these
steps:
1. Call
800-358-8292 or 760-597-2155
Our Customer Service Representative will ask you to provide the following
information:
a) your table’s serial number (located on the underside of the head
section of the table top)
b) a description of the problem
2. Under warranty, our representative will coordinate a technician in your area if one
is available. The technician will contact you to arrange for a convenient time for
on-site service. This service is scheduled during normal business hours, 8.AM to
5.PM, Monday through Friday. For non-warranty, a referral will be made so that you
can contact a service technician in your area.
3. You will need to allow the technician access to your table at the scheduled time. If
there is a lengthy delay, you will be charged for the delay time at the service
agent’s hourly rate. To cancel the appointment, notify the technician 24 hours
prior to the scheduled appointment. If you fail to notify the technician, you will be
charged for the service call.
4. Please remember that any unauthorized service will not be covered. Please be
sure to contact us first.
5. As expressed in your warranty, damage from abuse or mishandling is not covered.
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 13 of 15

Operation manual – Pro Salon
04/30/10
12
Section 6
WARRANTY
Pro Salon Electric Hydraulic Lift
Tables are warranted against defects in materials, design and workmanship, to the
original owner, as follows:
xFrame
- Lifetime ¢
xFoam & Vinyl
- 3 years
xHydraulic System, Pneumatic Assisted Lifts, Motors, Controls, Electronics
- 2 years
Warranty is onsite where available.
Warranty does not cover damage caused by accident, misuse, or neglect. All
warranties limited to repair or replacement, at our discretion, to the original
purchaser.
-¢Lifetime warranty applies to original owner, as long as you own your
table or 5 years after the model is discontinued or five years for private
label tables
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 14 of 15

Operation manual – Pro Salon
04/30/10
13
Section 7
Pro Salon Electric Hydraulic Lift
SPECIFICATIONS
FEATURES:
¾Top Width options: 28”, 30”, and 32”
¾Length: 73”
4” Strata Memory Foam
¾Height Range: 25” to 37”
¾Electric Hydraulic Lift
¾Heavy-Duty foot pedal to raise and lower table
¾Power Supply: 110 volt, Standard Wall Outlet
¾International Power Supply: Alternate voltages and plugs available for all countries
¾Lifting capacity: 500 lbs
¾Standard Base: Cabinet
¾Optional Bases: Trestle, Shelf
¾Standard Top: Salon Top
¾Electric lifting system
¾¾” Veneer Core Ply
¾Solid hardwood Maple & ¾” Multi-ply frame construction
¾Includes:
¾Neck Roll
¾Heavy Duty Foot & Hand Controls
¾Electric Salon Top
¾Round Corners
¾Quietech Hydraulic Lift System
¾Electrified and Hot Towel Cabbie Ready
Surge Protected Outlet Strip
¾ADA Compliant
¾Patent #6163904
ELECTRICAL DATA –
Power Cord
Non-grounded, polarized,
double insulated
Input Voltage /
Amp.
120VAC ~ , 60 Hz,
2.7 A max.
Input Amperage
Rating Max. 12A
Duty Cycle 10%, Max. 2 min./18 min.
OUTLET STRIP Rated 12A - 125VAC - 60 Hz
Product Code: LE04X
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 15 of 15
