M-Spa Line User manual

Owner’s Manual
P-SH069 Line

CONTENT
Safety precautions………………………………………………………………......................................................
Specifications and product overview………………………………………………..............………........................
First use preparation and set-up………………………………………………….........................……………........
Spa set-up……………………………………............................…………………………......….............................
Wired controller operation………………………………………........................…................................................
Water maintenance and chemicals………………….......................................………..………………..…...........
Drainage, cleaning and storage………………………...................................………………..………..……..........
Disposal and environmental protection…………………………....................................…..................................
Troubleshooting…………………………………………….......……………………….…...…...…..........................
3
9
11
13
17
19
21
22
23
2

3
SAFETY PRECAUTIONS
For your own safety and that of your product, make sure to follow the safety
precautions below. Failure to follow the instruction may result in serious injury,
property damage, or death. Improper installation or operation will void the warranty.
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS
KEEP THE MANUAL FOR FUTURE REFERENCE
!DANGER
●Risk of Accidental Drowning. Extreme caution must be exercised to prevent
unauthorized access by children.
●Risk of drowning. Inspect the spa cover regularly for leak, premature wear, and
tear, damage or signs of deterioration. Never use a worn or damaged cover as it
will not provide the level of protection required to prevent unsupervised access
to the spa by a child.
●Risk of drowning. Always lock the spa cover after each use.
●Risk of injury. If the supply cord is damaged, it must be replaced by the
manufacturer, service agent or similarly qualified persons to avoid a hazard.
●Risk of Electric Shock. Do not permit any electrical appliances, such as a light,
telephone, radio or television within 1.5m (5 feet) of a spa tub.
●Risk of Electric Shock. Do not use the spa when it is raining, thundering, or
lightning.
●To reduce the risk of electric shock, do not use an extension cord, timers, plug
adaptors or conversion plugs to connect the unit to electric supply. Provide a
properly located outlet.
●The appliance with incorporated heating elements must be connected to a
grounded mains supply socket and a supply cord fitted with a plug and PRCD
equipped with a tripping current of 10mA.
!WARNING

4
● Transportable whirlpool spas with earthing must only be plugged directly into an
earthed socket-outlet of the fixed wiring.
● Components containing moving parts, except parts supplied with safety
extra-low voltage not exceeding 12V, must be inaccessible to occupants in the
spa.
● Parts incorporating electrical components, except remote control devices, must
be located or fixed, so that they cannot fall into the spa.
● Electric installation should fulfill the local requirement or standards.
● The wired controller shall be properly stored at the side pocket when not used,
to protect the controller from falling or from other factors.
● This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be performed by children without supervision.
● To reduce the risk or injury, keep children away from this product unless they
are closely supervised at all times.
● To reduce the risk of child drowning, supervise children all times. Attach and
lock the spa cover after each use.
● Make sure the floor is capable of supporting the expected load, which you can
find from the spec sheet. Calculate the expected load of water capacity plus the
total weight.
● Adequate draining system must be provided around the spa to deal with
overflowing water.
● To reduce the risk of injury:
a) Lower water temperatures are recommended for young children and when
spa is used for more than 10 minutes. In order to avoid the possibility of
hyperthermia (heat stress) occurring it is recommended that the average
temperature of spa-pool water should not exceed 40°C (104°F).
b) Since excessive water temperature has a high potential for causing fetal
damage during the early months of pregnancy, pregnant or possibly pregnant
women should limit spa water temperature to 38°C (100°F).
c) Before entering a spa or hot tub the user should measure the water
temperature with an accurate thermometer since the tolerance of water

5
temperature-regulating devices varies.
d) The use of alcohol, drugs, or medications before or during spa use may lead
to unconsciousness with the possibility of drowning.
e) The use of alcohol, drugs, or medications can greatly increase the risk of fatal
hyperthermia in spas.
f) The causes and symptoms of hyperthermia may be described as follows:
Hyperthermia occurs when the internal temperature of body reaches a level
several degrees above the normal body temperature 37°C (98.6°F). The
symptoms of hyperthermia include an increase in the internal temperature of
body, dizziness, lethargy, drowsiness, and fainting. The effect of hyperemia
includes failure to perceive heat; failure to recognize the need to exit spa;
unawareness of impending hazard; fetal damage in pregnant women;
physical inability to exit the spa; and unconsciousness resulting in the danger
of drowning.
g) Obese persons or persons with a history of heart disease, low or high blood
pressure, circulatory system problem, or diabetes should consult a physician
before using a spa.
h) Persons using medications should consult a physician before using a spa
since some medications may induce drowsiness while other medication may
affect heart rate, blood pressure, and circulation.
i) Check with doctor before use if pregnant, diabetic, in poor health, or under
medical care.
● People with infectious disease should not use a spa or a hot tub.
● To avoid injury exercise care when entering or existing the spa the or hot tub.
● Water temperature in excess of 40°C (104°F) may be injurious to your health.
● Never use a spa or hot tub alone or allow others to use the spa alone.
● Do not use a spa or hot tub immediately following a strenuous exercise.
● Spa heat in conjunction with alcohol, drugs, or medication can cause
unconsciousness.
● Exit immediately if uncomfortable, dizzy or sleepy. Spa heat can cause
hyperthermia and unconsciousness. Do not put the spa under 0°C (32°F)
environment in order to avoid freezing if there is still water in the pool. It is
helpful to put a temp barrier mat in between the spa pool and the ground. Similar
mat, which is made of foam material, or other materials with heat barrier function
can also be used. Do not turn on the spa when the water is frozen.

6
● Always add chemicals to water, never add water to chemicals. Adding water to
chemicals may cause strong fumes or violent reactions and hazardous chemical
spray.
● For water already used, discharge it in time or use water chemicals for cleaning.
Usually, it is recommended to drain and refill the spa with clean water every 3-5
days.
● Use Mspa chemical kit for disinfection in accordance with manufacturer’s
instructions.
● Do not leave or set up the spa in temperature lower than 4°C (39°F) if heater is
not operating.
● Always enter and exit the spa or hot tub slowly and cautiously. Caution of wet
floor.
● To avoid damage to the pump, never turn on the spa or hot tubs unless it is
filled with water to the minimum water line.
● Place the spa or the hot tub only on a properly prepared site that can withstand
the floor loading requirement of the spa.
!CAUTION
● Never pour water with a temperature higher than 40°C (104°F) directly into the
spa.
● Always unplug this product from the electrical outlet before removing, cleaning,
servicing, or making any adjustment to the product.
● Never jump or dive into a spa or any shallow body of water.
● No part of the electric appliance is to be located above the bath during use.
● Do not bury the electrical cord. Locate the cord where it will not be damaged by
lawn mowers, hedge trimmers, and other equipment.
● Do not attempt to plug in or unplug this product while standing in water or when
your hands are wet.
● Do not use the spa if damaged during the delivery and/or malfunctioning in any
way. Contact [email protected] for further direction.
● Keep all pets away from the spa to avoid any damage.
● Do not add bath oil or bath salts to the spa water.

7
● Do not leave the spa empty for extended period of time. Drain water inside the
pool thoroughly if it is not used for a long period of time. Do not expose the spa
to direct sunshine. Check regularly before each use. Put away the spa or fence
it up in time after using.
● Open the spa top lid when the Bubble function is on.
● In order to avoid a hazard due to inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and off by the
utility.
● Refer to relevant chapter for details concerning cleaning and other
maintenance.

8
Zone 2 Zone 2
h
h
Zone 1
Zone 0
Zone 0
2.5 m
2.5 m
1.5 m 1.5 m2.0 m 2.0 m
Warning: The water protection levels of appliance at different product zones are
different. See the following diagram. ( Installation regulations comply to IEC
60364-7-702)
NOTE-The measured zone dimensions are limited by walls and fixed partitions.
Zones
Zone 0
Zone 1
Zone 2
Description of the zones
Zone 0 is the interion of the basin including any recesses in their
walls or floors.
Zone 1 is limited by
• Zone 0
• A vertical plane 2m from the rim of the basin.
• The floor or the surface expected to be occupied by persons
• The horizontal plane 2.5m above the floor or the surface
Zone 2 is limited by
• A vertical plane external to zone 1 and parallel plane 1.5m
from the former.
• By the floor or surface intended to be occupied by persons.

9
SPECIFICATIONS
Control System
Total Power
Heater
Massage Air Blower
Filter Pump
Integrated Ozone Generator
Top Lid
Pool Cover
Pool Material
AC 220-240V~ 50Hz
2300W
1500W
3 Levels (Level 1: 300W, Level 2: 500W, Level 3: 720W)
12V/60W
5.5W, 30-50mg/Hr
Premium PVC leather cover with foil inside
Premium PVC tough leather, waterproof and anti-UV
Premium PVC fabric
Control System Specs P-SH069
BUBBLE SPA
Model No.
/ Code Shape Seating
Capacity Water Capacity Outside Dimensions Inside Dimensions Height Weight
P-SH069 /
Line Square 930Ltr
(245gal)
1.85m
(73”)
1.45m
(57”)
0.68m
(27”)
35.5kg
(78.3lbs)
6

E.
I. J. K. L.
M.
F. G. H.
B. C. D.
10
PRODUCT OVERVIEW
Content of the package
NOTE: Drawings for illustration purpose only. The actual product may vary. Not to scale.
A.
®
* Round or square
Only for P-SH069
* Buckle spa cover * Ground mat

11
REF. NO. PARTS DESCRIPTION QTY.
Spa tub
Wired controller
Inflation hose for bladder
Filter cartridge*2, cartridge base
Spa drain valve adaptor
Repair kit
Inflatable bladder
Wrench
Buckle spa cover and ground mat set (only for P-SH069)
NOTE: When ordering parts, be sure to quote the model number and description.
A
B
C
G
H
I
J
K
L
M
1
1
1
1
1
1
1
1
1
1
Spa cover with aluminum foil inside
(Line P-SH069 comes with a ground mat with the cover)
FIRST USE PREPARATION AND SET-UP
●The spa can be installed indoors and outdoors. For household use only.
●The spa must be set up on a flat, smooth, and firm surface that is capable of supporting the maximum load
of the filled spa with the listed number of maximum occupants.
●Make sure the area is free of sharp objects under or around the spa. Uneven or unsound surfaces can
damage the spa and void your warranty. Level the surface before filling the spa with water.
●Provide adequate drainage system around the spa to deal with overflowing water and splashes.
●Make sure there is enough clearance around the spa for full access to the spa equipment for maintenance
and/or service.
Site preparation and requirements
● Verify the floor can support the filled weight of spa with the maximum number of occupants. Check with a
qualified contractor or structural engineer to verify the requirement.
● Make sure the floor is water resistant and provides a non-slip surface. Do not install the spa on a carpet of
any other material that could be damaged by the moisture.
● Humidity is a naturally side effect of indoor spa installation. The room shall be properly ventilated to allow
moisture to escape. Install a ventilating system to prevent excess condensation moisture in the room.
Additional requirements for indoor installation

12
2. 3.
● Make sure to set up the spa on a firm, level, and smooth surface that is strong enough to support the full
weight of the filled spa and the number of maximum occupants.
● Do not set up the spa on grass or directly on the ground, as this increases the amount of debris entering the
spa and can damage the spa floor.
● Do not leave the spa tub exposed to direct sun light for long timespan.
● Always keep the manometer on yellow section when using the spa at a temperature higher than 20°C
(68°F) or exposed to sunlight for a short time.
● Do not install or use the spa outdoor at a temperature lower than 4°C (39°F). Do not use the spa when the
water inside the circulation system, the pump, and the pipes is frozen. Put a Heat Preservation Mat in
between the spa bottom and the ground to prevent heat loss from the bottom of the spa and to provide
better heat retention.
Additional requirements for outdoor installation
Spa Control Unit Connected to External Equipotential Bonding Conductors
A qualified electrician shall wire the spa control unit to the household equipotential terminal using a minimum
1.5mm² solid copper conductor.
1. Plug the machine into the mains.
2. Press the RESET button on the PRCD. The indicator turns red.
3. Press the TEST button on the PRCD. The red color shown on the indicator should disappear. Otherwise the
PRCD is faulty. Do not use the spa if the spa is faulty. Contact a qualified electrician to correct the fault.
4. Press the RESET button on the PRCD again. The indicator should turn red. If yes, the spa is ready for use.
PRCD Testing
Risk of electric shock: This product is provided with a PRCD located at the end of the power cord. The
PRCD must be tested before each use. Do not use the spa if the PRCD does not function properly.
Disconnect the power cord until the fault has been identified and corrected. Contact a licensed electrician to
correct the fault. There are no serviceable parts inside the PRCD. Opening the PRCD will void the warranty.
!WARNING
RESET
TEST
RESET
Indicator TEST
RESET
TEST
1.
√
PRCD doesn’t
work on faulty
sockets or plug
boards.

13
31
SPA SET-UP
1. Move the entire package to the selected site. Open the carton carefully as it can be used to store the spa
during long term storage or when not in use.
2. Lay out all the parts on the ground and make sure all parts are accounted for. Make sure the spa tub is right
side up. (*For missing or damaged part, contact [email protected])
3. Spread the Heat Preservation Ground Mat over a cleared area. Spread out the spa liner over the ground
mat. The heat Preservation Mat prevents heat loss from the bottom of the unit.
2
NOTE:
Line P-SH069: Spread out
the square ground mat and
place it to the selected site.
Make sure the buckle of
cover and mat is attached
when the spa is not in use.
●
this side
face down
Spa Inflation
4.1 Plug the spa into the grounded supply socket.
4.2 Press the RESET button on the PRCD, the screen on controller shows numbers.
4.3 Turn the inflation knob to the inflation status <ON> and long press (≥2 minutes) the bubble button on
the controller to start inflating until the yellow section of the manometer is pushed out.
4.4 Stop pressing the bubble button and turn the knob back to <OFF> for activating other functions.
4.
4.3 4.4
Yellow
ON OFF
BUBBLE

14
5
Spa Bladder Inflation.
5.1 Open the air valve (a) on the bladder. Insert the inflation
hose (b) into the valve. Open the air valve (C) on the spa
pool. Make sure you choose the correct one in black color.
5.2 Press the Bubble button to inflate until the bladder
is firm to touch but not hard.
5.3 Press Bubble button for more than 3 seconds to
turn off the function. Disconnect the inflation hose from the
air blower outlet and the valve.
5.4 Replace the air valve cap (c) back. Close and recess the
inflation valve (a).
5.
(a)
(b)
(c)
Note:
Before inflation, check whether the manometer cap is screwed up tight on the valve of pool
body. If not, please tighten and then inflate. After inflation, the manometer cannot be removed,
otherwise the air will be released.
When the Yellow section is pushed out, the Spa inflation is completed. You can fill the Spa with water.
After water filling is completed, check the air pressure once again to ensure the manometer reaches its
Green section. Always ensure the manometer is in the Green section during use.
If the White section of the manometer appears, the spa is over inflated. Rotate the valve cap counter
clockwise, have the air released till the Green section is pushed out, then tighten it clockwise.
To avoid over inflation caused by warm weather or sunshine when leaving spa for weeks inflated and
filled with water in temperature higher than 20°C (68°F), please release some air to make sure the
manometer is always on in the Yellow section.
Green
Yellow
White
BUBBLE
BUBBLE
NOTE: Deflation Instruction
Spa Deflation
1. Unscrew the air valve cap on the spa pool to deflate the spa.
2. Once the deflation is completed, place the cap back.
Spa Bladder Deflation
1. Pull the valve cap out and squeeze the valve at its base until deflated.
2. Close and recess the valve back.

15
6.5
6
●The water level must reach the Minimum water line but not exceed the Maximum line to avoid
pump failure.
●Never pour water with a temperature higher than 40°C (104°F) directly into the spa.
●To avoid control system failure, do not operate the spa until water reaches the Minimum
line.
Water Filling
6.1 Check the spa mark is at the selected area and point
the drain valve toward a suitable draining area
before inflation.
6.2 Fill the spa tub with fresh water to a level between
Minimum and Maximum line marked on the inside
of the spa wall. Do not over fill the spa. It is recommended to fill the spa with lukewarm water for quick
heating and energy saving.
WARNING:
6.3 After water filling, double check the spa pool air pressure to make sure the manometer points out to
the Green section.
6.4 Install the filter cartridge. Please refer to the instruction on P20
6.5 Place the inflated air bladder and the zipper spa cover over the spa tub. Make sure the spa cover is
zipped and locked by the digital lock in the accessory pack.
IMPORTANT:
● Inspect the spa pressure regularly for leak, premature wear, or deterioration.
● Check and wax the zipper regularly, to make it smooth for operation and to avoid splits.
6.
6.6 Turn on the Heater on the spa wired controller, refer to the “Wired Controller Operation” section.
Maximum heating temperature is 40°C (104°F). Hourly heating rate is about 1.5°C-2°C (2.5°F-3.5°F)
for 4 persons and 1.2°C-1.8°C (2°F-3°F) for 6 persons.
Zipper and Buckle Operation
7.1 Digital Lock Operation
The default password is “000”. Follow the steps below to change the password:
● Push the button (a) in the direction of Fig.7.1.(1) to unlock the digital lock.
● Set your preferred password in 3 digits by turning the number wheel (b), see Fig.7.1.(2).
● Insert back the cable (c). The new password is set.
7.

7.2
7.1.(1) 7.1.(2) 7.1.(3)
16
(b)
(a) (c)
7.2 Square Spa Buckle Lock Operation
Lock the Buckle
● Insert the buckle on the Ground Mat into the Spa cover buckle, until you hear a “Click” sound.
Unlock the Buckle
● Pinch both sides of the locked buckle, and press down the round dot in center in the same time.
Press down the center button and release the lock.
Lock Unlock

17
WIRED CONTROLLER OPERATION
Heater Button
- Adjust the bubble level by pressing
the button (L1:300W, L2: 500W, L3:720W)
Bubble Button
Up Button
Filter Button
Timer Button
Down Button
Celsius/Fahrenheit
Toggle Button Ozonator Button
Temperature display: press RESET on PRCD, read the current temperature on the screen.
Heater Button: Press HEATER button to start or stop heating.
The filter will automatically be running for 15 seconds to test the working condition once the HEATER
function is started. If there is no abnormality, the heater will keep working until the water temperature
reaches the set value. When the water temp goes below the set temp, the heater will restart to heat
the water automatically. The HEATER button displaying red means that the heating system is
activated. The HEATER button displaying green means that the system is at rest and keeping the
water at the set temp.
Filter Button: Press FILTER button to turn the function on/off. The light of FILTER button displays
green when activated.
NOTE: Filtration cannot be turned off when heating function is on (Whether the heater is running or at
rest) . When the Heating function is turned off, filtration will be stopped after 30 seconds. Filtration
function can then be activated separately.
NOTE: The auto-filtration system is automatically activated every 4 hours.
Bubble Button: Can adjust among 3 levels of bubbling power. The default bubbling massage
power is at level 2 (500W). Press the BUBBLE button again, switching to level 3 (720W). Press again
to enable level 1 (300W). To shut down the function, press the BUBBLE button for 3 seconds.
NOTE: The bubbling massage function will be shut down automatically after every 20 minutes
operation for safety concern. It cannot be operated within 10 minutes after shutting down.
FILTER
HEATER
BUBBLE

18
Attention: The bubble function can only be activated when the inflation knob is in <OFF> position.
Adjustment Buttons: Press UP or DOWN button, the screen flashes setting temperature. Re-set
the temperature within 3 seconds. Otherwise the temperature setting mode will end automatically. If
the other button is pressed during the setting , the setting will also stop. The current temperature
shown on the screen is confirmed.
NOTE: Default setting temperature is 38°C; Temperature setting range: 20 - 40°C.
Controller Locking: Press UP and DOWN button at the same time for 3 seconds, the buzzer will ring
3 times, meaning that the controller is locked. In this mode, the function will not be turned on if the
button is pressed. Press UP and DOWN button at the same time again for 3 seconds to unlock the
controller.
Timer Button: Press the TIMER button to enter the intelligent pre-setting mode. By pressing UP
and DOWN button, you can set and start heating automatically with in up to 99 hours. The TIMER
setting is confirmed if no further operation in more than 3 seconds or press TIMER button again. The
heater will start working after current setting hours. The setting hour can also be changed by entering
the pre-setting mode again. The light of TIMER button flashes green when activated.
Cancel: Press the TIMER button for 3 seconds to cancel the pre-setting.
NOTE: The pre-setting function cannot be turned on during heating process. The pre-setting mode
will also end once the heating function is on or after the spa is reboot.
Celsius/Fahrenheit Toggle Button: The temperature can be displayed in either Celsius or
Fahrenheit.
Ozonator Button: Activate the Ozone. The Ozone icon shows green when the Ozone function is
activated. For bathers' safety concern, the ozonator cannot be operated at the same time when the
Bubbling or Jet function is on. The Ozonator will be off automatically after operating for 2 hours. The
ozone output is 30-50mg/Hr.
NOTE: Please do not soak in the spa when the Ozone is on. The Ozonator will not work when the
spa has no water or when the Bubble Button is on. The filtration cannot be turned off when Ozonator
is in use.
TIMER
IMPORTANT: The following conditions will lead to slow water heating
● The ambient temperature is lower than 10°C(50°F)
● Outdoor wind speed is above 3.5-5.4m/s(8-12mph)
● The air bubble function is activated when heater is on
● The spa is not properly covered with the spa cover when the heater is on
Filter Cartridge Cleaning Reminder: When the red light keeps flashing (Filter
function is OFF) or red and green lights are alternately flashing(Filter function is
ON), the filter cartridge shall be cleaned or replaced. After that, press Filter button
for 3 seconds to clear the reminder.
DOWN
UP

19
WATER MAINTENANCE AND CHEMICALS
Water Sanitation
The spa owner must regularly check and keep the spa water sanitized with scheduled maintenance (daily, if
necessary). Adding sanitizer or other chemical will control bacteria and viruses reproduction in the spa water.
The maintenance of a proper water balance through appropriate use of sanitizers is the most important factor in
maximizing the life and appearance of the spa as well as ensuring clean, healthy and safe water.
Proper technique is important for water testing and treating the spa water. See your spa professional for
chemical, sanitizer, test kit and testing procedures questions.
NOTE:
● Low pH will damage the spa tub and pump. Damage resulting from the chemical imbalance will void the
warranty.
● High pH (hard water) will result in white coagulations inside the filter pump; which may lead to pump
damage.
Water Treatment:
● Always follow the chemical manufacturer’s direction, and the health and hazard warning.
● Never mix chemicals together. Add the chemicals to the spa water separately. Thoroughly dissolve each
chemical before adding one to the water.
● Please note that chlorine and bromine products should never be mixed. This is extremely dangerous. If you
usually use chlorine-based products and you want to switch to bromine-based products, or vice versa, it is
pH
Free Chlorine
Bromine residual
Total Alkalinity (TA)
Total Hardness (TH)
Daily
Daily
Daily
Weekly
Weekly
3-5 ppm
2-4 ppm
80-120 ppm
200-500 ppm
CORRECT LEVEL
Water Balance
Follow below instructions to maintain the spa water.
7.2-7.6 when using Chlorine;
7.2-7.8 when using Bromine
PARAMETER TEST FREQUENCY
Cumulative use up to 150hrs, or cleaning
reminder is activated
Check water quality in time and adjust to
recommended range
Not in used for 2~3 days or longer Use an overall cover for protection
Use water treatment products to adjust
FREQUENCY ACTION
Filter
Cartridge
SPA
Clean the filter cartridge or replace it with a
new one.The filter cartridge may need to be
replaced within 150hrs for initial use.

20
2. Change the spa water every 3-5 days depends on the spa use. See “Cleaning, draining and storage”
section for instruction.
3. Use spa chemicals to maintain proper water conditions. Spa damage resulting from misuse of chemicals
and mismanagement of spa water is not covered by the warranty. Consult with your local spa or pool
retailer for more information on chemical use.
4. All occupants must shower before entering the
spa. Do not use skin care or sunscreen products
while using the spa.
5. When spa inlet or outlet is stuck with dirt, use the
wrench to unscrew it and clean the inlet or outlet.
5
1.1
1.2
Maintenance of Spa Water and Cartridge
Protect all the spa occupants from possible water related illness by keeping the spa water clean and sanitized.
Always practice good hygiene. Ensure proper spa water quality by following these procedures:
1.1 Install clean filter cartridge to water inlet.
●First install the cartridge base to the inlet by rotating it clockwise.
Then install the filter cartridge to the base. Push and fix it. It should always stay in place when the spa
is filled with water.
1.2 Inspect and clean the filter cartridge after each use. Change the filter cartridge after it works continuously
for 150 hours, or after seeing cleaning reminder.
● Pull out the filter cartridge from the base.
● Use a garden hose to rinse off the cartridge.
● Reinstall the clean or spare cartridge back onto the spa tub wall.
Note: Do not throw away the cartridge base when replacing the filter cartridge. Only change the base
when it gets loose after long term using.
mandatory to completely change the spa water before any product changes.
● Do not add chemicals if the spa is occupied. This can cause skin or eye irritation.
● Do not over use the chemicals, or use concentrated Chlorine. This can damage the spa tub and cause
potential hazard to your skin. Improper chemical use will void the warranty.
