Spartherm Fuora Q/R User manual

Gas Outdoor Fireplace - For Use in Open Spaces.
Operating Manual |Fuora Q/R

PREFACE
Dear customer,
Thank you for choosing to buy a SPARTHERM product. We hope you enjoy the
comfortable, cosy fire of your gas fireplace. Our products have been developed
and produced according to the highest quality and safety requirements. For this
reason, you can enjoy many years of trouble-free use, guaranteed.
In this booklet, you can find instructions for installing and using your new unit.
Read the instructions and the user's manual well so that you can familiarise
yourself with the unit. If you would like more support, you can contact your dealer
or installer.
Your SPARTHERM Team
G.M. Rokossa

3
OVERVIEW OF THE OPERATING MANUAL // GAS OUTDOOR FIREPLACE
1. Warning 4
2. Installation instructions 4
2.1 Propane installation instructions 5
3. Technical data 5
4. Safety Instructions 6
5. Commissioning the unit 7
5.1 Switching the unit on 8
5.2 Burner flame 8
5.3 Adjusting the flame height 8
5.4 Switching the unit off 8
5.5 Warning – If you smell gas 8
5.6 Removing the glass casing 9
6. Gas cylinder adapter 9
6.1 Adapter for the connection 9
7. General warranty conditions 10
7.1 Area of application 10
7.2 General information 10
7.3 Warranty period 10
7.4 Warranty requirements 10
7.5 Exclusions from the warranty 10
7.6 Elimination of defects / repair 11
7.7 Extension to the warranty period 11
7.8 Spare parts 11
7.9 Liability 11
7.10 Closing remarks 11

4
• If you install a (separate) device in which to place the gas cylinder, be
sure that the cylinder is well ventilated. Propane is heavier than air, and
an accumulation of this gas can have dangerous consequences. If you
have any questions about the instructions in this manual, please contact
your sales outlet.
• It is dangerous and illegal to use this unit in an enclosed space! The unit has
been developed for outdoor use.
2. INSTALLATION INSTRUCTIONS
Packaging contents
1 Fully assembled burner
1 Bag of 8-16 mm lava stones
1 x Operating manual and installation manual
1 Cover (if a glass top is not provided)
1 Aluminium base with castors and levelling feet for safety
1 Rubber piece for mounting the gas cylinder
1 Pressure regulator + 0.4 m gas hose
1 Tip-protection valve
Unpacking
Once you have unpacked everything, you should dispose of the packaging
appropriately.
Usage
If your gas fire is set up in commercial areas, use a pressure reducer with
a pressure relief valve.
This is available for purchase as an optional component (see page 9).
1. WARNING
• Read the instructions carefully before using the gas outdoor fireplace
(Fuora) and keep the instructions for future reference.
• This product and, if applicable, the gas cylinder should be installed
in accordance with the instructions in this manual, as well as with all
applicable national and/or local regulations.
• The distance from flammable materials to the fireplace should be at
least 1.5 metres.
• Never leave the fire unattended.
• Do not move the gas outdoor fireplace (Fuora) when it is hot or in
operation.
• Keep children out of reach of the product while it is in use and until it
has completely cooled down.
• Caution! Touching the hot parts can cause blisters! A safety device has
to be provided to keep children as well as frail or disabled people from
coming too near to the unit.
• Always shut off the gas valve before moving the product.
• Shut off the gas supply after use.
• Never perform repairs on your own and do not make any changes to
the unit.
• Do not block the air flow in the direction of the burner and/or the injector.
• Do not interfere with the air flow in the direction of the gas cylinder
housing.
• In the case of strong wind, place the unit in a sheltered location to
prevent it from overturning.
• In the event of a gas leak, close the gas cylinder or shut the gas valve
connected to the main gas supply.

5
Caution: If you need assistance when installing the fireplace, please
contact your dealer.
2.1 PROPANE INSTALLATION INSTRUCTIONS
1. Connect the pressure regulator to the gas cylinder (left-handed thread)
(the maximum allowable filling amount is 10.5 kg). To do so, use suitable
(adjustable) pliers. It is not enough to tighten it by hand; This could allow
a leak to occur. Replace the gas cylinder only in well-ventilated areas and
not near candles, cigarettes or other flammable sources.
2. Caution: Before connecting the pressure regulator, always ensure that
the rubber gasket is present and undamaged. If not, the device must not
be used until the gasket is replaced.
3. Make sure that the gas cylinder is always standing upright. The gas hose
must not come into contact with sharp objects or edges which could
damage the inner tube. Be sure that the gas hose does not come into
contact with hot parts of the burner.
4. Check all of the connections for leaks. To do so, moisten all of the gas
connections with soapy water or use a gas leak detection spray. If bubbles
arise in the suds or the gas leak detection spray, there is a leak.
5. Distribute the supplied ca. 0.9 kg (8-16 mm) lava stones in the form of a
small hill (Fig.1b) on the burner bed. Be sure that no small pieces of stone
enter the burner. Also be sure that no stones are lying on the thermal
element. The fireplace is now ready for use.
6. Now, the two adjustable feet on the bottom of the gas fireplace have to be
adjusted in order to ensure a secure footing.
Warning
Check the gas hose at least once a month as well as each time you change
the gas cylinder. If the hose shows signs of cracks or other damage, it
should be replaced by a tube of the same length and quality.
3. TECHNICAL DATA
Manufacturer Spartherm Feuerungstechnik GmbH
Contact details Postbox 1751
D-49324 Melle
Phone: [phone]
Fax: [phone]
Model Fuora Q / R
Versions Propane, Butane
Country of destination Germany (FRG)
Standard EN 14543+A1
PIN Number CE 0063CO3494
Propane connection Pressure regulator 50mbar
Heat output 3-7 kW
Fig. 1a Fig. 1b

6
MODEL: Fuora Q /R
Suitable types of propane
Gas category I3P-30 I3P-37 I3P-50 I3B/P-30
Type of gas G31 G31 G31 G30
Injector (mm) 1.3 1.3 1.3 1.3
Pressure (mbar) 30 37 50 30
Rated load (kW) 6.00 6.80 7.80 7.00
Full gas rate (m3/h) 0.223 0.249 0.284 0.196
Country of destination Germany
Manufactured by Spartherm Feuerungstechnik GmbH
CE 0063
PIN: 0063CO3494
Serial number: 30100001
• Designed exclusively for use outdoors.
• Read the user's manual well before you operate the unit.
• The individual parts can become very hot; keep the unit out of reach of
children.
• The unit is intended for heating purposes.
• The unit has an open fire; Always ensure the safety of children
and elderly/infirm persons.
4. SAFETY INSTRUCTIONS
Please read these safety instructions carefully before operating the gas
fireplace! If the information from the instructions is not strictly followed,
fire or explosion could result, which could lead to property damage, serious
bodily injury or even death.
WARNING: Improper installation, adjustments, changes, care or maintenance
can result in injury or damage. Consult the user's manual which is included
in this delivery. If you have questions or would like additional information,
please contact an authorised gas fitter. When igniting the burner, make sure
that the valve of the gas cylinder is opened fully.
WARNING: This gas fireplace is only suitable for propane. The unit is
intended exclusively for outdoor use. It is not suited for installation in
buildings, garages or closed structures or in/on vehicles or boats.
WARNING: This gas fireplace should never be used underneath a
combustible structure or combustible materials and should never be placed
in the immediate vicinity of other combustible materials.
WARNING: The installation and maintenance of the unit should be conducted
by a recognised gas fitter. Local regulations should be followed in the
process. Improper installation, adjustment, alteration, care or maintenance
can result in damage or injury.

7
Note: The four cotter pins must always be used!
5. COMMISSIONING THE UNIT
1. Remove the weather protection hood (if provided).
2. Check that the gas is connected correctly to the gas cylinder and open
the cylinder. Secure the gas cylinder with the rubber mounting piece.
3. The gas outdoor fireplace (Fuora) is operated with the gas regulator
located behind the fireplace door.
4. In order for the gas to be able to flow to the burner, the tip-protection
(Fig. 3) has to be aligned horizontally.
WARNING: Follow all the instructions (provided in the manual) regarding
gas leak detection before operating the unit. Never try to loosen the gas
fitting when the unit is in use.
WARNING: Do not use or store petrol or other flammable vapours or liquids
near this or other units.
WHAT YOU SHOULD DO IF YOU SMELL GAS: Close the gas supply,
extinguish any fires, and then contact your gas fitter and follow his
instructions. If you cannot reach your gas fitter, you should contact the fire
brigade.
WARNING: This unit may not be used on a flammable surface,
such as a wood table.
WARNING: Transporting the unit must only be conducted with the four
secured cotter pins in place. The cotter pins are included with the unit and
are to be inserted in the gas cylinder compartment in the perforated steel
plates of the upper part of the glass (Fig. 2a /b).
Fig. 2a Fig. 2b
INCORRECT INCORRECTCORRECT
Fig. 3

8
5.1 SWITCHING THE UNIT ON
1. Turn the ignition knob on the gas control panel (Fig. 4) as far to the right
as possible. Push in the ignition knob. Then, turn it to the left, keeping it
pushed in until you hear a "click" (Fig. 5). This "click" is the ignition of
the pilot light. If necessary, repeat this process 3-5 times until the pilot
light is burning.
2. Once the pilot light is lit, continue holding in the ignition knob for another
10 seconds. Then release the ignition knob.
3. If the pilot light goes out, repeat steps 1 and 2 until the pilot light starts
burning.
Caution: If a new gas cylinder is installed or the fireplace has not been
used for a while, you first have to release the air from the gas hose. This
may take a while before the pilot light ignites.
5.2 BURNER FLAME
After the pilot light starts burning, the ignition knob (Fig. 6) has to be turned
to the left. Now the main burner (Fig 1) is supplied with gas.
5.3 ADJUSTING THE FLAME HEIGHT
1. The desired height of the gas flame can be adjusted by turning the flame
height controller (Fig. 7) to the right or left.
2. For a lower gas flame, turn the knob clockwise to the right (Fig. 8).
3. For a higher gas flame, turn the knob clockwise to the left (Fig. 7).
5.4 SWITCHING THE UNIT OFF
1. By turning the ignition knob to the right again (Fig. 4), you will shut off the gas
supply and the fire will go out. Then, the gas cylinder has to be closed.
5.5 WARNING – IF YOU SMELL GAS
Never ignite the unit if you smell gas. If the unit is on when you smell gas, you
have to interrupt the gas supply (close the gas cylinder or the gas valve).
Then, check all of the connections for leaks. To do so, moisten all of the gas
connections with soapy water or use a gas leak detection spray. If bubbles arise
in the suds or the gas leak detection spray, there is a leak.
You can only use the unit again after all the leaks have been sealed. Please
consult your dealer, if necessary.
Fig. 6Fig. 5
Fig. 4
Fig. 7 Fig. 8

9
5.6 REMOVING THE GLASS CASING
The glass casing is fitted on the body and is secured on the sides with four
steel lugs. (Fig. 9)
The steel lugs are inserted through the coated body and are secured in the
gas cylinder compartment with four cotter pins (Fig. 10).
To take off the glass casing, the four cotter pins must be removed from the
steel lugs (Fig. 11).
Then the glass can be carefully lifted up (Fig. 12).
6. GAS CYLINDER ADAPTER
Fig. 9
Fig. 12
Fig. 10
Fig. 11
Pressure reducer with a pressure
relief valve
For commercial use in Germany.
Order number: 1033198
Adapter fitting 1: Italy, Switzerland
Small cylinder external thread x external thread M 10 x 1
Order number: 1034297
Adapter fitting 2: Italy
Small cylinder external thread x internal thread W 20 x 1/14" LH
Order number: 1034298
Adapter fitting 3: Belgium, Denmark, Finland, Luxembourg,
Norway, Austria, Portugal, Scotland, Switzerland, Italy, Sweden
Small cylinder external thread x external thread M 14 x 1.5
Order number: 1034300
Adapter fitting 4: Denmark, England, France, the Netherlands,
Italy, Austria, Switzerland, Spain
Small cylinder external thread x internal thread W 21.8 x
1/14" LH
Order number: 1034302
6.1 ADAPTER FOR THE CONNECTION

10
7. GENERAL WARRANTY CONDITIONS
7.1 AREA OF APPLICATION
These standard warranty terms apply for the contractual relationship
between the manufacturer, Spartherm Feuerungstechnik GmbH, and
the dealer/distributor. These warranty conditions are not identical to the
contractual and warranty conditions governing relations between the dealer
or distributor and its customers.
7.2 GENERAL INFORMATION
This product has been manufactured in compliance with current standards
of quality control. The materials used have been carefully selected and –
like our entire production process – are subject to on-going quality control.
Specialist knowledge is required when assembling and installing the
product. The product must, therefore, only be installed and commissioned
into service by specialist technical staff, in compliance with current
statutory provisions.
7.3 WARRANTY PERIOD
The standard warranty terms only apply within Germany and the European
Union. The warranty period and scope of the warranty are ensured within
the framework of these conditions outside the statutory warranty, which
remains unaffected.
Spartherm Feuerungstechnik GmbH offers a 24-month warranty in respect
of the housing, operating components (such as handles, setting levers,
shock absorbers), electrical and electronic components (such as fans),
rotational speed controllers, original spare parts, the pressure regulator, all
items purchased as extras, and all safety appliances.
Spartherm Feuerungstechnik GmbH offers a 6-month warranty in respect of
consumables mounted in the combustion /firebox area, such as the fire clay,
vermiculite, fire grates, seals and glass ceramics.
7.4 WARRANTY REQUIREMENTS
The warranty period shall begin on the date when the product is delivered
to the dealer/intermediary This is to be substantiated by documentation,
such as invoices or delivery notes by the dealer/intermediary The warranty
certificate for the product must be presented by the claimant upon making
a warranty claim.
Spartherm Feuerungstechnik GmbH is not obliged to satisfy any claim if
such documentation is not presented.
7.5 EXCLUSIONS FROM THE WARRANTY
These warranty provisions do not cover:
• component wear
• fire clay/vermiculite, i.e. natural products which expand and contract
on exposure to cyclical heating and cooling. This can cause cracks to
appear. The combustion chamber linings will remain fully functional,
provided they are still in position and are not broken.
• the upper surfaces: discolouration of the coating or galvanic surfaces, due to
excessive thermal loading or over-heating.

11
• the push-up mechanism: failure to comply with installation guidelines,
resulting in over-heating of the guide rollers and bearings.
• seals: reductions in sealing strength due to seal hardening as a result
of thermal loading.
• glass ceramics: soiling, due to soot or other burnt-on combustion
materials and visual deterioration due to thermal loading.
• careless transportation or incorrect storage
• inappropriate or careless handling of fragile components, such as glass
or ceramics
• incorrect operation and/or use
• lack of maintenance
• incorrect installation or equipment connection
• failure to comply with installation guidelines or operating instructions
• technical modifications made to the appliance by persons other than the
qualified technical staff
7.6 ELIMINATION OF DEFECTS / REPAIR
Independent of any statutory provisions acknowledged as taking precedence
over the terms of this warranty, all necessary repair work resulting from
material or manufacturing defects shall be conducted free-of-charge and
shall not invalidate the remaining provisions of the warranty. Within the scope
of this warranty promise, Spartherm Feuerungstechnik GmbH reserves the
right to either remedy the fault or replace the device free of charge. The
elimination of defects shall take precedence.
The terms of this warranty shall not extend to any damage or compensation
not covered by statutory provisions.
7.7 EXTENSION TO THE WARRANTY PERIOD
The warranty period shall automatically be extended when claims made in
respect of these guarantee provisions result in the repair or replacement of
defective equipment.
7.8 SPARE PARTS
Only the manufacturer's own components, or replacement parts
recommended and approved by him, shall be used for appliance servicing
and repair.
7.9 LIABILITY
Damages and claims for compensation which are not the result of delivery
of a defective device from Spartherm Feuerungstechnik GmbH are excluded
and are not part of this warranty promise.
The above shall not include claims made in respect of statutory legal
requirements.
7.10 CLOSING REMARKS
In addition to these warranty conditions and our commitment to them, our
dealers and contractual partners are pledged to assist you in both word and
deed. We expressly recommend that our fireplaces and stoves be inspected
regularly by a qualified technician.

SPARTHERM
A1/GB/SP/0.000/12/2014
The global brand for your lounge
Spartherm Feuerungstechnik GmbH · Maschweg 38 · D-49324 Melle
Phone [phone] · Fax [phone] · www.spartherm.com
Your specialist dealer:
Reg. no.: Product inspected by: Date:
. .
Day Month Year
