SPEC snowball 1 Installation instructions

[Toll Free] 1-888-761-7732 [T] 416-246-5550 [F] 416-246-5549
[E] [email protected] [W] www.specfurniture.com
Family
snowball 2 snowball 3
stool hip chair
tablet snowake
snowball 1
Disassembly Instructions
There are 3 versions of the Snowball chair. All three Snowball’s
are available with or without arms, in four-point-to-the-oor,
sled base and stool designs, freestanding, or connected. The
standard width size of the Snowball range is 18”, but is also
oered in the 22”midsize and the 26” Bariartric. Included in the
Snowball family is the Snowake children's line. The Snowballs
are also oered with several accessory options such as storage
basket, foot rest, and tablet arm.
Tools: Phillips head or Robertson screwdriver, box cutter knife,
hammer or rubber mallet, pliers.
Skill Set: Good manual dexterity.
Estimated Time: 10min per chair.
Steps:
1. Back - 4min
On the Snowball 1 and 3, the back rest fastening plates are
exposed at the rear of the back rest. Locate the four
fasteners and unfasten. Remove back rest from the chair
frame.
For Snowball 2 lines and other custom orders, the fastening
plates may be concealed behind upholstery. In this event,
carefully cut through the upholstery on the back side of the
back rest with a box cutter or sharp knife. Position the cuts
to the left and right sides of the back rest (It may be helpful
to locate the fastening plates by feel). Pull away upholstery
on either side until fasteners are exposed. Once the
fastening plate is suciently exposed, remove the back rest
by unscrewing the four fasteners. Remove the back rest
from the chair frame.
2. Seat - 2min
Turn the chair upside down to access the underside of the
seat panel. Locate the four fasteners located on the
underside of the seat pan and unfasten. Remove the seat
panel from the chair frame.
3. Feet Glides - 1min
Once both the seat and back are removed from the frame,
re-position the chair upside down to access glides. With
pliers, rmly grasp the glide and wiggle upward until free.
Repeat process for all four feet.
4. Armrest - 2min
Place the chair frame on its side. With a rubber mallet or
hammer, knock the underside of the arm rest. Continue to
knock until the armrest is free from the frame. This process
may require some force. Flip the chair to the opposing side
and repeat the process.
5. Upholstered components. - 5min
Remove staples from the underside of the seat pan with
pliers. For seat back, make an incision around the perimeter
of the panel approximately 3 inches from the bottom. Once
you have cut all the way through, slip the upholstery cover
o the plywood panel. Pry foam seating pads away from the
plywood seat. Spec’s most recent Snowball models may
contain a recycled plastic seat.
Visit spec’s green news page at specfurniture.com and click
on “End of Product Life Options” for recycling and biodegra-
dation facilities near you.
17.76
9.40
2.76
5.60
steel frame
plywood back
plastic seat
Recyclable Material (lbs)
Total Weight

[Toll Free] 1-888-761-7732 [T] 416-246-5550 [F] 416-246-5549
[E] [email protected] [W] www.specfurniture.com
On all Snowball congurations, the tablet
accessory is available. Remove the tablet
component at the beginning of the
disassembly process. For disassembly,
locate the 8 fasteners on the underside of
the tablet. For easier access to fasteners,
ip the tablet surface up. Unfasten the
screws and remove the tablet.
Tablet
There is a steel storage basket option
which is recyclable. Remove the basket
component at the beginning of the
disassembly process. To remove the basket,
simply unhook from the chair frame.
Storage Basket
Foot Rest
The foot rest accessory is an integral part of
the Snowball Hip chair. For disassembly,
locate the 7 fasteners on the under side of
the panel and unfasten.
Ganging Clip
The ganging clip is frequently used in
order to organize and group multiple
Snowball chairs. Before disassembling any
chair components, remove these clips from
all chairs. Simply un-clip from the chair
frame.
Connecting Bars
Separate the individual chairs and
connecting tables before chair disassem-
bly. To separate, locate the connecting rods
and their corresponding fasteners.
Unfasten screws and remove connecting
rods from frame with the required
screwdriver. In addition, all connecting
tables should be disassembled by
removing the table top with the required
screwdriver.
Disassembly Instructions Accessories
