SPECIAL T FlipTop-C User manual

ASSEMBLY INSTRUCTIONS
S-T STRUCTURE FLIPTOP-C TABLE ASSEMBLY INSTRUCTIONS | 092021
specialt.net 888.705.0777
IF YOU ARE MISSING PARTS OR HAVE ANY QUESTIONS, PLEASE CALL CUSTOMER SERVICE AT 888-705-0777.
Structure
FlipTop-C
FLIP AND NEST TABLE
PARTS
A. Bases with Casters
Left and Right
(2)
B. Steel Beam
(1)
C. Modesty Panel
(1)
D. Wire Channel
(1)
STRUCTURE FLIPTOP-C TABLE | ASSEMBLY INSTRUCTIONS
TOOLS NEEDED
1. Impact Drill or Phillips Head Screwdriver
2. #3 Phillips Head Bit
3. #2 Phillips Head Bit
4. Safety Glasses
E. Release Rod
(1)
F. Round Phillips
Head Lock
Washer Screws
(8)
G. Wood Screws
(16)
H. Small
Phillips Head Screws
(2)
HARDWARE PACKET

ASSEMBLY INSTRUCTIONS
S-T STRUCTURE FLIPTOP-C TABLE ASSEMBLY INSTRUCTIONS | 092021
specialt.net 888.705.0777
IF YOU ARE MISSING PARTS OR HAVE ANY QUESTIONS, PLEASE CALL CUSTOMER SERVICE AT 888-705-0777.
Structure
FlipTop-C
FLIP AND NEST TABLE
STRUCTURE FLIPTOP-C TABLE | ASSEMBLY INSTRUCTIONS
2. Arrange the appropriately marked leg with the
coordinating side of the beam. Slide the bases
over the vertical plates on each side of the
beam. Align the holes on the legs with the holes
in the beam. Attach the bases to the beam by
inserting round washer head screws through long
side of the columns, hand-tighten them.
ALIGN
F
A
A
3. Use either #3 Phillips screwdriver or impact drill
with #3 Phillips bit to tighten bolts as much as
possible.
A
B
A
F
1. Lay the beam upside down on a piece of
cardboard or carpeted surface. Remove the
release rod from the hardware pack, and screw
it into the beam.
B
E

ASSEMBLY INSTRUCTIONS
S-T STRUCTURE FLIPTOP-C TABLE ASSEMBLY INSTRUCTIONS | 092021
specialt.net 888.705.0777
IF YOU ARE MISSING PARTS OR HAVE ANY QUESTIONS, PLEASE CALL CUSTOMER SERVICE AT 888-705-0777.
Structure
FlipTop-C
FLIP AND NEST TABLE
STRUCTURE FLIPTOP-C TABLE | ASSEMBLY INSTRUCTIONS
5. Attach the modesty panel by aligning
screws on top of the modesty panel with the
holes in the legs and insert Round Washer
Head Screws. The screws fasten the legs to the
beam, and the modesty panel to the legs. Use
either a #3 Phillips screwdriver or an impact
drill with #3 Phillips bit to tighteb the bolts as
much as possible.
Align holes in the lower part of the modesty
panel with the holes in the columns. Using
Small Phillips Head Screws, fasten the modesty
panel to the legs. Tighten the bolts with a
screwdriver or impact drill
4. To attach the modesty panel, position the
top ange on the beam and align the holes on
the side anges with the holes in the columns.
C
A A
F
C
H
6. Lay the table top upside down on a piece
of cardboard or a carpeted surface. Position
assembled base onto the top aligning the
holes on both. Use a Phillips screwdriver or
impact drill to install the wood screws through
the table base and into the top. Fully tighten
screws.
ASSEMBLED BASE
TABLE TOP
A

ASSEMBLY INSTRUCTIONS
S-T STRUCTURE FLIPTOP-C TABLE ASSEMBLY INSTRUCTIONS | 092021
specialt.net 888.705.0777
IF YOU ARE MISSING PARTS OR HAVE ANY QUESTIONS, PLEASE CALL CUSTOMER SERVICE AT 888-705-0777.
Structure
FlipTop-C
FLIP AND NEST TABLE
STRUCTURE FLIPTOP-C TABLE | ASSEMBLY INSTRUCTIONS
7. Holding onto the edges of the top, carefully turn the table over
in the upright position. Hang the wire channel on the hooks on the
backside of the modesty panel.
ASSEMBLED TABLE
D
