Speco VM-2105C User manual

21” HIGH RESOLUTION COLOR
MONITOR WITH AUDIO
Specifications
Specifications subject to change
For moreinformation contact us at:
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In MetroNY:631-957-8700 Fax: [phone] or 631-957-3880
VM-2105C
System .........................NTSC/PAL Auto Detect
Picture Tube Dimension . . . . . . . . . . . . . .21”
Front Control .....................Power ON/OFF: Push Switch –
SELECT/MENU/ENTER/UP/DOWN,Tack Switch; OSD
Controlled Function Key Control
Resolution .......................500 TV Lines
Input Signal ......................1Vp-p, composite Video, S-Video
Input Impedance ...................75 ohm or higher (Auto Termination)
Bandwidth ......................6MHz(-3dB)
Video Gain ......................3-dB
Linearity ........................30dB
Operating System ..................NTSC: 525 Lines/Frame
PAL: 625 Lines/Frame
Video (In/Out) ....................BNC Connector: Input x 2/Output x 2
S-Video Input x 1/Output x 1
Audio (In/Out) ....................RCA: Input x 1/Output x1
Audio Input Signal ..................1Vp-p
Speaker ........................3W/8 ohm
Input Voltage .....................AC 96/256V, 50Hz/60Hz
Power Consumption ................90W
Weight (N.W./G.W.) ................27kg/29.5kg
Dimension (W x D x H)mm ............490 x 501.2 x 453
Package Includes:
VM-2105C Instructions
Warranty card
Features
This color monitor has audio capability featuring convenient front controls, looping
video input/output, and comb filter for enhanced picturequality. It is UL listed.
•More than 500 line resolution • Convenient front controls • Rugged metal cabinet
•Looping video input/output • Hi/Lo impedance switch • Audio capability • YC output
•Comb filter for enhanced picture quality • 19.5"L x 19.25"W x 18"H • UL listed
