Speco M17VLED User manual

M17VLED (17” CCTV LED Monitor)
M19VLED (19” CCTV LED Monitor)
USER MANUAL
Speco Technologies
200 New Highway
Amityville, NY 11701
800-645-5516
www.specotech.com

2
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
DO NOT INSERTANY METALLIC OBJECT THROUGH VENTILATION GRILLS.
CAUTION:
CAUTION
Explanation of Graphical Symbols
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.

3
IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and usage instructions should be followed.
5. CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Clean only with a dry cloth.
6. ATTACHMENTS
The manufacturer of this unit does not make any recommendations for attachments, as they may cause hazards.
7. WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a
swimming pool.
8. ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury, and serious
damage to the unit. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart combination to overturn.
9. VENTILATION
Slots and openings at the rear cabinet and bottom are provided for ventilation, these are to ensure reliable operation of the unit,
and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by
placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat
source. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or
the manufacturer’s instructions have been adhered to.
10. POWER SOURCE
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure of the type of
power supply to your home, consult your appliance dealer or local power company.
11. POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the point where they exit.
12. LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line
surges.
13. POWER LINES
An outside antenna systemshould not be located in the vicinity of overhead power lines or other electric light or power circuits, or
where it can fall onto or against such power lines or circuits. When installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits, as contact with them might be fatal.
14. OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
15. OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could
result in fire or electric shock. Never spill or spray any type of liquid into the unit.
16. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
17. CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure
to do so may cause a product damage. Read the owner's manual of the other equipment carefully and follow the instructions
when making any connections.
18. LCD Do not press on or jolt the LCD panel. Doing so may cause the LCD panel glass to break and injury may occur. Should the LCD
panel be broken and liquid leaks out, do not inhale or swallow it. Doing so may cause poisoning. If you have got it into your mouth,
wash it out and consult your doctor. If your hands or clothes have touched it, wipe them with alcohol and a cleaning cloth and
then wash them well.
Important Information

4
Safety, Regulatory and Legal Information
US Regulatory compliance statements
Your LCD AV has been tested and found to comply with the limits for a Class B digital devices, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. Your LCD AV generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instruction, may cause harmful
interference to radio communication. However, there is no guarantee that interference with not occur in
a particular installation. If your LCDAV does cause harmful interference to radio or television reception,
which can be determined by turning your LCD AV off and on, the user is encouraged to try to correct the
interference by one or more the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/AV technician for help.
Warning: Use only shielded signal cables to connect I/O devices to your LCD AV. You are cautioned
that changes or modifications not expressly approved by the party responsible for compliance
could viold your authority to operate the LCD AV.
FCC STATEMENT
This LCDAV complies with part 15 FCC Rules. Operation is subject to the following two
conditions (1) This device may not cause harmful interference. (2) This LCDAV must accept
and interference received, including interference that may cause undesired operation.
Canada Regulatory compliance statements
This LCD AV does not exceed the Class B limits for radio noise emissions from digital apparatus as set
out in the radio interference regulations of Industry Canada.
Safety Precautions

5
Federal Communications Commission (FCC) Statement
This Equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
Safety Precautions
This device complies with Part 15 FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received including interference that may
cause undesired operation

6
Warning…………………………………………………………………………………………………2
Important Safeguards…………………………………………………………………………………………3
Safety Precautions……………………………………………………………………………………………4
Table of Contents……………………………………………………………………………………………6
Components…………………………………………………………………………………………………6
Feature…………………………………………………………………………………………………………7
Exploring Your New Monitor…………………………………………………………………………………8
Function Keys Instruction for AV……………………………………………………………………………9
I/O Connection………………………………………………………………………………………………10
OSD (On Screen Display)…………………………………………………………………………………10
AV/S-Video OSD-Image……………………………………………………………………………………11
AV/S-Video OSD-Audio……………………………………………………………………………………12
AV/S-Video OSD-Setup……………………………………………………………………………………13
VGA OSD-Image……………………………………………………………………………………………14
VGA OSD-Audio……………………………………………………………………………………………15
VGA OSD-Setup……………………………………………………………………………………………16
Applicable Timing……………………………………………………………………………………………17
Specification…….……………………………………………………………………………………………18
Wall Mountable………………………………………………………………………………………………19
Dimension…………………………………………………………………………………………………….20
LCD Color Monitor x1
Accessories
(a) Power cord x1
(b) User Manual x1
(c) VGA Cord x1
(d) Mounting base x1
(e) PC audio cord x1
(f) Adaptor x1
Table of Contents

7
★Bright, flick-free image
★Accurate color processing
★Multi-Scan support
★Built-in internal amplifier and speakers
★1280*1024 SVGA support for computer input (17”/19”)
Feature

8
You can operate your monitor by using the buttons on the front panel.
Front Panel
Back Side
Exploring Your New Monitor

9
Up: Select menu item
Down: Select menu item
MENU Menu: Push this button to display the main OSD menu / select item of next level
Right : Increase the setting of selected item
Left : Decrease the setting of selected item
SOU/AOU Source: Change input source / to return to last OSD control level
Power: Turn on or off the monitor power
Function Keys Instruction for AV

10
Illustration：
●Video Out is present “AV video out”
●Video In is present “AV video in”
●PC Audio In is present “PC audio in”
●Audio In 1 is present “AV audio in”
●Audio In 2 is present “S-Video audio in”
●S-Video In is present “S-Video video in”
●VGA In is present “PC - VGA signal in”
●Power In is present “Power in”
I/O Connection:

11
AV / S-Video OSD - Image
Scheme: Normal / Vivid / Cinema
Brightness: Picture brightness adjustment
Min. ~ Max.:0~100 / Default:70
Contrast: Picture Contrast adjustment
Min. ~ Max.:0~100 / Default:80
Hue: To adjust the color tint value
Min. ~ Max.:0~100 / Default:50
Saturation: Adjusts the saturation of the color
Min. ~ Max.:0~100 / Default:50
Sharpness: Sets the desired sharpening enhancement to the picture
Min. ~ Max.:0~23 / Default:12
OSD (On Screen Display)

12
AV / S-Video OSD - Audio
Volume: Controls built-in speakers’ output volumes
Min. ~ Max.:0~29 / Default:20
Balance: Adjusts the volume between speakers
Min. ~ Max.:0~20 / Default:10
Mute: To disable the audio function

13
AV / S-Video OSD –Setup
Auto Source: The monitor will auto detect the input source when the
signal is not present
Color Temp: Selects color temperature of either 6500°K or 9300°K
Key Lock: The Key-Lock function is provided to prevent tempering.
To unlock, press “+”and “MENU”button together
Source Display: This function is to allow the channel title to be displayed on
the monitor
Power On CH:This function is to assign a specific input source when turn
the monitor ON None / AV / S-VIDEO / VGA
Language: English / Dutch / Spanish / Italian / German / French
Scan: Full / Under / Over
Factory Reset: Restore all settings to Factory default

14
VGA OSD - Image
Brightness: Picture brightness adjustment
Min. ~ Max.:0~100/ Default:70
Contrast: Picture contrast adjustment
Min. ~ Max.:0~100 / Default:80
Advanced:
●Auto Adjust: VGA signal auto detection and adjustment
●Image Pos: Image position adjustment include H. V.
●Phase: It adjusts the sampling phase across one pixel time. When
the phase is not adjusted properly, the picture will be unclear
Therefore this value should be carefully adjusted
Note: improper adjustment will cause image failure
●Clock: It adjusts the numbers of the pixel clock across one line time
Therefore it can affect the picture position and size
Note: improper adjustment will cause image failure

15
VGA OSD - Audio
Volume: Controls built-in speakers’ output volumes
Min. ~ Max.:0~29 / Default:20
Balance: Adjusts the volume between speakers
Min. ~ Max.:0~20 / Default:10
Mute: To disable the audio function

16
VGA OSD - Setup
Auto Source: The monitor will auto detect the input source when the signal
is not present
Color Temp: Selects color temperature of either 6500°K or 9300°K
Key Lock: The Key-Lock function is provided to prevent tempering.
To unlock, press “+”and “MENU”button together
Source Display: This function is to allow the channel title to be displayed on
the monitor
Power On CH:This function is to assign a specific input source when turn
the monitor ON None / AV / S-VIDEO / VGA
Language: English
Factory Reset: Restore all settings to Factory default

17
VGATiming
There are a total of 11 timing modes that can be saved in memory by FIFO detecting architecture.
VGA Support Timing
Mode
No.
Resolution
H Freq. (kHz)
V Freq.
(Hz)
Pixel
clock
(MHz)
17”
19”
1280*1024
75Hz
1280*1024
75Hz
VGA
104
640x480@60
31.469
59.940
25.175
ˇ
ˇ
105
640x480@72
37.861
72.809
31.500
ˇ
ˇ
106
640x480@75
37.500
75.000
31.500
ˇ
ˇ
SVGA
108
800x600@60
37.879
60.317
40.000
ˇ
ˇ
109
800x600@72
48.077
72.188
50.000
ˇ
ˇ
110
800x600@75
46.875
75.000
49.500
ˇ
ˇ
XGA
111
1024x768@60
48.363
60.004
65.000
ˇ
ˇ
112
1024x768@70
56.576
70.069
75.000
ˇ
ˇ
113
1024x768@75
60.023
75.029
78.750
ˇ
ˇ
SXGA
114
1280x1024@60
63.980
60.000
108.000
ˇ
ˇ
115
1280x1024@75
79.976
75.025
135.000
ˇ
ˇ
PC RGB Input
Power Supply
Input Voltage
100~240VAC, 50/60Hz
Output Voltage
+12V DC, 5A
Power Consumption
Power Management
On: 25W max. (Green LED)
Off: 2.5W max. (Red LED)
Environment
Input Signal
Analog RGB 0.7Vp-p
Input Impedance
75 Ohm ± 2%
Polarity
Positive, Negative
Amplitude
0 ~0.7 ± 0.05Vp
Multi-mode Supported
Horizontal Frequency: 30~80KHz
Vertical Frequency: 50~75Hz
Operation Condition
Temperature
0°C to 50°C / 32°F to 122°F
Relative Humidity
20% to 85%
Storage Condition
Temperature
-10°C to 60°C / 14°F to 140°F
Relative Humidity
5% to 85%
Applicable Timing

18
Model
17”
19”
Display Resolution
(Panel)
1280 x 1024@75Hz
1280 x 1024@75Hz
Active Area (mm)
337.920 (H) x 270.336 (V)mm
376.32(H) x 301.056 (V)mm
Pixel Pitch
0.264mm
0.294mm
LCD Profile Ratio
5:4
Display Color
16.7M colors
Brightness (Central)
250 cd/㎡Typ.
Contrast Ratio
800 : 1 typ.
1000 : 1 typ.
Viewing Angle
Left 80°/Right 80°
Up80°/Down 80°
Left 85°/Right 85°/
Up 85°/Down 85°
Response Time
5ms
Input Voltage
96-256Vac, 60Hz/50Hz
Video Input
D-SUB 15 pin x 1, Video In x 1 (BNC), S-Video In x 1
Video Output
Video loop Out x 1 (BNC)
Audio Input
Audio In x 2, PC-Audio In x 1
Speaker
1W + 1W
Power Consumption
25W
Operation Temperature
0 to 50℃(32 to 122℉)
Storage Temperature
-10 to 60℃(14 to 140℉)
(1) The brightness spec. Is from panel spec.
(2) It is not guaranteed for all the specified range.
Design and Specifications are subject to change without notice.
Specification

19
Wall mountable
User please use the correct screw type when installation.
The desktop bracket and mount type bracket can use the same screw
1.61 2
M4
M4 M4
M4 x 16L
Wall Mountable

20
17”LCD
19”LCD
Dimension
