SP-525C
SP-625C
SP-825C
SP-525W
SP-625W
SP-825W
Owner’s Manual for In-Ceiling & In-Wall Speaker Models:
200 New Highway Amityville, New York 11701 • Outside Metro NY: 1-800-645-5516
631-957-8700 • www.specotech.com
7.04

Congratulations on your purchase of Speco Technologies’
Series 25 Audio Speakers!
Speco Technologies’ has leveraged over 40 years of residential sound expertise in developing our core
in-ceiling and in-wall audio line, the Series 25 Audio Speaker Line.
Manufactured from durable and quality components, Speco Technologies’ Series 25 Audio Speaker
Line provides strong value.
Enjoy the premium performance of full-range sound in your listening environment for countless
years to come!
Specifications
Mounting Instructions:
1) Carefully select areas of the ceiling or wall where there are no obstructions, plumbing,
heating/AC apparatus or electrical wiring to mount speakers.
2) Determine and make absolutely sure whether in-ceiling or in-wall mounting brackets are needed to
support speaker’s weight. Complementing mounting brackets can be ordered through
Speco Technologies. Speco Technologies assumes no liability for mis-installed speakers.
3) Use provided cutout guideline and trace cut out area with a pencil on mounting location.
4) Carefully cut out the area of traced guideline, removing portion of sheet rock or ceiling tile to
expose mounting hole.
5) Run speaker wire through ceiling or wall to mounting location.
6) Make sure all amplifiers/receivers are turned off prior to connecting any speaker wire.
7) Remove speaker grille by turning the rear easy mounting tabs counter-clockwise to stop, and then
push them upward to pop out grille.
8) After grille is removed, connect the positive speaker wire to the red push-spring wire terminal on
the back of the speaker.
9) Connect the common wire to the black push-spring wire terminal on the back of the speaker.
10) Pay close attention to proper impedance matching when wiring multiple speakers.
11) Once the speaker is wired, test the speaker at low volume to make sure connection is strong prior
to final placement.
12) Place speaker with easy mount tabs turned clockwise inward into the mounting hole.
13) Turn screws on outer rim of speaker face clockwise which will result in the easy mount tabs
clamping down on the mounting surface from behind.
14) When speaker is secure, position/pivot tweeter in direction of listening area.
15) On In-Wall Units, set +/- 3 dB Treble Switch to personal preference.
16) Carefully replace grille on speakers.
Speco Technologies offers a limited 15-year warranty on indoor speakers.
Please consult enclosed warranty card.
SP-625C
• 6.5” In-Ceiling Speakers
• 6.5” Polypropylene Woofer
with Rubber Surround
• 1” Pivoting Silk Dome Tweeter
• 40 Watts RMS/ 80 Watts Max
• Frequency: 50Hz-20kHz
• Sensitivity: 89 dB 1w/1m
• Impedance: 8 ohms
• Dimensions:
9 1/4” Dia. x 4 1/4” Depth
• Mounting Dimensions:
7 3/4” Dia.
• 3 lbs. Each
SP-525C
• 5.25” In-Ceiling Speakers
• 5.25” Polypropylene Woofer
with Rubber Surround
• 3/4” Pivoting Silk Dome Tweeter
• 30 Watts RMS/ 60 Watts Max
• Frequency: 70Hz-20kHz
• Sensitivity: 87 dB 1w/1m
• Impedance: 8 ohms
• Dimensions:
8” Dia. x 4” Depth
• Mounting Dimensions:
6 5/8” Dia.
• 2.4 lbs. Each
SP-825C
• 8” In-Ceiling Speakers
• 8” Polypropylene Woofer
with Rubber Surround
• 1” Pivoting Silk Dome Tweeter
• 50 Watts RMS/ 100 Watts Max
• Frequency: 49Hz-20kHz
• Sensitivity: 89 dB 1w/1m
• Impedance: 8 ohms
• Dimensions:
11” Dia. x 5” Depth
• Mounting Dimensions:
9 1/2” Dia.
• 4 lbs. Each
SP-525W
• 5.25” In-Wall Speakers
• 5.25” Polypropylene Woofer
with Rubber Surround
• 1” Pivoting Silk Dome Tweeter
• +/- 3dB Treble Switch
• 30 Watts RMS/ 60 Watts Max
• Frequency: 70Hz-20kHz
• Sensitivity: 87 dB 1w/1m
• Impedance: 8 ohms
• Dimensions:
7 5/8” W x 11” H x 3” D
• Mounting Dimensions:
6 1/8” W x 9 3/8” H
• 2.7 lbs. Each
SP-625W
• 6.5” In-Wall Speakers
• 6.5” Polypropylene Woofer
with Rubber Surround
• 1” Pivoting Silk Dome Tweeter
• +/- 3dB Treble Switch
• 40 Watts RMS/ 80 Watts Max
• Frequency: 68Hz-20kHz
• Sensitivity: 88 dB 1w/1m
• Impedance: 8 ohms
• Dimensions:
8 3/4” W x 12 1/4” H x 3 1/2” D
• Mounting Dimensions:
7 1/2” W x 11” H
• 3.4 lbs. Each
SP-825W
• 8” In-Wall Speakers
• 8” Polypropylene Woofer
with Rubber Surround
• 1” Pivoting Silk Dome Tweeter
• +/- 3dB Treble Switch
• 50 Watts RMS/ 120 Watts Max
• Frequency: 51Hz-20kHz
• Sensitivity: 88 dB 1w/1m
• Impedance: 8 ohms
• Dimensions:
10 3/4” W x 14 1/2” H x 3 5/8” D
• Mounting Dimensions:
8 3/4” W x 12 3/4” H
• 3.7 lbs. Each
