Spector&Co T1029 User manual

WARNING
Please read and follow all of the instructions & safety precautions detailed below prior to using this
product. Failure to do so may result in serious personal injury and / or property damage.
Read all the instructions before using the product.
Power bank main unit contains an internal lithium polymer battery. Upon initial use or after a
prolonged storage period, fully charge it once. The unit’s full performance is achieved only after 2 or 3
completed charge and discharge cycles.
Power banks are not allowed in checked luggage on commercial airline flights. Handle with care and
dispose of in accordance to local regulations. Carry-on only.
To reduce the risk of injury, close supervision is necessary when the product is used near children.
Do not put fingers or hands into the ports of product.
Do not expose power bank to rain, snow, water or liquids.
Use of a power supply or charger not recommended or sold with power bank manufacturer may result
in a risk of fire or injury to persons.
Do not use the power bank in excess of its output rating. Overload outputs above rating may result in
a risk of fire or injury to persons.
Do not use the power bank that is damaged or modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk of injury.
Do not disassemble the power bank. Bring unit to a qualified service person when service or repair is
required. Incorrect reassembly may result in a risk of fire or injury to persons.
Do not expose a power pack to fire or excessive temperature. Exposure to fire or temperature above
100°C may cause explosion. The temperature of 100°C is equivalent to the temperature of 212°F.
Have servicing performed by a qualified repair person using only identical replacement parts. This will
ensure that the safety of the product is maintained.
Do not charge an electronic device while the power bank unit is being charged.
Disconnect charging cable from the power bank when not in use
Wireless charging is most efficient when smartphone is placed directly over the QI certified wireless
charging dock
It is recommended to remove smartphone from cases with credit card holders as wireless charging
may demagnetize credit cards
It is recommended to remove smartphone from heavy & thick cases, or from multi-functional cases
(ex: credit card holder cases or cases with magnetic feature) when recharging your device as these
may disrupt wireless charging capability
T1029 USER MANUAL
The T1029 is a UL 2056/UL2738 Certified 10,000 mAh power bank with QI Certified wireless charging
capability. Please see below product specifications & user guide.

T1029 Specifications
1. Item No.: T1029
2. Model No.: SP0381
3. Battery Type: UL Certified Lithium Polymer battery
4. Battery Duration/Lifespan: 300 times
5. Battery/Cell Capacity: DC 3.7V / 10,000 mAh; 37Wh
6. Product Capacity (USB): DC 5V / 5,600 mAh; 28Wh
7. Product Capacity (Wireless): DC 5V/4,600 mAh; 23Wh
8. Power Input (Micro-USB): DC 5V/1.8A
9. Power Output (wireless): DC 5V/1A
10. Power Output (USB): DC 5V/1A & 2.1A
11. Maximum Current Input: DC 5V/2.4A
12. Operating temperature: 0~45˚C for Charging
0~45˚C for Discharging
13. Product Size: 3” x 6 1/8” x 5/8”
14. Net Weight: 264g
15. Power bank Charge Time (from 0-100%): up to 8 hours
16. Accessories included in the box:
1 T1029 power bank
1 Micro-USB/USB re-charging cable
1 User Manual
17. Product Name: Super Titan Power Bank
18. Built-in Overheating Protection: The integrated temperature sensor of this product automatically stops
charging an electronic device when temperature reaches over 70°C in case of unexpected circuit
shortage or malfunction.
T1029 Product Map
No
Description
1
Micro-USB input port
2
USB output port (DC 5V/1A)
3
USB output port (DC 5V/2.1A)
4
ON/OFF Power Button
5
1 LED indicator (wireless charging indicator)

T1029 Operation
1) ON: Press Power Button once
2) OFF: Press Power Button twice
NOTE: The T1029 will automatically power OFF when inactive for approx. 60 seconds.
To Recharge T1029
1) Insert the micro-USB output of the charging cable into the T1029 & connect USB output to a power
supply (wall adapter with DC 5V output –not included). Press Power Button once.
2) Flashing blue LED will appear while charging. Once the T1029 is 100% fully re-charged, the blue
LED will remain solid.
NOTE: Light up logo will remain lit while re-charging the T1029.
To wirelessly charge an electronic device using the T1029
** Make sure your device has integrated QI Certified wireless charging capability or is equipped with
wireless charging adapter (NOTE: some electronic devices with integrated wireless capability may
require users to manually enable wireless charging in the settings of their electronic devices)
1) Center your electronic device on top of QI Certified wireless charging silicone dock (see # 7 of
Product Map above) & power ON the T1029. Solid green & blue LED indicates the T1029 is
wirelessly charging your electronic device (NOTE: the solid green & blue LED will be lit while
wirelessly charging your device & will remain lit once your device is fully charged).
2) To stop charging, press Power Button twice & remove your electronic device from charging dock.
To charge electronic devices using the T1029 with charging cable
1) Insert the following cable into the T1029 USB output:
a. To chargeAndroid devices: use the micro-USB/USB cable included with the T1029.
b. To charge IOS devices: use the certified charging cable accessory that came with your smart
phone/electronic device.
2) Turn the T1029 power bank ON.
3) Solid blue LED will be lit while your device is being charged & will automatically power OFF once your
device is 100% fully charged
4) To stop charging, press Power Button twice & disconnect the charging cable
NOTES:
Light up logo will remain lit while charging electronic devices. Press Power Button twice to power
OFF light-up & charging functions.
6
4 LED battery status indicator
7
QI Certified wireless charging silicone dock
8
Light up logo position

To verify remaining battery percentage of T1029 press power button
4 blue LED (from left to right) indicates 100 –75% battery power remaining
3 blue LED (from left to right) indicates 75 –50% battery power remaining
2 blue LED (from left to right) indicates 50 –25% battery power remaining
1 blue LED (from left to right) indicates 25 –<0 % battery power remaining
ITE: Accessories Lithium Polymer battery
CAUTION:
Risk of Fire and Burns, don’t open, crush, disassemble and dispose of in fire. Accessible surfaces held or
touched for short periods only. Don’t heat above 50 °C or Incinerate. Follow Manufacturer’s Instructions
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Warning:
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

AVERTISSEMENT
S'il vous plaît lire et suivre toutes les instructions et consignes de sécurité indiquées ci-dessous avant
d'utiliser ce produit. De ne pas prendre ces précautions pourrait entraîner des blessures graves et/ou des
dommages matériels.
Précautions de sécurité
Veuillez lire les instructions avant d’utiliser le produit.
Le chargeur contient une batterie interne au lithium polymère. Lors de la première utilisation ou après
un longue période d’inactivité effectuer un chargement complet. Le rendement maximum du chargeur
ne s’obtient qu’après 2 ou 3 cycles complets de charge et décharge.
Les chargeurs ne sont pas permis aux points d’enregistrement de bagages de vols commerciaux.
Manipuler avec soin et suivre les règlements correspondants. Bagage cabine seulement.
Pour réduire le risque de blessures, superviser de près en présence d’enfants.
Ne pas mettre ni doigts ni mains dans les ports du produit.
Ne pas exposer le chargeur à la pluie, la neige ou à des liquides.
Utiliser une source d’énergie ou un chargeur non recommandé pourrait entraîner des risques
d’incendie ou de blessures.
Ne pas utiliser le chargeur à une puissance supérieure à la puissance de sortie maximale. Une
surcharge de sortie pourrait entraîner des risques d’incendie ou de blessures.
Ne pas utiliser un chargeur modifié ou endommagé. Des batteries endommagées ou modifiées
pourraient entraîner des conséquences imprévisibles telles qu’incendies, explosions et blessures.
Ne pas démonter le chargeur. N’utiliser que le service de personnes qualifiées lors de réparations. Un
assemblage fautif pourrait entraîner des risques d’incendie ou de blessures.
Ne pas exposer le chargeur ni au feu ni à des températures excessives. Le feu et les températures
en-dessus de 100ºC ou 212ºF pourraient causer des explosions.
S’assurer que le service d’entretien ou de réparation n’est effectué que par du personnel qualifié et
que seulement des pièces de rechange identiques sont utilisées. Cela pour assurer la sécurité du
produit.
Ne pas charger un dispositif électronique lors du chargement du chargeur.
Débrancher le câble de chargement du chargeur lorsqu’il n’est pas utilisé
Le chargement sans fil est plus efficace lorsque le cellulaire est placé directement sur support à
ventouse
Il est conseillé de retirer le cellulaire de tout étui portant des cartes de crédit car le chargement QI
certifié sans fil peut démagnétiser les cartes de crédit
Il est conseillé de retirer le cellulaire de tout étui lourd ou épais, ou étui avec des composants
métalliques ou magnétiques, lors d’une recharge car ceux-ci pourraient perturber les capteurs
responsables du chargement sans fil
Manuel de l’utilisateur du T1029
