Spectra CaraCups User manual

CaraCups
User Manual
Breast Pump Accessory

Please read this user manual before using CaraCups
for the first time. This is a single user accessory and therefore
should not be used by more than one individual. Sharing
CaraCups among multiple users may present a health risk.
Spectra CaraCups User Manual
wearable milk collection inserts

1
2
2
2
3
3
3
4
5
6
7
8
8
• Please read this user manual before using CaraCups for the first time.
• CaraCups are a single user product and therefore should not be used by more than
one individual. Sharing CaraCups among multiple users may present a health risk.
• Please use and maintain in a hygienic manner, as this product comes in direct
contact with breastmilk.
CaraCups features
CaraCups components
How to clean
Usage instructions
Preparation before use
How to use
Storage and care after use
Safety precautions
CaraCups assembly instructions
Additional accessories assembly instructions
How to connect CaraCups to Breast Pump
How to wear CaraCups
CaraCups detachment and breastmilk transfer instructions
How to detach
How to transfer breastmilk
Contents

Membrane
Silicone valve
Your pumping journey just got easier!
- 1 -
• Both your hands are free to multi-task while pumping.
• An economical solution through full compatibility with
Spectra Breast Pump products.
Effective Pumping
• You can save time at home by pumping
while breastfeeding.
• You can pump in the office with your clothes
on as CaraCups fit into your bra.
• You can pump in public where there is no
personal space.
Pump whenever, wherever
CaraCups are BPA & DEHP free.
Double layer system prevents
backflow of milk into pump

- 2-
Milk collection cup
Flange
Valve connector
Silicone valve
Membrane
Backflow prevention
cap
Tube
adapter end
Tubing
Bottle connector
CaraCups components
How to clean
1. Disassemble all parts in reverse order of assembly (flange, milk collection cup,
silicone valve, backflow prevention cap, valve connector, bottle connector).
2. Wash thoroughly using baby bottle cleansing detergent in warm water. Sterilize
all parts before first use by placing flanges, valve connectors, milk cups and
bottle connectors in boiling water for 5 minutes, and silicone valves, backflow
protector caps and membranes in boiling water for 2 minutes after washing with
baby bottle cleansing detergent.
3. Keep away from abrasives and excessive heat, and handle all parts with care.
4. Store away from reach of babies and children when not in use.
5. Dry all parts completely prior to storage.
Please note: tubing does not need to be cleaned as it does not come into contact with
breastmilk. Should tubing become soiled, please wash in soapy water, rinse and hang to dry
before use.
Usage instructions
1. For hygienic purposes, wash and dry your hands completely prior to use.
2. Ensure your breasts are clean and free of any foreign substances prior to pumping.
3. Ensure all parts that come in direct contact with breastmilk are clean, sanitized
correctly, and follow the instructions in the user manual to assemble before use.
Preparations for use

- 3 -
Tube
adapter end
1. Tilting of the flange may lead to the leakage of breastmilk. Please sit up straight while
pumping to ensure the flange does not tilt.
2. It is important to find the maximum vacuum level that is comfortable for you, as
pumping at an uncomfortably high vacuum level may cause pain and hinder your
milk flow.
3. To determine your own maximum vacuum level, use the vacuum level and cycle
speed controller buttons on the breast pump to increase the intensity until pumping
feels slightly uncomfortable (not painful), then decrease the intensity slightly.
4. On average, a typical expressing session goes for 10-15 minutes, but this is just a guide
and may vary for each individual.
5. Upon completion of pumping, do not just pull away the flange in its sealed state, but
instead turn off the power first and remove the flange slowly by breaking the seal
between your breast and the flange with your finger.
1. Disassemble and wash all parts that come in contact with breastmilk immediately
after use according to the instructions in the user manual using bottle washing
detergent and appropriately shaped bottle brush and rinse under running water.
2. The general practice is to sterilize the washed parts in boiling water for 5 minutes.
3. After washing and sterilizing, ensure all parts are completely dry and store in a
container or clean space.
4. Replace any worn out or scratched consumable parts.
Storage and care after use
Safety precautions
1. Persons with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, should not use the product unless they have been given supervision
or instruction by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the product.
3. Always inspect the product components for signs of damage before each use.
4. Use only genuine original Spectra accessories and parts.
5. Wash (do not use antibacterial or abrasive cleaners/detergents) and sterilize all
product parts before each use.
6. Avoid exposure to high heat and direct sunlight.
7. Never use while pregnant, as pumping can induce labor.
8. This product is a personal care item that should be used by a single user. Use of the
product under second-hand or rental conditions carries the risk of
cross-contamination between multiple users and requires caution.
9. Some discomfort may be felt when first using a breast pump, however, if you should
continue to feel pain, or if tearing or bleeding occurs around your nipples, you should
immediately seek medical advice.
How to use
Should milk backflow during pumping, stop the pump operation immediately and remove any milk
first, then check all consumable parts for damage / connection condition. If you suspect that the
milk has backflowed into the main pump unit, stop using the pump immediately and asses the unit
before using again.

Flange
Silicone valve
.
-4-
.
• Wash your hands thoroughly and dry completely before using the product.
Before you begin pumping, make sure your breasts are clean.
• Make sure that you have correctly washed, sterilized and assembled the
pump before use.
CaraCups assembly instructions
Valve connector
Membrane Backflow
prevention cap
Membrane
Ensure that the
convex side is
facing down.
View from above
after assembly
1. Prepare the valve connector, membrane
and backflow prevention cap.
2. Assemble in the order of valve connector,
membrane and backflow prevention cap.
3. Align the flange to the assembled valve
connector so flange should be lined up to
the tubing connect hole of the valve
connector.
4. Press the flange and the assembled valve
connector together firmly with both
hands.
5. Attach the silicone valve to the valve
connector.
6. Align the milk collection cup to the
previously assembled parts and join
them.
7. Connect the tubing to the assembled
CaraCups.
8. Check that the tubing is connected
properly.

-5-
Additional accessories assembly
instructions
• CaraCups can be used in place of the existing pumping method by using
the additional accessories.
• You can use the existing Spectra wide neck bottles.
(If you don’t have Spectra wide neck bottles, they can be purchased separately)
Ensure the tubing connector
is facing rearward
Membrane
Silicone valve
Spectra wide neck bottles available
View after completed assembly

Standard pump mode
-6-
Tubing
compatible!
Spectra
breast pump
How to connect CaraCups to breast pump
Spectra CaraCups are compatible with all Spectra Baby USA
electric breast pump models.
*Spectra CaraCups are not compatible with the manual and piston type breast pumps.
CaraCups pump mode
Tube adapter end
Spectra S1 Plus
Spectra S2 Plus
Spectra 9 Plus
Spectra
Synergy Gold
Spectra breast pump

How to wear CaraCups
Correct positioning example Incorrect positioning example
-7-
* Ensure the tubing connector on the milk collection cup is pointing up when
pumping
Flange not sealed
tight onto skin
Nipple not placed in
the center
1. In order to maintain the same suction pressure
while pumping, try placing CaraCups inside a
larger bra or a bra that you normally wear and
choose one that is more comfortable.
2. Keep CaraCups in the perpendicular position
inside the bra, and avoid bras that allow
CaraCups to slip, sag down or tilt sideways
during use.
3. Check that the flanges are sealed tight
onto your skin.
5. Tilting of the flange may lead to leaking of breastmilk. Please pump sitting
upright to ensure the flange does not tilt.
6. Each milk collection cup is capable of holding 250mL of breastmilk. When the cup
gets full, turn the power off and stop pumping. To pump more than 250mL of
breastmilk, stop pumping and empty out the milk collection cup then re-start
pumping.
4. Position CaraCups over your nipple, right in the center of the flange.
Use either a sports bra or standard bra that offers
a more comfortable fit and keeps CaraCups well in
position while allowing you to move around.

How to detach
How to transfer breastmilk
-8-
CaraCups detachment and breastmilk
transfer instructions
Place CaraCups on a flat surface where breastmilk
won’t spill over.
After disassembling the lid (flange)
like above picture, carefully pour breastmilk
into a Spectra milk storage bag or bottle.
1. Turn the pump power off.
2. Carefully remove the tubing while still keeping
CaraCups on in place. Grabbing the milk
collection cup with force may create a gap
between the flange and the milk collection
cup causing the breastmilk to spill out.
Handle with Care.
3. Carefully remove CaraCups from inside the bra,
being careful not to spill the breastmilk. (flange may still be sealed onto your
breast, then hold the milk collection cup and pull it out. Grabbing CaraCups
with force when pulling the cup out may cause the breastmilk to spill out.)

MM0122-2538-IFU
Rev.009
2021.01
Spectra Baby USA
3430 Davie Road, Ste. 306
Davie, Florida 33314
Tel: [phone]
www.spectrababyusa.com
If you need help with your Spectra product, our customer support team
members are here to happily answer any questions.
Product Support
Phone: [phone]
Email: [e-mail]
Lactation Assistance
Email: [e-mail]
Breastfeeding support: Book Appointment >
