Spectra Unitronics UCR-ST-B5 User manual
1
UCR-ST-B5 Router
The Unitronics UCR-B5 enable Unitronics PLC products to communicate via mobile networks (4G).
Highlights:
1. 1 Ethernet LAN port and 1 WAN (configurable can act as LAN)
2. Wireless LAN access point or client to existing network.
3. Embedded send / receive SMS messages directly from UniStream PLCs.
4. I/O: a. 1 Digital Input
b. 1 Digital Output
Note: UniLogic SMS embedded support from Ver. 1.29 and above.
Package Content
#
Description
Quantity
Unitronics P/N
1
UCR-B5 Router
1
2
Power cable, 2m, 4 pins terminal block
1
UCR-ACC-01
3
LTE antenna (swivel, SMA male)
2
UCR-ACC-07
4
WiFi antenna (swivel, RP-SMA male)
1
UCR-ACC-08
5
Ethernet cable (1.5 m)
1
6
Quick Start Guide
1
SIM Card
SIM Card Insertion
1
Push the SIM holder button with the SIM needle
2
Pull out the SIM holder
3
Insert your SIM card into the SIM holder
4
Slide the SIM holder back into the router
UCR-ST-B8
Unitronics
Front View
#
Description
1
Power LED
2
Power socket
3
Network type LED
4
SIM holder
5
Mobile signal strength indication LEDs
6
Ethernet ports
7
LAN LED
8
WAN LED
Back View
#
Description
1
WiFi antenna connector
2
Reset button
3
Mobile antenna connectors
LED: Status Indication
Power LED
ACTION
DESCRIPTION
LED turned ON
Router is powered up
LED turned OFF
Router is not powered up
UCR-ST-B8
Router: Teltonika RUT955
UCR-ST-B5_INSTAL_GUIDE
3
Ethernet Port LEDs
ACTION
DESCRIPTION
LED turned ON
Operating as a 10/100 Mbps connection
LED turned OFF
No link established
LED blinking
Connection established and there is activity on this port (data
being transferred)
LEDs light up and turn OFF in
sequence from WAN port to LAN1
port
The router is in the bootloader menu state*
* The bootloader menu is a special router state from which certain upgrades can be performed
Signal Strength LEDs
Each lit up LED represents a different value of the router's current signal strength in RSSI:
NO. OF LIT UP LEDs
SIGNAL STRENGTH VALUE
0
≤ -111 dBm
1
-110 dBm to -97 dBm
2
-96 dBm to -82 dBm
3
-81 dBm to -67 dBm
4
-66 dBm to -52 dBm
5
≥ -51 dBm
All 5 LEDs are lit up after pressing and holding the reset button to initiate a factory reset.
Powering Options
Power Connector
4 pin power connector:
Pin
Description
Direction
1
Power
Red
2
Ground
Black
3
Digital Input
Green
4
Digital Output
White
Passive Power Over Ethernet
The device may also be powered by an Ethernet
cable via the LAN port:
(Do not use in other ports!)
UCR-ST-B8
4
Input / Output Specification and Pinout
Associated
Pins
Description
3
Digital Input 1, 0-40VDC (Low 0-5V, High 8-40V)
4
Digital Output 1, 0-30VDC, 300mA (sink)
Mounting
Use the Din Rail bracket to mount the device.
UCR-ST-B8
Router: Teltonika RUT955
UCR-ST-B5_INSTAL_GUIDE
5
Technical Specifications
Power voltage range
9 –30 VDC, 4 pin DC connector
Power consumption
< 5W
Power over Ethernet
(passive)
Passive PoE over spare pairs. Possibility to power up through LAN
port, not compatible with IEEE802.3af and 802.3at standards
Status LEDs
2 x connection type status
5 x connection strength
2 x LAN status
1 x Power
SIM card
1 x external SIM holders
Ethernet
2 x 10/100 Ethernet ports:
- 1 x WAN (configurable as LAN)
- 1 x LAN
Inputs
1 x Digital Input
Outputs
1 x Digital Open Collector Output
Connectors
1 x 4 pin DC
2 x Ethernet
2 x Mobile SMA
1 x WiFi RP-SMA
Mobile
4G (LTE) –Cat 4 DL up to 150 Mbps, UL up to 50Mbps;
DC-HSPA+; UMTS; TD-SCDMA; EDGE; GPRS
Housing
Aluminum housing, plastic panels
Dimensions
83 mm x 74 mm x 25 mm (3.27”x2.91”x0.98”)
Weight
125 g (4.40 oz)
Storage and Operational
temperature
-40 °C to 75 °C (-40°F to 167°F)
