SpectraLink TGA116 Manual

Telephone Switch Interface Matrix
NetLink Wireless Telephones
Link Wireless Telephone System
Part Number: 72-0070-10
Issue W

SpectraLink Corporation Telephone Switch Interface Matrix
Part Number: 72-0070-10-W.doc Page 2
Notice
SpectraLink Corporation has prepared this document for use by SpectraLink personnel and customers. The
drawings and specifications contained herein are the property of SpectraLink and shall be neither reproduced in
whole or in part without the prior written approval of SpectraLink, nor be implied to grant any license to make,
use, or sell equipment manufactured in accordance herewith.
SpectraLink reserves the right to make changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases consult SpectraLink to determine whether
any such changes have been made.
The terms and conditions governing the sale of SpectraLink hardware products and the licensing of
SpectraLink software consist solely of those set forth in the written contracts between SpectraLink and its
customers. No representation or other affirmation of fact contained in this document including but not limited
to statements regarding capacity, response-time performance, suitability for use, or performance of products
described herein shall be deemed to be a warranty by SpectraLink for any purpose, or give rise to any liability of
SpectraLink whatsoever.
In no event shall SpectraLink be liable for any incidental, indirect, special, or consequential damages
whatsoever (including but not limited to lost profits) arising out of or related to this document, or the
information contained in it, even if SpectraLink has been advised, knew, or should have known of the
possibility of such damages.
Trademark Information
SpectraLink®
LinkPlus
Link
NetLink
SVP
Are trademarks and registered trademarks of SpectraLink Corporation.
The SpectraLink logo is a registered trademark in the United States of America and in other countries.
All other trademarks used herein are the property of their respective owners.
SpectraLink Corporation
5755 Central Avenue
Boulder, CO 80301
303 440 5330 or
800 676 5465
www.spectralink.com
Copyright © 1998 to 2007 SpectraLink Corporation. All rights reserved
Information in this document is subject to change without notice and does not represent a commitment on the
part of SpectraLink Corporation. The software described in this document is furnished under a license and
may only be used pursuant to the terms of (1) SpectraLink's software license agreement available at
http://www.spectralink.com/softwareUpdates OR (2) the terms and conditions previously agreed to in writing
between the user and SpectraLink Corporation OR (3) the terms and conditions previously agreed to in writing
between the user and an authorized SpectraLink reseller (each, the “Agreement”). The software may be used
only in accordance with the terms of the Agreement. No part of this manual, or the software described herein,
may be reproduced or transmitted in any form or by any means, electronic or mechanical, including
photocopying and recording, for any purpose except for the sole intent to operate the product or without the
express written permission of SpectraLink Corporation.

SpectraLink Corporation Telephone Switch Interface Matrix
Part Number: 72-0070-10-W.doc Page 3
Telephone Switch Interfaces
Switch
Vendor
Switch
Supported
Link 150
M3 Part
Numbers
Link
3000 Part
Numbers
NetLink
Part
Numbers
Telephone Set Emulated
Port Card
Required
Software
Release
Required
Any
Any PBX, some
KSUs SCA5xx CPA316 TGA116
Analog (aka ‘2500 type’,
‘Industry Standard
Telephone’ or ‘Tip-Ring’
set)
Analog port card
(some KSUs
require analog
telephone
adapters or
interface units)
N/A
Definity G31
(2-wire) SCD5xx, CPD316 TGD116
TN2181, TN2224,
TN2224B,
TN2224CP,
TN2214B,
TN2214CP
G3V2 or
later
Definity G1, G2,
G3 (4-wire) SCF5xx CPF316 TGF116
8410D Digital Voice
Terminal TN754 v11 or
higher,
TN754B v11 or
higher
R32or later
Merlin Legend3
Merlin Magix
(4-wire)
SCF5xx CPF316 TGF116 MLX-16DP
408 GS/LS MLX
Module or 008
MLX Module
Avaya
Avaya
S8700/S8500
S8300/S8100
with G700/G600
Media Gateway
Interface
SCD5xx CPD316 TGD116 8410D Digital Voice
Terminal
MM712/MM717
DCP Media
Module
Any
DX, DXP DXDST-8,
DXDST-16 Any
FX, FX II FXLDS-16,
FXSDS-16
(14A or
later)
Comdial
DSU II
SCD5xx CPD316 TGD116 8012S Impact
Speakerphone
DXDST-8,
DXDST-16 Any
Executone IDS SCB5xx CPB316 TGB116 Model 32 LSI II – 15750 or
15740-1 Any
Fujitsu
F9600 SCD5xx CPD316 TGD116 DT14DS
B16DLA,
B16DLC,
B16DLE
Any
Inter-Tel Axxess, Axxent Standard Digital Keyset 4.4 or later
Eclipse SCD5xx CPD316 TGD116 Associate
Digital Keyset
Card
(DKSC, DKSC-16) 5.2xx or later
IT 5000 (DEI)4DEM 1.1 or later
SX-50, SX-200
Digital / DNIC
Line Card or
Module
SX-2000 DNIC Line Card
Mitel
3300 ICP
SCX516 CPM316 TGX116 Superset 420
DNIC Line Card
Any
1 Includes Definity One, BCS, ECS, Prologix, and Guestworks platforms
2Releases earlier than R3 require the port be programmed as a 74xx type set. Menu functions will not be
supported
3Merlin II may be easily upgraded to Merlin Legend. The customer should contact his or her telecom
supplier
4Digital Expansion Interface

SpectraLink Corporation Telephone Switch Interface Matrix
Part Number: 72-0070-10-W.doc Page 4
Telephone Switch Interfaces (cont’d)
Switch
Vendor
Switch
Supported
Link 150
M3 Part
Numbers
Link
3000 Part
Numbers
NetLink
Part
Numbers
Telephone Set Emulated
Port Card
Required
Software
Release
Required
NEAX 2000 4DLCA,
4DLCD, 4DLCQ
1600 or
later
NEAX 2000 IVS 8DLCP D1-4.01
NEC
NEAX 2400
SCD5xx CPD316 TGD116 Dterm Series III or E
(ETJ-16DC-2)
16ELCH, 16ELCJ 5200 or
later
Meridian 1
(incl. Remote
Shelf)
NT8D02EA,
NT8D02EB,
NT8D02GA,
NT8D02HA
X11 rel. 145
or later
Option 11C Mini NTDK16 Version 25.1
or later
SL-1 QPC578
SL-100
with IPE6shelf
SCN5xx6CPN3166
TGN116 6
M2616 Modular
Telephone
w/ display
NT8D02EA,
NT8D02EB,
NT8D02GA,
NT8D02HA
X11 rel. 14
or later
Norstar Modular
ICS DR1-DR5
Nortel
Norstar Compact
ICS 616, 824
(only one type)
Any
Norstar BCM
(Digital)
SCD5xx CPD316 TGD116 M7310 Telephone
DSM 16, DSM 32 Any
Panasonic DBS & DBS 576 SCP5xx CPP316 TGP116 VB-44223 DEC/8 Any
8000 CBX;
9000 CBX
Rolm Phone
Interface (RPI) Any
9751 CBX
Models
10 – 70
RPI 9005 or
earlier
Siemens
/Rolm
9751 CBX
Models 30 & 80,
9200 CBX,
HiCom 300E
SCD5xx CPD316 TGD116 RolmPhone 400
SLMR, SLMR-16,
SLMR3 9006
Hicom 150/
HiPath 3000 optiset E Basic SLMO24, SLU8 Any
Hicom 300/
HiPath 4000
SCH5168
CPH3167
LKO:
TGH1167optiset E Standard SLMO Any
Toshiba Strata DK280,
DK24, DK96,
DK424,
CTX 100, CTX 670
SCD5xx CPD316 TGD116 2020SD Digital Telephone
PDKU, PDKU2,
PDKU2A,
BDKU/S, ADKU,
BWDKU9
Any
5 Earliest version of software that supports the emulated telephone set.
6 The Nortel Meridian interefaces SCN5xx, CPN316, and TGN116 also include the digital interface options
available on SCD5xx, CPD316, and TGD116 respectively.
7 Intelligent Peripheral Expansion shelf must be installed to operate an M2616 port on an SL-100.
8SCH516, CPH316 and LKO:TGH116 are available through Siemens and Siemens authorized distributors.
The wireless telephone product names for the NetLink system are the Siemens optiPoint W1/WL1
professional telephones. SCH516 and CPH316 also include the same digital interface options available on
SCD516, CPD316, and TGD116 respectively.
9 Toshiba BWDKU card is supported in version 53.028 or higher of the Link 150 MCU and in version 43.085
and higher on the Link 3000 MCU.
Toshiba BWDKU card is supported on the NetLink Telephony Gateway version .082 and higher.

SpectraLink Corporation Telephone Switch Interface Matrix
Part Number: 72-0070-10-W.doc Page 5
IP Telephony Interfaces
Switch Vendor Switch Supported Wireless Telephone
Product Numbers Telephone Set Emulated
Software Release Required
Alcatel1OmniPCX OXE Mobile IP Touch 300, 600 N/A 603.3L and above
Avaya2 Communication
Manager
3616, 3620, 3626, 3641,
3645 IP Wireless Telephone
3.x, 4.0
IP Office 3616, 3620, 3626, IP
Wireless Telephone
4612 IP Telephone
3.0, 3.1
CallManager 3.x, 4.1
CallManager Express PTE110, PTX110 IP Phone 7960 3.2
Cisco Systems
CallManager PTB7xx, PTB8xx IP Phone 12SP+ 3.1, 3.2
Digium Asterisk NetLink e340/h340/i640 N/A 1.2x
Inter-Tel3 Axxess 8.2 or higher
IT 5000
Model 8664, 8665, 8668
Wireless IP Phone Model 8660
1.1 or later4
SpectraLink NetLink 5.1, 6.0 and 7.0
3300 ICP
(any controller)5PTE140, PTN140, PTX140 5220 IP Phone 4.1.9.4 to 5.0
Mitel Networks
SX-200 ICP
(any controller)4PTE140, PTN140, PTX140 SpectraLink NetLink 2.1 and above
IPS 2000 MH110, MH120, MH140h 16LD RLS16
NEC IPS 2400 MH110, MH120, MH140h 16LD RLS8 H1 7.98
Nortel6Communications
Server (CS)1000
WLAN Handset 2210,
2211, 2212,
Succession 3.0
CS1000 V 4.x, 5.0
Communications
Server (CS)1000 WLAN Handset 6120, 6140
CS1000 V 4.5, 5.0
Communications
Server (CS)2000 SN09
Communications
Server (CS)2100 SE09
BCM 200/400
SRG 200/400
SRG50
WLAN Handset 2210,
2211, 2212
i2004 Internet Telephone
BCM 200/400 3.6 and 3.7
SRG 200/400 1.0
SRG 50 V1.0
1Available only through Alcatel and Alcatel authorized distributors.
2Available only through Avaya and Avaya authorized distributors.
3Available only through Inter-Tel and Inter-Tel authorized distributors.
4Version 1.2 or higher requires a Category C license per phone.
5Supported Mitel platforms: 3300 LX, 3300 MX, 3300 CX, 3300 CXi, SX-200 ICP, SX-200 MX, Sprint i4.
6Communications Server 1000 is formerly known as Succession 1000. Nortel Networks products are
available only through Nortel Networks and Nortel Networks authorized distributors. Not all call servers
and handsets are compatible. Please check Nortel.com to determine compatibility and the appropriate
version of handset software for each call server and release listed above.
The information provided in these tables is believed to be current and correct but is not guaranteed.
Verification with an appropriate demo kit is recommended.
