Spectrex SharpEye 40/40 Duct Mount User manual

Installation Manual
00925-0600-4975, Rev AC
May 2022
Spectrex SharpEye™ 40/40 Duct Mount

Legal notice
The device described in this document is the property of Emerson.
No part of the hardware, software, or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or by any means, without prior written permission from
Emerson.
While great efforts have been made to ensure the accuracy and clarity of this document, Emerson assumes no liability resulting
from any omissions in this document or from misuse of the information obtained herein. The information in this document has
been carefully checked and is believed to be entirely reliable with all of the necessary information included. Emerson reserves the
right to make changes to any products described herein to improve reliability, function, or design and reserves the right to revise
this document and make changes from time to time in content hereof with no obligation to notify any persons of revisions or
changes. Emerson does not assume any liability arising out of the application or any use of any product or circuit described herein;
neither does it convey license under its patent rights or the rights of others.
2

Warranty
1. Limited Warranty . Subject to the limitations contained in Section 2 (Limitation of Remedy and Liability) herein, Seller
warrants that (a) the licensed firmware embodied in the Goods will execute the programming instructions provided by
Seller; (b) that the Goods manufactured by Seller will be free from defects in materials or workmanship under normal use
and care; and (c) Services will be performed by trained personnel using proper equipment and instrumentation for the
particular Service provided. The foregoing warranties will apply until the expiration of the applicable warranty period.
Sensors and detectors are warranted against defective parts and workmanship for 24 months from the date of purchase
and other electronic assemblies for 36 months from the date of purchase. Products purchased by Seller from a third party
for resale to Buyer (Resale Products) shall carry only the warranty extended by the original manufacturer. Buyer agrees
that Seller has no liability for Resale Products beyond making a reasonable commercial effort to arrange for procurement
and shipping of the Resale Products. If Buyer discovers any warranty defects and notifies Seller thereof in writing during
the applicable warranty period, Seller shall, at its option, (i) correct any errors that are found by Seller in the firmware or
Services; (ii) repair or replace FOB point of manufacture that portion of the Goods found by Seller to be defective; or (iii)
refund the purchase price of the defective portion of the Goods/Services. All replacements or repairs necessitated by
inadequate maintenance; normal wear and usage; unsuitable power sources or environmental conditions; accident;
misuse; improper installation; modification; repair; use of unauthorized replacement parts; storage or handling; or any
other cause not the fault of Seller, are not covered by this limited warranty and shall be replaced or repaired at Buyer's sole
expense, and Seller shall not be obligated to pay any costs or charges incurred by Buyer or any other party except as may
be agreed upon in writing in advance by Seller. All costs of dismantling, reinstallation, freight, and the time and expenses
of Seller's personnel and representatives for site travel and diagnosis under this limited warranty clause shall be borne by
Buyer unless accepted in writing by Seller. Goods repaired and parts replaced by Seller during the warranty period shall be
in warranty for the remainder of the original warranty period or 90 days, whichever is longer. This limited warranty is the
only warranty made by Seller and can be amended only in a writing signed by an authorized representative of Seller. The
limited warranty herein ceases to be effective if Buyer fails to operate and use the Goods sold hereunder in a safe and
reasonable manner and in accordance with any written instructions from the manufacturers. THE WARRANTIES AND
REMEDIES SET FORTH ABOVE ARE EXCLUSIVE. THERE ARE NO REPRESENTATIONS OR WARRANTIES OF ANY KIND,
EXPRESSED OR IMPLIED, AS TO MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, OR ANY OTHER MATTER WITH
RESPECT TO ANY OF THE GOODS OR SERVICES.
2. Limitation of Remedy and Liability SELLER SHALL NOT BE LIABLE FOR DAMAGES CAUSED BY DELAY IN PERFORMANCE. THE
REMEDIES OF BUYER SET FORTH IN THE AGREEMENT ARE EXCLUSIVE. IN NO EVENT, REGARDLESS OF THE FORM OF THE
CLAIM OR CAUSE OF ACTION (WHETHER BASED IN CONTRACT INFRINGEMENT, NEGLIGENCE, STRICT LIABILITY, OTHER
TORT, OR OTHERWISE), SHALL SELLER'S LIABILITY TO BUYER AND/OR BUYER'S CUSTOMERS EXCEED THE PRICE TO BUYER
OF THE SPECIFIC GOODS MANUFACTURED OR SERVICES PROVIDED BY SELLER GIVING RISE TO THE CLAIM OR CAUSE OF
ACTION. BUYER AGREES THAT IN NO EVENT SHALL SELLER'S LIABILITY TO BUYER AND/OR BUYER'S CUSTOMERS EXTEND
TO INCLUDE INCIDENTAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES. THE TERM "CONSEQUENTIAL DAMAGES" SHALL
INCLUDE, BUT NOT BE LIMITED TO, LOSS OF ANTICIPATED PROFITS, REVENUE, OR USE AND COSTS INCURRED INCLUDING
WITHOUT LIMITATION FOR CAPITAL, FUEL AND POWER, AND CLAIMS OF BUYER'S CUSTOMERS.
3

4

Contents
Chapter 1 Description................................................................................................................ 7
Chapter 2 Install the Duct Mount................................................................................................9
Chapter 3 Technical support.....................................................................................................15
Chapter 4 Dimensional Drawing...............................................................................................17
Installation Manual Contents
00925-0600-4975 May 2022
SharpEye 40/40 5

Contents Installation Manual
May 2022 00925-0600-4975
6 Spectrex.net

1 Description
This document describes the installation instructions for the Duct Mount P/N 877670.
The Duct Mount is suitable for use with the SharpEye 40/40C and 40/40D models.
The Duct Mount allows flame detection in areas where high temperatures exist or in cases
where the detector cannot be installed inside the area. It consists of a special duct mount
arrangement with a specific optical window to allow installation in high temperature duct
applications.
The Duct Mount will limit the cone of vision of the installed detector to 70 ° horizontal and
70 ° vertical.
Ensure that the temperature of the Duct Mount installation is between : -67 and 392 °F
(-55 and 200 °C).
Installation Manual Description
00925-0600-4975 May 2022
SharpEye 40/40 7

Description Installation Manual
May 2022 00925-0600-4975
8 Spectrex.net

2 Install the Duct Mount
Procedure
1. Prepare the surface.
a) Check the air duct installation surface stability. Install the Duct Mount as
close as possible to a riding girder connection in order to ensure proper
support to the Duct Mount and the Flame Detector.
Also, ensure that the surface is stable and free of vibrations.
b) Locate the best installation surface for the detector, so that the detector will
have a full cone of vision to the protected area.
c) Drill the duct hole and the screw holes carefully.
Figure 2-1: Drilling Layout Dimensions for Duct Installation
A. Screw holes
B. Duct hole
C. Duct installation surface
2. Disassemble the Duct Mount.
a) Unscrew the nuts and washers.
Installation Manual Install the Duct Mount
00925-0600-4975 May 2022
SharpEye 40/40 9

Figure 2-2: Disassembling the Duct Mount
A. Four spring washers M6
B. Four plate nuts M6
C. Four spring washers M6
D. Four base nuts M6
b) Detach the internal plate and base plate.
Install the Duct Mount Installation Manual
May 2022 00925-0600-4975
10 Spectrex.net

Figure 2-3: Duct Mount Parts
A. Two internal plates
B. Base plate
C. Four spring washers M6
D. Four plate nuts M6
E. Duct mount base
F. Four spring washers M6
G. Four base nuts
3. Mount the Duct Mount.
a) Insert the first internal plate through the air duct hole.
b) Hold the first internal plate by hand and press the base plate to the
installation surface against the internal plate.
At the base plate, there is a gasket, which is glued.
c) Insert the internal plate screws into the gasket holes to prevent the internal
plate from falling.
d) Secure the base plate to the installation surface using four nuts and washers.
e) Remove your hand and repeat for the second internal plate.
f) Attach the duct mount base to the base plate and secure it with washers and
nuts.
Installation Manual Install the Duct Mount
00925-0600-4975 May 2022
SharpEye 40/40 11

Figure 2-4: Duct Mount Parts Before Final Assembly
A. Two internal plates
B. Screw holes
C. Air duct hole
D. Duct installation surface
E. Base plate
F. Four spring washers M6
G. Four plate nuts M6
H. Duct mount base
I. Four spring washers M6
J. Four base nuts M6
The base plate and duct mount base are now connected.
Install the Duct Mount Installation Manual
May 2022 00925-0600-4975
12 Spectrex.net

Figure 2-5: Duct Mount Parts After Assembly
4. Mount the detector. Insert the detector at the pin and secure it using a screw.
Note
The screw is already mounted on the detector. Remove it and reinstall it facing the
other direction.
Figure 2-6: Detector Mounted on Duct Mount
A. Detector
B. Pin
C. Screw
Installation Manual Install the Duct Mount
00925-0600-4975 May 2022
SharpEye 40/40 13

Install the Duct Mount Installation Manual
May 2022 00925-0600-4975
14 Spectrex.net

3 Technical support
For all technical assistance or support contact:
Emerson Automation Solutions
6021 Innovation Boulevard
Shakopee, MN 55379-9795
USA
T [phone]
F [phone]
[email protected]
Installation Manual Technical support
00925-0600-4975 May 2022
SharpEye 40/40 15

Technical support Installation Manual
May 2022 00925-0600-4975
16 Spectrex.net

4 Dimensional Drawing
Installation Manual Dimensional Drawing
00925-0600-4975 May 2022
SharpEye 40/40 17

00925-0600-4975
Rev. AC
2022
