Spectrum BB24V1U User manual

BB24V1U Battery
User Manual

1
BB24V1U UPS is designed to provide a local power solution for cable
telephony, wireless local loop (WLL) and fiber to the home (FTTH)
broadband equipment.
IMPORTANT SAFETY WARNINGS
This manual has important instructions on installing and operating this device.
Before you attempt to unpack, install or operate this device, thoroughly read this manual.
CAUTION
•Even when the AC input power is disconnected, the battery can still energize hazardous live parts inside of it.
•To reduce the risk of fire or electric shock, install the battery in a temperature- and humidity-controlled indoor area, free from
conductive contaminants. To find the acceptable temperature and humidity ranges, please refer to the device specifications.
•To reduce the risk of electric shock, keep the cover on. There are no user-serviceable parts inside the unit, including the
battery. Please contact us or our dealer for service.
•When replacing batteries, the replacement should have the same rating: Listed/Certified Valve Regulated Lead Acid
Battery, 12V, max. 10Ah.
•Before replacing batteries, remove conductive jewelry, such as chains, watches and rings, and use tools with insulated
handles. High energy passed through conductive materials can cause severe burns.
•Don’t dispose of batteries in a fire. Batteries may explode if improperly disposed. Recycle batteries in accordance with
local regulations.
•Don’t open or mutilate batteries. Battery material is harmful to the skin and eyes. It may be toxic.
•The UPS battery capacity can vary depending on storage time and temperature.
•The UPS battery is charging when it’s connected to utility power. The battery is charging during its first 24 hours of
normal operation. Don’t expect full battery capacity during this initial charging period.

2
6
5
4
3
1
2
Overview
Installation
Desktop:
1Using a screwdriver, remove the screw on the bottom of BB24V1U.
2Slide o the battery cover and connect the battery wires.
3Replace the battery cover and tighten the screw.
4Plug the AC power cable into an electrical outlet.
5Install the USC cable (TRS jack) and DC power cable (DC jack).
Wall Mount:
1LED indicator
2 Button
3AC power cable connector
4DC power cable connector
5UART serial communications
(USC) connector
6 Battery cover
Number Description
Mounting S urface
Max.5/16”
1’’~1.5”
1/8’’
Max.3/16”
STEP 1:
Connect the AC cable to an
electrical outlet.
STEP 3:
Use the wall mount template and a
screwdriver to position screws on a
wall. Hang BB24V1U on the screws.
STEP 2:
Connect the USC cable and DC
power cable between BB24V1U
and eMTA devices.
Recommended Screw Dimension

3
Battery Replacement (Technician Reference Only)
As long as utility power is on, you can leave BB24V1U and other connected equipment powered on while replacing a battery.
Button-Alarm Silence
When BB24V1U is operating under battery mode, or its battery power is low, the audible alarm is turned on.
1 Press and hold the button for 5 seconds. BB24V1U will beep once to confirm that audible alarms have been disabled permanently.
2To restore the audible alarm, press and hold the button for 5 seconds. BB24V1U will beep twice to confirm that
audible alarms have been turned on.
Button-Cold Start
Cold start uses battery power when BB24V1U is powered o, and no utility power is available.
Before using the cold start feature, make sure the battery is properly charged and installed.
To turn on the cold start feature, press and hold the button until 3 LED indicators are on.
LED Indicator
STEP 1:
ALoosen the screw
from the enclosure.
STEP 2:
ASlide o the
battery cover on
the back of the
BB24V1U.
STEP 3:
ARemove the battery
from the enclosure.
BDisconnect both
battery cable
connectors.
STEP 4:
AInstall a new battery
by connecting the
red wire to positive
terminal and the
black wire to the
negative terminal.
B Insert the battery into
BB24V1U.
STEP 5:
AReplace the battery
cover to resume normal
operation.
BTighten the screw into
the enclosure.
Fail
Mute
BLUE/RED
RED
BLUE
Battery replacement required. Alarm beeps once every 15 minutes. The LED also illuminates
when the battery is absent or when battery is in protection state then turn o the output power.
Press and hold the “Mute” button for 5 seconds to silence the audible alarm.
The LED will be on.
USC cable loss: The Status LED is easing between BLUE and RED for 120 seconds.
Note: After 120 seconds, the Status LED returns to its normal operational state (Battery
charging/Battery mode).
Battery charging mode: The Status LED is easing BLUE. The battery level is between 1%~99%.
Battery mode: Indicates the battery capacity.
1 Battery capacity > 20%: BLUE LED is on.
2Battery capacity between 10% and 20%: RED LED is on, and alarm beeps 4 times
per minute.
3Battery capacity ≤10%: RED LED blinks, and alarm beeps 4 times per minute.
Indicator Color Condition
Status

4
Battery Replacement (Technician Reference Only)
As long as utility power is on, you can leave BB24V1U and other connected equipment powered on while replacing a battery.
Communication Signals
The UART communication signals of BB24V1U are isolated from its internal circuitry via photo-coupler to transmit
and receive signals.
“SIG RTN” (Signal Return) is a common return point for all communication signals. In a typical application, the
equipment digital ground should be connected to Signal Return.
Specifications
UART DATA transmissionTX1
UART DATA receiveRX2
Signal returnSIG RTN
* Max signal voltage: 3.3V
* Max signal current: 5mA
3
AC inlet
Communication signals
BB24V1U
DC power outlet
1
2
3
PIN Signal Message
Voltage Range 100Vac - 240Vac
Frequency Range 50-60Hz
Output
On Battery Output Voltage 12Vdc
Continuous Power Capability 36W
Eciency (Max Load) ≥80%
Battery
Battery Type
Numbers of Battery 12Vdc / 10Ah x 1
Typical Recharge Time
24 Hours
Replaceable
Surge Protection and Filtering
Lightning / Surge Protection
Management
Battery Auto-Charge
Yes
Physical
Di mensions (LxWxD) 18.5cm x 8.5cm x 18.7cm
Weight (Net) 4.05kg (with 10Ah battery)
Environment
Operating Temperature
32°F - 104°F (0°C - 40°C)
Operating Humidity
Max Operating Elevation
13,123ft (4,000m)
50,000ft (15,240m)
-4°F - 140° F (-20°C - 60°C)
Model BB24V1U
Input
0-95% non-condensing within enclosure
Yes
Yes
Sealed, Maintenance Free Lead-Acid Battery
Max Storage Elevation
Storage Temperature

5
Specifications
Limited Warranty
Charter warrants to you, the Initial Purchaser, that the Product will be free from defects in material and workmanship for one year from the
date of original purchase, subject to the terms of this Limited Warranty. This Limited Warranty gives you specific rights, and you may have
other rights, which vary from State to State or Province to Province.
Any Implied Warranty of Merchantability or for Fitness for a Particular Purpose, if applicable to the Product, is limited in duration to one
year. This provision shall NOT create any Implied Warranty or Merchantability or of Fitness for a Particular Purpose that would not otherwise
apply to the Product. NOTE: Some States and Provinces do not allow limitations on how long an implied warranty lasts, so the above
limitation may not apply to you.
To be covered you must still be the owner of the Product at the time of the failure that results in the claim made under this Limited Warranty.
Your sole and exclusive remedies are those provided by this Limited Warranty. This exclusion of other express warranties applies to written
and oral express warranties. Charter excludes any liability for personal injury. Charter excludes any liability for direct, indirect, special,
incidental, or consequential damages, whether for damage to or loss of property, loss of profits, business interruption, information or data.
This exclusion applies even though damage or loss is caused by negligence or other fault. NOTE: Some States or Provinces do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation may not apply to you.
DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT OR OTHER HIGH RISK ACTIVITIES.
Charter does not sell the PRODUCT for use in high-risk activities. The PRODUCT is not designed or intended for use in hazardous
environments requiring fail-safe performance, including the operation of nuclear facilities, aircraft navigation or communication systems,
air trac control, weapons systems, life support or medical applications or for use in any circumstance in which the failure of the PRODUCT
could lead directly to death, personal injury, or severe physical or property damage, or that would aect operation or safety of any medical or
life support device (collectively, “High Risk Activities”). Charter expressly disclaims any express or implied warranty of fitness for High Risk
Activities. Charter does not authorize use of any PRODUCT in any High Risk activities.
ANY SUCH USE IS IMPROPER AND IS A MISUSE OF A CHARTER PRODUCT.
The Limited Warranty is governed by the laws of the United States, without reference to conflict of law principles. The application of the
United Nations Convention of Contracts for the International Sale of Goods is expressly excluded.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with these instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the following measures: (1)Reorient or relocate the receiving
antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Shielded signal cables must be used with this device to ensure compliance with Class B FCC limits.
CAUTION: Any changes or modifications not expressly approved by Charter could void the authority granted by the FCC to operate this equipment.
Deliver spent batteries to a recycling facility or ship to the manufacturer in the replacement battery packing material.
For more information, please contact:
Charter Communications, Inc. 400 Atlantic Street,Stamford,Connecticut 06901,United States Of America http://www.charter.com
K01-3612012-02
