Speed Clean SC-VSC-7000 Installation and operation manual
SpeedClean®
Innovative Maintenance Tools.
OPERATING & MAINTENANCE INSTRUCTIONS
MODEL
SC-VSC-7000
Vapor Steam Cleaner
SC-VSC-7000
2Model SC-VSC-7000 Operating and Maintenance Manual
Table of Contents
WARNING! Read and understand all instructions. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious personal injury.
Save these Instructions!!
• Warning: Risk of injection or severe injury – keep clear of nozzle – do not direct discharge
steam at persons — this product is to be used only by trained operators.
• Do not use the equipment near persons if they are not wearing protective clothing.
• Warning: Hot accessories can lead to injuries, do not touch with bare skin.
• Make sure that the water you fill into the water tank is clean. Avoid the use of buckets or
canisters to fill the tank unless these are completely free of dirt or foreign objects.
• Do not drag the machine by pulling the hose, this can damage the hose.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Check the power supply cable before use for any damage. In the event of damage
to the power supply cable, have it immediately replaced by the manufacturer or
qualified personnel.
• Over length of power cord extension (longer than 82 ft or 25 m) may lead to insufficient
voltage supply and malfunction.
Important Safety Instruction ................................................................................................... 2
Grounding Instructions............................................................................................................ 3
Overview ................................................................................................................................. 4
Setup and Operation.............................................................................................................. 5
Maintenance and Storage .................................................................................................... 6
Troubleshooting ................................................................................................................... 6
Specifications ...................................................................................................................... 6
Parts and Accessories List....................................................................................................... 7
Parts Breakdown ................................................................................................................ 8-11
Limited Warranty ................................................................................................................... 11
Important Safety Instructions
SC-VSC-7000
SC-VSC-7000
Thank you for purchasing SpeedClean’s SC-VSC-7000 Vapor Steam Cleaner. We appreciate
your business and look forward to serving you in the future. As with all SpeedClean products,
you can be assured that the finest quality components and workmanship have gone into
this machine.
Please take a few minutes to read the following Operating and Maintenance Instructions.
Please pay particular attention to the safety instructions and exercise caution when using
this machine.
© 2019 All Rights Reserved. 3
Table of Contents
• Warning: Inadequate extensions can be dangerous. Make sure that your extension is
correctly dimensioned and constructed according to national legislation.
• Never immerse any part of the machine in water or other liquids.
• Check the steam hose and all accessories for damage before use and replace or have
them repaired immediately.
• In the event of leakage of steam or liquid, switch off and disconnect power immediately.
Contact the manufacturer or service center.
• The equipment must not be used by children or untrained personnel.
• To guarantee safety of the equipment, only use original spare parts and accessories. These
must be supplied by SpeedClean.
• Never use the machine in a tilted position, all 4 wheels must stand on a level surface.
• Do not clean heat sensitive materials with steam, the heat of the steam could
cause damage.
• Operate the machine only wearing appropriate PPE.
• Ventilate work area when using toxic or pungent additives to reduce your exposure to
toxic fumes.
• Be careful of slippery floors. Some additives make a normally safe area extremely slippery
and dangerous.
• Keep operation area clear of all persons. Do not use unit with children or visitors in the
immediate area.
• Use only SpeedClean specified replacement parts and attachments.
• Keep objects, loose clothing, hair, body parts away from openings and moving parts.
• Do not operate unit when fatigued or under the influence of drugs or alcohol.
• Do not over reach or stand on unstable support. Keep good footing and balance at
all times.
• Stay alert and watch what you’re doing.
Grounding Instructions
SC-VSC-7000
This appliance must be grounded. If it should malfunction or breakdown, grounding provides
a path of least resistance for electric current to reduce the risk of electric shock. This appliance
is equipped with a cord having an equipment-grounding conductor and grounding plug.
The plug must be inserted into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING — Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you are in doubt as to
whether the outlet is properly grounded. Do not modify the plug provided with the appliance
— if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
SC-VSC-7000
4Model SC-VSC-7000 Operating and Maintenance Manual
Overview
1. Pressure Gauge
2. Water Level Low Indicator
3. Steam Control Knob
4. Hose Connector
5. Steam Ready Indicator
6. Power/Boiler Switch
7. Water Tank Cap (Not Shown)
1
2
3
4
6
5
© 2019 All Rights Reserved. 5
1. Pressure Gauge
2. Water Level Low Indicator
3. Steam Control Knob
4. Hose Connector
5. Steam Ready Indicator
6. Power/Boiler Switch
7. Water Tank Cap (Not Shown)
SC-VSC-7000 Setup and Operation
Setup
1. Remove the SC-VSC-7000 unit from the packaging.
2. Inspect the unit and all accessories for damage and missing parts. If anything is wrong, call
SpeedClean immediately (1-888-700-3540).
Operation
1. Fill the water tank until full.
2. Plug in the SC-VSC-7000 unit and press the power/boiler switch into the ‘ON’ position.
3. When the unit starts, continue filling the water tank until the pump stops and the boiler is
full. The pump will continue to stay on until the boiler water level is full (approximately 0.66
Gallons/2.5L).
4. Plug in the 3 meter steam hose into the hose connector port.
5. Once the unit reaches 2 BAR (29 PSI) on the pressure gauge, press the trigger on the steam
hose to prime the unit. After that, continue to allow the boiler to heat up until the green
steam ready indicator light turns on.
6. Once the light is on (about 4.5 BAR or 65 PSI), the unit is ready to use. NOTE: This unit is
not made for continuous use. There will be more condensation the longer the trigger is
continuously squeezed.
7. After use, switch the SC-VSC-7000 unit off, and then wait for the unit to cool and
depressurize before putting away.
SC-VSC-7000
6Model SC-VSC-7000 Operating and Maintenance Manual
Troubleshooting
PROBLEM PROBABLE CAUSE SOLUTION
Steam is leaking from the
hose or accessory.
• Broken o-ring on connector.
• Steam hose is punctured.
• Check to connector for any
broken seal and replace
if needed.
• Turn off the unit immediately
and contact SpeedClean to
replace the hose.
There is no steam
output, but there is
boiler pressure.
• Steam regulator valve on
the machine is closed.
• Trigger on the steam output
hose assembly is broken.
• Turn the regulator valve
counterclockwise to open the
valve for steam.
• Call SpeedClean to have the
trigger switch replaced.
Machine heating time is
too long.
• Too much limescale buildup
in the boiler.
• Follow the instructions on page
5 under MAINTENANCE to
remove the limescale from
the boiler.
Problem Not Listed Call Speedclean Customer Service: 1-888-700-3540
SC-VSC-7000
Power Requirements 115V 60 Hz 13.5A/230V 50 Hz 7A
Power Supply Cord 13’ (3.3M)
Steam Hose Length 10’ (3M)
Water Capacity 0.66 Gallons (2.5L)
Max Steam Temp (at Nozzle) 235˚F (113˚C)
Max Steam Pressure 65 PSI (4.5 BAR)
Weight 15.6 Lbs (Dry)
Specifications
Maintenance & Storage
Maintenance
The water filter must be cleaned periodically. To do this, you have to remove it from where the
water is poured into the water tank. Routine checks carried out by SpeedClean will increase the
life and reliability of the unit.
To prevent the buildup of Limescale, the boiler should be emptied and cleaned every 6-12
months. To do this, remove the slotted cap on the bottom of the machine, and then remove the
hex cap using the supplied hex socket. To remove the limescale, use SpeedyBright
®
and agitate
the limescale until it is removed and the SpeedyBright
®
is no longer reacting.
Storage
To prevent damage to the boiler, store this unit in a vertical position, and do not store in
freezing temperatures.
© 2019 All Rights Reserved. 7
PART NO DESCRIPTION PART NO. DESCRIPTION
SC-VSC-J11096 Steam Hose,
9.8’
(3 Meters)
SC-VSC-J0200 Drain
Cleaner
SC-VSC-M0113 Triangle Brush
with Joint
SC-VSC-G0018 Nylon Detail
Brush
SC-VSC-M0122 Floor Brush
with Joint
SC-VSC-G0126 Brass Detail
Brush
SC-VSC-M0018/N Extension
Wand
SC-VSC-G0125 Stainless Steel
Detail Brush
SC-VSC-M0017/N Glass
Cleaner
SC-VSC-D0024 Nylon Round
Brush
SC-VSC-M0119 Glass Cleaner
with Rubber
Blades
SC-VSC-D0025 Nylon Triangle
Brush
SC-VSC-M0114 Detail Nozzle
with 1 Hole
SC-VSC-J0680 Brass Round
Brush
SC-VSC-M0115 Detail Nozzle
with 3 Holes
`
SC-VSC-7000 Parts and Accessories List
SC-VSC-7000
8Model SC-VSC-7000 Operating and Maintenance Manual
Parts Breakdown
ITEM DESCRIPTION QTY ITEM DESCRIPTION QTY
1Bottom akr7000 v0 black 137 Pipe Cover 1
2Cable Winder Plate 138 Black Pipe Cover 1
3 Cable Winder Fitting 2 39 Nylon Strap 3
4 Cable Winder Fitting 2 40 Water Guard 1
5 Screw 6 41 Water Tank Assembly w/ Pump 1
6 Back Wheel 2 42 Water Level Sensor Assembly 1
7 Wheel Guard 2 43 Sealing Washer 1
8 Nut 2 44 Water Tank Cap 1
9 Front Wheel 2 45 Tank Union 1
10 Drain Cup 1 46 Silicone Water Guard 1
11 Power Cord 1 47 Oring 2
12 Insulating Connectors 2 48 Water Filter 1
13 Power Cord Block 1 v 49 Screw 2
14 Cable Clamp 1 50 Washer 2
15 Control Panel Support 1 51 Screw 4
16 Light Spacer 2 52 Cabling Assembly 1
17 Orange Light 1 53 PCB Spacer 1
18 Green Light 1 54 Main PCB 1
19 Steam Gauge 1 55 Main PCB w/ Power Cord 1
20 Brass Washer 1 56 PCB Support 1
21 Steam Regulator Valve 1 57 Screw 2
22 Steam Regulation Pin 1 58 PCB Cover 1
23 Ground Fastener 1 59 Top Cover 1
24 Screw 1 60 Handle Assembly 1
25 Washer 1 61 Small Caps for Handle 2
26 Nut 1 62 Large Caps for Handle 1
27 Socket Assembly 1 63 Screw 5
28 4 Pin Electrical Socket 1 64 Screw 8
29 Boiler Assembly 1 65 Screw 4
30 Washer 4 66 Regulator Knob 1
31 Washer 10 67 SpeedClean Label 1
32 Silicone Pipe 0 68 Yellow Caution Label 1
33 Screw 4 69 “Not for Space Heating
Purpose” Label 1
34 Covered Silicone Pipe 1 70 “Do Not Immerse” Label 1
35 Clamp 2 71 “Household Use” Label 1
36 Clamp 3
© 2019 All Rights Reserved. 9
SC-VSC-7000
19
18 15
17
16
36
36
37
48
49
50
45
31
33
33
33 30
20
29
32
55
57
56
58 40
64
7
68
27
28
51 1
5
13
64
2
69 11
12
8
6
7
5
51
14 3
4
910
70
71
54
53
5
30
31
44
46
50
68
62
61
67
60
63
63
66
Parts Breakdown
22 21
26
47
52
43
42
65
35
23
64
24
25
SC-VSC-7000
10 Model SC-VSC-7000 Operating and Maintenance Manual
Parts Breakdown
ITEM DESCRIPTION QTY
1Boiler with Drain Hole 1
2Insulation 1
3Heat Inductor 1
4Heating Elements 1
5Nut M5 11
6Thermostat 1
7Screw, 4x6 3
8Fastener Clips 2
9Boiler Bottom Space 4
10 Male Spade Connector 1
11 Washer 1
12 Drain Plug Fitting 1
13 Cap for Drain Plug 1
14 Rubber Washer 1
15 Water Level Sensor 1
16 Teflon Pipe (not shown) 1
17 Compression Fitting 1
18 Nut for Compression Fitting 1
19 1/8” Gas Fitting 1
20 Barb Fitting 1
21 Solenoid Valve 1
22 Safety Switch 1
23 1/8” to ¼” Reducer 1
24 Working Pressure Stat 1
25 Cross Fitting 1
26 Y Connector, 1/8” NPT 1
27 Rubber Grommet
(not shown) 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
19
20
21
22
23
24
25
26
View 1 — Boiler Assembly
© 2019 All Rights Reserved. 11
1
2
3
4
5
6
7
ITEM DESCRIPTION QTY
1Water Tank 1
2Water Tube 1
3Barb Fitting 1
4Bypass Valve 1
5Water Tank 1
6O-ring 2
7Pump Holders 2
8Pump 1
9Silicone Pipe 1
ITEM DESCRIPTION QTY
1Manifold Body 1
2Manifold Gun Lid 1
3Gun Lid Pin 1
4Manifold Lid Spring 1
5Power Switch 1
6Steam Gun Connector 1
7Snap Ring 1
1
2
3
4
6
9
View 2
SC-VSC-7000 Parts Breakdown
5
78
View 3
Limited Warranty
This unit has been carefully tested and inspected and is warranted to be free from defects in
material or workmanship. The company will, under this warranty, repair or replace any parts
which prove, upon examination, to be defective. This warranty is valid for one year from date of
purchase by original purchaser.
This warranty excludes accessories, unusual wear, abuse, damage resulting from an
accident, or unreasonable use of this machine. It is recommended that any repairs be done
by SpeedClean as improperly performed repairs will void the warranty.
For repairs or warranty information DO NOT contact the place of purchase. Call SpeedClean
Customer Service at (888) 700-3540.
To obtain warranty service a proof of purchase is required and the unit must be returned freight
prepaid. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state. SpeedClean reserves the right to improve products. Contact
the factory for the latest configuration and uses.
SC-VSC-7000
PO Box 110301
Stamford, CT 06911-0301
(888) 700-3540 • (203) 359-2645
www.speedclean.com
SpeedClean®is a registered trademark of Crossford International. SpeedClean®reserves the right to improve
products; contact the factory for the latest configuration and uses.
P / N : M N L - S C V S C 1119
IMPORTANT INFORMATION
Please take time to register your product with SpeedClean. Registering
only takes a few seconds and allows us to serve you better. Get access
to product news, specials and fast service & support.
www.speedclean.com/register
SpeedyFoam®CoilJet®Mini-Split Bib®Kit
Visit speedclean.com to learn about our other popular products.
Table of contents
