Sphere TCR-001 User manual

Sphere Touch Control
Rangehood
Model No. TCR-001
Please read and save the instruction

Sphere Touch Control Rangehood November 2013
Sphere Touch Control Rangehood
Features:
Touch Control Tempered Glass Front
Variable Speed
2 High Volume Airflow 12v Fans
Built In Clock
LED Stripe Light
Removable Easy to Clean Filter
Stainless Steel Construction
Vents through the Rear or Top
Easy to Fit
W 530mm x D 304mm x H 60mm
SPECIFICATIONS:
Power
12 volt
Rating Motor input Power: Maximum
2 x16W
Illumination: Maximum
3W
Total input Power
35W
Air Flow
100 m3/hr
Removable Filter
5 layer Aluminium mesh
Out Side Dimension
W 530mm x D 304mm x H 60mm
Body Material
Stainless Steel

Sphere Touch Control Rangehood November 2013
INSTALLATION:
Note:
When installing Rangehood into a Recreational Vehicle, ensure that it is fitted in
accordance to all Australian Standard requirements
The Sphere touch control Rangehood can be installed using 2 different methods.
Option 1. Top Mounting
Steps: (Hole cut out made to the specified sizing)
1. Remove filter to access to pre punched screw locating holes in the top of the Rangehood
2. Connect wires to the 12volt power source (Wires labelled +/- please ensure wires are
connected the correct way)
3. Lift Rangehood into designated position
4. Mount using 4 only SS screws into pre punched locating holes (Shown above)
5. Install filter
6. Test Rangehood and ensure unit is working correctly
Option 2. Side Mounting
Steps: (Hole cut out made to the specified sizing)
1. Remove filter to access to pre punched screw locating holes in the top of the Rangehood
2. Connect wires to the 12volt power source (Wires labelled +/- please ensure wires are
connected the correct way)
3. Lift Rangehood into designated position
4. Mount using 4 only SS screws into pre punched locating holes (Shown Above)
5. Install filter
6. Test Rangehood and ensure unit is working correctly

Sphere Touch Control Rangehood November 2013
PART NAMES:
1. Tempered glass
2. Switch
3. Switch box
4. Left panel
5. Right panel
6. PCB box base
7. Vent duct plate
8. Air flu
9. Air housing
10.PCB
11.PCB box
12.Filter
13.Light panel
14.Light cover
15.LED Light
CONTROL PANEL OPERATION:
: Control the light on and off
: Speed up and time setting
: Speed down and time setting
: Power on/off
How to set the clock:
When the hood is on standby status, Press the key for 3 seconds to enter the clock setting,
the Clock indicator are flicking, press the key or to set the hour. Then press again the
key move to the minute setting, press or to set the minute. The machine will
automatically confirm if without any operation in 3 seconds.
Note: Each time the rangehood connects to the power supply, the clock indicator just
show 00:00.
Display Panel
3 Speed Fan Indicator
Light
Speed up and
time setting
Clock indicator
Light indicator
Speed down and
time setting
On/off

Sphere Touch Control Rangehood November 2013
CLEANING AND CARE:
1. Turn off the Rangehood before cleaning
2. Remove filter
a. Wash using warm water and a Mild detergent
b. Using a NON abrasive cloth
c. Allow to dry before refitting clean filter
3. Clean all viewable surfaces
a. Wash using warm water and a Mild detergent
b. Using a NON abrasive cloth
Note: Do not clean electrical components with water or a wet cloth.
WARRANTY:
IF YOU HAVE A PRODUCT PROBLEM:
First:
If your Sphere TCR-001 Rangehood is factory fitted as part of your NEW RV, Please Contact the OEM
Manufacture of the RV or refer to the OEM RV User and Warranty handbook for further information.
Second:
Service Contact:
Coast RV Pty Ltd
trading as Coast to Coast RV Services
ABN 49 097 104 492 - ACN 101 461 330
PO Box 415, Regents Park NSW 2143
AUSTRALIA
Ph [phone] - Fax [phone]
Email: warran[email protected]
Web: www.coastrv.com.au
Coast to Coast RV Services
