Spidertracks Spider S5 User manual
Spider S5 Instruction Manual
Spider Tracks Ltd
203/150 Karanagahape Road
Auckland 1010
New Zealand
www.spidertracks.com
P + 64 6 353 3395
October 2013. This manual was correct at time of printing. Please contact
1. Installing your Spider S5
Spiders need a good, clear view of the sky.
Positioning
We recommend placing the Spider on top of the instrument panel in the
aircraft, not directly under any window frames or heated windows. If you
cannot physically see the sky from where the Spider is placed the Spider will
not be able to either. The Spider is not subject to Specific Absorption Rate
testing, however we recommend placing it no less than 200mm from a person.
Secure the Spider to the dashboard with the bracket supplied, please make
sure you can easily reach it while flying. The Spider can be quickly removed
from the mount when required. The top of the Spider should point upward.
Power
The Spider can be powered using the supplied power lead - just plug into your
vehicle’s 10 to 32 volt DC (cigarette lighter) power supply. Alternatively the
Spider can be hard-wired to the power supply in your vehicle if you prefer. It is
a simple process for a Licensed Aircraft Maintenance Engineer or technician
to wire in the supplied power lead to the battery.
The Spider draws can draw an excess of 1A on transmission, a 3A fuse is
recommended and if required 18 – 22 AWG wire can be used depending on
length. The Spider should not be used in line with a switch.
The power lead supplied has three wires. Brown is positive, black is earth, and
blue is not required.
2. Initial Power Up
Once your website account is set up and you have installed your Spider you are
ready to go flying.
Initial Start Up
When the power supply is connected and turned on the Spider will
automatically connect to a satellite. The left LED on the keypad of the will glow
red and the right LED will turn amber when it has a GPS fix. This will turn
green when it has sent the first position report through the Iridium Satellite
Network. The first time you power up, it may take the Spider a few minutes to
secure a GPS fix. After that it should take less than a minute if you use your
Spider often. It is recommended you have a GPS fix before moving.
Please remember the Spider must have a view of the sky in order to work.
3. Using the Spider S5
SOS
Pressing SOS on the Spider will cause an SOS to be sent to your tier one
support people setup in the website. The only way to stop the alert is to power
the Spider down and power up to start it tracking again.
SOS alerts will not be sent to emergency services. If you require the alert to be
sent to emergency services please contact your local authority and inform
them that you intend to do this. They may require further information on how
the alert service works. Please contact support@spidertracks.com if
information on the alert service is required.
Please also note that the mobile number must be in international format and
must be a valid mobile number. For example, a United States mobile number
555 234 567 would be entered +1555234567, where +1 is the international
calling code.
Watch
Press the Watch button for the website to monitor your flight. The website
will monitor the points coming in and if none are received for a 15 minute
period while Watch is active, the website will automatically send out an email
and text SOS to your support people.
You can have monitoring on for part or all of the flight, you are able to turn it
on and off by pressing the Watch button. The normal transmission rate will
occur when Watch is turned off. You must turn Watch off at the end of your
flight, and wait for the blue LED to stop flashing – this should take less than
one minute – to prevent an SOS from being sent.
MARK
Press the mark button to force a position point to be sent right now. A
description will be added to the point when viewed on the website. The
notification message from Mark 1 can be sent to email and the mobile
phones that have been set up to receive these in the Notification settings page
on the website. When the button is pressed once a Mark one is sent, Mark 2 ->
press twice, Mark 3 -> press three times, Mark 4 -> press four times. Presses
must be within one second of each other.
The Mark button can be used at any time and a point will be sent, as long as
the unit has a GPS fix.
4. Adjusting the LED brightness
You can adjust the Keypad LED brightness by pressing and holding the
Mark button down. The LED will scroll through the levels of brightness.
Release the mark button when your desired brightness is reached.
5. Spidertxt
Please refer to the Spidertxt article in support.spidertracks.com.
