Spirent Setup Guide: Vertex
®
High Frequency Converter
Information subject to change.
71-008347. A1
Page 1 of 8
4-Channel Vertex HFC
Instructions
1 Ensure the AC power cord is not connected to a wall outlet.
2 Connect the front panel cables by following the instructions on page 2.
3 Connect the rear panel cables by following the instructions on page 3.
4 Connect the power cord to the Vertex HFC and apply power to the system
by following the instructions on page 4.
Assembly Procedure
Vendor Model # Qty
Spirent VCE6-HFC-4C 1
System Components
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
RF
I/O1
RF
I/O2
RF
I/O3
RF
I/O4
I
O
Vertex High Frequency Converter
STATUS
POWER

+1 800-SPIRENT – www.spirent.com
Spirent Setup Guide: Vertex
®
High Frequency Converter
Information subject to change.
71-008347. A1
Page 2 of 8
4-Channel Vertex HFC
Cable Routing: Front Panel
To mmW Frequency ports
To RF ports of Vertex or VR5
mmW cable, up to 40GHz
RF cable, up to 6 GHz
Note: All connectors on front panel are SMA or 2.9mm interface.
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
RF
I/O1
RF
I/O2
RF
I/O3
RF
I/O4
I
O
Vertex High Frequency Converter
STATUS
POWER

+1 800-SPIRENT – www.spirent.com
Spirent Setup Guide: Vertex
®
High Frequency Converter
Information subject to change.
71-008347. A1
Page 3 of 8
4-Channel Vertex HFC
Cable Routing: Rear Panel
LO OUT
LO IN 10MHz Ref IN
AC power,100V~240V External 10MHz
Reference (if necessary)
LO OUT
LO IN 10MHz Ref IN
AC power,100V~240V External 10MHz
Reference (if necessary)
Using Internal LO
External LO
Using External LO
mmW cable, up to 40GHz
Power cord
BNC cable
Note: LO IN and LO OUT connectors are SMA or 2.9mm interface.

+1 800-SPIRENT – www.spirent.com
Spirent Setup Guide: Vertex
®
High Frequency Converter
Information subject to change.
71-008347. A1
Page 4 of 8
1Connect the AC power cord to the power connector on the rear panel of the
Vertex HFC.
2 Plug the power cord directly into the wall outlet.
3 Press the power swtich on the front panel of the Vertex HFC.
4Ensure the Vertex HFC powers up properly. The Power LED indicator will be
solid green.
Power Connection Procedure
Instructions
Perform the following steps after all cable routing has
been completed.
4-Channel Vertex HFC
Applying Power to the System
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
RF
I/O1
RF
I/O2
RF
I/O3
RF
I/O4
I
O
Vertex High Frequency Converter
STATUS
POWER

+1 800-SPIRENT – www.spirent.com
Spirent Setup Guide: Vertex
®
High Frequency Converter
Information subject to change.
71-008347. A1
Page 5 of 8
20-Channel Vertex HFC
Vendor Model # Qty
Spirent VCE6-HFC-20C 1
System Components
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
mmW
I/O6
mmW
I/O6
mmW
I/O7
mmW
I/O8
STATUS
Vertex High Frequency Converter
RF
I/O5
RF
I/O6
RF
I/O7
RF
I/O8
RF
I/O13
RF
I/O14
RF
I/O15
RF
I/O16
RF
I/O3a
RF
I/O4a
eNB UE
RF
I/O1
RF
I/O2
RF
I/O3
RF
I/O4
RF
I/O9
RF
I/O10
RF
I/O11
RF
I/O12
mmW
I/O9
mmW
I/O10
mmW
I/O11
mmW
I/O12
mmW
I/O13
mmW
I/O14
mmW
I/O15
mmW
I/O16
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
RF
I/O1a
RF
I/O2a
RF
I/O3b
RF
I/O4b
RF
I/O1b
RF
I/O2b
I
O
POWER
1 Ensure the AC power cord is not connected to a wall outlet.
2 Connect the front panel cables by following the instructions on page 6.
3 Connect the rear panel cables by following the instructions on page 7.
4 Connect the power cord to the Vertex HFC and apply power to the system
by following the instructions on page 8.
Assembly Procedure
Instructions

+1 800-SPIRENT – www.spirent.com
Spirent Setup Guide: Vertex
®
High Frequency Converter
Information subject to change.
71-008347. A1
Page 6 of 8
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
mmW
I/O6
mmW
I/O6
mmW
I/O7
mmW
I/O8
STATUS
Vertex High Frequency Converter
RF
I/O5
RF
I/O6
RF
I/O7
RF
I/O8
RF
I/O13
RF
I/O14
RF
I/O15
RF
I/O16
RF
I/O3a
RF
I/O4a
eNB UE
RF
I/O1
RF
I/O2
RF
I/O3
RF
I/O4
RF
I/O9
RF
I/O10
RF
I/O11
RF
I/O12
mmW
I/O9
mmW
I/O10
mmW
I/O11
mmW
I/O12
mmW
I/O13
mmW
I/O14
mmW
I/O15
mmW
I/O16
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
RF
I/O1a
RF
I/O2a
RF
I/O3b
RF
I/O4b
RF
I/O1b
RF
I/O2b
I
O
POWER
mmW cable, up to 40GHz
RF cable, up to 6 GHz
Note: All connectors on front panel are SMA or 2.9mm interface.
To mmW Frequency ports
To RF ports of Vertex or VR5
20-Channel Vertex HFC
Cable Routing: Front Panel

+1 800-SPIRENT – www.spirent.com
Spirent Setup Guide: Vertex
®
High Frequency Converter
Information subject to change.
71-008347. A1
Page 7 of 8
mmW cable, up to 40GHz
Power cord
BNC cable
Note: LO IN and LO OUT connectors are SMA or 2.9mm interface.
LO OUT
LO IN 10MHz Ref
IN
LO OUT
LO IN 10MHz Ref
IN
AC power,100V~240V
External 10MHz
Reference (if necessary)
AC power,100V~240V External 10MHz
Reference (if necessary)
Using Internal LO
External LO
Using External LO
20-Channel Vertex HFC Cable Routing: Rear Panel

+1 800-SPIRENT – www.spirent.com
Spirent Setup Guide: Vertex
®
High Frequency Converter
Information subject to change.
71-008347. A1
Page 8 of 8
Perform the following steps after all cable routing has
been completed.
20-Channel Vertex HFC
Applying Power to the System
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
mmW
I/O6
mmW
I/O6
mmW
I/O7
mmW
I/O8
STATUS
Vertex High Frequency Converter
RF
I/O5
RF
I/O6
RF
I/O7
RF
I/O8
RF
I/O13
RF
I/O14
RF
I/O15
RF
I/O16
RF
I/O3a
RF
I/O4a
eNB UE
RF
I/O1
RF
I/O2
RF
I/O3
RF
I/O4
RF
I/O9
RF
I/O10
RF
I/O11
RF
I/O12
mmW
I/O9
mmW
I/O10
mmW
I/O11
mmW
I/O12
mmW
I/O13
mmW
I/O14
mmW
I/O15
mmW
I/O16
mmW
I/O1
mmW
I/O2
mmW
I/O3
mmW
I/O4
RF
I/O1a
RF
I/O2a
RF
I/O3b
RF
I/O4b
RF
I/O1b
RF
I/O2b
I
O
POWER
1Connect the AC power cord to the power connector on the rear panel of the
Vertex HFC.
2 Plug the power cord directly into the wall outlet.
3 Press the power swtich on the front panel of the Vertex HFC.
4Ensure the Vertex HFC powers up properly. The Power LED indicator will be
solid green.
Power Connection Procedure
Instructions
