SIIG CE-H26F11-S1 User manual

1
3x3 4K Video Wall Processor with
USB-C / DP / VGA / HDMI
User Manual
04-1297A P/N CE-H26F11-S1

2
Dear Customer
Thank you for purchasing this product. For optimum performance
and safety, please read these instructions carefully before
connecting, operating or adjusting this product. Please keep this
manual for future reference.
Directory
1. FEATURES...................................................................................................................................3
2. NOTICE........................................................................................................................................ 3
3. SPECIFICATIONS ....................................................................................................................... 4
4. PACKING CONTENTS ...............................................................................................................4
5. PANEL DESCRIPTIONS .............................................................................................................5
6. CONNECTING AND OPERATING ............................................................................................6
7. CONTROL INSTRUCTION ........................................................................................................ 8
7.1 Remote Control...........................................................................................................................8
7.2 Video switching operation...........................................................................................................9
7.2.1 Video Switching...............................................................................................................9
7.2.2 Video Wall Setting..........................................................................................................10
7.2.3 Mirror............................................................................................................................. 11
7.2.4 Rotate ............................................................................................................................. 12
7.2.5 Edge ...............................................................................................................................13
7.2.6 Format............................................................................................................................ 14
7.2.7 EDID ..............................................................................................................................14
7.3. Audio Setting ........................................................................................................................... 15
7.3.1 Audio input setting .........................................................................................................15
7.3.2 Audio output setting .......................................................................................................16
7.4. System Setting .........................................................................................................................16
7.4.1 Baud rate ........................................................................................................................16
7.4.2 TCP/IP setting ................................................................................................................17
7.4.3 Reboot ............................................................................................................................19
7.4.4 Factory reset...................................................................................................................19
7.4.5 System information ........................................................................................................19
7.5. Web Control .............................................................................................................................20
7.5.1 Interface introduction..................................................................................................... 22
7.5.2 Video wall setting...........................................................................................................23
7.5.3 Mirror.............................................................................................................................25
7.5.4 Rotate .............................................................................................................................25
7.5.5 Edge ...............................................................................................................................26
7.5.6 Format ............................................................................................................................26

3
7.5.7 EDID ..............................................................................................................................27
7.5.8 Audio output setting .......................................................................................................27
7.5.9 Audio input setting .........................................................................................................28
7.5.10 Network interface......................................................................................................... 28
7.5.11 Reset ...........................................................................................................................29
7.5.12 Password ......................................................................................................................29
8. RS232 CONTROL......................................................................................................................30
9 FIRMWARE UPDATE ................................................................................................................30
9.1 MCU update......................................................................................................................30
9.2 GUI Update.......................................................................................................................31
MAINTENANCE ...........................................................................................................................31
PRODUCT SERVICE.....................................................................................................................31
1. FEATURES
Support USB TYPE-C /VGA /DP / HDMI input.
Support 4K 3x3 video wall, cascading to create 3x4,4x5,5X6, and max 10x10 video wall.
Support output image 180° rotation.
Support highest resolution up to 4K30HZ 4:4:4 for all inputs.
Support EDID management: Two default EDID: 4K30HZ, 1080P.
Support HDCP2.2/1.4.
Support panel button; IR remote; RS232 command and Web GUI to control.
Support SPDIF and Analog audio extraction
Support third-party platform control via RS232 port or Lan.
1U rack design, easy installment.
DC 24V 2A power supply.
Unit size: L438x W274x H44 mm.
2. NOTICE
Our company reserve the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.

4
3. SPECIFICATIONS
4. PACKING CONTENTS
1) 3x3 4K Video Wall Processor with USB-C / DP / VGA / HDMI
2) 1x Power supply 24V2A
3) 1x User manual
4) 6x Screws, 2x detachable mounting ears
5) 1x CD
6) 1x Remote controller
7) 1x USB cable (for firmware upgrade)
Operating Temperature Range 0 to +40°C (32 to +104°F)
Operating Humidity Range 5 to 90 % RH (no condensation)
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Video Format Supported Ultra HD TV/FHDTV: 4K@30Hz/1080P
Audio Format Supported LPCM 16bit 24bit 44.1KHz,48KHz
Input ports 1xUSB TYPE-C, 1x DP, 1xVGA, 1xHDMI
Output ports 9xHDMI,1xHDMI Loop out
Splitter mode 1x9 HDMI Splitter
Video wall mode 1x1;1x3;1x4; 2x
2; 2x3; 2x4; 3x1; 3x2; 3x3; 4x1; 4x2;
4x3-1; 4x3-2; 3x4-1; 3x4-2; 4x4-1; 4x4-2
Cascade video wall mode 4x3; 4x4; etc. Max10x10
Control Way Panel control, Web control, Remote control, RS232
control
Power consumption 33watts (Maximum)
Dimension (mm) L438x W274x H44 mm

5
5. PANEL DESCRIPTIONS
Front Panel
1. Input status light: the selected source has green light
2. Source: Short press to select source from Type-C→VGA→DP→HDMI Input
3. Up: Long press to choose device setting in the OSD menu
4. Down: Long press to choose device setting in the OSD menu
5. Menu/Left: Long Press to return to the main menu, short press to back to previous menu
6. Enter/Right: Short press to enter the sub-menu, if there is no sub menu, short press it to
confirm the setting selection
7. Firmware port: Use USB cable to upgrade firmware
8. IR: Receive the IR signal from the remote controller to control the device
9. Power: Turn on or turn off the power
Note: 1. Long press "Up" and "Down" together for 5 seconds can modify the
output format, the current input status indicator flashes at a frequency of 5Hz, and
then cyclically switches at 1.5S intervals. The four indicators correspond to a
resolution of 4k30-1080p-720p-auto.
2. Long press "Menu" and "Enter" together for 5 seconds, the input status lights
starts blinking, after the blinking is over, the device is reset successfully.
Rear Panel
1. DC24V2A input
2. Type-C input port
3. VGA input port
4. Audio input port for VGA source
5. DP input port
6. HDMI input port
7. HDMI loop output
8. S/PDIF output port
9. Analog Stereo output port
10. RS232 port
11. TCP/IP port
12. HDMI output1 to HDMI output9 ports

6
6. CONNECTING AND OPERATING
1) Connect the sources into the video wall controller and Press the button on the
remote, then choose the input Signal (USB TYPE-C; VGA; DP; 2 HDMI in).
2) Connect HDMI OUT to display equipment.
3) Power on the Video Wall Controller.
4) Control the Video Wall Controller by Panel button / Remote /RS232 Command.
3x3 Video Wall Displaying

7
6x4 Video Wall Displaying

8
7. CONTROL INSTRUCTION
7.1 Remote Control
8.1
1. Power on/off
2. Mute
3. Source switching
4. Switch signal source of IN1
(TYPE C)
5. Switch signal source of IN2
(VGA)
6. Switch signal source of IN3
(DP)
7. Switch signal source of IN4
(HDMI)
8. Menu
9. ▲: UP ▼: Down ◄: Left/Menu
►: Right/Enter, OK: Right/Enter
10. Display and hide OSD menu
11. Return to menu interface
12. 1-4: select the input source
IN1---IN4
Note 1: The function of Right/Enter in the remote controller is the same as the
"Right/Enter" key on the panel.

9
7.2 Video switching operation
Press the "Source" button to select the input from Type-C→VGA→DP→HDMI.
Note: 1. The video switching OSD interface only shows nine output channels and the
current input signal channels, and it can only switch one input source to all output
channels when the input and output are both connected to the device.
2. No operation for 20S, the OSD interface turns black, press any button to wake it.
OSD video menu
7.2.1 Video Switching
Press the "Left/Menu" on the panel to enter the "Switching" menu,
Press the "Right/Enter" on the panel to select and confirm the input source,
The selected one has a "@" to mark.
In1→Type-C input, In2→VGA input, In3→DP input, In4→HDMI, the
default input is HDMI.

10
Video switching interface
7.2.2 Video Wall Setting
Press the "Left/Menu" on the panel to enter the "Video Wall" menu,
"Preset" : Including 17 kinds of common scenes such as 2x2, 1x4,4x1,4x2 and so on,
The selected one has a "@" to mark.
"Set Up": Press the "Right/Enter" on the panel to enter the "Set up" menu,
Press the "Up" or "Down" on the panel to select, then press "Enter" to confirm,
The selected one has a "@" to mark.
"H_NUM " represents the total amount of display on the horizontal axis,
"V_NUM" represents the total amount of display on the vertical axis,
"Cascade" represents which cascading level the device is, support 12 layers in total,
"Port Map" represents each display corresponding to which HDMI output port.

11
Preset video wall mode
Video wall set up
7.2.3 Mirror
Press the "Left/Menu" on the panel to enter the "Mirror" menu,
Press the "Up" or "Down" on the panel to select, then press "Enter" to confirm,
The selected one has a "@" to mark.
"Normal" represents default mode (without mirror function),
"Only X" represents horizontal mirror,
"Only Y" represents vertical mirror,
"X and Y" equals to 180degree rotation.

12
Mirror interface
7.2.4 Rotate
Press the "Left/Menu" on the panel to enter the "Rotate" menu,
Each output image support 180degree rotation, select "Yes " or "No" to set up,
The selected one has a "@" to mark.
Rotate interface

13
7.2.5 Edge
Press the "Left/Menu" on the panel to enter the "Edge Set" menu,
Press the "Up" or "Down" on the panel to select, then press "Enter" to confirm,
The selected one has a "@" to mark.
"X" represents the margin setting between the horizontal displays, each image is
divided into 302 units.
"Y" represents the margin setting between the vertical displays, each image is divided
into 302 units.
The default margin of booth horizontal and vertical display screen is 3.5mm frame
size.
Edge set interface

14
7.2.6 Format
Press the "Left/Menu" on the panel to enter the "Format" menu,
Format including 4K30；1080P@60；720P@60；2560x1440；1920x1200；1366x768
and Auto for each output or all outputs to choose by pressing the "Up" or "Down"
button, press "Enter" to confirm the selection,
Default is Auto format, The selected one has a "@" to mark.
Format interface
7.2.7 EDID
Press the "Left/Menu" on the panel to enter the "EDID" menu,
Press the "Up" or "Down" on the panel to select, press the "Enter" to confirm the
selection, the selected one has a "@" to mark.
EDID including "4k30hz" and "1080p@60" for each input or all inputs to choose,

15
Default is "4k30hz"
EDID interface
7.3. Audio Setting
7.3.1 Audio input setting
Press the "Left/Menu" on the panel to enter the "Audio" menu,
Press the "Up" or "Down" on the panel to select, press the "Enter" to confirm the
selection, the selected one has a "@" to mark,
For HDMI input, there is "CH2.0" and "CH5.1" to choose, default
is CH2.0, Support digital audio 5.1 channel only when input is HDMI.
Audio input setting interface

16
7.3.2 Audio output setting
Press the "Left/Menu" on the panel to enter the "Audio" menu,
Press the "Up" or "Down" on the panel to select,press the "Enter" to confirm the
selection, the selected one has a "@" to mark.
For each output or all outputs, there are "Mute" and "Delay" to choose,
The default settings is Unmute and Delay 30ms.
Audio output setting interface
7.4. System Setting
7.4.1 Baud rate
Press the "Left/Menu" on the panel to enter the "Setup" menu then the "Baud" menu,
Press the "Up" or "Down" on the panel to select, then press the "Enter " to confirm,
The selected one has a "@" to mark.
It contains 4 kinds of Baud rate including "115200/57600/19200/9600 " to choose.
Baud rate interface

17
7.4.2 TCP/IP setting
Press the "Left/Menu" on the panel to enter the "TCP/IP" menu,
Press the "Up" or "Down" on the panel to select, then press the "Enter " to confirm,
The selected one has a "@" to mark.
It contains set up for " DHCP ON/OFF "; "IP Address"; Mask"; "GW"; "DNS",
Eg: IP address setting:
1. Modify the IP to 192.168.1.110, press the "up" and "down" to select IP [0], IP [1],
IP [2], and IP [3] to enter the next sub-item (each sub-item can be set from 0 to 255),
press the the "up" and "down" again to select "192", "168", "1", and "110"
respectively, and click "ENTER" to confirm.
2. After confirming the IP address, press the "up" and "down" keys to select "Apply",
and press the "ENTER" to enter and select "YES" to check whether the modification
is successful.
Note: 1. The operation steps of IP / MASK / GW / DNS setting are basically the same;
2. The above parameters can be modified manually under static DHCP, otherwise it
cannot be modified.
3. The modified parameters need to conform to the network protocol, otherwise it
cannot be modified and it will only display "Setting IP error" in the interface.
TCP/IP main interface
DHCP ON/OFF

18
IP address
Mask address
Gateway address
DNS Interface

19
7.4.3 Reboot
Press the "Left/Menu" on the panel to enter the "Reboot" menu,
Press the "Up" or "Down" on the panel to select "Yes" or "No" , then press the "Enter
" to confirm, the selected one has a "@" to mark.
Reboot interface
7.4.4 Factory reset
Press the "Left/Menu" on the panel to enter the "Factory" menu,
Press the "Up" or "Down" on the panel to select "Yes" or "No" , then press the "Enter
" to confirm, the selected one has a "@" to mark.
Factory reset interface
7.4.5 System information
Press the "Left/Menu" on the panel to enter the "INFO" menu,
Press the "Enter " to check the current setting of the device,
It Contains "System" and "IP"specific information.

20
Info interface
System information
IP information
7.5. Web Control
The host computer such as PC is connected to the control device through the TCP/IP
network port.
The control mode is divided into two types: connect with a computer without network
for single device control or connected to the LAN to realize multi-machine control
simultaneously
Control without network:
When the host computer is connected to a computer without network through the
TCP/IP port, the host computer is consistent with the control computer network
segment. It can be controlled by direct connection; when the network segment is
inconsistent, the network segment should be same for the control computer as the host
computer
