Splitvolt EGB 11-016 Setup guide

Splitvolt™ Extension and Adapter Cables
QuickStart User Guide
Extension models: EGB 11-016 / EGB 22-016 / EGB 33-016
Extension models: EGB 11-026 / EGB 22-026 / EGB 33-026
Adapter models: AGB 12-003 / AGB 31-003 / AGB 23-001 / AGB 32-001
Please read this manual before use.
Splitvolt, Inc.

Splitvolt™ Extension and Adapter Cables
Splitvolt™ extension cables are the perfect companion for Level 2 fast charging of your electric vehicle (EV) at home. At 16’5”
(5 meters) or 26’3” (8 meters) long, these extension cables let you safely extend the distance between your EV and your dryer
or other 240V outlet.
Splitvolt adapter cables enable the flexibility to connect an EV charger equipped with a NEMA 10-30, 14-30, or 14-50
interface to a NEMA 10-30, 14-30, or 14-50 outlet.
Contact information
Splitvolt, Inc. Email us: [email protected]
California Visit us: www.splitvolt.com/help
Splitvolt™ Extension Cable
Models covered in this guide
Model
SKU
UPC
Male NEMA
Female NEMA
Length
Electrical
Splitvolt EGB 11-016
EGB-11-016-30A-00
850019012606
10-30
10-30
16’5”
(5 meters)
220V - 240V 30A
Splitvolt EGB 11-026
EGB-11-026-30A-00
850019012637
10-30
10-30
26’3”
(8 meters)
220V - 240V 30A
Splitvolt EGB 22-016
EGB-22-016-30A-00
850019012613
14-30
14-30
16’5”
(5 meters)
220V - 240V 30A
Splitvolt EGB 22-026
EGB-22-026-30A-00
850019012644
14-30
14-30
26’3”
(8 meters)
220V - 240V 30A
Splitvolt EGB 33-016
EGB-33-016-50A-00
850019012620
14-50
14-50
16’5”
(5 meters)
220V - 240V 50A
Splitvolt EGB 33-026
EGB-33-026-50A-00
850019012651
14-50
14-50
(26’3”)
(8 meters)
220V - 240V 50A
If you’re using a standard 30-amp dryer plug, choose the length of the extension 16’5” (5 meters) or 26’3” (8 meters) model
whose male end corresponds to your plug type (NEMA 10-30 or 14-30). If your electrician has installed a standard 50-amp
circuit, choose one of the 14-50 models.
Splitvolt, Inc. 2

Features and capabilities
●Convenience: the long 16’5” (5 meters) or 26’3” (8 meters) extension cable gives you more flexibility in charging your EV
●Connects to 240V NEMA 10-30 or 14-30, 30 amp dryer found in most homes, or NEMA 14-50 outlet if you have upgraded
50 amp circuitry
●Cable specification: STW-10AWG (30 amp) or STW-8AWG (50 amp), ensuring all-weather use
●Safety certifications: UL certified components
●Warranty: a full 1-year warranty is included
●Ease of use: just plug it into your dryer plug or other 240V outlet and connect it to your EV charger
Specifications
Description
EGB 11-016, EGB 11-026
EGB 22-016,
EGB 22-026
EGB 33-016, EGB 33-026
Length
16’5” (5 meters) (EGB 11-016, 22-016, 33-016)
26’3” (8 meters) (EGB 11-026, 22-026, 33-026)
Interfaces
(1 male, 1 female)
NEMA 10-30
NEMA 14-30
NEMA 14-50
Cable type
STW service: elastomer oil resistant jacket, all-weather
Certification
UL certified components
Color
Black
Wire gauge
10AWG
8AWG
Wire diameter (per solid conductor)
2.588 mm
3.264 mm
Wire cross-sectional diameter
5.261 mm2
8.367 mm2
Splitvolt, Inc. 3

Splitvolt™ Adapter Cable
Models covered in this guide
Model
SKU
UPC
Male NEMA
Female NEMA
Length
Electrical
Splitvolt AGB 12-003
AGB-12-003-30A
850019012705
14-30
10-30
1’7”
(.5 meters)
220V - 240V 30A
Splitvolt AGB 31-003
AGB-31-003-30A
850019012712
10-30
14-50
1’7”
(.5 meters)
220V - 240V 30A
Splitvolt AGB 23-001
AGB-23-001-50A
850019012071
14-50
14-30
1’7”
(.5 meters)
220V – 240V 50A
Splitvolt AGB 32-001
AGB-32-001-30A
850019012088
14-30
14-50
1’7”
(.5 meters)
220V – 240V 30A
Features and capabilities
●Convenient 1’7” (half-meter) length
●Allow connectors to be adapted from NEMA 14-30 to 10-30, NEMA 10-30 to 14-50, NEMA 14-50 to 14-30, or NEMA 14-30
to 14-50.
●NOTE: When using an AGB 31-003 or AGB 32-001 adapter cable you must manually set your car / EV charger to a
maximum charge rate of 24 amps.
●Cable specification: STW-10AWG (30 amp) or STW-8AWG (50 amp), ensuring use in all-weather conditions
●Safety certifications: UL certified components
●Warranty: a full 1-year warranty is included
●Ease of use: just plug it into your dryer plug or other 240V plug and connect it to your EV charger
Splitvolt, Inc. 4

Specifications
Description
AGB 12-003
AGB 31-003
AGB 23-001
AGB 32-001
Length
1’7” (.5 meters)
Interfaces
Male 14-30 x Female 10-30
Male 10-30 x Female 14-50
Male 14-50 x Female
14-30
Male 14-30 x
Female 14-50
Cable type
STW service: elastomer oil resistant jacket, all-weather
Certification
UL certified components
Color
Black
Wire gauge
10AWG
10AWG
8AWG
10AWG
Wire diameter (per solid
conductor)
2.588 mm
3.264 mm
5.264 mm
5.264 mm
Wire cross-sectional diameter
5.261 mm2
8.367 mm2
18.5 mm
18.5 mm
Disclaimers, Warranty, and Troubleshooting
Disclaimers
By using this product, you acknowledge that it is an early-release version that it is made up of UL certified components.
Extension cables should be protected from cuts, puncture, sharp bends, crushing weight, or excessive exposure to weather. They should never be
submerged in water. If you suspect an extension cord has been damaged, immediately cease use and replace it or have it inspected by a qualified
electrician.
Using extension cables with 240V power over long distances, or daisy-chained together, may reduce voltage outside of the 220V-240V operating
range.
The EGB 11 and EGB 22 models of this product are designed to operate at a maximum continuous charging rate of 24 amps on a standard
household 30-amp circuit, according to the National Electrical Code (NEC). Exceeding this rate can lead to damage or risk of fire.
The EGB 33 models are designed to operate at a maximum continuous charging rate of 40 amps on a standard household 50-amp circuit, according
to the National Electrical Code (NEC). Exceeding this rate can lead to damage or risk of fire.
When using an AGB 31-003 and AGB 32-001 adapter cables you must manually set your car / EV charger to a maximum charge rate of 24 amps.
Failure to do so can result in over-powering of the circuitry and tripping of your home electrical breaker, or risk of fire.
These products are for use with standard home wiring that is built and maintained to the latest National Electrical Code (NEC) safety standards. If
you suspect that your home wiring does not meet code, or is worn-out or damaged in some fashion, contact an electrician for a safety inspection
prior to using this product.
1-year limited warranty
Splitvolt, Inc. warrants that this product shall be free from defects in material, workmanship, and assembly under normal use in accordance with
the specifications and warnings for a period of one year from the date of purchase. This warranty does not cover damages as a result of an
accident; resulting from the use or misuse of parts not manufactured or sold by Splitvolt, Inc; or resulting from modification of the Splitvolt
Extension Cables and Adapters.
These warranties extend only to the original purchaser of the product and are non-transferable. To exercise your rights under this warranty, you
must provide proof of purchase in the form of an original sales receipt that shows the product name, model number, amount paid, payment
method, and date of purchase. These warranties apply only to original purchasers of Splitvolt Extension Cables and Adapters for personal, family,
or household use, not to commercial, institutional, or industrial purchasers.
These warranties are valid only in the United States. In no event shall Splitvolt, Inc. be liable for any direct, indirect, incidental, special,
consequential, or multiple damages arising out of the use or misuse of the Splitvolt Extension Cables and Adapters.
Troubleshooting
If you are experiencing difficulty, please check our website (www.splitvolt.com/help), and then contact us if you are still
unable to resolve.
Splitvolt, Inc. 5

Need more help?
Please visit www.splitvolt.com/help or email [email protected]om.
