Splitvolt SPS 01-031-30A-01 Setup guide

Splitvolt™ Splitter Switch™
QuickStart User Guide
Applies only to Splitter Switch Model: SPS 01-031-30A-01
Please note that this User Guide applies only to the model numbers listed above.
Thank you for choosing the Splitvolt™ Splitter Switch™! Charging your electric vehicle (EV)
just got easier!
The Splitter Switch allows you to share your existing 240V dryer circuit safely and
automatically with your dryer and EV charger to get Level 2, fast home charging, but avoiding
the high cost and complexity of having an electrician install a new, dedicated 240V charging
circuit.
The Splitter Switch switches full power between your EV charger and clothes
dryer—automatically provides power for EV charging any time the dryer is not running.
This new category of product can save you thousands of dollars and weeks of time. Just plug
it in, and Splitvolt monitors, displays, and switches full 24-amp power on-demand between
Copyright © 2022 Splitvolt, Inc. All rights reserved.

attached devices, providing the fastest possible safe charging on a standard 30-amp circuit,
at a fraction of the cost of installing a new, dedicated circuit in your home.
Please read this manual before use.
Contact information
Splitvolt, Inc. www.splitvolt.com
Santa Clara, California www.splitvolt.com/help
Splitvolt Splitter Switch
QuickStart User Guide
Models covered in this guide
Model
SKU
UPC
Wall Plug
Pigtail
Connector
(Male)
Dryer Socket
Connection (L,
Female)
EV Socket
Connection (R,
Female)
SPS 01-031
SPS-02-031-30A-01
850019012064
NEMA 10-30
NEMA 10-30
NEMA 14-50*
NOTE: * When connecting a NEMA 14-50 EV charger to this device, you must restrict the charging rate on either the EV or
EV charger to 24 amps.
When connecting a NEMA 14-50 EV charger to this device, you must manually
restrict the charging rate on either the EV or EV charger to 24 amps in order to
stay within the maximum safe charging rate and avoid tripping the safety
circuit breaker. This model is not safety certified. If safety certification is
important to you, please visit our store and select one of our safety certified
Splitter Switch products.
2
Splitvolt, Inc.

Be sure to select the right model based on your wall socket, dryer plug, and EV socket type
according to the photo above. You can reference the socket-type images in the diagram to
determine which type you have if you are unsure. Contact www.splitvolt.com/help with any
questions.
Features and capabilities
●Automated power switching between dryer and EV power sockets
●Full-color display screen and LED status lights
●Real-time voltage, current, temperature, kWh, and status indicators
●Integrated 25-amp circuit breaker with easy reset for added protection
●Optional manual power-off switch for extra safety and convenience
●Supports standard 30-amp dryer circuits (maximum 24-amp NEC safe charging rate)
●Compatible with common 3rd-party electric vehicles and chargers
●Supports common household dryer (10-30) and charger (14-50) plug types
●The NEMA 14-50 plug is for convenient access to common charger plugs; the maximum
safe charging rate on the socket is 24 amps
●Integrated wall-mount screw holes and 3.3 ft (1 m) pigtail plug for easy installation
Get to know your Splitvolt Splitter Switch
●Automatic safety circuit breaker
●3-line color LCD real-time power display
●Displays real-time watts, amps, volts, and accumulated kWh
●Optional manual power-off switch
●Resettable accumulated kWh — use a pen to press and hold the flat reset button
on the right side of the screen for 5 seconds
●LED indicator: ON indicates EV charger (EVSE) has power
●Left outlet: for electrical appliance (dryer)
3
Splitvolt, Inc.

●Right outlet: for EV charger
Specifications
Wall Plug Pigtail Connector
NEMA 10-30 Male for SPS 01-031-30A-01
Dryer Socket Connector (left socket)
NEMA 10-30 Female for SPS 01-031-30A-01
EV Socket Connector (right socket)
NEMA 14-50 Female for SPS 01-031-30A-01
Safety Circuit Breaker
240VAC, 25A
Nominal Input
240VAC, ~60Hz
Maximum Continuous Load
240VAC, 24A
Rated Impulse Voltage
4000V
Dust and Water protection
Indoor Use Only
Case Flammability Safety Rating
UL-94 V0
LED Indicator (Lit)
EV Socket Power On
Ambient Operating Temperature
-20°C to +50°C
Unit Weight
6.7 lb (3.04 kg)
Unit Dimensions
12" x 8.5" x 4" (30.5 x 21.6 x 10.2 cm)
Package Dimensions
14" x 14" x 7" (35.5 x 33 x 17.8 cm)
Package Shipping Weight
8.7 lbs
Limited Warranty
1 Year Standard
Safety Certification
This model is not safety certified. If safety
certification is important to you, please visit our
store and select one of our safety certified
Splitter Switch products.
Quick start
1. Plug the SPS into the 240VAC, 30A dryer wall outlet
2. Plug the dryer into the left outlet labeled “Dryer” of the SPS
3. Plug the EV charger into the right outlet labeled “EV” of the SPS
4. If using NEMA 14-50, restrict amps to 24 amps on either your EV charger or vehicle
5. Switch the circuit breaker to the ON position
4
Splitvolt, Inc.

Optional wall mount
The unit may operate on a shelf or dryer, but for convenience, screw holes and mounting
hardware has been provided if optional wall mounting is desired.
1. Position the SPS so that the plug reaches the wall outlet
2. Mark screw holes
3. Unplug the SPS
4. Use 5/16” or 8 mm drill bit to create drill holes
5. Push the supplied 5/16” x 1.5” (8 mm x 38 mm) anchors into the drill holes
6. Secure the SPS into anchors with supplied screws
Disclaimers
This product is intended for indoor use and must be protected from moisture and the elements to maintain
safety, durability, and preserve warranty coverage.
This model is not safety certified. If safety certification is important to you, please visit our store and select
one of our safety certified Splitter Switch products.
Note that power is prioritized to your dryer, so some special low-power dryer features (such as wrinkle
guard) may interfere with the operation of either your Tesla EV charger or your SPS unit, and therefore is not
supported or recommended. Contact www.splitvolt.com/help with any questions or for more information.
This product is designed to operate at a maximum continuous electric vehicle charging rate of 24 amps on a
standard household 30-amp circuit. According to the National Electrical Code (NEC), exceeding this rate is
unsafe. It can trip the Splitter Switch internal safety circuit breaker, cutting off power, in order to reduce risk
of damage or risk of fire. Contact an electrician if you ever have questions about local safety codes, or if you
are unsure of the condition of your wiring.
5
Splitvolt, Inc.

DO NOT DISASSEMBLE. OBSERVE ALL WARNING LABELS. Do not remove warning labels.
Connect to a properly rated, protected, correctly sized power circuit which has been installed to local safety
code standards.
If an electrical supply line, connectors, or other circuit elements are worn or damaged, do not use and
consult a qualified electrician. The Splitvolt Splitter Switch is intended only for use with electrical circuits and
wiring that is in good condition and meets local building safety codes.
Set your EV charger or EV to a maximum charge rate of 24 amps for EV chargers using NEMA 14-50
connectors.
This product is not intended for use with NEMA or other plug adapters.
Includes 1-year limited warranty (optional extended warranties are available)
Splitvolt, Inc. warrants that this product shall be free from defects in material, workmanship and assembly,
under normal use, in accordance with the specifications and warnings, for a period of one year from the
date of purchase. This warranty does not cover damages as a result of an accident; resulting from the use or
misuse of parts not manufactured or sold by Splitvolt, Inc; or resulting from modification of the Splitvolt
Splitter Switch.
These warranties extend only to the original purchaser of the product and are non-transferable. To exercise
your rights under this warranty, you must provide proof of purchase in the form of an original sales receipt
that shows the product name, model number, amount paid, payment method, and date of purchase. These
warranties apply only to original purchasers of Splitvolt Splitter Switch for personal, family, or household
use, not to commercial, institutional, or industrial purchasers.
These warranties are valid only in the United States. In no event shall Splitvolt, Inc. be liable for any direct,
indirect, incidental, special, consequential, or multiple damages arising out of the use or misuse of the
Splitvolt Splitter Switch devices.
Troubleshooting
The following table identifies steps for troubleshooting the operation of the device. If you
are experiencing difficulty, please review the table below, check our website
(www.splitvolt.com), and then contact us at www.splitvolt.com/help if you are still unable to
resolve or have additional questions.
Issue
Resolution
Splitter Switch’s LED and LCD
are not turning on
Is power available?
1. Check that the wall socket has power
2. Check that the wall plug is plugged in fully
3. Check that the built-in breaker is in ON position
The wall socket seems to be
upside down
There is no universal orientation for NEMA plugs, so yours could be
upside down. Just plug it in anyway.
The pins on the cable do not
match my wall socket
It is possible that the wrong model was ordered. Please contact
www.splitvolt.com/help for assistance.
Not getting power from either
one of the sockets
Double-check all plugs are pushed in completely. Note that the “EV”
socket will not have power when the “Dryer” socket is active.
6
Splitvolt, Inc.

Splitter switch is not turning off
the EV Socket when dryer is
running
1. Turn Off/On the internal circuit breaker switch and verify
whether this corrected the issue.
2. Check your house power panel for a partially tripped circuit
breaker by turning On/Off the appropriate breaker, verify.
3. Confirm what type of dryer you have. If you have a gas line
running into the dryer, you have a gas dryer (even if it is plugged
into a NEMA 10-30 or NEMA 14-30 plug).
4. Turn off energy saver mode on your dryer. Does the splitter
switch turn off the EV socket? If so, you have a rare
high-efficiency dryer that downshifts to 120V during part of the
cycle.
Please contact www.splitvolt.com/help immediately for assistance.
Hear a buzzing sound coming
from splitter switch
Turn off the breaker and turn it back on. The contacts may have
become misaligned. Powering on/off will help it self-realign.
My Tesla has an alert saying
“Unable to AC charge – Unplug
and retry”
Simply unplug/replug-in the charger handle to the vehicle to continue
charging. NOTE: Some special high-efficiency sensor dryer settings
may cause multiple switching, triggering the Tesla charger power
protection fault to pause charging. It is recommended that Tesla users
do not use special low-power dryer settings when charging.
My internal safety breaker
keeps tripping off
Verify that your EV or EV charger is only charging at 24 amps. If it is
not, set it to charge at only 24 amps or less. If you are unable to
change this setting, or/and the internal breaker keeps tripping, please
contact us at www.splitvolt.com/help.
Need more help?
Please visit www.splitvolt.com/help for information and assistance.
