Spracht Blunote Buds TW User manual
Blunote Buds TW™
True Wireless Bluetooth®Ear Buds
with Recharger Case
U G
English
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
CONTENTS
Features 1
Powering On Stereo Mode, Method 1 1
Powering On Stereo Mode, Method 2 2
Powering On Stereo Mode, Method 3 2
Reconnecting 3
Using Only One Bud 3
Powering Off 3
Using Voice Commands 4
Left/Main and Right/Second Buds 4
Charging 4
Notes 5
Table of Ear Bud States 6
Warranty 7
FEATURES
Thanks for choosing Blunote Buds TW™. It’s important to
read this User Manual: it will help you connect the Buds
and pair with your Bluetooth™ device.
• Bluetooth® V4.1 + EDR
• To enhance your music listening experience, the Buds
feature a high quality, embedded 48 MIPS dual-MAC
DSP co-processor
• Support for noise reduction and echo cancellation
• Recharger battery case (650mAh) to charge Buds on
the go
• Play time up to 2.5 hours on one charge
• You have the option of three methods to pair Buds
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
➊ Red and blue LED indicator
➋ Multi Function Button (MFB)
➌ Microphone
➍ Charging and power capacity indicator LEDs
➎ On-O switch
➏ Micro USB
POWER ON/OFF AND CONNECT
IMPORTANT Before using the Buds for the first time,
make sure to fully charge the Buds in the case. When the
Red LEDs on the Buds turn off and the Blue LEDs turn on,
the Buds are charged. When all 4 Blue LEDs on the case
are lit up, it indicates the case is fully charged;.
P O I S M —M 1
This method allows you to hear the voice prompts while
you are setting up the buds.
1. You can either put both buds in your ear to start with,
or put just the Left Ear Bud in your ear. Press the Multi
Function Button (MFB) for 3 seconds, then release: you
will hear “Power On”.
Note: If you want to see the LEDs to confirm the Buds
➊➊
➋➋
➌
➍➎
➏
1
Correct Bud placement
with mic facing forward
Note: the Buds
are marked L
and R on their
back sides
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
are in pairing mode, you’ll have to take them out of your
ears. The Blue and Red LEDs will be flashing alternately.
2. Confirm that Bluetooth® on your phone/tablet is turned
on. Look for available Bluetooth® devices. You should
see Blunote Buds TW:choose that one. You will hear
“Pairing”, then “Pairing Successful”, and “Connected”.
3. If you haven’t already, place the Right Bud in your ear.
Press the Multi Function Button (MFB) for 3 seconds,
then release: you will hear “Power On”. As soon as
the Second Bud connects with the Main, you will hear
“Connected”. Each Bud will announce which it is: Right
Channel for the Right Bud and Left Channel for the Left.
P O S M —M 2
1. Take the Buds out of the case. Press the Multi Function
Button (MFB) on both Buds for 3 seconds, then release:
the blue LEDs will flash 3 times.
2. Double press both Buds. After a few seconds, the Left/
Main Bud will begin to connect to the Right Bud. When
they have successfully connected, the Left Bud’s LEDs
will alternately flash blue and red. On the Right Bud
only the blue LED will flash.
3. The Left Bud will now enter pairing mode.
4. Confirm that Bluetooth® on your phone/tablet is turned
on. Look for available Bluetooth® devices. You should
see Blunote Buds TW:choose
that one. Your phone/tablet
should now be connected to the
Ear Buds.
P O S M —
M 3
1. With the Buds in the case, turn the switch to the left
(ON) and wait for 5 seconds. The blue LEDs on the
2
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
3
case will turn off.
2. Slide the switch to the right; the Buds power on.
Double press both Buds. The Left/Main Ear Bud will
connect to the Right Ear Bud. The LED on the Left Ear
Bud will flash alternately blue and red indicating a
successful connection.
3. Confirm that Bluetooth® on your phone/tablet is turned
on. Look for available Bluetooth® devices. You should
see Blunote Buds TW:choose that one. Your phone/
tablet should now be connected to the Ear Buds.
A V Use your phone or tablet’s volume
settings to adjust the volume
on your Buds.
R Once you
have paired using any method,
your Buds will remember the
phone/tablet they were paired to last. To reconnect,
take both Buds out of the case or turn on both units (by
pressing the MFB for 3 seconds), and the Left/Main Bud
will re-pair automatically, and the Right/Second Bud will
connect to the Left automatically.
U O O B
1. Turn on the Bluetooth®device you want to pair.
2. Power on the Bud by pressing and holding the MFB for
3 seconds until the blue LED flashes.
3. When the blue and red LEDs flash alternately, select
Blunote Buds TW on your phone/tablet’s Bluetooth® list.
4. The LEDs will stop flashing, indicating your device
is paired.
IMPORTANT: If you use just one bud, first in Single Ear
Mode, and then want to use both Buds at the same time
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
in Stereo Mode later, please note that you must pair the
LEFT/Main Bud first. If you pair the Right Bud first, the
Left one will not connect afterwards in Stereo Mode.
You will need to start over by deleting your old profile in
your phone/tablet, turn o/restart your device, and then
start the pairing process from the beginning.
P O press the MFB on either Bud until you hear
the voice confirmation of “Power Off”.
U V C
Press and hold the MFB on the Left/Main Bud for 3-4
seconds to enter voice command mode.
L/M R (S) B
The Buds are marked R and L on their back sides.
1 –While pairing, the Bud that alternately flashes both
the blue and red LEDs is the Left/Main.
2 –If you double click the MFB, the Bud which can redial
the last number is the Left/Main.
3 –If you make a phone call, you will only hear the voice
at the other end through the Left/Main Bud.
The Left channel is the Left/Main Bud, the Right channel
is the Right/Second Bud.
N If the Left Bud re-pairs with your device and is
playing music, but the Right Bud is not playing because
it’s not connected with the Left/Main Bud, turn o both
units and start the pairing and connecting process from
the beginning.
C
1. Put the Buds in the case and slide the switch to the
left. The red LEDs on the buds will light up, indicating
they’re charging.
2. When the red LED turns o, and the Blue LED turns
on, the charge is complete.
4
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
3. There are also 4 blue LEDs on the case indicating the
charge level in the case. When all 4 are on, the case is
fully charged.
NOTES
1. Whether using both Buds or only a single one, the
pairing time is 120 seconds.
2. If the Buds don’t connect with a phone, tablet or other
Bluetooth® device they will power off after 5 minutes.
3. When using the Buds as a pair, if the Left/Main Bud
fails to connect with the Right Bud, you will need to
reset them by powering them off and back on.
4. If you’re using a single Bud connected to one phone/
tablet and you want to pair the other one to a dierent
device, make sure the buds are separated by 33' (10m)
before attempting to pair the second device.
5. If you want to pair the Buds with a new phone/tablet,
you need to first turn o both Buds, and delete the
profile in the Bluetooth® settings in your original
device. This is especially true if your devices are within
33’ (10M) of each other, the Bluetooth® range. You can
then follow the Power On instructions to pair with the
new device.
6. If you are using the buds as a set, only the Left/Main
Bud can be used to answer calls, or reject, cancel
and redial calls. You will hear the voice on a call only
through the Left Bud; the Right will be inactive.
7. To charge the Buds, place them in the case, slide the
switch to the left (ON), and plug the USB cable into a
power source.
8. Use the recharge battery case to charge your Buds
on the go. The blue LEDs on the case will indicate
how much charge is left (1 is the lowest level, 4 is fully
charged, no LED lights means recharge the case).
5
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
Ear Bud State Button
Action
Result Voice Prompt LEDs
Power O Press/
hold 5s
Power On Power On Blue LED
flashes 3x
Power On Press/
hold 5s
Power O Power O Blue LED
flashes 3x
Connected Press Play/Pause No Change
Incoming Call Press Answer Call Answer
Call Active Press End Call Call Ends
Outgoing Call Press Cancel Call Cancel the
Call
Connected/
Music
Press 2x Last # Redial Last Redial
Incoming Call Press 2x Reject Call Reject the
Call
Incoming Call Call from
Phone #
Enter Pairing
Mode
Press 2x Enter TWS
Pairing
Mode
Pairing
Left/Right
Connect
Left Channel
Right Channel
6
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
Warranty Information
All information is believed to be reliable, however specifications are subject
to change without notice.
Spracht warrants its products against defects or
malfunctions in material and workmanship under normal
use and service, with the exceptions stated below. This
warranty lasts for one year from the original date of
purchase. Coverage terminates if you sell or otherwise
transfer the product. In order to keep this warranty in
effect, the product must have been handled and used as
prescribed in the instructions accompanying the product.
Spracht shall (at its option) repair or replace a defective
unit covered by this warranty, or shall refund the
product purchase price. Repair, replacement with a
new or reconditioned unit, or refund, as provided under
this warranty, is your exclusive remedy. This warranty
does not cover any damages due to accident, misuse,
abuse, or negligence. Spracht shall not be liable for
any incidental or consequential damages. Some states
do not allow limitation or exclusion of incidental or
consequential damages, so the above limitation or
exclusion may not apply to you.
To make a warranty claim, the purchaser must obtain
a return authorization number (RA) from Spracht (serial
number and purchase date required), and then return
the product to Spracht at purchaser’s expense. A copy
of the original dated receipt or shipping document must
accompany the product. To obtain a return authorization,
see “Warranty” on our website at www.spracht.com, send
Spracht
974 Commercial Street, Suite 108
Palo Alto, CA 94303 USA
Ph: 650-215-7500 Fx: 650-485-2453
For repair or replacement of a failed product, allow 4 to 6
weeks for processing and shipment. This warranty gives
you specific legal rights, and you may also have other
rights which vary from state to state.
rev 2 7
Blunote Buds TW™ Wireless Bluetooth® Ear Buds
Spracht
974 Commercial Street, Suite 108
Palo Alto, CA 94303
www.spracht.com
© Copyright 2017 Spracht®. All rights reserved. Spracht®
and the logo, and Blunote Buds TW are trademarks and
registered trademarks of Spracht®. Any other trademarks
are properties of their owners.
