JBL Harman Tune Buds User manual

quick
start
guide
quick
start
guide

S / m / l
WHAT’S
IN THE
BOX

APP
GET EVEN MORE CONTROL AND PERSONALIZATION OF YOUR
LISTENING EXPERIENCE WITH THIS FREE APP.
JBL Headphones

how
to
wear 2
S / m / l
1 Try different sizes for a perfect fit and audio performance.
APP
GET EVEN MORE CONTROL AND PERSONALIZATION OF YOUR
LISTENING EXPERIENCE WITH THIS FREE APP.
JBL Headphones

Choose "JBL TUNE BUDS" to connect
Settings Bluetooth
Bluetooth
DEVICES
Now Discoverable
Connected
JBL TUNE BUDS
OTHERS Android™ 6.0+ Windows 10 v1803+
ON
ON
power
on &
CONNECT
JBL TUNE BUDS
JBL TUNE BUDS will appear on
devices linked with
my [email protected]
Microsoft Swift Pair
JBL TUNE BUDS
First
time
use

Choose "JBL TUNE BUDS" to connect
Settings Bluetooth
Bluetooth
DEVICES
Now Discoverable
Connected
JBL TUNE BUDS
OTHERS Android™ 6.0+ Windows 10 v1803+
ON
ON
power
on &
CONNECT
JBL TUNE BUDS
JBL TUNE BUDS will appear on
devices linked with
my [email protected]
Microsoft Swift Pair
JBL TUNE BUDS

MULTI-POINT CONNECTION
Tap × 1
HOLD (5S)
(Maximum 2 devices)
L/r
DUAL CONNECT + SYNC
Stereo Mode Mono Mode
L/RrL

MULTI-POINT CONNECTION
Tap × 1
HOLD (5S)
(Maximum 2 devices)
L/r
DUAL CONNECT + SYNC
Stereo Mode Mono Mode
L/RrL

CONTROLS
L r
BIXBY/SIRI®/OTHERS BIXBY/SIRI®/OTHERS
* Enable advance controls by connecting your JBL Tune BUDS to JBL Headphones App .
** ENABLE YOUR VOICE ASSISTANT THROUGH JBL HEADPHONES APP AND ASSIGN IT TO YOUR PREFERRED EARBUD (L/R).
ANC* Ambient Aware*
TALKTHRU*
Tap × 1
Tap × 2
Tap × 3
HOLD (2S)
Voice AssistantS**
Ok Google

VOICEAWARE

FACTORY RESET
L/R
Tap × 2
HOLD (5S)
power off

FACTORY RESET
L/R
Tap × 2
HOLD (5S)

15 4
Charging
DO MORE WITH THE APP
*
*Only available on Android™

15 4
Charging
DO MORE WITH THE APP
*
*Only available on Android™

TECH
SPEC
led behaviors
BT connecting
BT connected
BT not connected
CHARGING
LOW BATTERY
FULLY CHARGED

TECH
SPEC
Model: TUNE BUDS
Driver size: 10 mm/ 0.39”Dynamic Driver
Power supply: 5V 1 A
Earbud:
5.4 g per pc (10.8 g combined)/
0.012 lbs per pc (0.024 lbs combined)
Charging case: 42 g/ 0.093 lbs
Earbud battery type: Lithium-ion Battery (70 mAh/ 3.85 V)
Charging case battery type: Lithium-ion Battery
(750 mAh/ 3.7 V)
Charging time: 2 hrs from empty
Music playtime with BT on
and ANC o: Up to 12 hrs
Music playtime with BT on
and ANC on: Up to 10 hrs
Talk time with ANC on: Up to 6 hrs
Talk time with ANC o: Up to 6.6 hrs
Frequency response: 20 Hz – 20 kHz
Impedance: 32 ohm
Sensitivity: 101 dB SPL@1 kHz
Maximum SPL: 93 dB
Microphone sensitivity: -38 dBV/Pa@1 kHz
Bluetooth version: 5.3
Bluetooth prole version: A2DP V1.3.2, AVRCP V1.6.2, HFPV1.8
Bluetooth transmitter
frequency range: 2.4 GHz – 2.4835 GHz
Bluetooth transmitter
power: <11 dBm (EIRP)
Bluetooth transmitter
modulation: GFSK, π/4-DQPSK, 8-DPSK
Maximum operation
temperature: 45 °C
led behaviors
BT connecting
BT connected
BT not connected
CHARGING
LOW BATTERY
FULLY CHARGED
IP54
