SPS HUGO User manual

HUGO User Manual
SafeGuard Power Solutions, LLC. Rev 1.3 www.safeguardpowersolutions.com

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 1
Table of Contents
PRECAUTIONS AND GENERAL GUIDELINES................................................................................................... 3
ELECTRICAL SAFETY PRACTICES .................................................................................................................... 4
ELECTRICAL SAFETY PRACTICES .................................................................................................................... 5
BATTERY WARNING ...................................................................................................................................... 5
INTRODUCTION............................................................................................................................................. 6
PACKING LIST ................................................................................................................................................ 6
KEY FEATURES ............................................................................................................................................... 6
WORKING PRINCIPLE .................................................................................................................................... 7
MOUNTING AND INSTALLATION................................................................................................................... 7
•FRONT PANEL OF UPS ....................................................................................................................... 7
•LED DISPLAY ...................................................................................................................................... 8
•INSTALLATION ................................................................................................................................... 8
FLOW SENSOR INSTALLATION .................................................................................................................... 11
NO-FLOW INSTALLATION............................................................................................................................12
TEMPERATURE SENSOR SETUP................................................................................................................... 12
HARDWIRING INSTRUCTION.......................................................................................................................13
OPERATIONS ...............................................................................................................................................14
STORAGE AND TRANSPORTATION.............................................................................................................. 15
MAINTENANCE AND TROUBLESHOOTING..................................................................................................15
1. Maintenance ...................................................................................................................................15
2. Troubleshooting.............................................................................................................................. 16
TECHNICAL SUPPORT ..................................................................................................................................17
REGISTER YOUR HUGO................................................................................................................................17
TECHNICAL SPECIFICATIONS ....................................................................................................................... 18

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 2
IMPORTANT
Read this User Manual carefully before operation.
•Retain this manual for future reference.
•It is prohibited to connect any appliance or electrical load other than those for which this
product is intended.
NOTE: Throughout this document the HUGO-X1R (Uninterruptible Power Supply) may also be
referred to as "UPS".

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 3
PRECAUTIONS AND GENERAL GUIDELINES
The basic condition for safe use and proper operation of the UPS is the knowledge and attention to
the safety information provided in this manual.
The following safety information must be observed by all persons who will work with the UPS.
This symbol is used to call your attention to hazards or unsafe practices which
could result in an injury or property damage. The symbol, defined below, indicates
the severity of the hazard. The message after the symbol provides information for
preventing or avoiding the hazard.
WARNING Hazards which, if not avoided, COULD result in severe injury or death.
CAUTION Hazards or unsafe practices which, MAY result in injury or property
damage.
WARNING
•Read all safety warning and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or
serious injury.
•Save all warnings and instructions for future reference.
HUGO recommends the UPS be used with all installed safety features. Customer
assumes all liability for injury that could result from improper use of this UPS and
responsibility for all necessary training to ensure safe operation of this UPS.
For installation and use by trained personnel only.
If any damage to the product is apparent or suspected, do not use the product. Refer
product to qualified service personnel.
FCC WARNING: Changes or modifications to the product could void the user’s authority
to operate the product.
Use recommended accessories. Consult the owner’s manual for recommended
accessories. The use of improper accessories may cause risk of injury to person.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 4
ELECTRICAL SAFETY PRACTICES
GROUNDING:
In the event of a malfunction or breakdown, grounding provides a path of least resistance
for electric current which reduces the risk of electrical shock.
Improper connection of the equipment grounding conductor can result in a risk of electric
shock. The conductor with insulation having an outer surface that is green with or without
yellow stripes is the equipment-grounding conductor.
Check with a qualified electrician, or service personnel if the grounding instructions are not
completely understood; or if in doubt as to whether the UPS is properly grounded.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
DO NOT remove the ground connection from the UPS’s power plug.
WARNING
Use personal protective equipment. Safety glasses must be worn at all times by
all persons installing the UPS.
Have your UPS serviced by a qualified repair person using only identical
replacement part.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 5
ELECTRICAL SAFETY PRACTICES
WARNING
ONLY OPERATE THE UPS IN A CLEAN ENVIRONMENT.
DO NOT EXPOSE THE UPS INTERIOR TO RAIN OR WET CONDITIONS.
WATER ENTERING A UPS WILL INCREASE THE RISK OF ELECTRIC SHOCK.
KEEP AWAY FROM LIVE CIRCUITS
•Operating personnel must not remove covers.
•Replacement of components and internal adjustments must be made by qualified
maintenance personnel.
•Disconnect power when replacing components.
•Dangerous voltages may exist even with the power removed.
•To avoid injuries, always disconnect power and tum power switch to OFF.
•Input connection to the product must remain accessible as a disconnect device.
•DO NOT work on the product; connect or disconnect cables during periods of lightning.
•Provide wiring per national and local electrical codes.
BATTERY WARNING
•Turn off the UPS and unplug it from the AC power source before battery replacement.
•This UPS contains a sealed lead-acid battery. DO NOT open the battery.
•DO NOT short or bridge the battery terminals with any object.
•The battery must be charged within 80 days from receiving the UPS. If the UPS is stored away, it is
strongly recommended to cycle the charge within the battery every 90-120 days for battery to maintain
its optimum performance.
•Ensure to charge the battery fully with each charge. Battery damage may occur if these instructions are
not followed.
•Before replacing battery, make sure the replacement battery has the same charging voltage (12V/38 Amp
Hours.) If any doubt, contact the manufacturer.
•Once the battery has reached the end of its life, properly dispose of the battery. REFER TO YOUR LOCAL
LAWS AND REGULATIONS FOR BATTERY DISPOSAL REQUIREMENTS.
•DO NOT alter the system in any way.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 6
INTRODUCTION
The new and improved HUGO-X1R is a 350W interruptible power supply (UPS) that is designed to
support gas tankless water heaters, direct vent space heaters, vent free space heaters, boilers,
furnaces, or any other gas-powered appliances. The UPS can also be used to charge mobile devices
such as mobile phones, tablets, laptops, modems, and routers.
NOTE: The UPS shall be used for its intended purposes listed above only. Any alternation to the
product or if used inappropriately will void all warranties. Please consult with SPS prior to any such
actions.
PACKING LIST
•HUGO Power Supply
•Flow Sensor, if applicable
•Hanging brackets (4)
•Wall mount screws and anchor (4 sets)
•Bracket screws (9)
•User Manual (1)
•Door Key (1)
•Rubber pads to support floor standing installs (4)
KEY FEATURES
•Low output harmonic
The output wave form is pure sinewave, the harmonic is at minimal.
•IntelligentMCU Technology
The intelligent MCU (Micro-Computing Unit) automatically monitors the input voltage surge,
sags, break, output loads and battery status, providing the downstream application with
maximum protections.
•HighlyReliable
The UPS constantly monitors input voltage for surge, sags, or breaks, whenever such occurs, the
UPS will transfer to battery mode within 15ms. It will also constantly monitor output load to
prevent over-load and provide LED indications and chirp sequence alarm to alert user of such
event. The UPS is also built with self-protect and self-reset functions.
•DC Start and Restart
The UPS is capable to switch on from the battery mode without city power, it will also automatically
re-start after 10 minutes of the city power source is restored.
•Green Power
This series is equipped with high efficiency, EMC standard meet A class, it meets green power
standard.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 7
WORKING PRINCIPLE
When the utility power is normal, the UPS will transfer the utility power to downstream application.
During a power outage or when the utility power is below 92v or above 138v, the UPS will transfer to
inverter mode.
While in inverter mode, the UPS will monitor flow and temperature sensor (if purchased). When flow
sensor detects a demand for water, it will turn on power output to downstream application. When the
temperature senses 37deg f (+/- 2 deg f) or below, it will also override the UPS to turn on AC output. If
flow sensor does not detect a flow or if temperature is above 37 deg f, the UPS will be in standby mode.
For non-flow applications, unplug (temp.flow) port in front of inverter to allow flow sensing bypass. For
this operation, whenever utility power is lost, the UPS will provide continuous power to downstream
application immediately.
MOUNTING AND INSTALLATION
•FRONT PANEL OF UPS
1. DC input connector bar (Connected to the battery)
2.
Toggle power switch
3.
Temperature dry contact*
4.
Flow dry contact*
5.
Input/output socket
6.
Indicator lamp
Note that when the toggle power switch is in the “ON” position, voltage may still be present at
the output terminals even when the input terminals are disconnected from power. DO NOT
transport or attempt to make connections to the terminals when the toggle switch is in the
“ON” position.
*Connected by default, disconnect for no-flow installation only.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 8
•LED DISPLAY
•INSTALLATION
Ensure that the ON/OFF switch is in the “OFF” position during installation. The UPS
can store a significant amount of power for an extended period. AC/DC voltage
may be present at the output terminals even when the input terminals are
disconnected from power.
1. After unpacking the UPS, check whether there is any mechanical damage due to
transportation. If the UPS has been noticeably damaged, contact your sales
representative forassistance.
2. Tools Required
3. Remove the (4) hangers and (8) M5 screws. Tighten each hanger with (2) screws.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 9
4. Choose and prepare proper installation location. Note: Center point distance between
left and right hangers is 15.5 inches.
Warning! Ensure UPS is located above flood and snow lines. If at any time the UPS
becomes damaged due to water or other, please consult with SPS customer care.
5. Hang the UPS on a flat surface that will adequately support the weight of the UPS (45
lbs). When replacing hanger screws, please consult with professionals to use the
proper mounting screws or bolts. If the unit is to be wall mounted, it is strongly
recommended by the manufacturer to mount on wall studs or ¾” plywood panels only
due to the heavy weight of the unit (45 lbs). SPS is not liable for any installation errors
such as improper use of mounting material and/or mounting methods.
6. Using a Phillips head screwdriver, remove the wiring cover at right side of the UPS,
connect appliance to "utility output socket", Flow Sensor to "Flow signal interface" (if
applicable), as shown below:

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 10
7. Double check wiring to ensure the connection is correct, close and lock the side panel
as shown below.
8. Finally, connect HUGO’s power cord with the main power outlet. NOTE: HUGO’s rated
input and output is 115 volts, can be fitted to any circuit breaker rated 15A. Ensure all
connects are correct and that the input and output power cord is properly grounded.
9. Turn the front door cam clockwise to “OPEN” and using the supplied KEY turn the lock
counterclockwise to open the front door.
10. If the UPS is used for tankless water heaters and the flow sensor is installed, then plug
in “temp.flow” port in front of the UPS panel. Otherwise, leave this port unplugged.
11. Turn the UPS on via the toggle switch on the left side of the inverter panel. When
turned on, the unit shall chirp once, and the indicator lamp “LINE” will stay lit if utility
power is normal.
12. Indicator lamps on the front panel will display the operational status of the UPS as
shown in Table 1 above. The UPS is also equipped with chirping alerts as shown in
schedule below.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 11
At any time, the UPS detects overload or under/over voltage as indicated by the LED display or
chirping alarm, it will attempt delay restarts. Once such issue is resolved, i.e., battery charge is
normal or load is under 350w, the UPS will automatically restart and remove any fault
indicators.
FLOW SENSOR INSTALLATION
•NOTE: Before installing the flow sensor, make sure water is shut off at the cold-
water supply side.
•Once water pipe is disconnected, some water will drip out of the pipe. Place a bucket or
towel directly under the disconnect point of the water pipe to catch any dripping.
•Flow sensor should be installed in the cold-water piping with the arrow pointing in the same
direction as the cold-water flow (towards the tankless water heater) and in the horizontal
(preferred position) with the 4 screw heads of the sensor on top pointing upward. The flow
sensor can also be mounted vertically. However, in this orientation, when water flow is less
than 0.5gpm, the flow sensor may not be able to open the mechanical flap inside to activate.
•The included flow sensor will require two (2), not provided, ¾” Female BSP “G” Thread
Adapters to transition from G Thread to desired piping (PEX, CPVC, Copper, NPT Etc.)
oEnsure Female Hose Thread Adaptors utilize proper sealing gaskets (washers).
oMake sure to never over-tighten the adapters to the flow sensor. It is also critical to
align the threads correctly to avoid stripping of the threads on the flow sensor.
oIf flow sensor is installed outdoors, please make sure it is properly jacketed to protect
from direct sunlight and freezing conditions.
•Once Flow Sensor is installed and tested for leaks, connect the flow sensor Molex plug securely
into flow signal interface located in the wiring compartment on the right side of the unit.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 12
•After flow sensor is properly installed, turn on the cold-water supply and double check for
leakage.
NO-FLOW INSTALLATION
If this product is to be used with no-flow appliances such as furnace, boiler, direct vents, wall
heaters, etc. or if this product is intended to be used with gas tankless water heaters without the
need of flow sensing function, you MUST unplug the “Temp.Flow” port as shown below in order for
HUGO to function properly. With this setup, HUGO will provide AC output automatically and
continuously whenever there is a power loss and operate in battery mode; when power restores,
city power will automatically recharge HUGO and pass-thru city power to downstream appliances.
Flow sensor can also be purchased separated from SPS, please visit
www.safeguardpowersolutions.com for more details.
TEMPERATURE SENSOR SETUP
•Guide the temperature sensor out of HUGO’s right compartment.
•Attach the sensor’s silver plate to a location on the cold-water supply line that is closest to the
tankless water heater and not jacketed, this will ensure maximum protection of the tankless
water heater’s heat exchanger from freezing.
•Use the provided string tie to secure the silver plate to the cold-water piping.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 13
HARDWIRING INSTRUCTION
If your appliance does not have a plug and requires hardwiring, it is strong recommended that the
following procedures to be completed by a certified electrician and the installer must follow all
codes to ensure the safety of installation and operation. Improper install may cause personal harm
and may void the warranty for the HUGO product. Upon completion, please send a photo of the
completed install to [e-mail] to ensure warranty will still be intact.
a) Make sure HUGO is disconnected to any and all power sources both input and output.
b) Make sure the battery is disconnected from the inverter.
c) Make sure the on/off toggle switch is set to the OFF position.
d) Unplug the terminal block as indicated below.
e) Loosen the three wiring screws on the “AC Output” as shown in photo below:
f) Remove the three wires from factory:
•Green-yellow (Output Ground, or “PE”)
•Blue (Output Neutral, or “N”)
•Green (Output Hot, or “L”)
g) Place wire cap or insulation tape over the removed wires to ensure no conductors are exposed if
touched accidentally.
h) Feed your appliance’s power cord from the outside of HUGO’s wiring box to get inside the HUGO
unit, as shown below:

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 14
i) Make sure not to tangle the wires inside the HUGO unit for easier maintenance and service calls
in the future.
j) Connect your appliance’s wire cords G (green), N (white), and L (red or black) to the
corresponding positions on HUGO’s “AC Output” of the green MOLEX plug.
•G to PE
•N to N
•L to L
k) Ensure no bare wires are exposed to the outside.
l) Tighten the flat head screws on the green connector.
m) Pull the newly installed wires to ensure a tight connection.
n) Plug the green connector back to the inverter.
OPERATIONS
•When city power is normal, HUGO will bypass power to downstream application while monitors
for input voltage. At this time, the “line” LED light on the front panel should be steady green.
When input voltage reaches beyond the safety zone as set under “input voltage” on section 13
below, HUGO will automatically switchover to battery mode to protect downstream appliances.
At this time, the “INV” LED light will be steady green.
•Once a power outage is detected, HUGO will first chirp once to alert user HUGO is in inverter
mode. The chirp will continue once every 30 seconds and will auto shutoff after 5 minutes.
During this mode, there are two operation sequences:
oThe “INV” LED light is blinking green indicating HUGO is in Standby mode and there is
no AC power output from HUGO. This will occur if the flow sensor is installed and the
“temp.flow” port is plugged in and there is no flow detected in the water line.
oThe “INV” LED light is steady green indicating HUGO is in operation mode and is
providing AC power to downstream application. This happens when:
a. “temp.flow” port is NOT plugged in for no-flow installation;
b. “temp.flow” port is plugged in and the installed flow sensor has detected a
flow in the water supply line.
•When HUGO is operating with the flow sensor, there is a delay shutoff feature that works as
followed:
oDuring inverter mode, at any time the flow sensor senses a signal, HUGO will turn on AC

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 15
output continuously for 5 minutes.
oAfter 5 minutes, if no flow is detected, HUGO will turn off AC output.
This feature will prevent frequent restart cycle of tankless water heaters and will allow
users to freely turn the faucet on/off in between water usage.
Note: when tankless water heater is restarting, some models may experience minimized or
stopped water flow, this is due to servo valve inside the tankless water heater is closed.
Once tankless water heater completes its restart cycle, full flow will resume. If at any time
the water flow has stopped and does not return to full flow within 30 seconds, unplug the
temp.flow port to force HUGO to provide power to the tankless water heater. Once the
tankless water heater restarted completely, push in the “temp.flow” port again to resume
water sensing operation.
•When the supply 12v sealed lead acid battery is not fully charged, the third LED light (batt. Lim)
will continue to blink amber. When city power restores and HUGO is charging the battery, this
light will be a steady amber. Once battery is fully charge, this light will be off.
When the supplied battery drops below 20% of its full capacity, HUGO will sound the
audio alert by 2 chirps and 1 pause, after 2 seconds the audio alert will be off. At the
same time, the “batt.lim” LED light will blink twice then pause and continue to blink this
sequence until HUGO is connected to a power source or when city power restores.
•The fourth LED light “Fault” will be steady red when the following occurs:
oThe battery is no longer holding a charge, a replacement is needed. Refer to “Protection
– Battery Under Voltage Protection” in section 13 below.
oThe downstream appliance connected to HUGO has reach above 350W, remove the load
and HUGO will auto reset. Refer to “Protection – Overload or Short Circuit Protection” in
section 13 below.
•When city power is restored after a power outage, HUGO will start charging itself and reset to
utility power mode after 10 minutes. This time delay will allow power grid to become steady to
avoid possible spikes that may harm appliances.
STORAGE AND TRANSPORTATION
Retain the packing box and packing materials. The UPS is a sensitive piece of power equipment.
When storing or transporting, place the unit back into the original packing box to avoid any
damage from moisture, dust, dirt, or chemical corrosion.
MAINTENANCE AND TROUBLESHOOTING
1. Maintenance
•Upon successful installation of the unit, user shall visit the manufacture’s website

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 16
(www.safeguardpowersolutions.com) to register the UPS under “Product Registration”.
Once registered, the UPS’s serial number will activate its warranty starting date.
•If the unit has not been activated by any power outage for a long period of time, it is
recommended to unplug the UPS from the main power source to allow the unit to
operate on battery mode until battery depletes. Once battery depletes, plug the unit
back to main power source to allow battery recharge. This maintenance shall be done
every 6 months for the battery to maintain its optimum performance.
•It is recommended to periodically unplug the UPS from the main power source to check
the UPS’s normal operation. If any fault is detected, read the LED indicator and note
the chirping sequence, then report this information back to point of purchase or consult
with the manufacture.
•Though no necessary, but it is strongly recommended to install any 3rd party surge
protection on the wall outlet where HUGO is plugged in. This added protection will also
prevent any HUGO board burnouts when city power is unstable.
2. Troubleshooting
Scenario: The unit does not operate in battery mode.
Possible Cause and Solution:
•Flow sensor installed: If the flow sensor is installed, the UPS will ONLY
operate when it detects cold-water flow. Turn on any faucet and check the
operating status of the UPS. If problem persists, unplug the “temp.flow”
port in front of the UPS panel to bypass the flow sensing loop. Once
unplugged, if the UPS’s operation is normal under battery mode, then
contact point of purchase to replace the flow sensor. If problem persists,
call the manufacture at 855.484.6797.
•Battery low voltage: Charge up the battery for a full 24 hours. If problem
persists, replace the battery. Battery can be purchased off-the-shelf, 12V,
35Ah, sealed lead-acid battery.
•Output overload: Remove the appliance connected to the UPS, wait for 5
minutes. Double check the connected appliance is rated under 350W. Plug
the appliance back into the UPS. Turn on the UPS.
•Output short circuit: Contact point of purchase or the manufacture for
inverter replacement if under warranty.

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 17
TECHNICAL SUPPORT
SafeGuard Power Solutions, LLC.
Email: [e-mail]
Phone: [phone] (M-F, 9-5 pst)
REGISTER YOUR HUGO
URL: https://safeguardpowersolutions.com/register-your-product/
DATE OF PURCHASE: _____________________________________________
POINT OF SALE: _____________________________________________
ORDER NUMBER: _____________________________________________
MODEL: _____________________________________________
SERIAL NUMBER: _____________________________________________
INSTALLER: _____________________________________________

HUGO USER MANUAL
REV 1.3
SAFEGUARD POWER SOLUTIONS
855.484.6797
PAGE | 18
TECHNICAL SPECIFICATIONS
Model No. HUGO-X1R
Input
AC Voltage
92-138V
Frequency 50 Hz/60Hz ±10%
Output
P.F. (VA/W) = 0.6 500VA/350W
Voltage 113-117V (at Battery Mode)
Frequency
Utility power mode: Output frequency is the same as input.
Battery mode: 50/60Hz ±0.1
Battery Battery Charging 2.5 A, about 8-10 hours to charge a fully depleted 38A sealed lead acid battery
Protection
Utility Power Under
Voltage Under 92 VAC
Utility Surge
Protection When the utility power is >138VAC, it will transfer to battery mode
Battery Under Voltage
Protection
The UPS turns off automatically when the battery voltage too low
Overload or Short-
Circuit Protection
Battery mode: 105%<load<150%, it lasts 5s then protect; 150% ≤ load, it lasts 200ms
then protect; when short circuit, it protects immediately.
Utility mode: 105%<load<130%, alarm but no protection; 130%
≤ load<150%, it lasts 5min
then protect; 150%
≤ load, it last 10s then protect.
Transfer Time
less than 15ms
Others
LED display Refer to this manual
Weight 43 lbs.
Dimensions
(W x D x H)
14 x 9 x 12 inches
Operating
Temperature 23 to +104°F
Humidity < 95% (non-condensing)
