SPT SO-2003 User manual

by SUNPENTOWN
SO-2003
DIGITAL CONVECTION OVEN
with
8 PRE-PROGRAMMEDSETTINGS
INSTRUCTION MANUAL
Please read instructions thoroughly and keep for future reference.
TABLE OF CONTENTS
Important Safeguards ………………………………… 1, 2
Features ……………………………………………… 3
Part Identification …………………………………….. 4
Assembly / Instructions ……………………………… 5~8
Cleaning ………………………………………………. 9
Time and Temperature Reference …………………. 10~12
Internal Food Temperature Guide .…………………. 12
Warranty

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
1.
A
ll instructions should be read thoroughly prior to first use.
2. THIS OVEN GETS EXTREMELY HOT while in use.
A
lwa
y
s use
with the base, being careful not to touch the hot surfaces.
3. To protect against electrical shock, do not immerse the cord, plug or
motor housing in water or any other liquid.
4. Close supervision is necessar
y
when this appliance is used b
y
or
near children.
5. Do not pull b
y
the cord when disconnectin
g
from the electrical outlet,
as this may damage the cord.
6. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
7. Do not operate this appliance with a dama
g
ed cord or plu
g
or after
the appliance malfunctions or has been damaged in any manner.
8. Do not use outdoors. This appliance is for household use onl
y
.
9. Do not let cord han
g
over ed
g
e of table or counter or come in
contact with hot surfaces.
10. Do not place on or near a hot
g
as or electric burner or inaheated
oven.
11. Place on a heatproof surface. Do not place on top of plastic, vinyl,
varnished wood or any surface that burns easily.
12. Use extreme caution when movin
g
this appliance if it contains hot oil
or other hot liquids.Allow to cool off prior to disposing hot grease.
13. Ensure this appliance is OFF before removin
g
the plu
g
fromthe wall
outlet.
14. Do not use this appliance other than described in this manual.
15. Unplu
g
the unit from the outlet when not in use and before cleanin
g
.
16. Fire hazard ma
y
occur if appliance is covered or touchin
g
flammable
material (curtains, draperies, walls and the like) during operation.
17. Do not use abrasive cleaners or scourin
g
pads when cleanin
g
the
unit.
18. Do not leave appliance unattended while in use.
19. Do not operate in the presence of explosive and/or flammable
fumes.
1
20. This product is intended for household use onl
y
and not for
commercial or industrial use.
21.
A
n extension cord should not be used with the appliance.
22. Do not touch or stare directl
y
intothe bulb.
23. Do not move the oven when in use.
24. Do not place oversizedfood into the oven, the glasslid must be
completelyclosed.
25. Neverplace paper, cardboard, plastic or other flammable materials
inside the unit.
26. When usin
g
the unit for the first time, allowmotor to run for a few
minutes in order to burn off any excess lubricants, which were used
during the manufacturing of this item. You may seeasmall amount
of smoke during the first few uses.
WARNING
This appliance generates heat and steam may escape during use.
Proper precautions must be taken to prevent the risk of burns, fires or
other injury to persons or damage to property.
CAUTION HOT SURFACES
This appliance is hot during use and retains heat for some time after
turning off.Always use oven mitts when handling hot materials and
allow to cool before cleaning.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock,thisplug willfit in a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the plug.
If it still does not fit,contact a qualified electrician. Do not attempt to
modifythe plug in any way.
SAVE THESE INSTRUCTIONS
2

This versatile cooker combines infrared, conduction heat and convection
technology to keep foods moist on the inside yet browned and crispy on
the outside – all without the use of added fats or oils.
Infrared heat cooks food from inside out, sealing in juices. Conduction
heat targets the surface of the food for browning. Convection circulates
the hot air to cook the food evenly and speeds cooking up to 3 times
faster. Pre-programmed settings take the guesswork out of cooking:
hamburger, steak, pork chops, salmon steak, chicken pieces, whole
chicken, pizza and thaw/wash dehydrate. You can also manually set the
cooking time and temperature.
FEATURES OF SO-2003:
Combines Infrared, Conduction Heat & Convection technology
Digital display with adjustable time and temperature
8 programmedsettingfor effortlesscooking
Deep heat penetration and instant heating – no defrosting
necessary.
Cooks and browns food evenly and quickly, retaining its nutrients
Meat sears quickly on the outside, sealing juices on the inside
Quick response to manual temperature changes
Heatprooftempered glass can withstand temperature variance up to
365°F
Two cooking racks (low & raised)for cooking multiple foods
No soot or unsavorysmoke produced.
Adjustable temperature: 120 - 480°F (in 5°F increments)
Timer: up to 1 hour and 59 minutes
3
PART IDENTIFICATION
1. Glass Lid with Digital Control Panel Conduction
1a. Time display
1b. Temperature display
1c. Adjustment buttons: Increase(+) and Decrease (-)
1d. 8 one-touch program buttons
1e: Start/Stop button
2. Safety Handle
–
A
utomatically turns off the unit when handle is
raised.
3. Extender Rin
g
–
Increases capacit
y
to cooklar
g
er foods
4. High Cooking Rack
–
additional rack for extra food
5. Low Cooking Rack –main rack for cooking food
6. Glass Bowl
7. BowlBase
8. Tong
4

Before initial use, remove all packaging materials and cleanglass bowl,
plastic base, cooking racks and tongs with hot soapy water and allow to
dry completely/
WARNING: Do not immerse the lid with digitalcontrols, cord or plug in
water or any other liquid. Do not place lid in the dishwasher.
ASSEMBLY:
Place unit on a level and heatproof surface, where a 15-amp outlet
is within reach.
Place the
g
lass bowlontothe plastic base.
Place the low and highcooking racks into the glass bowl.
Place the
g
lass lid on top of the
g
lass bowl. The lid should sit on the
inner rim of the bowl.
If using extender ring, place it on top of the glass bowl, then place
the lid on the ring.
INSTRUCTIONS:
Always have oven mitts ready to removethe lid and cookedfood.
Any oven safe pans, plates, cookware can be used inside this oven.
PLACING FOOD IN OVEN:
•Open the lid and place the racks inside, use one or both racks,
depending on the amount or type of food.
•You ma
y
combine both racks to make a
g
rid when cookin
g
foods
like French fries. Place the high rack in first, then layer the low rack
over the high rack, align to form a grid.
•Place food to be cooks on rack
–
this will allow the hot air to
circulate aroundthe food for faster and even cooking.
•If extender rin
g
is needed, placethe flat part of the extender rin
g
over the glass bow. The ring has its own lip that will create a perfect
seal with the lid.
•Close the lid. Plu
g
the power cord into outlet. The LED displa
y
s will
illuminate 0:00 and 000.
MANUAL COOKING TIME & TEMPERATURE SETTING
Use the adjustment buttons (+/-) to manually set the time (0:00 to
1:59) and the temperature (120 to 480°F)
Cookin
g
time advances in 1 minute increments, the temperature is
in 5°F increments. Press and hold the buttons to advance faster.
5
PRE-SET PROGRAMS
If using one-touch preset buttons, the time and temperaturewill
display automatically.
The cookin
g
time and temperature can still be ad
j
usted with the
adjustment buttons (+/-).
When a pro
g
ram is selected,the indicator li
g
ht next to the selection
will start blinking. However, unit will not start to operate until you
press the Start/Stop button.
PROGRAM RACK DEFAULT
TEMP
DEFAULT
TIME
Hamburger High 400°F 12 min
nim01F°004hgiHkaetS
Pork Chops High 400°F 16 min
Salmon Steak High 400°F 15 min
Chicken Pieces Low 400°F 20 min
Whole Chicken Low 460°F 45 min
Pizza (frozen) High 400°F 10 min
Thaw/Wash/Dehydrate High 260°F 60 min
NOTE: The cooking time depends on the size and weight of the food.
Most meats have recommended cooking times, those times should be
used as a guide as this oven cooks faster than conventional ovens, you
may need to adjust cooling time accordingly.
6

TURNING UNIT ON/OFF:
Be sure handle is full
y
lowered. The handle must be flat down for
the oven to operate.
Press the Start/Stop button to start cookin
g
.
NOTE: the handle operates as a safety switch, as soon as it is lifted,
the oven will stop operating. Once the unit is ON, the carbon lamp
and fan will turn on. The carbonlampwillcycle on and off to
maintain set temperature – it will go off when the required heat
setting has been reached.
If at an
y
time
y
ou need to check the food, simpl
y
liftthe handle up to
stop operation. The cooking time and temperature displays will
pause.
CAUTION: before removing the glass lid, be sure handle is in the
upright position as this will activate the safety switch and stop the
oven’s operation. The oven will be very hot. If using the extender
ring, be extra careful as it will get very hot during cooking process.
Use oven mittswhenremovingthe glasslid.
When down checking, lower the handle until it snaps in and press
the Start/Stop button to resume cooking.
If at an
y
time
y
ou need to turn off the unit before timer is up, simpl
y
press the Start/Stop button.
When the timer counts down to 0:00, the oven will beep several
times and will turn off automatically.
NOTE: The carbon lamp will turn off immediately once timer counts
down to 0:00, while convection fan will stay on to allow the unit to
cool off (approx 1 to3minutes).
Removelid and check to make sure food is fully cooked.
NOTE: to ensure food is cooked, useacooking thermometer or
piercethe food with a fork to check for uncooked juices on meats
and poultry. When cooking vegetables,check for desired
tenderness. Moisture may build up inside the oven when cooked
food is not removed soon after timer has gone off.The
steam/moisture build-up can be avoided by removing the food as
soon as cooking is done.
•Use provided ton
g
to lif
t
out the food and/or racks
DEHYDRATE FUNCTION
To dehydrate fruits, vegetable and herbs
Wash and dry the fruits or vegetables. Peel the skin, if desired.
7
Slice the fruits/ve
g
etables into 1/16”inches thickness. If usin
g
soft
fruit like bananas, briefly place in the freezer to harden, this will
make slicing easier.
Placefruit slices inalemon
j
uice solution of ½ cup water with ½ cup
lemon juice for 10 minutes. When soaking banana slices, soak only
for 5 minutes. Do not soak vegetables.
A
rran
g
e both racks
(
hi
g
h and low
)
to form a
g
rid.
NOTE: if dehydrating herbs, use the lower rack alone.
Place the slices close together, but not touching in one layer. Do not
stack on top of the other. Closethe lid.
PresstheTHAW/WASH/DEHYDRATE preset button. The time and
temperature willdisplay automatically. Adjust time/temperature if
needed by using the adjustment (+/-) buttons.
Lower the handle and press the Start/Stop button.
NOTE: it is recommended to check the food every 15 minutes.
Most fruit will be pliable or leather
y
when done
(
bendin
g
without
breaking). To check – tear a piece of dried fruit in half and if no
moisture beads up on the inside and there is no stickiness on the
outside, it’s done.
THAWING
Although you can cook from frozen food, there is also the option to thaw
frozen foods first:
PRE-HEATING
Make sure the racks are place inside the oven prior to pre-heatin
g
.
If pre-heating is required, set the required temperatureusing the
adjustment buttons. Set the time to 10 minutes. Once the
temperature is reached, the conduction heat light willturn off. You
can now open the lid and place food insde.
8

CARE &CLEANING
Make sure oven is turned off an unplu
gg
ed.
Always wait until the unit cools down completely.
Thoroughly wash the glass bowl, plastic base, extender ring,
cooking racks and tongs in hot soapy water and allow to dry
completely. Glass bowland cooking racks are dishwasher safe.
When washing the cooking racks, do not soak in water for long
periods of time. Once washed, best to dry with cloth or paper towel.
This will preserve the surface and willextend the life of the racks.
Once unplugged,the glasslid surface can be wipedcleanusing a
damp cloth or sponge.
WARNING: Do not immerse the lid, cord or plug in water or any liquid.
Do not use abrasivecleaners. Do not place the lid in dishwasher. All
parts must be dry before next use. When storing the unit, be sure ALL
parts are dry, to avoid any moisture collecting in the lid.
SELF CLEANING OF GLASS BOWL
If food particles are stuck on the bottom or sides of glass bowl,you can
perform a self cleaning.
Pour approximatel
y
1 to2inches of water into the bowl, add a small
amount of mild dishwashingliquid.
Place lid on and plug into outlet.
Press the THAW/WASH/DEHYDRATE preset button. The time and
temperature willdisplay automatically.
Change the cooking time to 10 minutesusing the adjustment
buttons.
When the timer counts down to 0:00, carefull
y
open the lid and wait
for the glass bowl to cool down before emptyingtheliquid inside.
Rinse the
g
lass bowl in clean warm water to remove soap residue.
TECHNICAL SPECIFICATION
Model: SO-2003
Capacity: 12.5 Quarts Glass bowl / With Extender ring: 16 quarts
Rate: 120V / 1300W
9
SUGGESTED COOKING TIMES
Please refer to the below cooking times as a guide only. Time may vary
according to the weight of food, adjust to your preference.
You can use your favorite conventional oven recipes with this unit and
decrease the cooking time by approximate 25 to 35%. Because this
oven cooks faster than conventional ovens.
FOOD RACK TEMP TIME (min)
(fresh/frozen) Notes
MEATS
Bacon Low 400°F 10 /16 Crisscrossracks.
Turnafter 5 min.
Hamburger
(1/4lb) High 400°F
10/12 (rare)
12/15 (med)
15/18 (well)
Turn once
Hot dogs High 400°F 8/10 Crisscross racks
Sausage links
(1lb) Low 400°F 15/22 Turn once
Lamp chops
(1 ½” thick) High 400°F 20/30 Turn after 5 min
Meat loaf (2lbs) Low 350°F 40/60
Frozen: cover
w/foil half way
through
Pork chops (1/2”
thick) High V 16-18/30 Turn after 10 min
Pork roast (3lbs) Low 360°F 60/95 Fat side down.
Turn half way
Shish kabob Low 400°F 10-12/15-18 Turn and baste
Spare ribs Low 400°F 30/45 Turn, baste
Steak (1” thick) High 400°F 10/15 (med
rare) Turnafter 7 min
SEAFOOD
Breaded fish High 400°F 10/12 Crisscross racks
Shrimp High 400°F 10/12 Crisscross racks
Turn, baste
Salmon steak
(4oz)High 400°F 15-18/25 Turn once
10

FOOD RACK TEMP TIME (min)
(fresh/frozen) Notes
SEAFOOD (continued)
Scallops (6oz) High 400°F 15-18/20 min Crisscross racks
Fish fillet (4oz) High 400°F 14/16 Crisscross racks
Whole fish (1lb) Low 400°F 30/35min
POULTRY
Chicken breast
(boneless thick)High 400°F 13-15/15-18 Crisscross racks
Chicken breast
(boneless thin) High 400°F 10/13 Crisscross racks
Chicken breat
(bone in) Low 400°F 20/40 Breast side down Turn halfway
Chicken legs /
thighs / wings Low 400°F 20/30 Turn halfway
Cornish hen
(3 1/2 lbs) Low 460°F 45/50 Breast side down Turn halfway
Chicken quarter Low 400°F 35/45 Turn half way
Turkey breast
(3lb) Low 460°F 60/120Breast side down Turn halfway
Whole chicken
(4lb) Low 460°F 45/90 Breast side down Turn half way
Whole turkey Low 350°F 15/23 min/lb Use extender ring
VEGETABLES
Squash Low 400°F 30 Cut in half
Baked potatoes Low 460°F 45
Corn on the cob
(4) Low 400°F 8-10/12/15Cook in1inch of water in bowl
Eggplant (1/2”
slices) Low 400°F 8-10 Turn halfway
French fries High 460°F 12/15 Crisscross racks
Roasted garlic High 460°F 45 Wrap in foil
Steam broccoli High 400°F 25 Wrap in foil.Add
1tsp of water
Sweet potatoes Low 400°F 35
Vegetable
medleyHigh 400°F 10 Wrap in foil.Add
1tsp of water
11
FOOD RACK TEMP TIME (min)
(fresh/frozen) Notes
ASSORTED
Baked apples or
pears Low 400°F 25 Cook in shallow casserole dish
Pizza High 400°F 10 Crisscross racks
Popcorn Low 420°F 9 Use shallow pan.
Do not use oil
DEHYDRATING (soak fruit slices in 1:1 lemon/water solution for 10 min)
Apples / pears /
peaches / plums High 260°F 60 Crisscrossracks. 1/16” thick slices
Bananas High 260°F 60 Soak 5 min
Parsley Low 260°F 5 Crisscross racks
Tomatoes High 260°F 50-60Crisscrossracks.
1/16” thick slices
INTERNAL FOODTEMPERATURE GUIDE
This is a list of the internal temperature that different food must reach to
kill bacteria. These are NOT the temperature to use to cook the food.
F°541)erardem(laevrobmal,feeB
F°061)dem(laevrobmal,feeB
Beef, lamb, pork or veal (well done) 170°F
F°071tsaerbnekcihC
F°081sgniwroshgihtnekcihC
F°541hsifllehsdnahsiF
F°061kroprofeebdnuorG
F°561yekrutronekcihcdnuorG
F°061kroP
When cooking poultry, always cook to the internal temperature of 170-
18°F. Another sign of cooked poultry is when the juices run clear. Fish is
done when it looks opaque and flakes easily with a fork. Shellfish
(shrimp,crab or lobster) will turn reddish pink on the outside and
opaque on the inside.
12

Your Guarantee
This guarantee is subject to the following terms:
•Sunpentown must be notified of the fault.
•Proof of purchase must be presented to Sunpentown’s nominated
representative.
•The warrant
y
will be void if the product if modified, misused or
repaired by an unauthorized person.
•The warranty after repair will not be extended beyond the original
one-year period.
•
A
ll replacement parts will be new or reconditioned.
•Parts, which are replaced, become the propert
y
of Sunpentown.
•The warranty applies for the use of the product in the USA only.
What is NOT COVERED
•Dama
g
e due to installation error, product abuse and/or misuse.
•Incidental or consequential dama
g
e caused b
y
possible defects with
this product.
•Dama
g
e to product caused b
y
improper power suppl
y
volta
g
e,
accident, fire, floods or acts of nature.
•Failure of product resulting from unauthorized modifications to the
product.
•Improper installation or failure to perform the necessar
y
maintenance.
•Normal wear and tear on parts or replacement of parts desi
g
ned to
be replaced.
•Dama
g
e to personal propert
y
from use of product.
•Replacement or repair of household fuses, circuit breakers, wiring or
plumbing.
This GUARANTEE is in addition to your Statutory Rights
SUNPENTOWN INTERNATIONALINC.
14625 Clark Ave. City of Industry, CA 91745
Tel: [phone] · [e-mail]
