SPT MICRO-COMPUTER RR-9215 User manual

Micro-Computer Radiant Cooktop
RR-9215
INSTRUCTION MANUAL
Thank you for your purchase.
Please read thoroughly before initial use and keep in a safe
place for future reference.

IMPORTANT SAFEGUARDS
 Read all instructions.
 Do not touch hot surfaces
 To protect against electrical shock, do not immerse cord or appliance
in water or any other liquid.
 Close supervision is necessary when any appliance is used by or
near children.
 nplug from outlet when not in use and before cleaning.
 Do not operate any appliance with a damaged cord or plug; or after
the appliance malfunctions or has been damaged in any way. Return
appliance to the Sunpentown for examination, repair or adjustment.
 The use of accessory attachments not recommended by the
manufacturer may cause injuries.
 Do not use outdoors.
 Do not allow cord to hang over the edge of table or counter; or touch
hot surfaces.
 Do not place on or near a hot gas or electric burner, or in a heated
oven.
 Do not use appliance for anything other than intended use.
 se of an extension cord is not recommended. If needed, use an
extension cord of 14 gauges on diameter not longer than 10 feet.
INDEX
Index………………………………………………...
2
Structure description & function………………….
3
Operation…………………………………………...
4
Timer.…..…………………………………………...
4
Lock……..…………………………………………...
4
Key points before use……………………………..
5
Selecting the proper cookware.…………………. 6
Care and maintenance………..…………………. 6
Specifications………………………………………
6
Trouble shooting………………………………….. 7
Warranty
2

STRUCTURE DESCRIPTION & FUNCTION OPERATION
8 power levels (wattage): 100, 300, 500, 700, 900, 1100, 1300, 1500.
1. Plug power cord to power source and place cookware centered on
cooktop. (Once power is connected, the LOCK button will illuminate).
2. To turn on, press LOCK followed by ON/OFF button. If ON/OFF is
not pressed within 30 seconds, unit will return to locked mode.
3. Press + or - button to set cooking level; press LOW button to jump to
lowest setting (100W) or press HIGH button for highest setting
(1500W).
Note: Factory default setting is at 900W.
CA TION: When the Warning indicator is on, the ceramic plate is
extremely hot – DO NOT TO CH.
TIMER SETTING
1. Press TIMER button.
2. Press + or - button to set cooking time.
 Each single press is increment of 1 minute.
 Press and hold for increments of 10 minutes.
 Press LOW button to jump to 1 minute on the timer
 Press HIGH button to jump to the maximum 8 hours.
 Note: factory default is 2 hours.
LOCK BUTTON
1. Press LOCK button to lock in settings.
 When locked, display will jump between time left and setting.
 No changes can be made (level or time).
2. Press LOCK button again to unlock.
Timer
button
Warning
indicator
Timer / Cook
indicator
Cook
button
Power
button
Lock
button
Power level / Timer
controls
LED
display
3 4

KEY POINTS
 When the Warming indicator is on, this means the ceramic plate is
extremely hot, DO NOT TO CH.
 Cooker will automatically shut-off after 2 hours of inactivity (when not
set on timer).
 Place cooktop on flat surface, but keep a clearance of 4 inches all
around for proper ventilation. If air inlet or outlet is blocked, the
internal temperature will rise and cause unit to overheat and shutoff
during cooking.
 Never power on unit without cookware. May cause ceramic plate to
overheat and crack.
 Keep away from water source. Never immerse unit in water or clean
under running water.
 Do not place paper or cloth in between the cooktop and cookware.
 To prevent damage to your cookware, do not heat an empty pan.
 Do not place one cooktop on top of another.
 Do not place on or near a hot gas or electric burner or in a heated
oven. If the surrounding temperature is high, unit will shut off.
 Do not use cookware consisting of inferior enamel, synthetic material,
china or aluminum. DO NOT SE PLASTIC WRAP.
 Never heat an unopened can on the cooktop as it may explode.
 Plug cooktop in a dedicated 15-amp outlet. Do not share the outlet
with other appliances.
 Do not damage the ceramic plate. Be careful not to drop anything
onto the ceramic plate. If the plate is broken or cracked, stop using
immediately. Turn unit off and unplug.
 Deep-fry is prohibited.
 This cooktop is not intended for use by persons (including children)
with reduced physical sensory or mental capabilities; or lack of
experience and knowledge, unless supervised by person responsible
for their safety.
SELECTING THE PROPER COOKWARE
 This radiant cooktop is not selective with cookware. However,
cookware with a flat bottom and matte finish will have the best heat
conductivity.
 It is not suggested to use pressure cooker on the cooktop. If you do
use one, please use with caution.
CARE & MAINTENANCE
 nplug unit from power source.
 Wipe ceramic plate and exterior surface with a soft damp cloth. If
excessively dirty, soak cloth in a mild detergent and water mixture.
SPECIFICATIONS
Model RR-9215
Voltage 120V~ / 60Hz
Power consumption 1500W (max)
Dimension 12.25 L x 15.5 W x 2.75 H in.
Weight 6.6 Lbs
Power range 100 ~ 1500 W
Cord length 4ft
5 6

TROUBLESHOOTING / ERROR CODES
PROBLEM CHECK POINTS
nit is plugged in
but power indicator
does not come on
 Is cooktop firmly plugged into a correct
outlet?
 Was there a power shortage?
Power indicator is
lit but not heating  Please contact Sunpentown
Error code: E2  nstable voltage detected, please wait until
voltage returns to normal.
Error code: E4  Blown fuse, please contact Sunpentown.
Error code: E5
 Internal temperature is too high. Please
check if fan is running; if ambient
temperature is high; or if air inlet or outlet is
blocked.
nit suddenly stops
heating during
normal operation
 Check if unit reached set timer.
 nit has been operating and idle for 2 hours.
Safety feature automatically shuts unit off
after 2 hours with no setting changes.
 Is the Display indicating any of the above
error code?
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may ca se ndesired operation.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance co ld void the ser’s a thority to operate the
eq ipment.
NOTE: This equipment has been tested and found to comply with the limits for a
consumer ISM equipment, pursuant to Part 18 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
 Consult the dealer or an experienced radio TV technician for help.
Yo r G arantee
If this product is found to be faulty as a result of faulty materials or
workmanship within one year from date of purchase, it will be repaired
free of charge.
This guarantee is subject to the following terms:
• Sunpentown must be notified of the fault.
• Proof of purchase must be presented to Sunpentown’s
nominated representative.
• The warranty will be void if the product if modified, misused or
repaired by an unauthorized person.
• The warranty after repair will not be extended beyond the original
one-year period.
• All replacement parts will be new or reconditioned.
• Parts, which are replaced, become the property of Sunpentown.
• The warranty applies for the use of the product in the SA only.
What is NOT COVERED:
• Warranty does not include freight charges.
• Incidental or consequential damage caused by possible defects
with this product.
• Damage to product caused by improper power supply voltage,
accident, fire, floods or acts of nature.
• Failure of product resulting from unauthorized modifications to
the product.
• Improper installation or failure to perform the necessary
maintenance.
This G ARANTEE is in addition to your Statutory Rights
SUNPENTOWN INTERNATIONAL INC.
1-800-330-0388
service@s npentown.com
www.s npentown.com
7
