SRS Lighting DTA16 User manual

( 1 / 8)
Instruction Manual
Models:
version 1.0 since 21 May 2018
ATTENTION!
This instruction manual contains important information about the installation and the use of
the equipment. Please read and follow these instructions carefully.
Always ensure that the power to the equipment is disconnected before opening the
equipment or commencing any maintenance wor .
Rigging manual_template
DMX De ultiplexer
DTA16

( 2 / 8)
General
IMPORTANT INSTRUCTIONS
All safety and operating instructions should be read before the equipment is
installed or operated.
IMPORTANT SAFETY INFORMATION
The following general safety precautions have to be observed during all phases
of operation, service, and the repair of this equipment. Failure to comply with
these precautions or with specific warnings in this manual violates safety
standards of design, manufacture, and the intended use of this equipment.
Do not operate in an explosive atmosphere!
Do not operate this equipment in the presence of flammable gases or fumes.
Operation of any electrical instrument in such an environment constitutes
a definite safety hazard.
ater, moisture, heat and humidity
Do not operate this equipment near water or in areas with wet floors or in high
humidity atmosphere where condensation forms on the equipment. It should
never be placed near or over a heat register or other source of heated air and it
should not be installed or operated without proper ventilation.
Proper use
Use only original adapter.
Let the device adapt the environment for at least 10 minutes after unpac ing.
Analogue output connection
Analogue outputs (standard 0/+10V) are in a form of SUB-D soc et.

( 3 / 8)
DMX input and output connections
Male and female DMX standard 3- or 5-pin XLR connectors are located on the
front panel. DMX input is optically isolated.
Device description
Front panel:
1. DMX input
2. DMX output
3. Switch DMX start address (UP = ON)
 #1-9 are allocated for DMX start address selection 1-256
 #10 is TEST mode activation. In this mode, the outputs runs
in sequence 1-16 automatically 0/+10V.
4. LED indication
 POWER ON ON when device is powered
 DMX OK ON when correct DMX is received
 DMX OK BLINKING when test DIP is activated
 DMX ERR ON when DMX with inversed polarity is
detected
Rear panel:
1. SUB-D output connector
2. Power supply

( 4 / 8)
Inputs and Outputs:
Pin out of the XLR connectors:
Pin 1: Data CMN
Pin 2: Data -
Pin 3: Data +
Pin 4, 5: Not connected
Pin out for the SUB-D connector:
Pins 1-16 Channels 1-16
Pins 19-25 Ground
echnical data
Power supply:
DC15V, 0.8A, external adapter
echnical attributes:
 16 channel DMX to analog 0/+10V converter
 Optically isolated input with true output
 LED indication of the DMX line
 DIP switch for setting of the DMX address
 Test function
Input:
USITT DMX 512 (1990)
Output:
16x analog output 0/+10V, max. 10mA per output
Housing:
Steel housing with gray powder coating
110 x 44 x 145 mm
Weight:
0.6 g

( 5 / 8)
DECLARA ION OF CONFORMI Y
According to guidelines 89/336 EEC and 92/31 EEC:
Name of producer: SRS Group s.r.o.
Address of producer: Rybnicna 36/D, SK- 83106 Bratislava, Slova Republic
Declares that the product
Name of product: DTA16
ype: DTA16-3, DTA16-5, DTA16-C and their variants
Corresponds to the following product specifications:
Safety: EN60065, resp. EN 60950
EMC: EN55103-1, resp. EN55103-2
Bratislava, 7 November 2002
