SRS Lighting DSR10-RDM-N User manual

( 1 / 4)
Instruction Manual
Models:
version 1.0 since 3 February 2020
ATTENTION!
This instruction manual contains important information about the installation and the use of
the equipment. Please read and follow these instructions carefully.
Always ensure that the power to the equipment is disconnected before opening the
equipment or commencing any maintenance wor .
DSR10-RDM-N_en_manual_M297.doc
MX Splitter
with R M Support
SR10-R M-N

( 2 / 4)
IMPORTANT SAFETY INFORMATION
The following general safety precautions have to be observed during all phases of operation,
service, and the repair of this equipment. Failure to comply with these precautions or with
specific warnings in this manual violates safety standards of design, manufacture, and the
intended use of this equipment.
Do not operate in an explosive atmosphere!
Do not operate this equipment in the presence of flammable gases or fumes. Operation of any
electrical instrument in such an environment constitutes a definite safety hazard.
Water, moisture, heat and humidity
Do not operate this equipment near water or in areas with wet floors or in high humidity
atmosphere where condensation forms on the equipment. It should never be placed near or over
a heat register or other source of heated air and it should not be installed or operated without
proper ventilation.
DMX connections
DMX RJ45 connectors are located on the front panel of the device. Splitter consists of DMX in,
thru and outputs mar ed as A-J. These outputs are optically/electrically isolated and equipped
with RDM filter on each output. Both input lines should be terminated by the termination switch
mar ed as “120R”. When the line is terminated by the 120R resistor, RED LED indication is on.
There is also a bus line driver indication of signal on both signal lines with two LEDs indicating
the polarity of the DMX signal.
Pin 1, 3 Data +
Pin 2, 6 Data -
Pin 4, 5 NC
Pin 7, 8 Ground / Common

( 3 / 4)
Controls and indication
1. Power indication
2. DMX input signalization
3. DMX input connector channel A
4. DMX Termination switch 120R + signalization LED
5. RDM filter switch + signalization LED
6. DMX data output signalization for positive and negative signal
7. DMX output connector
Device Design
Front panel:
Rear panel:
Device se/servicing:
The Power LED indicator indicates the device is on the main power. All other DATA indication
LEDs being off mean no incoming signal. The termination red LEDs are ON when the termination
switch is activated. Each DMX source is retransmitted to the ten outputs. When there are
connected the RDM devices without RDM support turn the RDM filter on by switch. This is
indicated with the GREEN LED close to the switch.
When the DMX cable is connected to the device, all LEDs mar ed with symbols D+/D- or the sign
of signal polarity go ON. This indicates that DSR10-RDM is functioning properly and is
retransmitting the input to the outputs. If any of LEDs is off, chec the cable first – short circuit
on a line causes the respective LED is off.
Device is upgradeable via USB to DMX cable. As on [e-mail] for more details.

( 4 / 4)
Technical data
Main:
AC 100-255V / 50-60Hz / 10W
Inp t/ O tp t:
1x USITT DMX512 / RDM
10x USITT DMX512 / RDM amplified
Size:
1U, 19’’, 482.5 x 44.5 x 130 mm
Weight:
2.1 g
DECLARATION OF CONFORMITY
According to the g idelines 89/336 EEC and 92/31 EEC:
Name of prod cer: SRS Group s.r.o.
Address of prod cer: Rybnicna 38/B, SK- 83106 Bratislava, Slova Republic
Declares that the product
Name of prod ct: 10-way DMX/RDM Splitter with RJ45 connectors
Type: DSR10-RDM-N
Corresponds to the following product specifications:
Safety: EN60065, resp. EN 60950
EMC: EN55103-1, resp. EN55103-2
Additional information:
Unit and all connected apparatuses must be earthed via main cable.
Bratislava, 2 November 2019
Robert Sloboda
Copyright 2017 SRS Group, s.r.o. | Specifications subject to change without notice.
Document: DSR10-RDM-N_en_manual_M297.doc | Version 1.0 | Actual as of: 3 February
2020
SRS Gro p s.r.o.
Rybnicna 38/B | 831 07 Bratislava | Slova ia
Phone: [phone]
Email: [e-mail] | www.srs-group.com
Package consists of:
•DSR10-RDM-N unit,
•1.5m 3G0.75mm2 PowerCon cable,
•Printed manual
Warranty:
Life-time warranty
