SSANGYONG KYRON 2010.01 User manual

GENERAL
0000-00
GENERAL
1. DIMENSIONS........................................
2. SPECIFICATIONS.................................
3. VEHICLE IDENTIFICATION...................
4. MAINTENANCE INTERVAL...................
5. RECOMMENDED FLUIDS AND
LUBRICANTS........................................
6. JACK-UP POINTS .................................
7. PIN ARRANGEMENT OF DIAGNOSTIC
CONNECTOR........................................
8. ELECTRIC COMPONENTS AND
LAYOUT................................................
9. STANDARD BOLTS SPECIFICATIONS.
GENERAL
3
4
6
7
13
14
16
17
19


undefined
0000-00
GENERAL


GENERAL
undefined
0000-00
0000-00
GENERAL
GENERAL
1. DIMENSIONS Unit: mm
* ( ) : Optional


undefined
0000-00
GENERAL
2. SPECIFICATIONS * ( ) Optional


GENERAL
undefined
0000-00
* ( ) Optional


undefined
0000-00
GENERAL
3. VEHICLE IDENTIFICATION
1. Engine Number
Gasoline Engine:
The engine number is
stamped on the lower
area of cylinder block
in exhaust manifold
side.
2. Chassis Number
The chassis number is
stamped on the frame
behind the front right tire.
Diesel Engine:
The engine number is stamped on the lower area of
cylinder block behind the Intake manifold.
3. Certification Label
The certification label is
located on the driver's
door sill.
4. Vin Label


GENERAL
undefined
0000-00
4. MAINTENANCE INTERVAL
* Use only approved Ssangyong genuine parts.
Maintenance service and record retention are the owner's responsibility. You should retain
evidence that proper maintenance has been performed on your vehicle in accordance with the
scheduled maintenance service chart.
* EU Countries: Only countries that belong to EU. (It does not apply to all countries in EU.)
ENGINE CONTROL SYSTEM
NOTE 1: Adjust as required; When excessive smoke is visible (black or white)
Poor performance/economy
-
-
Chart Symbols:
Inspect these items and their related parts. If necessary, correct, clean, replenish, adjust or replace.
Replace or change.
(1)* If vehicle is operated under severe condition:
- Frequent stop-and-go traffic, extended idling, short driving distance below 6 km, driving
distance below 16 km when the outside temperature remains below freezing
- Driving in a hilly or mountainous terrain, sandy, or dusty area
- High load driving such as trailer towing
- Taxi, patrol service or delivery service (extended idling and excessive driving with low speed)
Shorten the service interval. Inspect the engine oil at any time, occasionally, if necessary
refill the engine oil.
(2)* If vehicle is operated under severe condition, driving in dusty condition or sandy condition,
pollutant area or off-road driving, frequently inspect the air cleaner, if necessary, change
the air cleaner.
(3)* More frequent maintenance is required if under dusty driving condition.
󱳽
Water separator: When replace the engine oil, also drain the water from the fuel filter.
I -
R -
*
1) Diesel Engine


undefined
0000-00
GENERAL
* Use only approved Ssangyong genuine parts.
* EU Countries: Only countries that belong to EU. (It does not apply to all countries in EU.)
CHASSIS AND BODY
Chart Symbols:
Inspect these items and their related parts. If necessary, correct, clean, replenish, adjust or replace.
Replace or change.
(3)* Refer to "Recommended fluids and lubricants".
(4)* More frequent maintenance is required if the vehicle is operated under any of the following
conditions:

- In hilly or moutainous terrain, or
- When doing frequent trailer towing, or
- Uses such as found in taxi, police or delivery service.
(5)* Inspect manual transmission fluid every 15,000 km (Inspect the leak of fluid at any time,
occasionally), then change every 60,000 km
(6)* Change automatic transmission fluid and every 60,000 km if the vehicle is mainly driven
under severe conditions: Towing a trailer or off-road driving (Inspect the leak of fluid at
any time, occasionlly)
I -
R -


GENERAL
undefined
0000-00
CHASSIS AND BODY
Chart Symbols:
Inspect these items and their related parts. If necessary, correct, clean, replenish, adjust or replace.
Replace or change.
(3)* Refer to Recommended fluids and lubricants.
(6)* After completion of off-road operation, the underbody of the vehicle should be throughly
inspected. Examine threaded fasteners for looseness.
(7)* If necessary, rotate and balance wheels.
(8)* After completion of off-road operation, the drive shaft boots should be inspected.
(9)* Inspect propeller shaft grease every 5,000 km or 3 months if the vehicle is mainly driven
under severe condition.
- In off-road or dusty road, or

- In hilly or moutainous terrain.
I -
R -
* Use only approved Ssangyong genuine parts.
* EU Countries: Only countries that belong to EU. (It does not apply to all countries in EU.)
Severe Conditions in Air Conditioner Filter
- Pollutant area or off-road driving, extended air conditioner or heater operation


undefined
0000-00
GENERAL
* Use only approved Ssangyong genuine parts.
Maintenance service and record retention are the owner's responsibility. You should retain
evidence that proper maintenance has been performed on your vehicle in accordance with the
scheduled maintenance service chart.
* EU Countries: Only countries that belong to EU. (It does not apply to all countries in EU.)
ENGINE CONTROL SYSTEM
Chart Symbols:
Inspect these items and their related parts. If necessary, correct, clean, replenish, adjust or replace.
Replace or change.
In order to secure engine long life and effective break-in, first oil (factory filled) would be recommended to
drain with in 10,000 km.
I -
R -
**-
(1)*If vehicle is operated under severe condition: short distance driving, extensive idling or
driving in dusty condition, shorten the service interval.
(2)*If vehicle is operated under severe condition, pollutant area or off-road driving, driving in
dusty condition or sandy condition, frequently inspect the air cleaner, if necessary,
change the air cleaner.
(3)*Refer to "Recommended fluids and lubricants".
2) Gasoline Engine
