SSANGYONG TURISMO 2015 Technical manual

INDEX - VICS(VEHICLE INSTRUCTION CARD)
SSANGYONG VEHICLES
Page Vehicle Details
1Index n/a
2Supplement (Electronic Parking Brake, etc) n/a
3Turismo 5 seats / 5 door MPV
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
INDEX PAGE 1

Vehicle specications are subject to change. This vehicle does not include any manufacturer handbooks or manuals.
VEHICLE INSTRUCTION CARD SUPPLEMENT
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for
assistance.
SSANGYONG VEHICLES
24-10-2015
Don’t panic! Despite seeing a new light pop-up on your instrument panel, unless it is red it is likely the car is still running ne, and while there may be a
problem to attend to, proceed with condence and patience.
RED
Red indicates a potentially serious problem or safety issue. Attend to it! Red may also indicate an important reminder.
YELLOW
Yellow/orange means something needs to be serviced or repaired soon. If it is ashing, it is important that you contact your rental agent for advice.
GREEN
Green or blue is only telling you that a system is on or operating normally.
WARNING LIGHTS AND WHAT THEY MEAN
Deadlock / safelock messages shown on the instrument display when the engine is turned off simply indicate that once you exit the vehicle and lock the
doors, they’re effectively deadlocked and anyone left in the car wouldn’t be able to get out in the event of an emergency. The warning is nothing to worry
about and is just a standard advisory message.
DEADLOCKS
A seatbelt warning light may illuminate when the engine is turned on. This may mean that the electronic parking brake (EPB) becomes auto activated to
prevent vehicle movement. To deactivate these warning lights, and turn off the auto activation of the EPB in this instance, ensure all passengers fasten
their seatbelts, and remove any luggage from on top of the seats. For safety secure all luggage inside the boot.
SEATBELT WARNING LIGHTS

design and production by : Drake Enterprises Limited - Phone : [phone]
USEFUL INFORMATION ABOUT YOUR VEHICLE
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is tted with
an active airbag (SRS). Follow all
tting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the parking brake should be
fully applied with the vehicle left in rst or
reverse gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION! NOTE: SHOULD THIS VEHICLE NOT
BE SUPPLIED WITH A SPARE WHEEL,
PLEASE REFER TO THE TELEPHONE
NUMBERS SHOWN ON THE TAX DISC
HOLDER.
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
SSANGYONG TURISMO 5 SEATS
5 DOOR MPV
Key / remote control operated central deadlocking. Auto-locking on driving away. To lock all doors press the central locking
switch on the centre console.
Vehicles are tted with an alarm system. Passive arming of electronic engine immobiliser after removal of the key from the
starter switch. Visible VIN.
Centrally locked. Use the key or remote control to unlock / open.
Electric internal adjustment operated via a control pad on the driver’s door.
Electric front and rear operated via control switches on the driver’s door.
If tted: electric slide sunroof, operated by roof mounted switchgear.
Fitted to the edge of the rear passenger doors. To activate press the central locking button to lock all doors and
tailgate. Ensure the doors are securely locked before use.
Ensure gear selector is in neutral (or N or P if automatic) and foot operated parking brake is on. Place ignition key in starter
switch on righthand side of steering wheel. Use a normal starting routine. Select desired gear. Release foot operated parking
brake and brake pedal and gently press the accelerator to move the vehicle.
Located on the rear nearside. Centrally locked. Use the key to unlock the fuel ller cap, and twist the cap off anticlockwise.
Pull the bonnet release lever located on the right side panel in the driver’s foot well. Depress the catch under the bonnet to
release it.
The rear seats are divided into sections which can be separately folded. The second row of seats can be folded into
captains tables. The second and third row of seats can be slid forwards/backwards. Unlock the seat catch before folding/
sliding. When returning the seat to normal use ensure seat is rmly locked into position.
The full size spare tyre with tools and jack are located under a oor panel in the boot. Move the vehicle to rm / level ground.
Turn the engine off, select rst gear (manual) or P (automatic). Apply the foot operated parking brake. Loosen the wheel nuts
by turning them anticlockwise (do not remove them) before jacking up. Only use the specic reinforced jack points on the
underside of the vehicle. Crank the jack to lift the vehicle. Completely loosen / remove nuts and wheel and replace with the
spare. Ret / tighten the wheel nuts. Lower the vehicle. Tighten the wheel nuts.
To change gears press the button on the shift lever and move the lever forwards or backwards. Select N for neutral, P
when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this gear can be selected).
For normal driving select D where the transmission will use all available forward gears automatically (a ‘kickdown ‘ facility is
provided when the accelerator is pressed all the way to the oor past the normal acceleration point forcing the transmission
to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to return to normal accelerator
use). Use the M+ or M- settings for manual selection of gears. Whenever the vehicle is at a standstill apply the foot operated
parking brake. (Some models may also feature 4x4 wheel drive).
VIC-SYG-01 / 28-01-2015
Locking the doors?
Anti-theft system?
Opening the tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel ller cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an automatic?
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
ller ap).
Fuel Tank Capacity:
80.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
215/65 R16
225/65 R16
225/65 R17
Conrm tyre ination pressures by
consulting the tyre pressure table found on
the driver’s door B-pillar.
Some vehicles are tted with an electronic
tyre pressure monitoring system.
Vehicles carry a full size spare wheel, but
some models may carry a spacesaver
spare which has limited travel distance and
road speed when it used.
1 Heating & Ventilation
2 Hazard Lights
3 Starter Switch
4 Headlights
5 Sidelights
6 Indicators
7 Wipers
8 Rear Screen Wipers
9 Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic Parking Brake
Tilt
Lumbar
Legroom
Height
11
1
3
4 / 5 / 6 / 12 / 13
9 9
10
7 / 8
P
R
N
D
M+
M-
2
14
