SSI SAFE-T-LOCK User manual

EL510
-
1001
P
ROGRAMMABLE
CODE SWITCH
WARRANTY
• The
Safe-T-Lock
™
is a sealed unit
.
R
emoving or tampering with t
he epoxy encapsul
ant will void the warranty
.
• Units damaged due to overload, abuse or incorrect installation will not be acce
pted
in warranty.
• Units have no serviceable parts.
This product is warranted against defects in materials or workmanship
for one year
for one year
from the date of purchase.
from the date of purchase.
Should service be required, the customer should return the
product for warranty consideration. Shipping will be prepaid via ground transportation.
All products requiring warranty service shall be returned
within one year from the date of
within one year from the date of
purchase.
purchase.
Exclusions from this warranty are the fi nish, and damage caused by improper
installation or use.
The manufacturer assumes no liability for costs incurred to remove or reinstall the
product, or for lost revenues due to equipment downtime.
This warranty gives you specifi c legal rights. You may also have other rights which vary
from state to state
and country to country.
USER OPERATION*
OPERATIONOPERATION
INSTRUCTIONS
INSTRUCTIONS
Read and Save
16355 SOUTH LONE ELM ROAD
OLATHE, KANSAS 66062
•
USA
TOL
L FREE:
800-447-3693
•
PHONE:
913-
780-1
440
•
FAX
:
913-780-1427
www.superiorsignals.com
USER LOG ON:
1. Enter the two-digit user ID, followed by the 4-8 digit PIN.
2. Press Enter key.
3. High tone BEEP and GREEN LED fl ash indicates TRUCK IS
READY.
4. Low tone BEEP and RED LED fl ash indicates, INVALID
ENTRY TRY AGAIN.
User MENU:
1 – Change user PIN
*For security, create a new PIN as soon as possible,
IMPORTANT
Users have one minute to enter a menu function after LOG ON. After one minute the
menu functions will be locked out until the next time user LOGS ON.
MENU 1:
Change User
PIN
Enter New PIN followed by Enter key.
Repeat New PIN followed by Enter key.
High tone BEEP indicates change was successful and exited this
menu function.
Pressing the CE key will clear the last entry. Press CE to exit.
USER LOG OFF:
1
. Press
Power/En
ter key
3 options
2
. Automatic Seat Time Out: If the user is out of the seat for more
than 3 minutes, the Programmable Code Switch will
automatically log the user off. (If seat switch is connected)
3
. Turn truck ignition off. (On units with Key Switch Connection)
*Copy this page and hand out as neede
d
*For security, create a new PIN as soon as possible,

SUPERVISOR OPERATION
The 00 ID location is reserved for the Supervisor. Supervisor default Personal
Identifi cation Number (PIN) is 1234. Supervisor PIN can be reset by pressing and
holding 1, 3, 7 and 9 key until the unit sounds a reset tone. (approximately 5 seconds)
The reset will be confi rmed by 4 fl ashes of the GREEN and RED LED.
*For security, create a new PIN as soon as possible.
SUPERVISOR
LOG ON:
Press ‘00’ then enter supervisor PIN.
Press Enter key
High tone BEEP and RED LED FLASH to confi rm the entry
was accepted.
Low
tone BEEP and RED LED FLASH for invalid code.
SUPERVISOR
M
ENU
:
1 – Change supervisor PIN
2 – Add/Delete users
3 – Last User
4 – Maintenance menu
To select a menu function, press the corresponding number followed by the Enter key.
The red LED will blink to indicate the menu entered.
MENU 1:
Change Supervisor
PIN
Enter new PIN followed by Enter key.
Repeat the PIN and Enter key to confi rm.
High tone BEEP, GREEN LED and RED LED will fl ash to indicate
change was successful.
Low tone BEEP and RED LED fl ash indicates change was
rejected
Pressing the CE key at any time before the BEEP will start over.
Press CE after the BEEP to return to supervisor menu.
MENU 2:
Add/Delete users
Enter two-digit user ID (01-99)
RED LED FLASH and BEEP indicates user ID is taken.
GREEN LED FLASH and BEEP indicates user ID is available.
To Add a user (if ID is not taken)
Press Enter, the GREEN LED will
FLASH
to indicate the user has
been added.
To Delete a user (if ID is taken
Press Enter, the RED LED will FLASH
to
indicate the use
r has
been remo
ved.
(Pressing Enter again will add user ID with default PIN)
Enter the next two digit user and press the Enter key to add
another user.
Press the CE key to return to the supervisor menu.
SUPERVISOR OPERATION
MENU 3:
Last User
LED FLASHES will indicate the last user ID (01-99).
A GREEN LED FLASH is for the 10’s digit.
A RED LED FLASH is for the 1’s digit.
Press Enter key to start and repeat.
Example: for user 83: 8 - Green fl ashes, 3 - Red fl ashes
Press the Enter key to repeat
Press the CE key to return to supervisor menu.
MENU 4:
Maintenance Menu
Press the Enter key to enable / disable the alarm.
RED LED will FLASH when alarm is disabled.
GREEN LED will FLASH when alarm is enabled.
Press 1 and enter to hear alarm tone.
When alarm is enabled, maintenance hours will be reset 250 hrs.
Press the CE key to return to supervisor menu.
To Exit the Supervisor Menu, press the CE key
Unit will automatically log the supervisor out, 1 minute after last key press.
*IMPORTANT – NOTE
SUPERVISOR MUST KEEP A LOG OF USER ID NUMBERS AND USER NAME.
SAMPLE LOG
Truck
_________________________
Truck _________________________Truck
Serial Number
____________________
USER ID USER NAME (& EMPLOYEE NUMBER)
USER ID USER NAME (& EMPLOYEE NUMBER)
USER ID USER NAME (& EMPLOYEE NUMBER)
*For security, create a new PIN as soon as possible.
