Ssl DD889B User manual

To ensure safety while driving
and to comply with laws,
drivers should not watch video or
operate the video device while driving.

PRECAUTION
Class 1 laser product
This car multimedia player is a class 1 laser product. However
This car multimedia player uses a visible/invisible laser beam
which could cause . Hazardous radiation exposure if directed.
Be sure to operate the car multimedia player correctly as
instructed. Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure. Do not open covers and do not
repair yourself. Refer servicing to qualified personnel.
-1-

-2-
Content
Precaution.........................................................................................
Content.............................................................................................
Installation diagram...........................................................................
Wiring diagram..................................................................................
Remote control..................................................................................
Controls on main unit........................................................................
Remote control description................................................................
Universal functions............................................................................
Radio operation................................................................................
Bluetooth operation..........................................................................
Disc/USB/Card operation..................................................................
1. Loading or unloading a Disc, USB or Card....................................
1.1 Loading a Disc, USB or Card......................................................
1.2 Unloading a Disc, USB or Card...................................................
2. Function Icons............................................................................
2.1 Function Icons-board of Digital Video/CD(Video)/MPEG4/Image
/MP3/WMA.................................................................................
2.2 CD interface..............................................................................
3. Function of controls on the touch screen/main unit/remote
control........................................................................................
* Region Code...............................................................................
* Parental Control..........................................................................
AUX IN operation..............................................................................
External iPod operation....................................................................
Rear View Camera.............................................................................
Troubleshooting...............................................................................
Specification....................................................................................
1
2
3
4
5
6
7
8
11
14
17
17
17
18
18
18
19
20
29
30
31
32
33
34
35

-3-
MOUNTING BRACKET
MOUNTING BRACKET
MOUNTING BOLTS
Installation diagram
HEX NUT
SPRING WASHER
PLAIN WASHER
TAPPING SCREW
DASH BOARD
METAL MOUNTING
STRAP
CONSOLE
HEX BOLT
PLASTIC FRAME

-4-
Wiring diagram
IGNITION SWITCH
RED
WHITE
WHITE/BLACK
GREY
GREY/BLACK
GREEN
GREEN/BLACK
VIOLET
VIOLET/BLACK
YELLOW
CONSTANT 12 VOLTS
BLACK
GROUND(B-)
BLUE
AUTO ANTENNA
Front Left
BROWN
(B-) PARKING BRAKE
PINK
RADIO ANTENNA
(B+) 12V
REAR CAMERA SWITCH
REAR CAMERA INPUT
YELLOW
GREY
SUB WOOFER
Front Output White(L)
VIDEO OUTPUT (brown)
FUSE
ISO CONNECTOR
Front Output Red(R)
Rear Left
Front Right
Rear Right
NOTE:
1. Must use 4 ohm speakers.
2. After connecting parking brake input line, video on screen of control panel
will be displayed only after
3. Before finishing wiring, do not attach control panel onto chassis.
applying parking brake.

-5-
1. Removing insulating sheet
If
)
)
)
.
)
)
)
.
)
)
using remote control for the first time, you
can see an insulating sheet at the bottom
side of remote control as right.
you must remove the insulating sheet as right.
Otherwise, the remote control is disabled.
2. Replace battery
If the electric energy of battery is weak,
replace it.
1 Press and hold the movable block as direction
indicated by arrow 1 as right, at one time pull
batteryl holder out of remote control as
direction indicated by arrow 2 as right.
2 Replace the old battery by a new one with (+)
polarity side upward as right.
3 Insert the battery holder into remote control
again as right.
3 Note about using remote control
1 You should face the emitting window of remote control towards the sensor
window of the unit.
2 Operation angle for front panel: About 30 degree
3 The distance between the emitting window of remote control and the sensor
window of the unit : < 5M .
4 Battery Warning
leakage may cause damage to remote control.1 Battery
2Do not throw batteries into fire.
.
3.To avoid risk of accident, keep batteries out of reach of children.
REMOTE CONTROL

-6-
Controls on Main Unit
Control Panel
1. POWER or SRC BUTTON
2.
4.
MUTE BUTTON
>|| or CH1~6 BUTTON
3. RESET BUTTON
SEL BUTTON and VOL KNOB
5. OPEN BUTTON
6. USB PORT and COVER
7. AUX IN JACK
8.
9. EQ BUTTON
10. BAND BUTTON
11. MICROPHONE
12. REL BUTTON
13. IR SENSOR WINDOW
14. DISC SLOT
15. EJECT BUTTON
16. CARD SLOT
Top Front View Drawi ng after Flipping down Control Panel Front View Dr awi ng after Removing Control Panel
15
14
16
1
7
2
3
4
6
9
8
10
11
12
13
5MIC

1
2
6
10
11
3
20
21
33
9
12
17
34
23
4
5
7
8
13
14
15 16
18
19
22
24
25
26
27
28
29
30
31
32
Remote Control Description
16. VOL- BUTTON
17. SEL BUTTON
18. SETUP BUTTON
19. GOTO or * BUTTON
20. >|| BUTTON
21. STOP BUTTON
22. AUDIO or MO/ST BUTTON
23. ANGLE BUTTON
24. EQ or LOUD BUTTON
25. CLK BUTTON
26. ^ BUTTON
29. > BUTTON
30. V BUTTON
31. |<< BUTTON
32. INT BUTTON
33. NUMBER(0~9) BUTTON
34. +10 or # BUTTON
35. AF BUTTON
36. TA BUTTON
37. RPT BUTTON
27. >>| BUTTON
28. ENTER BUTTON
1. POWER or SRC BUTTON
2. MUTE BUTTON
3. HANG UP or REDIAL BUTTON
4. ZOOM BUTTON
5. CALL or PAIR BUTTON
6. MENU or SW BUTTON
7. >> BUTTON
8. SUBTITLE or LO/DX BUTTON
9. < BUTTON
BAND or OSD
<< BUTTON
12. A/PS or TITLE/PBC BUTTON
13. TOP BUTTON
14. VOL+ BUTTON
15. RDM BUTTON
10. BUTTON
11.
-7-
35
36
37

-8-
Universal functions
1. POWER button or icon
In power off mode, pressing POWER button on remote control or pressing POWER button on
control panel powers on main unit.
In power on mode, long pressing POWER button on remote control or long pressing POWER
button on control panel or touching icon on source menu(see Source menu fig.on next
page) powers off main unit.
2. VOL knob & VOL+/VOL- buttons
To adjust volume level, rotate VOL knob on control panel or press or hold VOL+ or VOL- button
on remote control.
3. SEL button
To switch between BASS,TREBLE,BALANCE, FADE,COLOR,BRIGHTNESS,CONTRAST, TINT
and VOLUME, briefly and repeatedly press SEL button.
After switching on the desired mode above, rotate VOL knob or press VOL+/VOL- buttons to set it.
To switch between BLUETOOTH, REG, PI, TA, AF, LOUD, SWF, EQ, DX/LOCAL(in radio mode),
STEREO/MONO(in radio mode), TIME 12H/24H, CLOCK, BUZZ,EUR/USA FREQ,ANIMATION and
BG, long press SEL button to switch on Bluetooth, then briefly and repeatedly press SEL button.
After switching on the desired mode above, rotate VOL knob or press VOL+/VOL- buttons to set it.
4. MUTE button
To switch MUTE mode on or off, press MUTE button on remote control or press MUTE button on
control panel.
5. EQ button
To select a desired preset EQ mode from JAZZ, CLASSIC, POP, ROCK and USER, press EQ
button on remote control or on control panel continuously.
6. LOUD button
To switch on or off LOUD mode, long press LOUD button on remote control .
7. SW button
To switch on or off SUBWOOFER mode, long press SW button on remote control.
8. CLK button
Press CLK button on remote control to display clock time .
9. SRC button and source menu
To switch work source between RADIO, DISC(after inserting a disc), USB(after inserting a USB
storage), CARD(after inserting a card), AUX and BLUETOOTH MUSIC, press SRC button on
remote control or press SRC button on control panel continuously.
During disc(non-CD)/USB/card playback, touch screen to pop up Function Icons-board and then
touch the icon in the Function Icons-board to enter the source menu(refer to Disc/USB/Card
Operation) .
During AUX playback, touch screen to pop up AUX interface and then touch icon to enter the
source menu(refer to AUX Operation operation).
In radio, bluetooth music or CD mode, touch icon to enter the source menu(refer to Radio
Operation, Bluetooth Operation and Disc/USB/Card Operation).

-9-
The source menu displays as follows:
In source menu, touch one icon of RADIO, DISC, BLUETOOTH MUSIC, AUX, SD CARD and USB
to enter one work source of RADIO, DISC, BLUETOOTH MUSIC, AUX, SD CARD and USB.
10.SETUP icon
1) SETTINGS SYSTEM
In source menu, touch SETUP icon to display SYSTEM page of SETUP menu as follows:
In the SYSTEM page of SETUP menu, repeatedly touch the or icon to highlight one setting
item of BRIGHTNESS, CONTRAST, COLOR, TINT, ANIMATION, WALLPAPER and BLUETOOTH.
After highlighting a desired setting item, touch the or icon to set it.
2) SETTING SOUND
In SOUND menu, touch SOUND icon to display SOUND page of SETUP menu as follows:
Source Menu
System page of SETUP menu
Sound page of SETUP menu
COLOR
TINT
CONTRAST
16
BASS
TREBLE
+03
BALANCE

In the SOUND page of SETUP menu, repeatedly touch the or icon to highlight one setting
item of TREBLE, BASS, BALANCE, FADE, SUBWOOFER, LOUDNESS, RADIO LOC/DX(entering
Source Menu in radio mode), RADIO STEREO(entering Source Menu in radio mode) and BUZZER
ON/OFF. After highlighting a desired setting item, touch the or icon to set it.
3) SETTING TIME
In CLOCK menu, touch TIME icon to display TIME page of SETUP menu as follows:
In the TIME page of SETUP menu, repeatedly touch the or icon to highlight one setting item
of HOUR, MINUTE and 24H/12H. After highlighting a desired setting item, touch the or
icon to set it.
4) SETTING RDS
In RDS menu, touch RDS icon to display RDS page of SETUP menu as follows:
In the RDS page of SETUP menu, repeatedly touch the or icon to highlight one setting item
of REGION and PI SOUND/MUTE. After highlighting a desired setting item, touch the or
icon to set it.
After finishing setting, touch icon to return back to normal playback.
11.OPEN button
press OPEN button on control panel to flip down the control panel.
12.REL button
Press REL button on control panel to detach the control panel, then hold the right part of the
control panel to lift up a little and pull it rightwards to remove it.
13.RESET button
When LCD displays wrongly or some buttons are not available or sound is distorted, use the
sharp end of a pointed object to press RESET button to reset the program to zero.
-10-
Time page of SETUP menu
HOUR
MINUTE
24H/12H
08:13 AM
RDS page of SETUP menu
REGION
PI SOUND/MUTE
MUTE

-11-
Radio Operation
1. To enter RADIO mode(SRC button or RADIO icon)
When you use SRC button or source menu (tapping RADIO icon) to enter RADIO
mode, it will display radio interface as follows:
* Some icons on radio interface correspond with the buttons on remote control or control
panel as follows:
MUTE icon = MUTE button
& icons = VOL- and VOL+ buttons = VOL knob
EQ icon = EQ button
icon : To pop up BLUETOOTH PHONE interface.
icon: To enter source menu.
2. To switch between bands (BAND)
The BAND icon or button can switch between bands of FM1, FM2, FM3, MW1 and MW2,
and the word FM1,FM2,FM3,MW1 or MW2 will be displayed on screen.
3. To search for a station ( and icons or v and ^ buttons)
1) Long touching or icon or long pressing v or ^ button on remote control can
automatically search down or up for an available station beginning from the current
frequency.
2) Briefly touching or icon or briefly pressing v or ^ button on remote control can
manually search down or up for a your desired station beginning from the current
frequency.
4. To preset and scan all memory stations (APS icon or A/PS buttons)
1) When long touching APS icon or long pressing A/PS button on remote control , the radio
searches from the lowest frequency and checks the signal strength level until 1 cycle
search is finished, and the 6 strongest stations are preset to corresponding preset number
memory bank for the current band.
The presetting function can be implemented in selected FM or MW band. (It can presets
3x6 stations for FM and 2x6 stations for MW in all)
2) When briefly touching APS icon or briefly pressing A/PS button, the radio scans
for each preset station in FM or MW band from NO.1 bank, each preset station broad-
casts for 5 seconds. After finishing a circle of scanning, it will resume broadcasting the
station in NO.1 bank.
NOTE: In FM band, FM1,FM2 and FM3 are preset and scaned as one band at a time;
In MW band, MW1 and MW2 are preset and scaned as one band at a time.
DX
DX ST USER
1
2
36
5
4
87.50
90.00
98.00
89.50
89.50
107.00
107.00
106.00
FM1
107.00
107.00
MHZ
MHZ
AF

-12-
5. To preset and listen to a memory station(1~6 icons or 1~6 buttons or CH1-6 button )
1) Long touching one of 6 number(1~6) icons or long pressing one of 6 number(1~6)
buttons can preset the current broadcasting station of the current band in the number
memory bank; .
2) Briefly touching one of 6 number(1~6) icons or briefly pressing one of 6 number(1~6)
buttons can listen to the memory station in the current band preset in the number
memory bank.
* CH1-6 button:
1)To preset a station in a memory bank with CH1-6 button, first select a desired
band; then press CH1-6 button to select a desired memory bank; and then search
for a desired station; finally long press CH1-6 button to store the station in the
memory bank.
2)To listen to a preset station with CH1-6 button, first switch on a desired band, then
continuously press CH1-6 button highlight and listen to it.
6. To switch on between stereo and mono mode (MO/ST button)
Press MO/ST button on remote control to select STEREO or MONO mode for FM band.
When the STEREO mode is activated, it can get better audio effect; when the
MONO mode is activated, it can get clearer audio signal.
7. To switch on between local and distance mode (LO/DX button)
Press LO/DX button to turn LOC on to tune for local stations with weak interference;
Press LO/DX button to turn DX on to tune for distance stations with stronger signal.
8. To search for a RDS station that is broadcasting a typed program (PTY)
Continuously touching PTY icon on touch screen switches between the program
types such as: NEWS ...and so on.
After selecting a desired program type, no operation for a while, it displays PTY
SEEK and automatically searches for a station that is broadcasting the selected
type of program.
If the station that is broadcasting the selected type of program does not exist, it will
display NO PTY and return back to the previous normal station.
9. To automatically alternate a stronger signal of frequency for the current RDS station(AF)
During broadcasting a typed program of a RDS station, use the AF icon in the RADIO
interface or SEL and VOL buttons to set AF mode on or long press AF button on remote
control to switch on AF mode, then AF icon flashes on screen.
After switching on AF mode, the radio checks the signal strength of AF(alternate
frequency) all the time. Whenever a new AF is stronger than the current frequency,

It switches over to the AF for a short time, and the AF icon is light on screen(not
flash).
* In FM mode, when switching on AF mode, the radio auto searches for or preset
only those RDS stations.
* In FM mode, when switching on AF and TA modes, the radio auto searches for
only those RDS stations broadcasting traffic announcement.
10. REGION mode
use the RDS page of the SETUP MENU or the SEL and VOL buttons to set
REGION mode on or off.
In REGION on mode, when switching on AF mode, the radio can’t switch over to
those AF stations which have a different regional program content.
In REGION off mode, when switching on AF mode, the radio can switch over to
those AF stations which have a different regional program content.
11. PI mode
use the RDS page of the SETUP MENU or the SEL and VOL buttons to set PI
SOUND or PI MUTE mode.
In PI SOUND mode, when switching on AF mode, if a car cruises that critical area
back and forth, an oscillation phenomenon can be occurred, because the different
PI code can be receive from a same AF. when the different PI sound (DIP) is heard
once in a while, the different PI sound will be heard for less than 1 second.
In PI MUTE mode, when switching on AF mode and under above same situation,
a mute sound will be heard for less than 1 second.
12. To automatically search for traffic announcements (TA)
In any mode, use the TA icon or SEL and VOL buttons to set TA mode on or long press
TA button on remote control to switch on TA mode, then TA: ON will display on screen
for a while and begin to search for those RDS radio stations transmitting traffic an-
nouncement.
When an RDS radio station transmits traffic announcement and is received by the
radio, temporarily switch the current work source to an RDS radio station broad-
casting traffic announcement, and TRAFFIC will be displayed on screen.
When the traffic announcement is over, it will return back to previous work source.
-13-

-14-
Bluetooth Operation
1. Pairing and Connecting
Prior to using the bluetooth device named SSL as a handfree system for a
bluetooth-enabled mobile phone for the first time, you must
as follows:
* Prior to pairing and connecting, when displaying No Video interface of radio, CD,
AUX IN or Bluetooth music, the logo Bluetooth flashes in the touch screen.
* During using the Bluetooth device named SSL as a handfree system for a
bluetooth-enabled mobile phone, place the bluetooth-enabled mobile phone in
3 meters from the Car A/V System;
1) Long press PAIR button on remote control to enter pairing mode and flash the
logo of the Bluetooth with blue frame(pressing BAND button can exit pairing mode).
2).Switch on the bluetooth mode of your mobile phone; then s
bluetooth device and enter it; b device car
SSL , select it and enter it; then it will show an
interface that asks you to input a password, input 8888 and enter it; then i
with the bluetooth device SSL of the car A/V system, Confirm it,
then the frame of the bluetooth logo will be filled by blue color and they are light
all the time.
* finishing pairing and ing
or the mobile phone
plays music
2. BLUETOOTH PHONE
1) Make a call
(1) Dial with mobile phone directly;
(2)Dial with the controls on BLUETOOTH PHONE interface or on remote control or
on control panel
a. Long press button on remote control or touch icon to pop up BLUETOOTH
PHONE interface as follows:
pair and connect
them
elect the item to find a
When it finds the luetooth of the A/V
system, the name will be displayed
t will
pair and connect
When connect , the audio of the mobile phone transfers
to the car audio system whenever a call is made or received
.
: Same as MUTE button.
& : Same as VOL+ and VOL- or
VOL knob.

-15-
b. Use the number icons or buttons to input your desired phone number;
* When inputting a wrong digit, use icon or < button to delete it.
c. After finishing inputting, touch icon or press button on remote control to
dial out.
2) Redial last dialed phone number
Touch icon or long press button on remote control to dial out the last dialed
phone number.
3) Answer a call
During an incoming call, the incoming telephone number displays in the the
BLUETOOTH PHONE interface. If you want to receive it, touch icon or press
button on remote control; if you want to reject it, touch icon or press
button on remote control.
4) End a call
When ending a call, touch icon or use button.
5) Switch the audio between the unit and your device
During phone luetooth handfree system of the car A/V system,
if you want to change the phone audio to your mobile phone, touch icon or
press button on remote control.
During phone talking using the mobile phone, if you want to change the phone
audio to the the car A/V system again, use button.(only for some mobile
phone)
6)
During phone + and - icon or
; use icon or MUTE button to mute sound
* * / # icons and buttons
they perform as * / # buttons on mobile phone.
3 BLUETOOTH MUSIC
1 Touching BLUETOOTH MUSIC on source menu or pressing SRC button can pop
up BLUETOOTH MUSIC interface as follows:
talking using the b
Adjusting the volume during a call
talking, use VOL knob or VOL+ and VOL-
buttons to adjust volume level .
.
)
USER SWF
USER SWF
Bluetooth
MUSIC
Bluetooth
MUSIC

-16-
and icons = VOL- and VOL+ buttons = VOL knob
MUTE icon = MUTE button
EQ icon = short pressing EQ/LOUD button
icon : Popping up BLUETOOTH PHONE interface(after pairing and connecting
a mobile phone with Bluetooth function).
icon = button
icon = button
and icons = and button
icon: To enter source menu.
TA icon : To switch TA mode on or off.
AF icon : To switch AF mode on or off.
) using your mobile phone with the bluetooth function to audio/video if
it the audio of the mobile phone will change
into .
The SSL(DD889B) supports A2DP, which enables the user to stream audio from
their device
) T the car A/V system so these icons on
the BLUETOOTH MUSIC interface except Bluetooth Music and their
buttons on control panel or on remote control are available for audio/video play-
back of your mobile phone during playback. But n
for / icon and / buttons, and the function of resume playback after
pausing or stopping is available only for some mobile phone
to display BT, to
Bluetooth
2 When play ,
is paired and connected to the unit,
the car A/V system
3he Bluetooth device of supports AVRCP,
corresponding
o fast forward/backward functions
.
* If you don’t want to use the Bluetooth function of the car A/V system , long press
SEL button then use VOL knob or VOL+ and VOL- buttons switch
off .

-17-
Disc/USB/Card Operation
1. Loading or unloading a Disc, USB or Card
1.1 Loading a Disc, USB or Card
To play files in a disc, press OPEN button on control panel to flip down the control
panel, then insert a disc with label surface up into disc slot, then flip up the control
panel and attach onto chassis till hear a click sound, finally it will automatically play.
* Caution of Disc Handeling
1) Handle a disc by its edge, do not touch the surface of play side.
2) Before inserting a disc, wipe the disc outwards from the disc
center with a clean, soft, dry, lint-free cloth. Do not use solvents
/thinner such as petrol/benzine, cleaner.
3) After ejecting a disc, place the disc inside of a disc case.
USB: To use a USB function, open the port cover, insert the USB flash drive
and the unit will begin to play the files automatically.
SD: To use a SD function, remove the control panel, insert the SD card. Re-
attach the control panel and the unit will begin to play the files automatically.
Label
surface up
MIC

-18-
1.2 Unloading a Disc, USB or Card
To unload the disc in disc slot, use STOP button to stop playback and then press
OPEN button to flip down the control panel, then press EJECT button to eject disc,
then remove it.
* During MP3/WMA playback, the information of file, folder, title, artist and album
will be scrolling on LCD display. As long as the current playing MP3/WMA music
contains relevant ID3 tag information in version 1.0/2.0 format, the 3 items
underlined above will be scrolling on LCD display; otherwise, they will not.
* There is ESP function for all formats of discs.
2. Function Icons
2.1 Function Icons-board of Digital Video/CD(Video)/MPEG4/Image/MP3/WMA
During Digital Video/CD(Video)/MPEG4/Image playback, tapping any place on
touch screen can pop up Function Icons-board 1 as next page, then tap icon
to pop up Function Icons-board 2 as next page.
During MP3/WMA playback, tapping any place except folder area, track area and
MP3/WMA&Image&MPEG4 icons can pop up Function Icons-board 1 same as one
of Digital Video/CD(Video)/MPEG4/Image, then tap icon to pop up Function
Icons-board 2 same as one of Digital Video/CD(Video)/MPEG4/Image.
To remove the USB flash drive or SD card, press STOP and you may now remove
the respective media.
WMA
WMA
Mp3
Mp3
[MP3]
ITLE / SONG: TRACK 03 /
ITLE / SONG: TRACK 03 /
001
001
002
002
003
003
004
004
005
005
006
006
007
007
008
008
007
001
002
003
Folder area Track area
MP3/WMA icon Image icon MPEG4 icon
