Ssl CL10D User manual

03.2012
CL10D
CL10D
10
10

35
0.573
4.851
0.65
1.2
0.236
1.8
94
900W/1800W
2
35
0.617
6.067
0.687
1.167
0.236
7.2
96
900W/1800W
8
10” (254mm) Subwoofer
(900 Watts RMS Sealed Enclosure)
Wiring
Please take every precaution to wire your DVC woofers
for the correct impedance
+-+-
+-+-
10” (254mm) CUSTOM TOOLED HIGH EFFICIENCY POLY
INJECTION CONE BUTYL RUBBER SURROUND
DUAL 2-1/2” (64mm) HIGH TEMPERATURE KAPTON
VOICE COIL
1800 WATTS PEAK/900 WATTS RMS
FREQUENCY RESPONSE: 35 Hz-2.2 KHz
SENSITIVITY: 94dB (1 WATT/1 METER)
IMPEDANCE: DUAL 4 OHMS
MOUNTING DEPTH: 5-13/16” (148mm)
MOUNTING DIAMETER: 9-3/16” (233mm)
2 ohms 8 ohms

Box Volume :
1.0 Cu Ft to 1.5 Cu Ft
Port Frequency :
Port Diameter :
Port Length :
Box is given as internal air volume including driver displacement
Ported Enclosure
Frequency
CL10D Amplitude Response(dB/Hz)
Box Volume :
0.4 Cu Ft to 1.0 Cu Ft
Box is given as internal air volume including driver displacement
Sealed Enclosure
Recommended Enclosures
Frequency
Please note : Our recommended box volumes are given for
internal air requirements.
CL10D Amplitude Response(dB/Hz)
Sealed Enclosure
Ported Enclosure
3
58 to 45
6 to 4
49
42
lnches
Hz
lnches
CAR AUDIO ACCESSORIES
SOUND STORM LAB AUDIO ACCESSORIES
