ST Engineering Electronics DigiSAFE DiskCrypt M10 User manual

DigiSAFE
DISKCRYPT M10
USER MANUAL
Version 1.0.1

This page has been left blank intentionally
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual i
Disclaimer
Thank you for purchasing DigiSAFE DISKCRYPT M10.
DISKCRYPT M10 has been designed to be compliant with the M.2 SATA Solid State Drive
operating specifications as well as USB 3.1 operating specifications. DISKCRYPT M10 is
also backward compatible with USB 3.0/2.0 machines.
ST Electronics (Info-Security) accepts no liability for any loss of data or the inability of
DISKCRYPT M10 to work with equipment that are not compatible with the above operating
specifications. Nor can ST Electronics (Info-Security) accept any liability or responsibility
for software which is also non-compliant.

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual i
Disclaimer
Thank you for purchasing DigiSAFE DISKCRYPT M10.
DISKCRYPT M10 has been designed to be compliant with the M.2 SATA Solid State Drive
operating specifications as well as USB 3.1 operating specifications. DISKCRYPT M10 is
also backward compatible with USB 3.0/2.0 machines.
ST Electronics (Info-Security) accepts no liability for any loss of data or the inability of
DISKCRYPT M10 to work with equipment that are not compatible with the above operating
specifications. Nor can ST Electronics (Info-Security) accept any liability or responsibility
for software which is also non-compliant.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual i
Disclaimer
Thank you for purchasing DigiSAFE
DISKCRYPT M10.
DISKCRYPT M10 has been designed to be compliant with the M.2 SATA Solid State Drive
operating specifications as well as USB 3.1 operating specifications. DISKCRYPT M10 is
also backward compatible with USB 3.0/2.0 machines.
ST Electronics (Info-Security) accepts no liability for any loss of data or the inability of
DISKCRYPT M10 to work with equipment that are not compatible with the above operating
specifications. Nor can ST Electronics (Info-Security) accept any liability or responsibility
for software which is also non-compliant.
ST Engineering accepts no liability for any loss of data or the inability of DISKCRYPT M10
to work with equipment that are not compatible with the above operating specifications.
Nor can ST Engineering accept any liability or responsibility for software which is
also non-compliant.

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual ii
Contents
1. About this Guide............................................................................................. 1
2. Introduction..................................................................................................... 2
2.1. About DISKCRYPT M10 ......................................................................... 2
2.2. Connection Ports..................................................................................... 3
2.3. Checklist ................................................................................................. 3
2.4. Specifications .......................................................................................... 4
3. Using DISKCRYPT M10................................................................................. 5
3.1. Authentication ......................................................................................... 5
3.2. Using the built-in keypad......................................................................... 7
4. Smart Card Security Features ........................................................................ 8
4.1. Change Smart Card PIN ......................................................................... 8
4.2. Administrative Functions ......................................................................... 9
4.2.1 Smart Card Initialization......................................................................... 9
4.2.2 Smart Card Lockout mode ................................................................... 10
4.2.3 Admin Smart Card Initialization ............................................................ 11
4.2.4 Change Admin PIN .............................................................................. 12
4.2.5 Buzzer On/Off Function ....................................................................... 12
4.3. User Interface........................................................................................ 13
5. Optional Accessories.................................................................................... 14
5.1. DISKCRYPT key Management Software (DMS)................................... 14
6. Helpful Information ....................................................................................... 15
6.1. Partitioning and formatting your hard drive ........................................... 15
7. Care and Handling ....................................................................................... 16
8. Frequently Asked Questions ........................................................................ 17
9. Troubleshooting............................................................................................ 20
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual ii
Contents
1. About this Guide............................................................................................. 1
2. Introduction..................................................................................................... 2
2.1. About DISKCRYPT M10 ......................................................................... 2
2.2. Connection Ports..................................................................................... 3
2.3. Checklist ................................................................................................. 3
2.4. Specifications.......................................................................................... 4
3. Using DISKCRYPT M10................................................................................. 5
3.1. Authentication ......................................................................................... 5
3.2. Using the built-in keypad......................................................................... 7
4. Smart Card Security Features ........................................................................ 8
4.1. Change Smart Card PIN ......................................................................... 8
4.2. Administrative Functions ......................................................................... 9
4.2.1 Smart Card Initialization......................................................................... 9
4.2.2 Smart Card Lockout mode ................................................................... 10
4.2.3 Admin Smart Card Initialization ............................................................ 11
4.2.4 Change Admin PIN .............................................................................. 12
4.2.5 Buzzer On/Off Function ....................................................................... 12
4.3. User Interface........................................................................................ 13
5. Optional Accessories.................................................................................... 14
5.1.
DISKCRYPT key Management Software (DMS)................................... 14
6. Helpful Information ....................................................................................... 15
6.1. Partitioning and formatting your hard drive ........................................... 15
7. Care and Handling ....................................................................................... 16
8. Frequently Asked Questions ........................................................................ 17
9. Troubleshooting............................................................................................ 20

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 1
1. About this Guide
This guide is designed to provide step-by-step instructions for the installation of
DISKCRYPT M10 and as a reference for its operation and usage.
PLEASE READ AND FOLLOW THE INSTRUCTIONS
PROVIDED IN THIS GUIDE CAREFULLY AND
THOROUGHLY.
FAILURE TO DO SO MAY RESULT IN DAMAGE TO
DISKCRYPT M10 AND ANY OR ALL OF THE
CONNECTED DEVICES.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 2
2. Introduction
2.1. About DISKCRYPT M10
Congratulations on your purchase of DigiSAFE DISKCRYPT M10. DISKCRYPT M10
represents the most advanced secure Mobile storage solution today, utilizing smart card
authentication technology and AES 256 bits full disk encryption. With DISKCRYPT M10,
you can enjoy Mobile storage with the speed and convenience of USB 3.1 in a compact
form factor, and be assured that your data is safe from prying eyes.
DISKCRYPT M10 is a secure portable M.2 Solid State Drive (SSD) which consists of
hardware-based encryption module that performs full disk encryption, i.e. it encrypts
every byte and every sector of data that is written into the SSD. The device is designed
to fit standard 2242 form factor M.2 SSD and communicates with the computer via
standard USB 3.1/3.0/2.0 ports. DISKCRYPT M10 is operating system independent and
does not require any software drivers. It encrypts every single byte and sector that
includes all temporary files, as well as areas that would normally be missed and left “in
the clear” by software encryption products. Encryption and decryption occurs
transparently without any loss in disk performance. Users simply use their computers as
usual with the assurance and complete peace of mind that their data is fully protected in
the unfortunate event that their hard drives are stolen or lost.
DISKCRYPT M10 stores the hard drive encryption key securely in smart cards (two are
provided per device). Smart card technology is well understood and represents the
highest level of security possible for secure data storage. It is vastly more secure than
other solutions that use hardware tokens, where the encryption key is stored in insecure
memory that can be easily read and duplicated. In contrast, smart cards store the
encryption key securely within, and can only be accessed upon presentation of a valid
PIN. The user will need both the smart card as well as knowledge of its PIN to be able to
access the data in the connected SSD. By doing so, DISKCRYPT M10 enforces two-factor
authentication, which is a higher security protection by ensuring that the user possesses
both the physical smart card and the knowledge of its PIN.
The user is required to authenticate him or herself each time DISKCRYPT M10 is plugged
into the computer. After authentication, the drive presents itself to the operating system
and the user is granted normal drive access.
Congratulations on your purchase of ST Engineering DISKCRYPT M10. DISKCRYPT M10
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 4
2.4. Specifications
BUS INTERFACE
USB 3.1
PHYSICAL
USB 3.1 Type C Receptacle
Smart card slot
M.2 connector (internal)
SOLID STATE DRIVE
M.2 SSD (2242 form factor and max. height of 3.6mm)
MLC NAND flash type
DIMENSIONS
91.2mm (L) x 59.2mm (W) x 8.9mm (H)
POWER
5V, approximately 300mA
AUTHENTICATION
Supports two-factor authentication via smart card and PIN
SMART CARD
Supports FIPS 140-2 level 3 and Common Criteria EAL 5+
certified smart card
ENCRYPTION
AES hardware cipher engine
Supported key strengths: 256 bits
Encryption chip is FIPS 140-2 level 2 certified
KEY MANAGEMENT
User-configurable smart card PIN
Admin password for Administrative mode
OPERATING SYSTEMS
Operating system independent
Tested with Windows 10/8/7/XP, Linux, MAC OS
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 5
3. Using DISKCRYPT M10
3.1. Authentication
DISKCRYPT M10 comes with the 2242 form factor M.2 SSD installed. You are ready to
use it with your computer anytime. If the SSD is not installed, simply approach your
local reseller/distributor.
DISKCRYPT M10 requires users to authenticate themselves via two-factor authentication
before they are granted access to the installed drive. In order to do so, users must have
the included smart card (something you have) and its associated PIN (something you
know). The authentication process involves inserting the correct smart card into
DISKCRYPT M10, followed by PIN entry. Upon completion of these two steps, the
connected drive will present itself to the operating system, and can be used like a
normal drive.
To connect DISKCRYPT M10 to your computer via USB, follow these easy steps:
1. Insert the USB cable to your computer’s USB A port with the other type C
end to DISKCRYPT M10.
Ensure correct connector orientation to obtain a snug fit.
2. Insert the smart card with the contacts facing up.
You may insert the card before or after connecting DISKCRYPT
M10 to your
computer. Once a valid card is inserted, the keypad will then allow key entry. If an
invalid card is inserted, the ERROR LED will light up.
3. Enter your PIN.
Once DISKCRYPT M10 recognizes that a valid card is inserted, you may proceed to
enter your 8-digit PIN. The default factory PIN is “12345678”. At the end of your
PIN entry, press the ENTER button.
(For Enterprise deployment, the default PIN will be provided by the Administrator.)
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 6
Insert the smart card into the smart card slot with the
contacts facing up.
Enter your 8-digit PIN, followed by the ENTER button.
Important:
It is recommended that the default PIN is changed for each smart card.
Refer to
Section 4.1 for details.
The default mode is “Lockout” mode. This is the recommended (higher security) mode
of usage.
In Lockout mode, DISKCRYPT
M10 is automatically disconnected from the host PC
upon card removal. Do NOT remove the smart card while DISKCRYPT
M10 is being
accessed as this may cause unrecoverable data loss/corruption
Please ensure that the host machine connected to DISKCRYPT M10 has updated Anti-
virus software to ensure no malicious software/malware installed.
If an incorrect PIN is entered, the ERROR LED will blink continuously. Press the ESC
button to restart DISKCRYPT M10. If you think you have mistyped your PIN, press the
ESC button at any time to restart the entire authentication process.
You will be locked out of your smart card after 8 consecutive incorrect PIN attempts.
Due to security implementations, it is not possible to unlock the smart card. Please
ensure that you have the correct PIN to the smart card.
You shall approach their Administrator in the event that their smart
card is locked.
(Applicable to Enterprise Users)
Each DISKCRYPT M10 comes with two smart cards. It is recommended that you use
only one card and keep the other in a secure place. In the event that one card is
stolen/lost, you may authenticate with the other card.
Please always remov
e the smart card when: device is not in use or device is
unattended.
Please perform preliminary visual inspection of device for tamper signs before usage.
The continuous blinking of the ERROR LED upon device boot up indicates Power-On-
Self-Test failure. Users should contact their local reseller/distributor
Users should not leave the device unattended.
NOTE:
DO NOT force the smart card into the
device. DISKCRYPT M10 is designed with
the smart card half inserted with a
purpose to remind users to remove the
smart card after use.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 7
3.2. Using the built-in keypad
The built-in keypad allows you to enter or change your PIN (refer to Section 4.1 on
Change Smart Card PIN) and perform other administrative functions. It works on the
principle of capacitive sensing to provide a better user experience and can detect the
presence of a touch on the button.
Note:
The keypad is only activated when the user inserts the smart card.
Status LED
indicators
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 8
4. Smart Card Security Features
You can perform certain smart card related security functions with DISKCRYPT M10.
These functions are only available before connecting to the disk. The following functions
are available.
CAUTION:
Smart card security and Administrative functions must be performed carefully as they
cause changes in smart cards and associated PIN. Please read the following instructions
carefully and follow them when performing administrative functions.
4.1. Change Smart Card PIN
You can change your 8-digit smart card PIN with DISKCRYPT M10. It is recommended
that you change the default factory PIN to another one that only you know. Follow these
steps to change your PIN.
1. Insert smart card into DISKCRYPT M10. The keypad should turn on to allow key
entry.
2. Press the CHANGE PIN button, followed by the ‘1’ button.
3. Press ENTER. The STATUS LED will blink three times.
4. Enter the current 8-digit smart card PIN and press ENTER. The STATUS LED
blinks twice.
5. Enter the new 8-digit smart card PIN and press ENTER. The STATUS LED blinks
twice.
6. Repeat the new 8-digit smart card PIN and press ENTER. While the PIN change
process is taking place, the STATUS LED will continue to blink. DISKCRYPT M10 will
provide three ‘beep’ sounds to indicate that this operation is successful.
Upon a successful PIN change, DISKCRYPT M10 will proceed to connect the drive. If the
PIN change is not successful, the ERROR LED will blink continuously.
Note:
Smart card PIN are specific to the physical smart card. Please be aware that you
may have different PIN for each of the two included smart cards.
The user is responsible to remember his/her smart card PIN. The smart card will
be locked after 8 consecutive incorrect PIN attempts. Due to security
implementation, it is not possible to unlock the smart card PIN.
DISKCRYPT M10 only accepts 8-digit PINs. If a shorter or longer PIN is entered, the
ERROR LED will blink continuously. Press the ESC
button to restart the
authentication process again. You will nee
d to restart the entire PIN Change
process from step 2.
Pressing the ESC key restarts the entire authentication process.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 9
4.2. Administrative Functions
(Note that this section is not applicable to Enterprise Users. Enterprise Users may
approach their Administrators.)
DISKCRYPT M10 provides the following administrative functions:
1) Initialize a DigiSAFE smart card to use it with DISKCRYPT M10
2) Enable/disable the smart card Lockout mode.
3) Admin smart card initialization
4) Change the Admin PIN
Additional smart cards may be purchased from your local reseller/distributor. You will
need a supported smart card and the 8-digit Admin PIN to enter the mode. The default
factory Admin PIN is “87654321”. To exit Administrative Mode, remove and reconnect
the USB cable.
Note:
It is recommended to change the default 8-digit Admin PIN. Refer to Section
4.2.4 for details.
You are responsible to remember the Admin PIN. The Administrative functions will
be locked after 8 consecutive incorrect PIN attempts.
It is NOT possible to connect to the hard disk via ANY of the above administrative
modes. To do so, remove and reconnect the USB cable to exit the Administrative
mode and proceed to enter the smart card PIN to authenticate to DISKCRYPT M10.
4.2.1 Smart Card Initialization
This procedure allows a DigiSAFE smart card to be used with the particular DISKCRYPT
M10 device. To initialize a smart card, follow these steps:
1. Insert the new smart card into DISKCRYPT M10. The keypad will be activated to
allow key entry.
2. The ERROR LED will light up indicating an invalid card has been inserted. Ignore the
LED if it lights up.
3. Press the ADMIN button, followed by the ‘0’ button.
4. Press ENTER. The STATUS LED will blink three times.
5. Enter the 8-digit Admin PIN and press ENTER.
6. DISKCRYPT M10 will proceed to initialize the smart card to be used with that
particular DISKCRYPT M10 device. While the initialization process is taking place, the
STATUS LED will continue to blink. At the end of the process, DISKCRYPT M10 will
provide three ‘beep’ sounds to indicate that this operation is successful.
7. Remove and reconnect the USB cable to exit the Administrative mode.
Note:
Once a new smart card is initialized, you will need to repartition/reformat any existing
drive, as the encryption key will be different. The existing data in the drive will be lost
with the new card.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
smart card to use it with DISKCRYPT M10
This procedure allows a smart card to be used with the particular DISKCRYPT M10 device.
To initialize a smart card, follow these steps:

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 10
4.2.2 Smart Card Lockout mode
This mode controls the behavior of DISKCRYPT M10 when the smart card is removed
after authentication. DISKCRYPT M10 allows the user to choose between two smart card
Lockout modes. There are two supported modes:
1. Lockout (default) –DISKCRYPT M10 is automatically disconnected from the host PC
upon smart card removal.
(The STATUS LED is GREEN in authenticated mode.)
2. No lockout –DISKCRYPT M10 remains connected to the host PC upon smart card
removal.
(The STATUS LED is RED in authenticated mode.)
To toggle the smart card Lockout mode, follow these steps:
1. Insert the smart card into DISKCRYPT M10. The keypad will turn on to allow key
entry.
2. Press the ADMIN button, followed by the ‘1’ button.
3. Press ENTER. The STATUS LED will blink three times.
4. Enter the 8-digit Admin PIN and press ENTER. DISKCRYPT M10 will proceed to
change the settings. While the change process is taking place, the STATUS LED will
continue to blink. At the end of the process, DISKCRYPT M10 will provide three ‘beep’
sounds to indicate that this operation is successful.
5. Remove and reconnect the USB cable to exit the Administrative mode.
Note:
The default mode is the Lockout mode. This is the recommended (higher
security) mode of usage.
In Lockout mode, DISKCRYPT M10 is automatically disconnected from the host PC
upon card removal. Do NOT remove the smart card while DISKCRYPT M10 is being
accessed as this may cause unrecoverable data loss/corruption.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 11
4.2.3 Admin Smart Card Initialization
(Note that this section is applicable only to Enterprise User. This function shall be invoke
by Administrators during DISKCRYPT M10 setup and provisioning. Administrators may
refer to the DISKCRYPT Key Management Guide on preparation of the Admin smart card)
This procedure allows a supported Admin smart card to be initialized with DISKCRYPT
M10 device. This function injects a Disk Key into DISKCRYPT M10. The Disk Key is used
in conjuncture with the User Key (stored in User smart card) to deduce a Data
Encryption Key (DEK) used for cryptographic functions of DISKCRYPT M10. To initialize
the Admin smart card, follow these steps:
1. Insert the Admin smart card into DISKCRYPT M10. The keypad will be activated to
allow key entry.
2. The ERROR LED may light up indicating an untagged card has been inserted. Ignore
the LED if it lights up.
3. Press the ADMIN button, followed by the ‘5’ button.
4. Press ENTER. The Status LED will blink three times.
5. Enter the 8-digit Admin PIN and press ENTER. The STATUS LED will blink
continuously. Proceed to the next step.
6. Enter the 8-digit Admin smart card PIN and press ENTER
7. DISKCRYPT M10 will proceed to initialize the Admin smart card with the DISKCRYPT
M10 device. While the initialization process is taking place, the Status LED will
continue to blink. At the end of the process, DISKCRYPT M10 will provide three ‘beep’
sounds to indicate that this operation is successful.
8. Remove and reconnect the USB cable to exit the Administrative mode.
Note:
The Admin smart card shall be stored in a secure location as it contains the Disk Key.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 12
4.2.4 Change Admin PIN
The Admin PIN provides a layer of protection around your DISKCRYPT M10 device to
deter others from unauthorized access of the administrative functions. It is
recommended that you change the default factory Admin PIN to another one that
only you know. To change your Admin PIN, follow these steps:
1. Insert the smart card into DISKCRYPT M10. The keypad will be activated to allow key
entry.
2. Press the CHANGE PIN button, followed by the ‘0’ button.
3. Press ENTER. The STATUS LED blinks three times.
4. Enter the current 8-digit Admin PIN and press ENTER. The STATUS LED blinks
twice.
5. Enter the new 8-digit Admin PIN and press ENTER. The STATUS LED blinks twice.
6. Repeat the new 8-digit Admin PIN and press ENTER. While the Admin PIN change
is taking place, the STATUS LED will continue to blink. DISKCRYPT M10 will provide
three ‘beep’ sounds to indicate that this operation is successful.
7. Remove and reconnect the USB cable to exit the Administrative mode.
If you have mistyped your PIN, press the ESC key at any time to restart the entire
authentication process.
4.2.5 Buzzer On/Off Function
For better user experience where device is to be used in quiet places, e.g. during
meeting etc, the buzzer can be activated on or off with the following step:
1. Insert the smart card into DISKCRYPT M10. The keypad will be activated to allow key
entry.
2. Press the Admin button, followed by the ‘6’ button.
3. Press ENTER. The STATUS LED will continue to blink until the buzzer is toggled
successfully.
4. Remove and reconnect the USB cable to exit to buzzer on/off mode.
Note:
Like the smart card user PIN, DISKCRYPT M10 only accepts 8-digit Admin PIN. If a
shorter or longer PIN is entered, the ERROR LED will blink continuously. Press the
ESC button to restart the authentication process again. You will need to restart the
entire PIN Change process from step 2.
Note:
If the device’s buzzer is in on mode, this operation will toggle to off mode.
Likewise, if the device’s buzzer is in off mode, this operation will toggle to on mode.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 13
4.3. User Interface
Button
Colour
Status
Actions
ACTIVE
Green
Blinking
Processing data
Solid
Device is ready for PIN entry
Authenticated / Device is
Operational
STATUS
Red
Blinking
Processing data in non-Lockout mode
Solid
Functional in non-Lockout mode
Yellow
Blinking
Processing data in Admin mode
Solid
Waiting for response in Admin mode
Green
(default)
Blinking
Processing data in Lockout mode
Solid
Functional in Lockout mode
ERROR
Red
Blinking
Wrong PIN entry
Solid
Invalid smart card / Incorrect smart
card orientation
Buzzer Beep
Notification
2 beeps
Ready to enter PIN
3 beeps
Correct PIN entry
Long beep sound
Unable to complete the process
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 14
5. Optional Accessories
5.1. DISKCRYPT key Management Software (DMS)
DISKCRYPT key Management Software (DMS) provides a way for enterprises to manage
their own smart cards for usage with DISKCRYPT M10. System administrators may also
use this software to back up the encryption keys that are pre-loaded in the two smart
cards that come together with DISKCRYPT M10.
DMS comes with the general features:
1) Generation and loading of encryption key into a smart card
2) Duplication of smart card with the same encryption key
3) Editing smart card record
4) Reading smart card and backup of encryption keys
5) Delete smart card record
(For Enterprise users, please refer to DMS guide document for details)
Note:
Please contact your local reseller/distributor for any enquiries or purchase
of the
software and/or additional smart cards.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 15
6. Helpful Information
6.1. Partitioning and formatting your hard drive
Note that in most cases, it is not necessary to do this because the hard drive will be
shipped, completely formatted.
In any case, if you wish to partition and format the drive, simply follow these steps.
CAUTION:
Performing partition and format operations will erase all data in the drive.
Windows XP and above
1. Connect and authenticate into DISKCRYPT
M10.
2. Right click on My Computer and Select
Manage.
3. From the Computer Management
window, select Disk Management.
4. Right click on the drive and choose
Initialize.
5. Right click on the drive and select New
Partition.
6. Follow the New Partition Wizard to create
as many partitions as desired.
7. Right click on each partition and select
Format to format the drive.
8. The drive is ready to be used once
formatting completes.
Note:
You must have Administrator privileges to use the Disk Management utility.
Mac
1. Connect and authenticate into DISKCRYPT
M10.
2. Enter the Applications folder, followed by
the Utilities folder
3. Run Disk Utility.
4. Select DISKCRYPT M10 on the left hand
column and click on the Partition tab.
5. Choose the number, size and names of
the desired partitions.
6. Mac OS will then format the drives
automatically.
7. The drive is ready to be used once
formatting completes.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle

G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 16
7. Care and Handling
The following are some important information on the proper care and handling of
DISKCRYPT M10. Please take a moment to review these instructions.
Ensure that you follow the proper removal procedure to disconnect DISKCRYPT M10.
Do not move or disconnect this device from your computer while it is reading or
writing data. This may cause damage to DISKCRYPT M10 and it is possible that the
data that is read from or written to the device becomes corrupted.
Do not expose device to direct flame or heat (Recommended operating temperature:
0-45 degree Celsius).
Do not place the device near to equipment generating strong electromagnetic fields.
Exposure to strong electromagnetic fields may cause the device to malfunction or
data to be corrupted.
Do not drop or cause shock to your DISKCRYPT M10.
Do not expose DISKCRYPT M10’s internals to water.
Do not attempt to disassemble and service DISKCRYPT M10 yourself.
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
G
G-P6029-TM001
Issue B
DigiSAFE DISKCRYPT M10 User Manual 3
2.2. Connection Ports
2.3. Checklist
The following items are included with DISKCRYPT M10. If you discover any missing
items, please contact your local reseller/distributor.
1 x DISKCRYPT M10
1 x USB 3.1 cable
2 x Smart cards
1 x Quick start guide
USB 3.1 Type C receptacle
