USB 2.0 to Gigabit Ethernet Adapter
User Manual
Ver. 1.00
All brand names and trademarks are properties of their
respective owners.

MN Page
Contents:
Chapter 1: Introduction ............................. 3
1.1 Product Introduction ....................................................3
1.2 Features........................................................................3
1.3 System Requirements ..................................................4
1.4 Package Contents.........................................................4
Chapter 2: Getting Started......................... 4
2.1 Hardware Installation ..................................................4
2.2 Driver Installation........................................................5
2.2.1 Installation for Windows XP/Vista/7 ....................5
2.3 Hardware Verify...........................................................7
2.3.1 Verifying for Windows XP/Vista/7 .......................7

MN Page
Chapter 1: Introduction
1.1ProductIntroduction
This USB 2.0 to Gigabit Ethernet Adapter add a single RJ-45 Ethernet
networking port to a USB enabled computer system with link speeds
up to 1000 Mbps. Backwards compatible with USB 1.x computer
system and 10/100 Mbps Ethernet networks, this compact and portable
adapter is ideal as a desktop replacement network adapter or laptop
accessory.
1.2Features
Compliant with the Standard Specification of USB 1.1 and 2.0
Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
10/100/1000M data auto-negotiation
Support USB Full and High Speed modes with bus power
capacity
Supports suspended mode and remote wakeup
Upstream port: USB type A
Downstream port: RJ45

MN Page
LEDs indicate the status of Power status and Ethernet connection
Support Windows® XP/Vista/7 (32/64 bit)
1.3SystemRequirements
Windows® XP/Vista/7 (32/64 bit)
Available USB port
1.4PackageContents
1 x USB 2.0 to Gigabit Ethernet Adapter
1 x Driver CD
1 x User Manual
Note: Contents may vary depending on country/market.
Chapter 2: Getting Started
2.1HardwareInstallation
1. Plug the USB 2.0 to Gigabit Ethernet Adapter directly into an
available USB port on your computer.
2. Connect one end of your network cable into the RJ45 port of USB
2.0 to Gigabit Ethernet Adapter.

MN Page
3. Connect the other end of the network cable into an available
Ethernet port on your router, switch, or any other networking
device.
2.2DriverInstallation
The following section shows you how to install the USB 2.0 to Gigabit
Ethernet Adapter driver on different operating systems.
Important! Do not connect the USB 2.0 to Fast Ethernet to your PC
before the install.
InstallationforWindowsXPVista
1. Insert the provided CD into your disk drive. The CD-ROM will
start automatically. The following screen will show up and please
click “Install Driver”.

MN Page
Note: If the install program doesn’t run automatically, please
locate and double-click on the Autorun.exe file in the CD to
launch the install program.
2. Please click “USB 1000M” to start the installation.
3. Follow the instructions on screen to install the driver.

MN Page
2.3HardwareVerify
VerifyingforWindowsXPVista
1. Click on the “Device Manager” tab in the Windows Control
Panel.
Start > Control Panel > Device Manager
2. Entry “Network adapters” item, and you can read “LAN7500
USB 2.0 to Ethernet 10/100/1000 Adapter” in the Device
Manager.
