STEVAL-ISV012V1 lithium-ion solar battery charger
Domenico Ragonese; Alessandro Nicosia; Giovanni Conti
Introduction
The STEVAL-ISV012V1 evaluation board mounts an SPV1040 (solar energy harvester) for the input
stage and an L6924D (Li-Ion battery charger) as the output stage. It targets any portable application
powered by lithium-ion batteries and merges the SPV1040 power extraction capacity of the solar
module with the linear regulation of the L6924D for optimum battery charging load protection while
reducing the power dissipation at the bottom.
Figure 1: STEVAL-ISV012V1 evaluation board
The board is designed to charge lithium-ion and lithium-polymer batteries with VBATT_max = 4.1 or 4.2 V
and it includes a 400 mWpk polycrystalline PV panel (SZGD6060-4P from NBSZGD) with VOC = 2.2 V
and ISC = 220 mA.
According to specific application requirements, some components may be replaced
a
:
The PV panel can be replaced as long as VOC < VBATT_max and IS< 1.65 A.
The inductor L1 can be replaced, but consider its effect on the maximum peak current to ensure
that the input overcurrent limit is not triggered.
The maximum output current can be limited by replacing the current sensing resistor RS(0 0Ω by
default).
Resistor R14, which limits the charge current threshold (500 mA by default).
a
For more details on component selection, refer to Application note AN3319, section “external component selection”

Contents
AN4050
2/17
DocID022816 Rev 3
Contents
1SPV1040 operation..........................................................................4
2L6924D operation ............................................................................6
2.1 L6924D operation in solar powered applications...............................6
3Reference design description ......................................................10
4Schematic diagrams......................................................................12
5Bill of materials..............................................................................14
6Revision history ............................................................................16

AN4050
List of figures
DocID022816 Rev 3
3/17
List of figures
Figure 1: STEVAL-ISV012V1 evaluation board..........................................................................................1
Figure 2: Typical application circuit.............................................................................................................4
Figure 3: SPV1040 equivalent circuit..........................................................................................................4
Figure 4: MPPT working principle...............................................................................................................5
Figure 5: SPV1040 internal block diagram.................................................................................................5
Figure 6: Basic application schematic ........................................................................................................6
Figure 7: Typical charge curve in Quasi-pulse mode.................................................................................7
Figure 8: Battery charging at low irradiation...............................................................................................8
Figure 9: Battery charging at low irradiation (zoom)...................................................................................8
Figure 10: Maximum available current vs. Pin, 200 mW peak PV panel....................................................9
Figure 11: Maximum available current vs. Pin, 2 W peak PV panel...........................................................9
Figure 12: Application set-up....................................................................................................................10
Figure 13: V-I and P-V plot diagrams .......................................................................................................10
Figure 14: Partial charge ..........................................................................................................................11
Figure 15: Full charge...............................................................................................................................11
Figure 16: STEVAL-ISV012V1 schematic, battery charge section ..........................................................12
Figure 17: STEVAL-ISV012V1 schematic, solar power optimizer section ...............................................13

SPV1040 operation
AN4050
4/17
DocID022816 Rev 3
1 SPV1040 operation
The SPV1040 device is a low power, low voltage, monolithic step-up converter with an
input voltage range from 0.3 V to 5.5 V, capable of maximizing the energy generated by a
single solar cell (or fuel cell), where low input voltage handling capability is important.
When combined with the L6924D, it provides an ideal solution for charging lithium battery
packs with energy harvested from a very small solar panel.
The SPV1040 is a 100 kHz, fixed-frequency pulse width modulation (PWM) step-up
converter able to maximize the energy harvested by a few solar cells. It employs a
maximum power point tracking (MPPT) algorithm which continuously tracks its output
voltage and current. The converter guarantees the safety of the overall application and its
own by stopping PWM switching in case of an overvoltage, overcurrent or overtemperature
condition. The IC integrates a 120 mΩ N-channel MOSFET power switch and a 140 mΩ P-
channel MOSFET synchronous rectifier.
Figure 2: Typical application circuit
The SPV1040 acts as an impedance adapter between the PV module and the output load.
The equivalent circuit is shown below.
Figure 3: SPV1040 equivalent circuit
The MPPT algorithm sets up the correct DC working point by ensuring Zin = Zm(assuming
Zmis the impedance of the supply source). In this way, the power extracted from the supply
source (Pin = Vin * Iin) is maximum (Pm= Vm* Im).
Lx RS
LVBATT
XSHUT
GND
MPP-SET
VPV
R1 R3COUT
RF1
CFRF2
R2
CINsns COUTsns
CIN DOUT
ICTRL_MINUS
ICTRL_PLUS
VCTRL
VOUT
SPV1040
I I
R
C
I
V V
gm V
C
I
Z DC
R
V V
PV
Panel
IN
IN
IN
IN OUT
OUT OUT
OUT

AN4050
SPV1040 operation
DocID022816 Rev 3
5/17
The voltage-current curve shows all the available working points of the PV panel at a given
solar irradiation. The voltage-power curve is derived from the voltage-current curve by
plotting the product V*I for each voltage generated
a
.
Figure 4: MPPT working principle
Figure 5: SPV1040 internal block diagram
The duty cycle set by the MPPT algorithm can be overwritten if one of the following events
is triggered:
Input overcurrent protection (OVC): inductor peak current ≤1.65 A
Overtemperature protection (OVT): internal temperature ≤155 °C
Output voltage regulation: VCTRL pin triggers the 1.25 V internal reference
Output current limitation: RS* (ICTRL_PLUS - ICTRL_MINUS) ≤50 mV
MPP-SET voltage VMPP-SET ≤300 mV at startup and VMPP-SET ≤450 mV in
running mode.
Application components must be carefully selected to avoid any undesired triggering of the
above thresholds.
a
For more details regarding the MPPT algorithm, refer to the SPV1040 datasheet.
IMP PMAX
[A]
[W]
urrent
ower
C
P
Voltage [V]
0VOC
VMP
STARTSTART SSIGNALIGNAL
Lx
XSHUT
MPP BLOCK
DETECTOR
-
Burst Ref
CLOCK
+
-
GND
OVER CURRENT
OVER TEMPERATURE
REVERSE POLARITY
+
BURST MODE DIGITAL
DAC CODE CORE MPP-SET
VREF
V
-
CTRL_PLUS
I
CLOCK
CTRL
V
CTRL_MINUS
MPP-REF
PWM
DRIVERS
CONTROL
MPP-SET
V
ZEROZERO CROSSINGCROSSING
OUT
V
ANALOG BLOCK
MPP-REF
I
+
Iout Reg
Vin Reg
Vout Reg VREF
+
-

L6924D operation
AN4050
6/17
DocID022816 Rev 3
2 L6924D operation
The L6924D is a fully monolithic battery charger dedicated to single-cell Li-Ion/polymer
battery packs. It is designed with BCD6 technology and integrates all of the power
elements (Power MOSFET, reverse blocking diode and sense resistor) in a small
VFQFPN16 3 mm x 3 mm package.
It normally works as a linear charger when powered from an external voltage regulated
adapter. However, thanks to its very low minimum input voltage (down to 2.5 V) the
L6924D can also work as a quasi-pulse charger when powered from a current limited
adapter, dramatically reducing the power dissipation.
The L6924D charges the battery in three phases:
Pre-charge constant current: a deeply discharged battery is charged with a low
current.
Fast-charge constant current: the device charges the battery with the maximum
current.
Constant voltage: when the battery voltage is close to the selected output voltage, the
device starts to reduce the current until the charge termination has completed.
Regardless of the charging approach, a closed loop thermal control features protects the
device from overheating. The L6924D allows the user to program many parameters, such
as pre-charge current, fast-charge current, pre-charge voltage threshold, end-of-charge
current threshold and charge timer.
The L6924D offers two open collector outputs for diagnostic purposes, which can be used
to either drive two external LEDs or communicate with a host microcontroller.
Finally, the L6924D also provides other battery related functions, such as checking for
battery presence, monitoring and protection from unsafe thermal conditions.
Figure 6: Basic application schematic
2.1 L6924D operation in solar powered applications
Thanks to its very low minimum input voltage (down to 2.5 V), the L6924D can also work as
a quasi-pulse charger when powered from a current limited adapter such as a PV panel or
a current limiting device such as the SPV1040 step-up.
BATTERY
SHDN
ON
OFF
GND VOPRGIPRE
TPRG
VPRE
IPRG
IEND
VOSNS
VOUT
TH
VREF
VINSNS
VIN
ST1
ST2
L6924D
CHARGER
Vref
L6924D
R3 R9
C4
C1
R1 R2
LD1 LD2 C2
R7 R8
R4
R5
R6 R10
J5

AN4050
L6924D operation
DocID022816 Rev 3
7/17
To work in this condition, set the device charging current (with R14) higher than the
maximum peak current of the PV panel. During the fast-charge phase, the output voltage of
the SPV1040 that supplies the L6924D drops down to the battery voltage plus the voltage
drop across the power MOSFET of the charger.
In this mode, the L6924D charges the battery with the same three phases as in linear
mode, but power dissipation is greatly reduced, as shown in the following figure.
Figure 7: Typical charge curve in Quasi-pulse mode
During the fast-charge phase, the output voltage of the SPV1040 (VIN of L6924D) drops
down to the battery voltage (VBAT) plus the voltage drop across the Power MOSFET
(ΔVMOS) of the charger.
Consequently, the internal MOSFET works in saturation mode with a voltage drop given by:
Equation 1

        

L6924D operation
AN4050
8/17
DocID022816 Rev 3
where
Equation 2

  󰇛󰇜 
ILIM is the current limit of the SPV1040, which depends on solar irradiation.
Neglecting the voltage drop across the charger (ΔVMOS) when the device operates in this
condition, its input voltage is equal to the battery’s, and therefore a very low operating input
voltage (down to 2.5 V) is required. The power dissipated by the device during this phase
is:
Equation 3
  󰇛󰇜 

The advantage of the quasi-pulse charging method allows the energy harvested by few
solar cells to be maximized.
The STEVAL-ISV0012V1 LEDs D1 and D2 indicate (when ON) whether the
charge is in progress or is completed, respectively.
R14, and consequently ILIM, must be set up according to the power provided by the PV
panel at the maximum irradiation, but it is possible that D1 starts flickering (or appearing
ON) at lower irradiation levels, while D2 is ON as well.
This is due to the battery charger, which tries to charge the battery at 4.2 V (or 4.1 V,
depending on the VOPRG setting) and ILIM, but the required power can only be sustained if
enough irradiation is available on the PV panel side. If the irradiation is not sufficient, the
input voltage of the L6924D drops down to the battery voltage, causing battery charging to
stop and D1 to turn ON. Shortly after, the voltage rises back to 4.2 V (or 4.1 V) and the
battery charge starts again (D1 turns OFF).
In these low irradiation conditions the battery is charged by current packets anyway.
The plots below demonstrate the behavior in the event of low irradiation.
Figure 8: Battery charging at low irradiation
Figure 9: Battery charging at low irradiation
(zoom)
The plots below show the maximum available current that can be provided to the battery
charger according to the input power.

AN4050
L6924D operation
DocID022816 Rev 3
9/17
Figure 10: Maximum available current vs. Pin, 200 mW peak PV panel
Figure 11: Maximum available current vs. Pin, 2 W peak PV panel
0
10
20
30
40
50
60
70
80
0 50 100 150 200 250 300 350 400
Pin [mW]
Iout max[mA]
Vout =4.5V
0
50
100
150
200
250
300
350
0 200 400 600 800 1000 1200 1400 1600 1800 2000
Pin [mW]
Iout max[mA]
Vout =4.5V

Reference design description
AN4050
10/17
DocID022816 Rev 3
3 Reference design description
The set-up used for measurements is shown below.
Figure 12: Application set-up
A solar array simulator (SAS, SAS-FL05/01 from CBL Electronics) to simulate the PV
module with VOC = 2.5 V, ISC = 210 mA, Vmp = 2.0 V, Imp = 200 mA (@ 1000 W/m²
irradiance) and a Li-Ion battery 3.7 V-700 mAh, are used. Figure 13: "V-I and P-V plot
diagrams" shows the I-V and P-V curves generated by the SAS, obtained using a PV
module analyzer (ISM490 from ISOTECH).
Figure 13: V-I and P-V plot diagrams
Figure 14: "Partial charge" and Figure 15: "Full charge" show the partial and full charge
curves respectively. The partial charge curve shows charge current and voltage within a
one hour time frame at full irradiation starting from a 3.4 V condition. The full charge curve
shows charge current and voltage until the fully charged status is triggered, starting from a
3.4 V condition. After the one hour charge period time, the battery voltage reaches 3.8 V.
Different results can be obtained if a different PV panel and/or battery are used
a
.
a
Visit the support section on www.st.com if you require help regarding the use of different PV panels or batteries.

AN4050
Reference design description
DocID022816 Rev 3
11/17
The average overall power efficiency is approximately 85% (94% for SPV1040 and 90% for
L6924D).
Figure 14: Partial charge
Figure 15: Full charge
0
20
40
60
80
100
120
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
050 100150200250300
Output Current [mA]
Output Voltage [V]
Time [m]
90
92
94
96
98
100
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
0 10 20 30 40 50 60
Output Current [mA]
Output Voltage [V]
Time [m]

Schematic diagrams
AN4050
12/17
DocID022816 Rev 3
4 Schematic diagrams
Figure 16: STEVAL-ISV012V1 schematic, battery charge section
L6924D
VFQFPN16
SW3, SW4: default is 0 Ohm on LED (2-3 closed)
ST1 ST2
Tprg
Vin Vin_sns
default closed
default closed
default open
PV-
SHDWN
TH
Voprg
Vosns Vo
Iend
Vpre
Iprg
Ipre
PV-
VOUT_SPV1040
mc2 mc1
VREF
VBAT
NTC
PV-
PV- VREF
VBAT
PV-
R16 DNM
R9
470 Ohm
SW3
1 32
R15 DNM
SW4
1 32
D1D1
R6 1k Ohm R6 1k Ohm
4.7uF
C9
R12 DNM
TP9TP9
TP7TP7
R14 24k Ohm
1J1J
1
2
C7 10nF C7 10nF
C6 47uF C6 47uF
2J2J 1
2
3J3J 1
2
C8 1nF C8 1nF
R10 3.3k Ohm R10 3.3k Ohm
R13 DNM
R7 1k Ohm R7 1k Ohm
TP8TP8
R8
1k Ohm
R8
1k Ohm
J28J28
1 2 3 4
5
6
7
8
9 10
14
16
15
13
12 11
D2D2

AN4050
Schematic diagrams
DocID022816 Rev 3
13/17
Figure 17: STEVAL-ISV012V1 schematic, solar power optimizer section
SPV1040
Vctrl =1.25V
TSSOP8
@Vout = 3.45V
VRs=50mV @ Imax
Vout
SMM4F5.0A
VOUT_SPV1040
VIN_sns
PV-
LX_1040Vctrl
Ictrl-
Ictrl+
X_SHUT
Vctrl
Vrs+
Vrs-
Ictrl+
Ictrl-
Vrs+
Vrs-
VIN_sns
PV +
RF2 1kRF2 1k
C2
1nF
C2
1nF
TP1TP1
CF1
1uF
CF1
1uF
Cout1
10uF
Cout1
10uF
TP2TP2
R2
820k
R2
820k
R4
DNM
R4
R3
1
R3
1k
J26
CON8B
J26
CON8B
1 2 3 45
6 7 8
Rs1 0 OhmRs1 0 Ohm
C4C4
1nF
R1
2.2M
R1
2.2M
RF1 1k RF1 1k
Dout1
TRISIL
Dout1
TRISIL
TP5TP5
R5 0 OhmR5 0 Ohm

Bill of materials
AN4050
14/17
DocID022816 Rev 3
5 Bill of materials
Table 1: STEVAL-ISV012V1 bill of materials
Item
Q.ty
Ref.
Part/Value
Description
Manufacturer
Order code
1
1
PV1
(polycris
talline)
400 mW, Vmp =
1.92 V; Imp = 200
mA; Voc = 2.2 V;
Isc = 220 mA
Solar panel
NBSZGD
SZGD6060-
4P
2
1
Cin1
47 µF, 6.3 V, 0805
Multilayer
ceramic
capacitor
Kemet
C0805C476M
9PAC7800
3
2
C2, C4
1 nF, 50 V, 0805
Ceramic
capacitors
Kemet
C0805C102K
5RAC
4
1
Cout1
10 µF, 16 V, 0805
Multilayer
ceramic
capacitor
Kemet
C0805C106K
4PAC7800
5
1
R3
1 kΩ, 0805
Resistor
Vishay
CRCW08051
K00FKEA
6
1
R4
3.3 mΩ, 63M
Resistor
DNM
7
1
L1
10 µH, Isat > 1.5 A
at vmp = 2 V,
2220(EIA)
Power inductor
Coilcraft
MSS7341-
103ML
EPCOS
B82442T110
3K050
8
1
VRS
50 mV at Iout_max,
0805
Thick film
resistor
Vishay
CRCW08050
000Z0EA
9
1
R1
2.2 mΩ, 0805
Resistor
Multicomp
MCHV05WAJ
0225T5E
10
1
R2
820 kΩ, 0805
Resistor
Vishay
CRCW08058
20KFKEA
11
1
R5
0805
Resistor
Vishay
CRCW08050
000Z0EA
12
1
J26
SPV1040, TSSOP8
High efficiency
solar battery
charger with
embedded
MPPT
ST
SPV1040T
13
1
Dout1
Vbr = 5 V, Vcl = 9
V, STmite Flat,
SMM4F
400 W Transil™
ST
SMM4F5.0
14
1
J28
L6924D,
VFQFPN16
Battery charger
system with
integrated power
switch for Li-
Ion/Li-Polymer
ST
L6924D

AN4050
Bill of materials
DocID022816 Rev 3
15/17
Item
Q.ty
Ref.
Part/Value
Description
Manufacturer
Order code
15
2
RF1,
RF2
1 kΩ, 0805
Thick film
resistors
Vishay
CRCW08051
K00FKEA
16
1
CF1
1 µF, 10 V, 0805
Multilayer
ceramic
capacitor
Murata
GRM21BR71
C105KA01L
17
2
D1, D2
SMD, 2.5 V, 25 mA,
0805
Green LED
Kingbright
KP-2012SGC
18
3
R6, R7,
R8
1 kΩ, 0805
Resistors
Vishay
CRCW08051
K00FKEA
19
1
C6
47 µF, 6.3 V, 0805
Ceramic
capacitors
Kemet
C0805C476M
9PAC7800
20
1
C7
10 nF, 50 V, 0805
Ceramic
capacitors
Kemet
C0805C103K
5RAC
21
1
C8
1 nF, 50 V, 0805
Multilayer
ceramic
capacitor
Kemet
C0805C102K
5RAC
22
1
C9
4.7 µF, 0805
Ceramic
capacitor
Murata
GRM21BF51
A475ZA01L
23
1
R10
3.3 kΩ
Resistor
Bourns
CR0805-FX-
3301GLF
24
1
R9
470 Ω, 0805
Resistor
Bourns
CR0805-FX-
4700GLF
25
1
R14
24 kΩ, 0.1 W, 0805,
± 1%
Resistor
Multicomp
C2012C0G2A
103J125AA
26
3
J1, J2,
J3
Jumper100
Jumpers
Any
27
2
SW3,
SW4
0 Ω, 0805, SMD,
1/8 W
Thick film
resistors
Vishay
CRCW08050
000Z0EA
28
2
J29
3-position wire
to board terminal
block
Phoenix
Contact
1935174

Revision history
AN4050
16/17
DocID022816 Rev 3
6 Revision history
Table 2: Document revision history
Date
Version
Changes
11-Jun-2012
1
Initial release.
21-Mar-2013
2
Updated Figure 5: SPV1040 internal block diagram.
05-Dec-2017
3
Text and formatting changes throughout document.
Updated Section 5: "Bill of materials"

AN4050
DocID022816 Rev 3
17/17
IMPORTANT NOTICE –PLEASE READ CAREFULLY
STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, enhancements, modifications ,
and improvements to ST products and/or to this document at any time without notice. Purchasers should obtain the latest relevant
information on ST products before placing orders. ST products are sold pursuant to ST’s terms and conditions of sale in place at
the time of order acknowledgement.
Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application
assistance or the design of Purchasers’ products.
No license, express or implied, to any intellectual property right is granted by ST herein.
Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such
product.
ST and the ST logo are trademarks of ST. All other product or service names are the property of their respective owners.
Information in this document supersedes and replaces information previously supplied in any prior versions of this document.
© 2017 STMicroelectronics –All rights reserved
