STA-RITE IntelliPro Variable Speed User manual

IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
IntelliPro®Variable Speed
Programmable Pump
(Compatible with IntelliComm®communication center and
EasyTouch®, IntelliTouch®and SunTouch®control systems)
Installation
and
User’s Guide

© 2011 Pentair Water Pool and Spa, Inc. All rights reserved.
This document is subject to change without notice.
1620 Hawkins Ave., Sanford, NC 27330 • [phone]
10951 West Los Angeles Ave., Moorpark, CA 93021 • [phone]
Trademarks and disclaimers: IntelliComm®, EasyTouch®, IntelliTouch®, SunTouch®,IntelliPro®, Eco Select™, Pentair
Water Pool and Spa®and Sta-Rite® are registered tradmarks and/or trademarks of Pentair Water Pool and Spa, Inc.
and/or its affiliated companies in the United States and/or other countries. Teflon®is a registered trademark of E.I. Du
Pont De Nemours and Company Corporation and Plasto-Joint Stik®is a registered trademark of La-Co Industries, Inc.
Unless noted, names and brands of others that may be used in this document are not used to indicate an affiliation or
endorsement between the proprietors of these names and brands and Pentair Water Pool and Spa, Inc. Those names
and brands may be the trademarks or registered trademarks of those parties or others.
P/N 354831 Rev A 6/15/11
IntelliPro®Variable
Speed Pump
(P/N P6E6VS4H-209L)
Customer Service / Technical Support
If you have questions about ordering Pentair Water Pool and Spa (“Pentair”) replacement parts,
and pool products, please use the following contact information:
Customer Service (8 A.M. to 5 P.M. — Eastern and Pacific Times)
Phone: [phone]
Fax: [phone]
Technical Support
Sanford, North Carolina (8 A.M. to 5 P.M. ET)
Phone: [phone]
Fax: [phone]
Moorpark, California (8 A.M. to 5 P.M. PT)
Phone: [phone] (Ext. 5591)
Fax: [phone]
Web site
visit www.pentairpool.com or www.staritepool.com to find information about Pentair products.

Important Warning and Safety Instructions ........................................................iii
Section 1: IntelliPro®Pump Overview.................................................................1
IntelliPro®Pump.......................................................................................................1
External Control.......................................................................................................1
Features...................................................................................................................2
IntelliPro®Drive Assembly and Control Panel..........................................................3
IntelliPro®Motor Features........................................................................................3
Section 2: Operator Control Panel ......................................................................4
IntelliPro®Operator Control Panel ...........................................................................4
Controls and LEDs...................................................................................................4
Section 3: Operating the Pump ...........................................................................6
Starting the pump ....................................................................................................6
Stopping the pump...................................................................................................6
Operating the pump at preset speeds .....................................................................6
Pump Operating Modes...........................................................................................7
Programming the Pump...........................................................................................7
IntelliPro®Variable Speed Pump Menus..................................................................8
Settings: Pump Address ..........................................................................................9
Settings: Set Time....................................................................................................9
Settings: Set AM/PM or 24 Clock.............................................................................10
Settings: Set Temperature Unit ................................................................................10
Settings: Screen Contrast Level...............................................................................10
Settings: Language..................................................................................................11
Settings: Set Minimum Speed (RPM) ......................................................................11
Settings: Set Maximum Speed (RPM) .....................................................................11
Settings: Password ..................................................................................................12
Password Protection ................................................................................................12
Speed 1-8 (Schedule a Time to Run the Pump) .....................................................14
External Control.......................................................................................................15
Features: Quick Clean .............................................................................................15
Programming for Constant Run ...............................................................................15
Features: Time Out ..................................................................................................16
Priming.................................................................................................................17
AntiFreeze............................................................................................................19
Priming the pump for the first time, or after service .................................................20
Priming the Pump ................................................................................................21
External Control with IntelliComm Communication Center......................................22
Connecting the pump to EasyTouch and IntelliTouch Systems ...............................23
Connecting the pump to a SunTouch System..........................................................25
Contents
i
IntelliPro®Variable Speed Pump Installation and User’s Guide

Section 4: User Maintenance...............................................................................26
Pump Strainer Basket..............................................................................................26
Pump Strainer Basket Service.................................................................................26
Motor Service ..........................................................................................................27
Winterizing ...............................................................................................................28
Priming the pump after service................................................................................28
Section 5: Installation and Removal ...................................................................29
IntelliPro®Variable Speed Kit Contents ...................................................................29
Installing the IntelliPro®............................................................................................29
Location .......................................................................................................29
Piping ...........................................................................................................29
Electrical ......................................................................................................29
Wiring the IntelliPro®Pump......................................................................................30
Ground Wire Connection..............................................................................30
Pump Disassembly ..................................................................................................31
Shaft Seal Replacement ..........................................................................................32
Pump Reassembly/Installing New Seal ...................................................................32
Drive Assembly Removal and Installation................................................................33
Section 6: Troubleshooting ..................................................................................34
Alerts and Warnings ................................................................................................34
General IntelliPro®Troubleshooting Problems .........................................................35
Section 7: Replacement Parts .............................................................................37
Illustrated Parts List .................................................................................................37
IntelliPro®Pump Dimensions ...................................................................................38
IntelliPro®Flow and Power vs Flow Pump Curve.....................................................38
IntelliPro®Electrical Specifications ..........................................................................38
Contents
ii
IntelliPro®Variable Speed Pump Installation and User’s Guide

Pentair Water Pool and Spa®
PUMP WARNING AND SAFETY INSTRUCTIONS
For Pool and Spa Pumps (Non SVRS Pumps)
(Pentair Water Pool and Spa®, Sta-Rite®, and Pentair Pool Products®)
FAILURE TO FOLLOW ALL INSTRUCTIONS ANDWARNINGS CAN RESULT IN SERIOUS BODILY
INJURY OR DEATH. THIS PUMP SHOULD BE INSTALLED AND SERVICED ONLY BY A
QUALIFIED POOL SERVICE PROFESSIONAL. INSTALLERS, POOL OPERATORS AND
OWNERS MUST READ THESE WARNINGS AND ALL INSTRUCTIONS IN THE OWNER’S
MANUAL BEFORE USING THIS PUMP. THESE WARNINGS AND THE OWNER’S MANUAL
MUST BE LEFT WITH THE POOL OWNER.
SUCTION ENTRAPMENT HAZARD: STAY OFF THE MAIN DRAIN AND AWAY FROM ALL
SUCTION OUTLETS!
THIS PUMP PRODUCES HIGH LEVELS OF SUCTION AND CREATES A STRONG VACUUM AT
THE MAIN DRAIN AT THE BOTTOM OF YOUR POOL OR SPA. THIS SUCTION IS SO STRONG
THAT IT CAN TRAP ADULTS OR CHILDREN UNDER WATER IF THEY COME IN CLOSE PROX-
IMITY TO A POOL OR SPA DRAIN OR A LOOSE OR BROKEN DRAIN COVER OR GRATE.
READ AND KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
Warnings and safety instructions for Pentair Water Pool and Spa®pumps and other related products are available at:
http://www.pentairpool.com/pool-owner/safety-warnings/ or call [phone] for additional free copies of these
instructions.
Please refer to http://www.pentairpool.com/pool-owner/safety-warnings/ for warning and safety instructions
related to the IntelliPro®Variable Speed Pump.
READ AND FOLLOW ALL WARNING AND SAFETY INSTRUCTIONS
This is the safety alert symbol. When you see this symbol on your system or in this manual, look
for one of the following signal words and be alert to the potential for personal injury.
Warns about hazards that can cause death, serious personal injury, or major property damage
if ignored.
Warns about hazards that may cause death, serious personal injury, or major property damage
if ignored.
Warns about hazards that may or can cause minor personal injury or property damage if ignored.
NOTE indicates special instructions not related to hazards.
Carefully read and follow all safety instructions in this manual and on equipment. Keep safety labels in good
condition; replace if missing or damaged.
iii
IntelliPro®Variable Speed Pump Installation and User’s Guide
F

THE USE OF UNAPPROVED COVERS OR ALLOWING USE OF THE POOL OR SPA WHEN COVERS ARE
MISSING, CRACKED OR BROKEN CAN RESULT IN BODY OR LIMB ENTRAPMENT, HAIR ENTANGLEMENT,
BODY ENTRAPMENT, EVISCERATION AND/OR DEATH.
The suction at a pool or spa drain or outlet can cause:
Limb Entrapment: When a limb is sucked or inserted into an opening resulting in a mechanical bind or swelling.
This hazard is present when a drain cover is missing, broken, loose, cracked or not properly secured.
Hair Entanglement: When the hair tangles or knots in the drain cover, trapping the swimmer underwater. This
hazard is present when the flow rating of the cover is too small for the pump or pumps.
Body Entrapment: When a portion of the body is held against the drain cover trapping the swimmer underwater.
This hazard is present when the drain cover is missing, broken or the cover flow rating is not high enough for the
pump or pumps.
Evisceration/Disembowelment: When a person sits on an open pool
(particularly a child wading pool) or spa outlet and suction is applied directly to the intestines, causing severe
intestinal damage. This hazard is present when the drain cover is missing, loose, cracked, or not properly secured.
Mechanical Entrapment: When jewelry, swimsuit, hair decorations, finger, toe or knuckle is caught in an opening
of an outlet or drain cover. This hazard is present when the drain cover is missing, broken, loose, cracked, or not
properly secured.
NOTE: ALL SUCTION PLUMBING MUST BE INSTALLED IN ACCORDANCE WITH THE LATEST NATIONAL
AND LOCAL CODES FOR SWIMMING POOLS, SPAS AND HOT TUBS, INCLUDING NSPI STANDARDS AND
CPSC GUIDELINES.
TO MINIMIZE THE RISK OF INJURY DUE TO SUCTION ENTRAPMENT HAZARD:
• Pools and spas should utilize a minimum of two drains per pump.
• A properly installed and secured ANSI/ASME A112.19.8 approved anti-entrapment
suction cover must be used for each drain.
• Each suction cover must be installed at least three (3’) feet apart, as measured from the
nearest point to nearest point.
• Regularly inspect all covers for cracks, damage and advanced weathering.
• If a cover becomes loose, cracked, damaged, broken or is missing, close the pool or
spa immediately, shut off the pump, post a notice and keep the pool or spa closed until
an appropriate certified cover is properly installed.
• Replace drain covers as necessary. Drain covers deteriorate over time due to exposure
to sunlight, pool chemicals and weather.
• Avoid getting hair, limbs or body in close proximity to any suction cover, pool drain or
outlet.
• Disable suction outlets or reconfigure into return inlets.
A clearly labeled emergency shut-off switch for the pool pump and spa jet pump must be in an
easily accessible, obvious place near the pool or spa. Make sure bathers know where it is and
how to use it in case of emergency.
Pentair Water Pool and Spa®
PUMP WARNING AND SAFETY INSTRUCTIONS
For Pool and Spa Pumps (Non SVRS Pumps)
(Pentair Water Pool and Spa®, Sta-Rite®, and Pentair Pool Products®)
iv
IntelliPro®Variable Speed Pump Installation and User’s Guide

The Virginia Graeme Baker (VGB) Pool and Spa Safety Act creates new requirements for owners and
operators of commercial swimming pools and spas.
Commercial pools or spas constructed on or after December 19, 2008, shall utilize:
(A) A multiple main drain system without isolation capability with suction outlet covers that meet ASME/ANSI
A112.19.8a Suction Fittings for Use in Swimming Pools, Wading Pools, Spas, and Hot Tubs and either:
(i) A safety vacuum release system (SVRS) meeting ASME/ANSI A112.19.17 Manufactured Safety Vacuum
Release systems (SVRS) for Residential and Commercial Swimming Pool, Spa, Hot Tub, and Wading
Pool Suction Systems and/or ASTM F2387 Standard Specification for Manufactured Safety Vacuum
Release Systems (SVRS) for Swimming pools, Spas and Hot Tubs or
(ii) A properly designed and tested suction-limiting vent system or
(iii) An automatic pump shut-off system.
Commercial pools and spas constructed prior to December 19, 2008, with a single submerged suction outlet
shall use a suction outlet cover that meets ASME/ANSI A112.19.8a and either:
(A) A SVRS meeting ASME/ANSI A112.19.17 and/or ASTM F2387, or
(B) A properly designed and tested suction-limiting vent system, or
(C) An automatic pump shut-off system, or
(D) Disabled submerged outlets, or
(E) Suction outlets shall be reconfigured into return inlets.
Pentair Water Pool and Spa®
PUMP WARNING AND SAFETY INSTRUCTIONS
For Pool and Spa Pumps (Non SVRS Pumps)
(Pentair Water Pool and Spa®, Sta-Rite®, and Pentair Pool Products®)
HAZARDOUS PRESSURE: STAND CLEAR OF PUMP AND FILTER DURING START-UP
Pool and spa circulation systems operate under high pressure. When any part of the circulating system (i.e. locking
ring, pump, filter, valves, etc.) is serviced, air can enter the system and become pressurized. Pressurized air
can cause the pump housing cover filter lid and valves to violently separate which can result in severe personal
injury or death. Filter tank lid and strainer cover must be properly secured to prevent violent separation. Stand
clear of all circulation system equipment when turning on or starting up pump.
Before servicing pool and spa equipment, make note of the filter pressure. Be sure that all controls are set to
ensure the system cannot inadvertently start during service. Turn off all power to the pump.
IMPORTANT: Place filter manual air relief valve in the open position and wait for all pressure in the
system to be relieved.
Before starting the system, fully open the manual air relief valve and place all system valves in the “open”
position to allow water to flow freely from the pool and spa back to the pool or spa. Stand clear of all pool and
spa equipment and start the pump.
IMPORTANT: Do not close filter manual air relief valve until all pressure has been discharged from the
valve and a steady stream of water appears. Observe filter pressure gauge and be sure it is not higher than
the pre-service condition.
v
IntelliPro®Variable Speed Pump Installation and User’s Guide

Pentair Water Pool and Spa®
PUMP WARNING AND SAFETY INSTRUCTIONS
For Pool and Spa Pumps (Non SVRS Pumps)
(Pentair Water Pool and Spa®, Sta-Rite®, and Pentair Pool Products®)
General Installation Information
• All work must be performed by a qualified pool professional, and must conform to all national,
state, and local codes.
• Install to provide drainage of compartment for electrical components.
• These instructions contain information for a variety of pump models and therefore some
instructions may not apply to a specific model. All models are intended for use in swimming
pool applications. The pump will function correctly only if it is properly sized to the specific
application and properly installed.
Pumps improperly sized or installed or used in applications other than for which the pump
was intended can result in severe personal injury or death. These risks may include but not
be limited to electric shock, fire, flooding, suction entrapment or severe injury or property
damage caused by a structural failure of the pump or other system component.
Thepump canproduce high levelsof suction withinthe suctionside of theplumbing system.
These high levels of suction can pose a risk if a person comes within the close proximity of
thesuction openings.Aperson can be seriously injured bythishigh level of vacuum or may
become trapped and drown. It is absolutely critical that the suction plumbing be installed
in accordance with the latest national and local codes for swimming pools.
General Warnings
Risk of Electrical Shock.
Connect only to a branch circuit protected by a ground-fault circuit-interrupter (GFCI).
Contact a qualified electrician if you cannot verify that the circuit is protected by a GFCI.
This unit must be connected only to a supply circuit that is protected by a ground-fault
circuit-interrupter (GFCI). Such a GFCI should be provided by the installer and should be
tested on a routine basis. To test the GFCI, push the test button. The GFCI should inter-
rupt power. Push the reset button. Power should be restored. If the GFCI fails to operate
in this manner, the GFCI is defective.
If the GFCI interrupts power to the pump without the test button being pushed, a ground
current is flowing, indicating the possibility of an electric shock. Do not use this pump.
Disconnect the pump and have the problem corrected by a qualified service representa-
tive before using.
This pump is for use with permanent swimming pools and may also be used with hot tubs
and spas if so marked. Do not use with storable pools. A permanently-installed pool is
constructed in or on the ground or in a building such that it cannot be readily disassembled
for storage. A storable pool is constructed so that it is capable of being readily disassem-
bled for storage and reassembled to its original integrity.
Electrical controls such as on/off switches, timers, and control systems, etc. should be
properly installed to allow the operation (start-up, shut-down, or servicing) of any pump or
filter without requiring the user to place any portion of his/her body over or near the pump
strainer lid or filter lid. Such installation should allow the user to stand clear of the filter and
pump during system start-up, shut down or servicing of the system.
vi
IntelliPro®Variable Speed Pump Installation and User’s Guide

Two Speed Pump Controls Notice California (Title 20 Compliance)
Please read the following important Safety Instructions.When using two-speed pumps manufactured
on or after January 1, 2008, the pump’s default circulation speed MUST be set to the LOWEST
SPEED, with a high speed override capability being for a temporary period not to exceed one
normal cycle, or two hours, whichever is less.
Pentair Water Pool and Spa®
PUMP WARNING AND SAFETY INSTRUCTIONS
For Pool and Spa Pumps (Non SVRS Pumps)
(Pentair Water Pool and Spa®, Sta-Rite®, and Pentair Pool Products®)
General Warnings, (Continued).
• Never open the inside of the drive motor enclosure. There is a capacitor bank that holds a 230
VAC charge even when there is no power to the unit.
• The pump is not submersible.
• The pump is capable of high flow rates; use caution when installing and programming to limit
pumps performance potential with old or questionable equipment.
• Code requirements for the electrical connection differ from state to state. Install equipment in
accordance with the National Electrical Code and all applicable local codes and ordinances.
• Before servicing the pump; press the Stop button and disconnect the communication cable,
then switch OFF power to the pump by disconnecting the main circuit to the pump.
• This appliance is not intended for use by persons (including children) of reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the appliance by a person responsible
for their safety.
• To reduce the risk of injury, do not permit children to use this product unless they are closely
supervised at all times.
SAVE THESE INSTRUCTIONS
vii
IntelliPro®Variable Speed Pump Installation and User’s Guide

Blank Page
viii
IntelliPro®Variable Speed Pump Installation and User’s Guide

Section 1
Pump Overview
Introduction
The IntelliPro®Variable Speed pump is well suited for all of your pool, spa, cleaner, waterfall and other
water applications. Using the control panel, IntelliPro®can use one of the four selectable preset speeds
or the pump speed can be adjusted to run at a specific speed. IntelliPro®outperforms all conventional
pumps in its class. Advanced energy conservation features ensure that your filtration system is operating
at peak efficiency.
The pump can operate from 450 RPM to 3450 RPM with preset speeds of 750, 1500, 2350 and 3110
RPM. The pump can be adjusted from the control panel to run at any speed between 450 RPM to 3450
RPM for different applications. The pump control panel alarm LED and error messages warn the user
against under and over voltage, high temperature, over current and freeze protection with user defined
minimum and maximum speed presets.
External Control
TheIntelliPro®VariableSpeedpumpcancommunicatewithan IntelliTouch®,EasyTouch®, or SunTouch®
control system or the IntelliComm®communication center via a two-wire RS-485 communication
cable. The communication cable is included with the IntelliPro®Variable Speed pump. EasyTouch®
and IntelliComm®can remotely control the IntelliPro®four preset speeds. The IntelliTouch®system
can be configured to control a total of eight speeds. The pump’s address and other pump functions are
accessed from the pump’s control panel.
IntelliPro®Variable Speed pump
IntelliPro® Variable Speed Pump Installation and User’s Guide
1

12 Programmable Speeds
Eight Set speeds
Schedule
Duration
Manual
Four IntelliComm speed modes
Priming Feature
Load Sensing
Enable or Disable
Lock out protection
Four Digit password
Enable or Disable
LCD Display
Power and Speed
Text Alerts
Antifreeze Protection
Adjustable speed
Adjustable Temperatures
Enable and Disable in stand alone
Additional Features
Clock and Timer
Maximum and Minimum Speed Limits
 Quick Clean Mode
Address up to 16 pumps
Service Features
Timeout Mode
Features
Adjusts to various pool sizes
Prevents thermal overload
Detects and prevents damage from under and over voltage conditions
Protects pump against freezing
Communicates with a Pentair EasyTouch, IntelliTouch or SunTouch control system or
IntelliComm communication center via a two-wire RS-485 cable connection
Easy to use operator control panel
Operator control panel buttons for speed control
Built-in strainer pot and volute
Ultra energy-efficient TEFC Square Flange Motor
Compatibility with most cleaning systems, filters, and jet action spas
Motor assembly features permanent magnet synchronous motor
Heavy-duty, durable construction designed for long life
2
IntelliPro® Variable Speed Pump Installation and User’s Guide

IntelliPro®Drive Assembly and Control Panel
The IntelliPro®drive assembly consists of an operator control panel and the system electronics that
drive the motor. The drive microprocessor controls the motor by changing the frequency of the current
it receives together with changing the voltage to control the rotational speed.
IntelliPro®Drive Assembly
IntelliPro®Variable Speed Motor Features
• Permanent Magnet Synchronous Motor (PMSM)
• High efficiency (3450© RPM 92% and 1000 RPM 90%)
• Superior speed control
• Operates at lower temperatures due to high efficiency
• Same technology as deployed in hybrid electric vehicles
• Designed to withstand outdoor environment
• Totally enclosed fan cooled
• Three-phase motor
• 56 Square Flange
• Six-Pole
• Low noise
Motor stand
Operator Control Panel,
buttons and LED
Communication port for connection to
EasyTouch, IntelliTouch or SunTouch
control system or IntelliComm
communication center via two-wire RS-
485 cable (P/N 350122)
AC power connection
compartment
(see page 33)
IntelliPro® Variable Speed Pump Installation and User’s Guide
3

Section 2
Operator Control Panel
This section describes the IntelliPro®Variable Speed pump operator controls and LEDs.
IntelliPro®Operator Control Panel
1
5
2
6
8
4
3
7
Quick
Clean
Time
Out
Speed
1
Speed
2
Speed
3
Speed
4
12:15
750 RPM
750 RPM
Running Speed 1
T 0.00 150 WATTS
4
IntelliPro® Variable Speed Pump Installation and User’s Guide
Controls and LEDs
Speed 1 button/LED: Press button to select Speed 1 (750 RPM). LED on indicates Speed 1 is active.
Speed 2 button/LED: Press button to select Speed 2 (1500 RPM). LED on indicates Speed 2 is active.
Speed 3 button/LED: Press button to select Speed 3 (2350 RPM). LED on indicates Speed 3 is active.
Speed 4 button/LED: Press button to select Speed 4 (3110 RPM). LED on indicates Speed 4 is active.
Select button: Displays available menu items or enters edit mode for changing a value on line two of the
display.
Escape button: Moves to next level up in the menu structure, and/or stops editing the current setting.
Menu button: Accesses the menu items if the pump is stopped.
Enter button: Saves current menu item setting. Press this button to acknowledge alarms and warning alerts.
5
1
2
3
4
6
7
8

Arrow buttons:
• Up arrow: Move one level up in the menu tree or increase a digit when editing a setting.
• Down arrow: Move one level down in the menu tree or decrease a digit when editing a setting.
• Left arrow: Move cursor left one digit when editing a setting.
• Right arrow: Move cursor right one digit when editing a setting.
Quick Clean: Duration and speed (RPM) can be preset to save energy. The LED is on when active.
Time Out: When active (LED on), at the end of a “Time Out” preset time, the pump will run a schedule.
Start/Stop button: Start or Stop the pump. When the LED is on, the pump is currently running or in a
mode to start automatically.
Reset button: Reset alarm or alert.
LEDs
On: This green, power LED is on when IntelliPro®is powered on.
Warning: LED is on if a warning condition is present.
Alarm: The red LED is on if an alarm condition occurs. See “Alerts and Warnings” on page 34.
Control Panel LCD:
• Line 1 - Key icon indicates password protect mode is active. If password protect is not enabled,
no key icon is displayed.
• Line 2 - Displays the current pump speed (RPM).
• Line 3 - Count down time and Watts
• Line 4 - Current pump status.
15.W
IntelliPro® Variable Speed Pump Installation and User’s Guide
5
9
10
11
12
13
14
15
12:15
Running Speed 1
Quick
Clean
Time
Out
Speed
1
Speed
2
Speed
3
Speed
4
10
11
13
12
14
15
Line 1
Line 2
Line 3
Line 4
T 0.00 150 WATTS
750 RPM
750 RPM
9

Section 3
Operating the IntelliPro Pump
This section describes how to operate the IntelliPro®Variable Speed pump using the control panel
buttons and menu features.
Starting the pump
To start the pump
1. Be sure the pump is powered on and the green power LED is on.
2. Select one of the speed buttons, then press the Start button (LED on) to start the pump.
Stopping the pump
To stop the pump
• Press the Stop button to stop the pump.
Note: The pump can automatically restart if the communication cable is connected.
Servicing Equipment (Disconnect Power to Pump)
• When servicing equipment (filters, heaters, chlorinators etc.), disconnect the communication
cable, and switch OFF circuit breaker to remove power from the pump
Operating the IntelliPro®pump at preset speeds
The IntelliPro®Variable Speed pump is programmed with four default speeds of 750, 1500, 2350 and
3110 RPM. A Speed button is assigned to each of the preset speeds as shown.
To operate the pump at one of the four preset speeds
1. Be sure the pump is powered on and the green power LED is on.
2. Press the Speed button (1- 4) corresponding to the desired preset speed, and release quickly.
The LED above the Speed button will come on as shown.
3. Press the Start button. The pump will quickly ramp to the selected preset speed.
Adjusting the pump speed
1. While the pump is running, press the Up Arrow to increase speed setting.
2. Press the Down Arrow to decrease speed Setting.
3. Press and hold down a Speed Button for three (3) seconds to save speed to the button or
press the Enter button to save the speed.
6
IntelliPro® Variable Speed Pump Installation and User’s Guide
LED lit

Pump Operating Modes
The IntelliPro®Variable Speed pump can be programmed three ways:
1. Manual Operation: Speed buttons 1-4 can be programmed for Manual operation. This means
the speed button is pressed and then the start button and the pump runs a programmed speed.
Speeds 5-8 can not be programmed for Manual operation because there are no buttons associated
with them.
To operate the pump in Manual Mode, press one of the four speed buttons, and press the Start/
Stop button to run the assigned speed for that button. When the pump is running a Manual
Speed Setting (speed 1, 2, 3 or 4 button pressed manually) and a scheduled speed is set to run,
the scheduled speed will take priority regardless of speed (RPM) assigned to each button. When
the Scheduled Speed’s time is over, it will not revert back to the manually pressed speed. If
the pump is running a schedule and a speed button is pressed manually, the pump will run the
manually selected speed until the next scheduled speed program.
2. Egg Timer (Duration): Speeds 1-4 can be programmed to run for a duration of time once
pressed. This means that the Speed button is pressed and then the start button and the pump
runs a programmed speed and the speed will turn off at the end of a pre programmed amount
of time. Speeds 5-8 have no direct pump speed buttons and therefore cannot be programmed
with an Egg-Timer.
3. Schedule: The speed button can be programmed to turn on and off at a certain time. The LED
above the Start/Stop button must be lit for the pump to run schedules. When a speed is set to
run in Schedule mode it can still be operated manually. When a speed is programmed to run 23
hours and 59 minutes per day it will not turn off. For example, for the pump to run 24 hours
per day, program the pump to start at 8:00 AM and stop at 7:59 AM.
Programming the Pump
When the pump is running a manual speed and password time out is activated (see page 12) the pump
can be turned off but it cannot be turned back on. Pressing the Start/Stop button places it in the Running
Schedule mode. Therefore, it will only run Speeds that are Scheduled to come on at their scheduled
Start Time.
IntelliPro® Variable Speed Pump Installation and User’s Guide
7

IntelliPro®Variable Speed Pump Menus
8
IntelliPro® Variable Speed Pump Installation and User’s Guide
Press MENU button to access menus
MAIN SCREEN
(page 9)
SETTINGS (1-16) Default: ADDRESS 1
(hr:mm) Default: 12:00 AM
Set AM/PM AM/PM
24 hr.
Fahrenheit - Default: F°
C° Celsius
(1-5) Default 3
(450 RPM - 1700 RPM) - Default: 450 RPM
(1900 RPM - 3450 RPM) - Default: 3450 RPM
Pump Address
Set Time
Temperature Unit
Screen Contrast
Language
Set Min Speed
Set Max Speed
PASSWORD
Password Time Out (1 min. - 6 hours) Default:10 minutes
Disabled/Enabled - Default: Disabled
Enter Password (xxxx) Default: 1234
(page 14)
SPEED 1-8 Speed 1 (1-4) Manual
Schedule
Egg Timer
Set Speed - Default: MANUAL
Set Speed
Set Start Time
Set Stop Time
Set Speed
Time
(page 15)
EXT CONTROL Program 1 Speed - Default: 750 RPM
Speed - Default: 1500 RPM
Program 2
(page 15)
FEATURES
Quick Clean Set Speed (1100 -3450 RPM) Default: 3450 RPM
Time (1 min. to 10 hrs.) Default: 10 minutes
Time Out Duration (1 min. to 10 hrs.) Default: 3 hours
Time Out
(page 17)
PRIMING DISABLED/ENABLED
(1 min. to 30 min. hrs.) Default: 11 minutes
MAX PRIMING TIME
(page 19)
ANTI FREEZE Disabled / Enabled - Default: Enabled
Program 3 Speed - Default: 2350 RPM
Speed - Default: 3110 RPM
Program 4
English - Default: English
Speed 5 (5-8)
Schedule Set Speed
Set Start Time
Set Stop Time
Disabled Default: Disabled
Default: Enabled
(1 - 100%) Default: 1
PRIMED SENSITIVITY
(1 second - 10 minutes) Default: 20 seconds
PRIMING DELAY
DISABLED/ENABLED
SET SPEED
40° F - 50° F (4.4° C - 10° C) Default: 40° F (4.4° C)
PUMP TEMPERATURE
Set Speed (750 RPM - 3450 RPM) Default 1000 RPM

IntelliPro®Pump Menus
The IntelliPro®pump menu descriptions are as follows:
Settings: Pump Address
The pump address needs to be changed when there is more than one IntelliPro®pump on an automation
system. Addressing the pump allows the automation system to know which pump to send a command
to. The “PumpAddress” setting is used when the IntelliPro®pump is connected via the RS-485 COM
port to an IntelliTouch®, EasyTouch®, SunTouch®or IntelliComm®system. The default pump address
is #1. When connected to EasyTouch®, SunTouch®or IntelliComm®the pump only communicates with
address #1. The pump address can be set from 1-16. However, IntelliTouch® can communicate to four
(1-4) IntelliPro®pumps. Note: IntelliPro®pumps cannot be connected in series with other pumps.
To access the Settings menu:
1. Be sure the green power LED is on and the pump is stopped.
2. Press the Menu button. “Settings” is displayed.
3. Press the Select button. “Pump Address” is displayed. The Factory default setting is address “1.”
4. To change the pump address, press the Select button. The first digit “1” selected.
5. Press Up or Down arrow button to change the address number from 1-16.
6. Press the Enter button to save the setting. To cancel any changes, press the Escape button to
exit edit mode without saving.
7. Press the Escape button to exit.
Settings: Set Time
Use “Set Time” to set the IntelliPro®system time. The IntelliPro®system clock controls all scheduled
start and stop times, functions, and programmed cycles. The system clock can store the correct time for
up to 96 hours after power is shut off. The IntelliPro®will retain the time memory for 96 hours before a
reset is needed.
To access the Set Time menu:
1. Check that the green power LED is on.
2. Press the Menu button. “Settings” is displayed.
3. Press the Select button. “Pump Address” is displayed.
4. Use the Up or Down arrow button to scroll to “Set Time”
5. Press the Select button. The cursor will appear in the Minutes column.
6. Press Up or Down arrow button to set the time.
7. Press the Enter button to save the setting. To cancel any changes, press the Escape button to
exit edit mode without saving.
8. Press the Escape button to exit.
IntelliPro® Variable Speed Pump Installation and User’s Guide
9

Settings: Screen Contrast Level
This setting changes the contrast of the LCD screen. The default setting is 3. Screen contrast levels can
be adjusted from 1 to 5 units for low or high lighting conditions.
To access the Temperature Units menu:
1. Check that the green power LED is on.
2. Press the Menu button. “Settings” is displayed.
3. Press the Select button. “Pump Address” is displayed.
4. Use the Up or Down arrow to scroll to “Contrast level.
5. Press the Select button. Screen will show current contrast setting number. The default is “3”.
6. Press the Select button to change the setting. Number will highlight.
7. Press the Enter button to save the setting. To cancel any changes, press the Escape button to
exit edit mode without saving.
8. Press the Escape button to exit.
Settings: Set AM/PM or 24 Hour Clock
This setting is for changing the pump’s time clock from regular time (AM/PM) to a 24 hour clock. For
example, Midnight (12:00 AM) is 0000 hr., 8:00 AM is 0800 hr., and 11:00 PM is 2300 hr.
To access the AM/PM or 24 hr. menu:
1. Check that the green power LED is on.
2. Press the Menu button. “Settings” is displayed.
3. Press the Select button. “Pump Address” is displayed.
4. Use the Up or Down arrow button to scroll to “AM/PM.”
5. Press the Select button to change the setting.
6. Press Up or Down arrow button to choose between 24 hr and AM/PM.
7. Press the Enter button to save the setting. To cancel any changes, press the Escape button to
exit edit mode without saving.
8. Press the Escape button to exit.
Settings: Set Temperature Unit
Use this setting to set the temperature unit to Celsius (°C), or Fahrenheit (°F). The IntelliPro®Anti
Freeze protection feature (see page 19) can be set to either Fahrenheit or Celsius.
To access the Temperature Units menu:
1. Check that the green power LED is on.
2. Press the Menu button. “Settings” is displayed.
3. Press the Select button. “Pump Address” is displayed.
4. Use the Up or Down arrow button to scroll to “Temperature Units” menu item. The factory
default setting is “F” (Fahrenheit).
5. Press the Select button. “F” is displayed.
6. Press Up or Down arrow button to choose between Celsius (°C), or Fahrenheit (°F).
7. Press the Enter button to save the setting. To cancel any changes, press the Escape button to
exit edit mode without saving.
8. Press the Escape button to exit.
10
IntelliPro® Variable Speed Pump Installation and User’s Guide
