“LT” SERIES
CENTRIFUGAL PUMPS
O W N E R’ S M A N U A L
INSTALLATION, OPERATION & PARTS
MODELS
1/6 HP LT1/6L
1/2 HP LTACL
3/4 HP LTADL
3/4-1/8 HP LTAYDRL
Sta-Rite Pool/Spa Group
293 Wright Street, Delavan, WI 53115
International: 262-728-5551, FAX: [phone]
www.starite.com
Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA
©2004, Sta-Rite Industries Printed in U.S.A. S61 (Rev. 9/13/04)
This manual should be furnished to
the end user of this pump; its use will
reduce service calls and chance of
injury and will lengthen pump life.

2
‘ LT’ SERIES CENTRIFUGAL PUMP
To avoid unneeded service calls, prevent possible injuries, and get the most
out of your pump, READ THIS MANUAL CAREFULLY!
The Sta-Rite ‘LT’ Series pump:
• Is designed to circulate water in above ground swimming pools, and in
spas, hot tubs, and solar systems.
• Is an excellent performer; durable, reliable, with non-clogging impeller.
Table of Contents
Safety Instructions ........................................................................................3
Installation.................................................................................................4-5
Electrical....................................................................................................5-6
Operation .....................................................................................................7
Storage/Winterizing ...................................................................................7-8
Pump Service...........................................................................................9-10
Troubleshooting Guide ...............................................................................11
Repair Parts List .....................................................................................12-15
Warranty.....................................................................................................16

3
READ AND FOLLOW SAFETY
INSTRUCTIONS!
This is the safety alert symbol. When you see this symbol on your system
or in this manual, look for one of the following signal words and be alert
to the potential for personal injury.
warns about hazards that will cause death, serious personal
injury, or major property damage if ignored.
warns about hazards that can cause death, serious personal
injury, or major property damage if ignored.
warns about hazards that will or can cause minor personal injury
or property damage if ignored.
NOTICE indicates special instructions not related to hazards.
Carefully read and follow all safety instructions in this manual and on equip-
ment. Keep safety labels in good condition; replace if missing or damaged.
Incorrectly installed or tested equipment may fail, causing
severe injury or property damage.
Read and follow instructions in owner's manual when installing
and operating equipment. Have a trained pool professional per-
form all pressure tests.
1. Do not connect system to a high pressure or city water system.
2. Use equipment only in a pool or spa installation.
3. Trapped air in system can cause explosion. BE SURE all air is out of system
before operating or testing equipment.
Before pressure testing, make the following safety checks:
•Check all clamps, bolts, lids, and system accessories before testing.
•Release all air in system before testing.
•Tighten Sta-Rite trap lids to 30 ft. lbs. (4.1 kg-m) torque for testing.
•Water pressure for test must be less than 25 PSI (7.5 kg/cm2).
•Water Temperature for test must be less than 100oF. (38oC).
•Limit test to 24 hours. After test, visually check system to be sure it is ready
for operation. Remove trap lid and retighten hand tight only.
NOTICE: These parameters apply to Sta-Rite equipment only. For
non-Sta-Rite equipment, consult manufacturer.
Motor normally operates at high temperature and will be too hot
to touch. It is protected from heat damage during operation by an automatic in-
ternal cut off switch. Before handling pump or motor, stop motor and allow it
to cool for twenty minutes.
IMPORTANT
SAFETY
INSTRUCTIONS
Always follow basic safety pre-
cautions with this equipment, in-
cluding the following.
To reduce the risk of
injury, do not permit children to
use this product unless they are
closely supervised at all times.
This pump is for use
with permanently installed pools
and may also be used with hot
tubs and spas if so marked. Do
not use with storable pools. A
permanently installed pool is con-
structed in or on the ground or in
a building such that it cannot be
readily disassembled for storage.
A storable pool is constructed so
that it may be readily disassem-
bled for storage and reassembled
to its original integrity.
SAVE THESE
INSTRUCTIONS

4
INSTALLATION
Only qualified, licensed personnel should install pump and wiring.
Pump mount must:
Be solid - Level - Rigid - Vibration free. (To reduce vibration and pipe stress,
bolt pump to mount.)
Allow pump suction inlet height to be as close to water level as possible.
Allow use of short, direct suction pipe (To reduce friction losses).
Allow for gate valves in suction and discharge piping.
Have adequate floor drainage to prevent flooding.
Be protected from excess moisture.
Allow adequate access for servicing pump and piping.
NOTICE: Use Teflon tape or Plasto-Joint Stik1 for making all threaded
connections to the pump. Do not use pipe dope; pipe dope will cause stress
cracking in the pump.
NOTICE: Pump suction and discharge connections have molded in thread
stops. DO NOT try to screw pipe in beyond these stops.
Teflon Taping Instructions:
Use only new or clean PVC pipe fittings.
Wrap male pipe threads with one to two layers of Teflon tape. Cover entire
threaded portion of pipe.
Do not overtighten or tighten past thread stop in pump port!
If leaks occur, remove pipe, clean off old tape, rewrap with one to two addi-
tional layers of tape and remake the connection.
NOTICE: Support all piping connected with pump!
1Lake Chemical Co., Chicago, Illinois
FIGURE 1

5
Piping:
Use at least 1-1/4" (32mm) IPS PVC. Increase size if a long run is needed.
To avoid strains on the pump, support both suction and discharge pipes inde-
pendently. Place these supports near the pump.
To avoid a strain left by a gap at the last connection, start all piping at the
pump and run pipe away from the pump.
Never use a suction pipe smaller than pump suction connection.
To avoid airlocking, slope suction pipe slightly upward toward the pump.
NOTICE: To prevent flooding when removing pump for service, all flooded
suction systems must have gate valves in suction and discharge pipes.
Fittings:
Fittings restrict flow; for best efficiency use fewest possible fittings.
Avoid fittings which could cause an air trap.
Pool fittings must conform to International Association of Plumbing and
Mechanical Officials (IAPMO) standards.
Use only non-entrapping suction fitting or double suction.
ELECTRICAL
Ground motor before connecting to electrical power supply. Failure to
ground motor can cause severe or fatal electrical shock hazard.
Do not ground to a gas supply line.
To avoid dangerous or fatal electrical shock, turn OFF power to motor
before working on electrical connections.
Ground Fault Circuit Interrupter (GFCI) tripping indicates an electrical
problem. If GFCI trips and will not reset, have a qualified electrician
inspect and repair electrical system.
Exactly match supply voltage to nameplate voltage (115 Volt single
phase only). Incorrect voltage can cause fire or seriously damage motor
and voids warranty. If in doubt consult a licensed electrician.
Voltage
Voltage at motor must be not more than 10% above or below motor name-
plate rated voltage or motor may overheat, causing overload tripping and re-
duced component life. If voltage is less than 90% or more than 110% of rated
voltage when motor is running at full load, consult power company.
Grounding/Bonding
Install, ground, bond and wire motor according to local or National Electrical
Code requirements.
Permanently ground motor. Use green ground terminal provided under motor
canopy or access plate (See Figure 2); use size and type wire required by
code. Connect motor ground terminal to electrical service ground.
Bond motor to pool structure. Use a solid copper conductor, size No. 8 AWG
(8.4 sq. mm) or larger. Run wire from external bonding lug (see Figure 2) to
reinforcing rod or mesh.
Hazardous voltage.
Can shock, burn,
or cause death.
Ground pump before
connecting to
power supply.
BONDING
LUG
MOTOR NAMEPLATE
GREEN
GROUND
SCREW
MOTOR
CANOPY
THROUGH
BOLTS 499 0993
Figure 2 – Typical ground screw and
bonding lug locations.

6
Connect a No. 8 AWG (8.4 sq. mm) solid copper bonding wire to the pressure
wire connector provided on the motor housing and to all metal parts of the
swimming pool, spa, or hot tub and to all electrical equipment, metal piping
or conduit within 5 feet (1.5 m) of the inside walls of swimming pool, spa, or
hot tub.
Wiring
Pump must be permanently connected to circuit. Table I gives correct wire
and circuit breaker sizes for the pump alone. If other lights or appliances are
also on the same circuit, be sure to add their amp loads to pump amp load
before figuring wire and circuit breaker sizes. (If unsure how to do this or if
this is confusing, consult a licensed electrician.) Use the load circuit breaker
as the master on-off switch.
Install a Ground Fault Circuit Interrupter (GFCI) in circuit; it will sense a short-
circuit to ground and disconnect power before it becomes dangerous to pool
users. For size of GFCI required and test procedures for GFCI, see manufac-
turer’s instruction.
In case of power outage, check GFCI for tripping (which will prevent normal
pump operation). Reset if necessary.
NOTICE: If you do not use conduit when wiring motor, be sure to seal wire
opening on end of motor to prevent dirt, bugs, etc., from entering.
Values given in table below are for PUMP ONLY. If additional acces-
sories are installed on pump motor circuit (heater, blower, etc.), in-
clude their amerage draw when figuring wire and circuit breaker sizes.
White
230
Volt
Lines
A
B
L2
L1
Blue
SINGLE
VOLTAGE
MOTORS
DUAL
VOLTAGE
MOTORS
A
B
L2
L1
White
w/Black
Tracer
Black
115
Volt
Lines
A
B
L2
L1
White
w/Black
Tracer
Black
230
Volt
Lines
Motor Terminal Board Connections
Figure 3A – Wiring hook-up diagram.
Power Supply for
Optional Timer.
Low Spd
High Spd Circuit
Protector
Remote
SPDT
Switch
Ground (Green)
Common
If using timer, Connect
Timer Motor to Low Speed Only
Minimum switch and timer amp rating must equal Branch Fuse
Rating given in "Recommended Fusing and Wiring Data" table.
A
B
L2
L1
Back of
motor
with
Terminal
Board
4213 0602
115 Volt
Lines
Figure 3B – Remote switching for 115V 2-Speed pumps. Timer supply should be
unswitched.
TABLE I - RECOMMENDED FUSING AND WIRING DATA – 60 Cycle Motors
Serv. to Motor - Dist. in Ft. (M)
Pump Motor Branch Fuse Max Load Voltage/ 0-100' 101-200' 201-300'
Model HP Rating Amps* Amps Hz/Phase (0-30M) (30-60M) (60-90M)
LT1/6L 1/6 15 4.5 115/60/1 14(2) 14(2) 14(2)
LTACL 1/2 15 8.4 115/60/1 14(2) 12(3) 10(5.5)
LTADL 3/4 15 11.4 115/60/1 14(2) 10(5.5) 8(8.4)
LTAYDRL 3/4-1/8 15 10.0-3.0 115/60/1 14(2) 12(3) 10(5.5)
* Branch Short Circuit Protection (Non Time-Delay Fuse).

7
OPERATION
NEVER run pump dry. Running pump dry may damage seals, causing leakage
and flooding. Fill pump with water before starting motor.
Do not add chemicals to spa system directly in front of pump suction.
Adding undiluted chemicals may damage pump and voids warranty.
Open gate valves before starting system.
Pump will prime itself when used in flooded suction system.
Be sure to release all air from filter and piping system; see spa/filter owner’s
manual.
On 2-Speed models, low speed is used for filtration and heating; high speed
provides therapy jet action.
Do not block pump suction. To do so with body may cause severe or
fatal injury. Small children using spa must ALWAYS have close adult
supervision.
•Tub should have dual suction outlets to prevent body or hair entrapment.
•Use only tub suction fittings certified to meet ASME/ANSI standard
A112.19.8M-1987.
NOTICE: Do not block pool return or spa jets! To do so may flood area caus-
ing damage to equipment and water damage to surrounding area.
Spa or Tub Water:
Keep water level at least two inches above bottom of skimmer opening when
system is not in use. Failure to do so can allow air to enter system, causing
pump to lose its prime.
Keep water temperature at 104°F (40°C) or below.
Age or health conditions may require a lower temperature; consult a physi-
cian for more information.
If in doubt, start at a lower temperature and gradually increase it according to
your experience.
Keep an accurate thermometer in bath; check it before getting in.
Do not use or allow the use of the spa by anyone using alcohol or
drugs. The effects of hot water, alcohol and/or drugs can cause dizzi-
ness and falling, loss of consciousness, or heart attack.
A long bath in hot water may cause hyperthermia (too much heat in
the body) which can be fatal. Some symtoms of hyperthermia are:
• Nausea
• Dizziness
• Fainting
If these symptoms appear while in the spa, GET OUT AT ONCE!
Cool the body at once with cold towels or a cool shower.
Call a doctor if symtoms do not go away.
Hazardous suction.
Can trap hair or
body parts, causing
severe injury
or death.
Do not block
suction.
Too much heat
can cause nausea,
dizziness, fainting or
death.
Check temperature
before using spa.

8
Draining Pump
To avoid dangerous or fatal electrical shock hazard, turn OFF power to
motor before draining pump.
Storage/Winterizing:
Explosion hazard. Purging the system with compressed air can
cause components to explode, with risk of severe injury or death to anyone
nearby. Use only a low pressure (below 5 PSI), high volume blower when air
purging the pump, filter, or piping.
NOTICE: Allowing pump to freeze will damage pump and void warranty!
NOTICE: Do not use anti-freeze solutions (except propylene glycol) in your
pool/spa system. Propylene glycol is non-toxic and will not damage plastic
system components; other anti-freezes are highly toxic and may also damage
plastic components in the system.
Drain all water from pump and piping when expecting freezing temperatures
or when storing pump for a long time (see instructions below).
Keep motor dry and covered during storage.
To avoid condensation/corrosion problems, do not cover pump with plastic.
For outdoor/unprotected installations:
1. Gravity drain system as far as possible.
2. Protect areas which retain water with non-toxic propylene glycol antifreeze
(“RV antifreeze”).
3. Enclose entire system in a weatherproof enclosure.
4. To avoid condensation/corrosion damage, allow ventilation; do not wrap
system in plastic.
5. Use a 40% propylene glycol/60% water solution to protect pump to
-50 degrees F (-46 degrees C).
Startup For Winterized Equipment
1. Remove any temporary weather protection placed around system.
2. Follow filter manufacturer’s instructions for reactivation of the filter.
3. Inspect all electrical wiring for damage or deterioration over the shutdown
period. Have a qualified serviceman repair wiring as needed.
4. Inspect and tighten all watertight connections.
5. Open all valves in suction and return piping.
6. Remove any winterizing plugs in piping system.
7. Drain all antifreeze from system.
8. Close all drain valves and replace all drain plugs in piping system.
9. Prime pump according to instructions on Page 7.
PUMP SERVICE
To avoid dangerous or fatal electrical shock hazard, turn OFF power to
motor before working on pump or motor.
No lubrication or regular maintenance is needed beyond reasonable care and
periodic cleaning.
Hazardous voltage.
Can shock, burn,
or cause death.
Disconnect power
before working
on pump or motor.
Hazardous voltage.

9
If shaft seal is damaged, repair as follows:
Removing Old Seal
1. Disconnect power to pump motor.
2. Drain water to below level of suction and discharge piping and discon-
nect pipes from pump body.
3. Remove nine capscrews, Key No. 10, Page 11, from pump body,
Key No. 8.
4. Remove pump body from seal plate, Key No. 3. Use care to not damage
gasket, Key No. 4, when opening pump body. If damaged, replace.
5. Remove cover from end of motor to expose shaft and electrical
components.
6. Place a 7/16” open end wrench on flats of motor shaft at cover end below
centrifugal switch mechanism. Hold shaft, and when looking at impeller,
turn impeller clockwise and remove from shaft.
7. Unscrew four through-bolts under motor cover to remove seal plate from
motor.
8. Drive stationary part of shaft seal out of seal plate using rigid tubing or
pipe as shown in Figure 4.
9. Clean seal plate cavity and motor shaft.
Installing New Seal
1. Coat seal cup with Sealastic #732 RTV sealant before pressing seal into
seal cavity. Press into place with a tube or pipe of correct diameter to
press on seal cup rim only, as shown in Figure 5.
2. Pry loose the ceramic seal seat in back of impeller, using screwdriver be-
tween seat and cavity in impeller as shown in Figure 6. Clean cavity from
which seat was removed.
3. Lubricate O-Ring on seal seat with liquid soap solution. Press seat into im-
peller cavity with polished face up as shown in Figure 7. Use cardboard
disc or large washer to protect surface of ceramic seat of new seal.
BE SURE you do not scratch or nick seal surface.
4. To Reassemble pump, reverse steps one through seven. See Exploded
View, Page 11.
Figure 4
Figure 5
Figure 6
Figure 7

10
TROUBLESHOOTING GUIDE
Read and understand safety and operating instructions in this manual
before doing any work on pump!
Only qualified personnel should electrically test pump motor!
Pump does not operate:
1. Check GFCI for proper operation according to GFCI manufacturer’s instru-
tions.
2. Check for plugged impeller. Follow disassembly/assembly instructions
under “Pump Service”, Page 8.
3. Consult dealer/installer or service representative.
Inadequate circulation or jet action:
1. Check for blocked fittings. Block fittings will cause poor flow and poor jet
action.
2. Consult dealer/installer or service representative.
Excessive air in system - pump loses prime:
1. Make sure water level is at least 2” (51mm) above top of jets with system
not operating.
2. Make sure there are no leaks in suction piping.
3. Make sure ther is no vortex (whirlpool) at the suction.
4. Consult dealer/installer or service representative.
Circuit breaker in home panel trips repeatedly:
1. Breaker must be of adequate capacity.
2. For GFCI breaker: test according to GFCI manufacturer’s instructions.
3. Be sure no other lights and appliances are on circuit.
4. Consult dealer/installer or service representative.
Mechanical troubles and noise:
1. If pump suction and discharge piping are not adequately supported, pump
assembly will be strained. See “Installation”, Page 4.
2. Do not mount pump on a wooden platform! Securely mount on a con-
crete platform for quietest performance.
3. Air leak in suction line (bubbles in water returning to pool). Repair leak.
Tighten trap lid.
4. Foreign matter (gravel, metal, etc.) in pump impeller. Disassemble pump,
clean impeller, follow “Pump Serivce” instructions on Page 8 for
reassembly.
5. Cavitation.
Improve suction conditions by increasing pipe size, decreasing number of
fittings. Increase discharge pressure (reduce flow by throttling discharge
gate valve).
Hazardous voltage.
Can shock, burn,
or cause death.
Disconnect power
before working
on pump or motor.

11
1
2
3
4
5
6A
6B 8
7
9
10
11
12
1164 0695
Model Number
Key LT1/6L LTACL LTADL LTAYDRL
No. Description Qty. 1⁄6HP 1⁄2HP 3⁄4HP 3⁄4-1⁄8HP
1Motor 115V/60H/1 Ph.* 1 A800A16L A800CLL A800DLL A800DLL-Y
2Slinger 1 C69-7 C69-7 C69-7 C69-7
3Seal Plate 1 C1-84P2 C1-84P2 C1-84P2 C1-84P2
4Gasket 1 C20-31B C20-31B C20-31B C20-31B
5Shaft Seal 1 U109-68SS U109-68SS U109-68SS U109-68SS
6A Shim (.010 Thick) As Required 2 C43-21D C43-21D C43-21D C43-21D
6B Shim (.029 Thick) As Required 2 C43-22D C43-22D C43-22D C43-22D
7Impeller 1 C5-151P2 C5-151P1 C5-175P C5-175P
8Volute 1 C101-247P C101-247P C101-247P C101-247P
9Pipe Plug, 1⁄4” NPT 1 WC78-40T WC78-40T WC78-40T WC78-40T
10 Capscrew, 10x5⁄8”9U30-871SS U30-871SS U30-871SS U30-871SS
11 Lockwasher 9 U43-22SS U43-22SS U43-22SS U43-22SS
12 Washer, Flat 9 U43-113SS U43-113SS U43-113SS U43-113SS
SERVICE PARTS
Seal and Gasket Kit 1 PP1075 PP1075 PP1075 PP1075
Overhaul Kit 1 PP1080 PP1081 PP1082 PP1082
Adapter, Union - 1-1/2” Slip 1 U11-183P U11-183P U11-183P U11-183P
Collar, Union 1 U11-182P U11-182P U11-182P U11-182P
O-Ring, Union 1 U9-226 U9-226 U9-226 U9-226
Adapter, Union - 1-1/4” MPT 1 U11-186P U11-186P U11-186P U11-186P
* For SK110 or SK220 Series Cabinet Spa, order Motor No. C218-221E.
NOTE: Includes quick disconnect Union Assemblies. Part No. U111-186p (2).
Contains 2 each of - U11-182P1, U11-183P1, U11-186P and U9-226.
REPAIR PARTS LIST
LT SERIES
CENTRIFUGAL PUMP

12

13

14

CREATE A RECORD OF YOUR WARRANTY AT STA-RITE:
• Complete a warranty registration at www.staritepool.com by clicking on “Register Products” and selecting Sta-Rite Pool OR
• Complete bottom portion completely and mail within 10 days of installation to Sta-Rite, Attn.: Pool Warranty Dept., 293 Wright St., Delavan , WI 53115
Warranty Registration Card
Name
Address
City State Zip
Installation (or Purchase) Date
Product Purchased
Model Number
■■New installation ■■Replacement
Years pool has been in service ■■less than 1 ■■1-3 ■■3-5 ■■5-10
This product was purchased from:
Company name
Address
City State Zip
STA-RITE LIMITED WARRANTY
For technical information about this product, contact the installer or call Sta-Rite at 262-728-9181.
Visit www.staritepool.com
• for more information about Sta-Rite products listed above
• to locate a Sta-Rite dealer near you
Product Specific Warranties (from date of installation)
Product Limited
Family Warranty Exceptions
Filters 1 Year System 3 Tank Bodies - 10 Yrs
Filter Valves 1 Year
Pumps 1 Year
Heaters 2 Years *Commercial Application - 1 Yr
Controls 1 Year
Above Ground Systems 1 Year
Lights and Niches 1 Year Lamps and Bulbs - 90 Days
White Goods 1 Year
Maintenance Equipment 90 Days
Drainer/Utility Pumps 90 Days
Replacement Parts 90 Days
Cleaners: Lil Shark 1 Year
Cleaners: Calypso 1 Year
Cleaners: Pool Shark 2 Years Footpad and Seal Flaps - 1 Yr
Cleaners: Great White 2 Years
* Commercial and multi-family application.
Retain this warranty certificate in a
safe and convenient location for your records.
Pumps, filters, skimmers, underwater lights (excluding bulbs), ac-
cessories and fittings manufactured by Sta-Rite are warranted to
be free of defects in material and/or workmanship for one (1) year
from the original date of installation.
The foregoing warranties relate to the original consumer purchaser
(“Purchaser”) only. Sta-Rite Industries shall have the option to re-
pair or replace the defective product, at its sole discretion.
Purchasers must pay all labor and shipping charges necessary to
replace the product covered by this warranty. Requests for war-
ranty service must be made through the installing dealer. This war-
ranty shall not apply to any product that has been subject to
negligence, misapplication, improper installation or maintenance,
or other circumstances which are not in Sta-Rite’s direct control.
Failure to have product installed by a professional in compliance
with local codes will void any and all manufacturers warranty.
This warranty sets forth Sta-Rite’s obligation and Purchaser’s ex-
clusive remedy for defective products.
STA-RITE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL,
INCIDENTAL OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER EXPRESS WARRANTIES. IMPLIED WAR-
RANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL NOT EXTEND BEYOND THE
DURATION OF THE APPLICABLE EXPRESS WARRANTIES
PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied war-
ranty lasts, so the above limitations or exclusion may not apply to
you. This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
Supersedes all previous publications.
S4877PS (Rev. 7/21/04)

16
