Stage right AlphaRoll Series User manual

PRODUCT INFORMATION PACKET
PRODUCT NAME: AlphaRoll Riser

1
Table of Contents
Introduction
General Safety Rules
Symbols
Technical Specifications
Instructions
Maintenance
Customer Service Information
Introduction
The StageRight AlphaRoll Riser has been designed and manufactured with safety, performance and
dependability as top priorities, making it easy to operate and maintain.
The care you give your AlphaRoll Riser will greatly determine your satisfaction with its performance and service
life. Careful study of this manual is encouraged to obtain a thorough understanding of your new AlphaRoll Riser
and its functions and maintenance.
If your manual becomes lost or destroyed, StageRight will gladly provide you with a new copy. Should you
require additional information or assistance, please feel free to contact us at 1-800-438-4499.
BECAUSE STAGERIGHT CORPORATION MAINTAINS AN ONGOING
PROGRAM OF PRODUCT DEVELOPMENT AND IMPROVEMENT, WE
RESERVE THE RIGHT TO MAKE IMPROVEMENTS IN DESIGN OR CHANGES
IN SPECIFICATIONS WITHOUT INCURRING ANY OBLIGATIONS TO INSTALL
THEM ON UNITS PREVIOUSLY SOLD.
1
2
3
4
5
8
8

2
General Safety Rules
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS.
Failure to follow all instructions listed below may result in serious
personal injury.
SAVE THESE INSTRUCTIONS
Stay clear of all pinch points.
Make sure that all fasteners are properly engaged before use. Faspins, button stops, and
jam nuts need to be properly engaged before use.
Make sure that all decks are positioned properly onto the support system.
Save these instructions. Refer to them frequently and use them to instruct others who may use
the AlphaRoll Riser.
Read the Product Information Packet. Failure to read the information packet is considered a
misuse of this equipment.
Become familiar with all caution and warning decals affixed to the support sytem before
use.
Never cover or deface caution/warning labels.

3
Symbols
Safety Alert: Precautions that involve your safety
Pinch Point Warning Label: Failure to keep hands away from
pinch points will result in personal injury
Read The Operator’s Manual: To reduce risk of injury, user
must read and understand operator’s manual before using this
product

4
StageRight Corporation Technical Specifications
AlphaRoll Riser
AlphaRoll Value Model AlphaRoll Elite Model
4’x8’ 6’x8’ 4’x8’ 6’x8’
360037 360038 360021 360022
Description
245 lbs 330 lbs 265 lbs 350 lbs Leg Sets
16”-24” Dual Height 107041 10 lbs
24”-32” Dual Height 107044 15 lbs
32”-40” Dual Height 107046 25 lbs
18”-24” Dual Height 107042 10 lbs
24”-30” Dual Height 107043 14 lbs
30”-36” Dual Height 107045 25 lbs
16”-24”-32”-40” Quad Height 107600 35 lbs
18”-24”-30”-36” Quad Height 107602 35 lbs
Construction, Finish, and Hardware
- UHMW-PE bushings
- Constructed of ASTM specified steel
- Baked-on powder coat finish.
- Zinc-plated hardware

5
Instructions
Instructions
1
2
See Step 4 for Height adjustment. To fold down riser, pull out knob on folding legs and fold the legs
into the locked position. Release the bungee strap connecting Side A and Side B. Start the set-up by
folding down Side A first. Once flat, fold down Side B.
To fold up the Riser, lift Deck B until it rests vertically. Then lift Deck A until it rests vertically. Engage
the lock located at the top center of Deck A.
Side ASide B

6
3
4
Engage bungee strap and finish putting into storage position by pulling out the knob on each leg and fold
them into the locked position.
Adjust height or replace leg set with the riser in the transport/storage position. To adjust height, remove
faspin, slide adjustable leg into desired position and reinsert faspin. Make sure ALL adjustable legs and
center supports are in the same position on the riser before using.

7
5
To switch deck surface, unbolt the four tie downs holding the deck down, lift the deck, flip, and drop in
frame. Insert (4) bolts into deck and tighten.

8
Maintenance
WARNING!
Read and Understand All Maintenance Procedures
Failure to follow all procedures listed below may cause serious injury
and a decrease in the equipments functional existence.
Frequently check to see that all fasteners are properly engaged.
Touch up paint can be used to cover any scratches or blemishes sustained through use.
Replace any damaged equipment with genuine StageRight parts. Failure to do so may result
in unsafe equipment and/or personal injury.
Customer Service
For parts or service contact StageRight Corporation. When ordering parts be sure to provide all relevant
information available including the name and part number of the equipment purchased. This information is
located on the technical specification page of this product information package. Customer Service hours are
Monday thru Friday from 8:00 a.m. to 5:00 p.m. Eastern Standard Time. Customers can phone toll-free at
[phone] or mail:
StageRight Corporation
495 Pioneer Parkway
Clare, Michigan 48617
www.stageright.com
