ARJO HUNTLEIGH MAXI MOVE User manual

001.25060.EN rev. 11 • January 2014
MAXI MOVE™
Instructions for Use
...with people in mind

Design Policy and Copyright
® and ™ are trademarks belonging to the ArjoHuntleigh group of companies.
© ArjoHuntleigh 2011.
As our policy is one of continuous improvement, we reserve the right to modify designs without prior
notice.The content of this publication may not be copied either whole or in part without the consent
of ArjoHuntleigh.

Contents
3
001.25060.EN rev. 11
General Information ................................................................................................................... 5
Definitions Used in this Manual........................................................................................................ 5
Manufacturer Information ................................................................................................................. 5
Intended Use.................................................................................................................................... 5
Conditions......................................................................................................................................... 6
Operational Life................................................................................................................................ 6
Policy on Number of Staff Members Required for Patient Transfer.................................................. 6
Safety Instructions..................................................................................................................... 7
Symbols Used .................................................................................................................................. 7
Homecare Environment Considerations........................................................................................... 8
Product Description/Functions................................................................................................. 9
Parts Referred to in this Manual....................................................................................................... 9
Slings.............................................................................................................................................. 11
Controls and Features.................................................................................................................... 13
Control Handset .................................................................................................................... 13
Control Panel......................................................................................................................... 13
Stop Button (red)................................................................................................................... 13
Power Button (green)............................................................................................................ 13
System Failure Wind Down Facility....................................................................................... 14
Automatic Cut-Out................................................................................................................. 14
Anti-Crush System ................................................................................................................ 14
Battery Indicator.................................................................................................................... 14
Sleep Mode........................................................................................................................... 14
Usage Counter...................................................................................................................... 15
Adjustable Width Chassis Legs............................................................................................. 15
Chassis Castor Brakes.......................................................................................................... 15
Jib and Spreader Bars/Stretcher Frame................................................................................ 15
Using your MAXI MOVE........................................................................................................... 16
Before Approaching the Patient...................................................................................................... 16
Powered Opening “V” Chassis....................................................................................................... 16
MAXI MOVE ‘Lock and Load’ System............................................................................................ 16
Testing the Attachment................................................................................................................... 17
Using the DPS Spreader Bar.......................................................................................................... 18
To Lift from a Chair...................................................................................................................... 18
To Lift from the Bed..................................................................................................................... 19
To Lift from the Floor ................................................................................................................... 21
Powered DPS Spreader Bar........................................................................................................... 22
Care of Your Powered DPS Spreader Bar .................................................................................. 23
Using the Loop Spreader Bar......................................................................................................... 23
To Lift from a Chair...................................................................................................................... 24
To Lift from the Bed..................................................................................................................... 25
To lift from the Floor..................................................................................................................... 25
Using the Stretcher Frame ............................................................................................................. 25
Using the Soft Stretcher ................................................................................................................. 25
Using the Strap Stretcher.............................................................................................................. 27
Scale.......................................................................................................................................... 30
Patient Scale Information ............................................................................................................... 30
Descriptive Marking/Seals C.E. Units only..................................................................................... 30
Reinspection................................................................................................................................... 30
Display Symbols/Functions ............................................................................................................ 31
Overload Warning Symbol.............................................................................................................. 31
Method A - Weighing Before the Patient is Suspended in the Sling............................................... 31
Method B - Weighing with the Patient Already Suspended in the Sling......................................... 32
Units of Measure ............................................................................................................................ 33
Scale - Handset Instructions Mini-Guide................................................................................ 34
Battery Charging ...................................................................................................................... 36
Contents

Contents
4
001.25060.EN rev. 11
Battery Pack.................................................................................................................................... 36
Removing the Battery Pack ............................................................................................................ 36
Charging your Battery..................................................................................................................... 36
Battery and Battery Charger Safety Practices................................................................................ 37
Care of your MAXI MOVE ........................................................................................................ 38
Sling Cleaning and Care................................................................................................................. 38
Lift Cleaning and Care.................................................................................................................... 38
Mandatory Daily Checks................................................................................................................. 38
Periodic Testing.............................................................................................................................. 38
Servicing Advice ............................................................................................................................. 39
Troubleshooting....................................................................................................................... 40
Labels........................................................................................................................................ 41
Technical Specifications......................................................................................................... 42
Lift Dimensions ............................................................................................................................... 43
Appendix - Scale Gravity Code Configurations.................................................................... 45
Viewing the Gravity Code Configuration......................................................................................... 45
European Gravity Zones Map......................................................................................................... 46
Gravity Adjustment Table................................................................................................................ 48
Electromagnetic Compatibility ............................................................................................... 50
Electromagnetic Compliance.......................................................................................................... 50
Electromagnetic Emissions.......................................................................................................... 50
Electromagnetic Immunity............................................................................................................ 51

General Information
5
001.25060.EN rev. 11
Thank you for buying an ArjoHuntleigh
product.
Your MAXI MOVE is part of a series of quality
products designed especially for hospitals,
nursing homes and other health care uses.
We are dedicated to serving your needs and
providing the best products available along
with training that will bring your staff
maximum benefit from every ArjoHuntleigh
product.
Contact us if you need more information, want
to report an unexpected event or need any
help in setting up, using or maintaining your
your ArjoHuntleigh product.
All references to the patient in these instructions
refer to the person being lifted, and references to
the attendant refer to the person who operates
the MAXI MOVE.
Techniques described in these instructions for
fitting slings and lifting patients from a reclining
position can be used for patients regardless of
where they may be lying; on the bed or on the
floor.
Similarly, lifting a patient from a chair employs the
same techniques as when lifting a patient from a
wheelchair or from a sitting position on the edge
of a bed.
These instructions specifically show both the clip
attachment slings being used with the standard
Dynamic Positioning System (DPS) and the loop
attachment slings for loop spreader bars. The
same methods and techniques described for the
standard DPS can also be applied to the optional,
powered DPS.
Definitions Used in this Manual
Means: Failure to understand and follow these
instructions may result in injury to yourself and
others.
Means: Failure to follow these instructions may
cause damage to the product(s).
Means: This is important information regarding
the correct use of the equipment.
Manufacturer Information
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö
SWEDEN
Intended Use
MAXI MOVE is a mobile, passive lift with
removable spreader bar.
MAXI MOVE is intended to be used under
professionnal staff supervision in hospitals,
nursing homes or other health care facilities
where the patient:
• sits in a wheelchair
• has no capacity to support himself/herself
• cannot stand unsupported and is not able to
bear weight; not even partially
• is dependent on the caregiver in most
situations
Or where the patient:
•ispassive
• might be almost or completely bedridden
• is often stiff or has contracted joints
• is totally dependent on the caregiver
MAXI MOVE must always be handled by a
trained caregiver and in accordance with the
instructions outlined in this manual.
MAXI MOVE is intended to be used with
ArjoHuntleigh slings. Only use slings and
stretchers supplied by ArjoHuntleigh that are
designed to be used with your MAXI MOVE.
MAXI MOVE equipped with optionnal extra low
height caster is not intended to be used on carpet.
NOTE: The need for a second attendant to
support the patient must be assessed in each
individual case.
WARNING:
CAUTION:
NOTE:
WARNING: To avoid injuries that can be
attributed to the use of inadequate parts,
ArjoHuntleigh strongly advises and warns that
only ArjoHuntleigh designated parts should be
used on equipment and other appliances
supplied by ArjoHuntleigh. Unauthorized
modifications on any ArjoHuntleigh equipment
may affect its safety. ArjoHuntleigh will not be
held responsible for any accidents, incidents or
lack of performance that occur as a result of any
unauthorized modification to its products.
General Information

General Information
6
001.25060.EN rev. 11
Conditions
• The unit is cared for and serviced in
accordance with recommended, published
“Instruction for Use” and the “Preventive
Maintenance Schedule”.
• The unit is maintained to the minimum
requirements as published in the “Preventive
Maintenance Schedule”.
• The servicing and product care, in accordance
with ArjoHuntleigh requirements, must begin
on first use of the unit by the customer.
• The equipment must be used for its intended
purpose only and is operated within the
published limitations. Only ArjoHuntleigh
designated spare parts should be used.
Operational Life
• The expected operational life of your
ArjoHuntleigh lift is ten years from the date of
manufacture, providing the following
conditions are adhered to:
• The expected operational life for fabric slings
and fabric stretchers is approximately two
years from date of purchase.
• This life expectancy only applies if the slings
and stretchers have been cleaned, maintained
and inspected in accordance with the
“ArjoHuntleigh Sling Information” documents,
the “Instruction For Use” and the “Preventive
Maintenance Schedule”.
• The expected life for other consumable
products, such as batteries, fuses, lamps, gel
cushions, filters, seal kits, seat inserts,
mattresses, safety belts, padded covers,
straps and cords is dependent upon the care
and usage of the equipment concerned.
Consumables must be maintained in accordance
with published “Instruction for Use” and the
“Preventive Maintenance Schedule”.
Policy on Number of Staff Members
Required for Patient Transfer
ArjoHuntleigh’s passive and active series of lifts
are designed for safe usage with one caregiver.
There are circumstances, such as combativness,
obesity, contracture etc. of the individual that may
dictate the need for a two-person transfer. It is the
responsibility of each facility or medical
professional to determine if a one or two person
transfer is more appropriate, based on the task,
resident load, environment, capability, and skill
level of the staff members.

Safety Instructions
7
001.25060.EN rev. 11
Symbols Used
Fig. 1
General Key to symbol
This symbol is accompanied by a date (to indicate the date of
manufacture) and by the address of the manufacturer.
This symbol indicates that the products comply
with medical device directive 93/42/EEC.
This symbol indicates that the products comply
with medical device directive 93/42/EEC, and that the Technical File has
been reviewed by BSI, accredited notified body in Europe.
This symbol indicates that the products comply
with medical device directive 93/42/EEC, and that the the scale was
initially calibrated under the authorization of the NATIONAL
MEASUREMENT OFFICE, accredited notified body in Europe
This symbol is accompanied by the manufacturer's catalogue number.
This symbol is accompanied by the manufacturer's serial number.
This symbol indicates “separate collection” for all batteries
and accumulators as per the WEEE Directive.
These symbols refer to the Instructions for Use.
This symbol indicates a type BF applied part.
This symbol indicates a risk of pinching.
This symbol represents a weight scale.
This symbol indicates that the scale is a
non-automatic instrument; accuracy class 3.
SWL Safe Working Load represents the maximum
load the lifter is rated for safe operation.
Battery Charger Related Key to symbol
This symbol indicates a class II electrical equipment: term
referring to electrical equipment in which protection against
electric shock does not rely on basic insulation only.
Safety Instructions
0086
0126

Safety Instructions
8
001.25060.EN rev. 11
Before using your MAXI MOVE, familiarize
yourself with the various parts and controls as
shown in Fig. 3, and other illustrations. Then,
read this manual thoroughly in its entirety before
using your MAXI MOVE. Information in the
manual is crucial to the proper operation and
maintenance of the equipment, and will help
protect your product and ensure that the
equipment performs to your satisfaction. Some of
the information in this booklet is important for your
safety and must be read and understood to help
prevent possible injury. If there is anything in the
manual that you find is confusing or difficult to
understand, please contact your local
ArjoHuntleigh agent (the telephone number
appears on the last page of this manual).
Fig. 2
This product has been designed and
manufactured to provide you with trouble-free
use. However, this product does contain
components that are subject to wear with regular
use.
See also “Care of your MAXI MOVE” section.
The MAXI MOVE can be supplied with a variety
of optional attachments, which are not all
described in these instructions. If your
MAXI MOVE has been equipped with an
alternative/optional sub-assembly such as
stretchers, etc., always refer to the separate,
relevant operating instructions supplement, as
well as these instructions, before you operate the
lift.
This product is intended to be operated entirely
by an attendant. The patient should not perform
any function relating to the control of this product.
A second attendant may be required with certain
patients.
Homecare Environment Considerations
CAUTION: Some of these parts are critical to
ensure the safe operation of the lift. They will
need examining and servicing on a regular basis
and must be replaced as needed.
CAUTION: Use only ArjoHuntleigh slings and
stretchers that have been specifically designed
for the MAXI MOVE.
WARNING: Before using the MAXI MOVE, a
clinical assessment of the patient’s suitability for
transfer must be carried out by a qualified health
professional considering that, among other
things, the transfer may induce substantial
pressure on the patient’s body. A transfer
conducted when it should not can degrade the
patient’s health condition.
WARNING: Patients with spasms can be lifted,
but great care should be taken to support the
patient’s legs to prevent fall risk and injuries.
References to “left” or
“right” in these
instructions are as
viewed from the
caregiver’s pushing
position, standing at
the rear of the
MAXI MOVE and
facing forward.
LEFT
RIGHT
WARNING: Do not overload the MAXI MOVE
beyond the approved lifting capacity of the
lowest rated attachment/accessory in order to
avoid patient injury. If the maximum load differs
between floor lift, spreader bar and body support
unit (i.e. sling), then the lowest maximum load
shall always be used.
Take care when manually lifting alternative/
optional components such as stretcher frames,
spreader bars etc., in order to avoid injury.
Do not attempt to manually lift the complete lift.
CAUTION: Although manufactured to a high
standard, the MAXI MOVE and accessories
should not be left in humid or wet areas.
Do not, under any circumstances, spray the
MAXI MOVE or accessories (excluding slings or
ArjoHuntleigh approved wet environment
equipment) with water suchas under the shower.
WARNING: Before lifting a patient it is advisable
to familiarize yourself with and understand the
operation of the various controls and features of
the MAXI MOVE, and to carry out any action
concerning inspection procedures.
WARNING: The MAXI MOVE is not intended to be
operated by children. Serious injuries could
occur.
NOTE: Rigorous cleaning action should be done
when the MAXI MOVE is exposed to an animal.
Pet hair trapped inside the device can reduce the
product performance.
WARNING: This product contains small parts
that might present a severe danger to children if
swallowed or inhaled.

Product Description/Functions
9
001.25060.EN rev. 11
Parts Referred to in this Manual
Fig. 3
1) Mast
2) Mast top cover
3) Maneuvering handle
4) Lift battery pack
5) Braked casters
6) Adjustable chassis legs
7) Medium DPS spreader bar (if included)
8) “Lock and Load” spreader bar carrier system
9) Jib
10)Control panel
11)Control handset
12)Stop button
13)Power button
14)Battery release button
15)Battery charger
16)Two-point loop spreader bar (if included)
17)Loop medium Combi (if included)
18)Four-point loop spreader bar (if included)
19)Small DPS spreader bar (if included)
20)Medium powered DPS spreader bar (if included)
21)Large powered DPS spreader bar (if included)
22)Stretcher frame (if included)
1
2
3
4
5
6
7
8
9
10
12
13
11
15
14
Product Description/Functions

Product Description/Functions
10
001.25060.EN rev. 11
Fig. 4
16
18
22
19
21
17
20
