Stage right ADA 350408 User manual

PRODUCT INFORMATION PACKET
PRODUCT NAME: ADA Ramp

1
Table of Contents
Introduction………………………………………………………………………………………………………………………………………….
General Safety Rules……………………………………………………………………………………………………………………………
Symbols…………………………………………………………………………………………………………………………………………………
Technical Specifications……………………………………………………………………………………………………………………….
Instructions……………………………………………………………………………………………………………………………………………
Maintenance…………………………………………………………………………………………………………………………………………
Customer Service Information…………………………………………………………………………………………………………….
Introduction
The StageRight ADA Ramp has been designed and manufactured with safety, performance and dependability
as top priorities, making it easy to operate and maintain.
The care you give your ADA Ramp will greatly determine your satisfaction with its performance and service life.
Careful study of this manual is encouraged to obtain a thorough understanding of your new ADA Ramp and its
functions and maintenance.
If your manual becomes lost or destroyed, StageRight will gladly provide you with a new copy. Should you
require additional information or assistance, please feel free to contact us at 1-800-438-4499.
BECAUSE STAGERIGHT CORPORATION MAINTAINS AN ONGOING
PROGRAM OF PRODUCT DEVELOPMENT AND IMPROVEMENT, WE
RESERVE THE RIGHT TO MAKE IMPROVEMENTS IN DESIGN OR CHANGES
IN SPECIFICATIONS WITHOUT INCURRING ANY OBLIGATIONS TO INSTALL
THEM ON UNITS PREVIOUSLY SOLD.
1
2
3
4
5
7
7

2
General Safety Rules
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS.
Failure to follow all instructions listed below may result in serious
personal injury.
SAVE THESE INSTRUCTIONS
Stay clear of all pinch points.
Make sure that all fasteners are properly engaged before use. Faspins, button stops, and
jam nuts need to be properly engaged before use.
Make sure that all decks are positioned properly onto the support system.
Save these instructions. Refer to them frequently and use them to instruct others who may use
the ADA Ramp.
Read the Product Information Packet. Failure to read the information packet is considered a
misuse of this equipment.
Become familiar with all caution and warning decals affixed to the support system before
use.
Never cover or deface caution/warning labels.

3
Symbols
Safety Alert: Precautions that involve your safety
Pinch Point Warning Label: Failure to keep hands away from
pinch points will result in personal injury
Read The Operator’s Manual: To reduce risk of injury, user
must read and understand operator’s manual before using this
product

4
StageRight Corporation Technical Specifications
ADA Ramp
PART # DESCRIPTION
350408
350409
350410
350411
350412
350413
350414
0-8” ADA Ramp
0-12” ADA Ramp
0-16” ADA Ramp
0-20” ADA Ramp
0-24” ADA Ramp
0-28” ADA Ramp
0-32” ADA Ramp
Construction, Finish, and Hardware
- Constructed of ASTM specified steel
- Baked-on powder coat finish.
- Zinc-plated hardware
PART # DESCRIPTION
0-36” ADA Ramp
0-40” ADA Ramp
0-48” ADA Ramp
0-56” ADA Ramp
0-64” ADA Ramp
0-72” ADA Ramp
350415
350416
350417
350418
350419
350420

5
Instructions
1
2
To set up your ADA Ramp, begin by unfolding the unit as shown. Setup ramp understructure in
approximate position in which the ramp will be used.
Set deck onto nodes, starting at the lowest section. Insert guardrail into tube. Place (2) faspins per rail
through the leg and guardrail. Repeat this step until all decks and rails are secured to ramp.

6
3
Once all sections are assembled, use Velcro straps to strap the individual sections together, securing the
tallest section to the stage first, and working to the shortest section.
4
To level the decks after they have been placed on the ADA Ramp Supports, simply raise or lower the
adjustable screw feet by threading them in or out. Once the deck has been leveled, go back and tighten
down all of the jam nuts on the screw feet to hold that position.

7
Maintenance
WARNING!
Read and Understand All Maintenance Procedures
Failure to follow all procedures listed below may cause serious injury
and a decrease in the equipments functional existence.
Frequently check to see that all fasteners are properly engaged.
Touch up paint can be used to cover any scratches or blemishes sustained through use.
Replace any damaged equipment with genuine StageRight parts. Failure to do so may result
in unsafe equipment and/or personal injury.
Customer Service
For parts or service contact StageRight Corporation. When ordering parts be sure to provide all relevant
information available including the name and part number of the equipment purchased. This information is
located on the technical specification page of this product information package. Customer Service hours are
Monday thru Friday from 8:00 a.m. to 5:00 p.m. Eastern Standard Time. Customers can phone toll-free at
[phone] or mail:
StageRight Corporation
495 Pioneer Parkway
Clare, Michigan 48617
www.stageright.com
