Service Manual
SERVICE PARTS & DIAGRAMS
This guide is a troubleshooting reference used for maintaining and
servicing your Bend Pak product. It provides comprehensive information
on identifying serviceable parts and components and assists in
troubleshooting problems and performing assembly /disassembly
procedures.
BENDPAK
LR-5T
PRODUCT SKU
5175231
DRAWING Nº
5260184 (Pre-2022)
CATEGORY
Low-Rise Scissor Li
REV
Version A
DATE
09.27.2022

DIMENSIONS ARE IN MM
☺
3
1
10 8
9
75
4
6
11
12
15
14
13
2
16
18
17
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5245046 LR-5T LIFT SUPERSTRUCTURE 1 A
2 5746463 LR-5T SAFETY RELEASE HANDLE ROD 1 A
3 5250074 LR-5T PARTS BOX 1 A
4 5905720 LR-5T WARNING INSTRUCTION 1 -
5 5905204 BENDPAK LABEL 2 -
6 5905135 CAUTION ALI/WL 300CSW 1 -
7 5905465 MANUFACTURER LABEL 1 -
8 5905951
2017_SERIAL_TAG-B-5905951-VERTICAL-NO
BLEED
1 -
9 5905940 PRODUCT DATA LABEL 1 -
10 5905176 WARNING TO PROLONG LIFE 1 -
11 5781005 LR-5T CARRIER BOX 1 A
12 5940003 LR-5T PALLET ASSEMBLY 1 A
13 5940004 LR-5T CARRIER BOX CORNER SUPPORT 2 A
14 5905285 SERIALTAG EXTERIOR PEEL OFF INVENTORY LABEL 1 -
15 5905967 LR-5T_PACKAGING_LABEL 1 -
16 5530107 HHB M14 x 2.0 x 40 4 -
17 5535014 NUT, M14 x2 NL 4 -
18 5545010 WASHER M14 x 28 FLAT 4 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5260173 02/21/2018 TM 00923
B ADDED 5530107, 5535014, 5545010 05/31/2018 TS 00954
SHEET 1 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5260184
LR-5T PRODUCTION LIFT
02/06/2018
DO NOT SCALE DRAWING
1:25
SCALE:
THIRD ANGLE PROJECTION
CA 06/04/2018
SEE ATTACHED LABEL PLACEMENT SHEET 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.

90
318 318
638
578
690
807
1089
SHEET 2 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260184
LR-5T PRODUCTION LIFT
1:12
SCALE:

2162
2124
608
610
SHEET 3 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260184
LR-5T PRODUCTION LIFT
1:15
SCALE:

DIMENSIONS ARE IN MM
☺
2
1
3
4
NEXT ASSEMBLY
5250074
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5620579 LR-5T LIFT PAD BASE WELDMENT 1 C
2 5716187 LR-5T RUBBER LIFT PAD, 100mm 1 C
3 5530022 BPHS M6 x 1 x 20 ZPL 4 -
4 5535357 NUT M6 x 1.0 NL 4 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE 04/16/2013 TM 00597
B
WAS BOLT ON NOW ADHESIVE STICKER,
REMOVED 5545012, 5530002, AND 5535357,
UPDATED BOM REVISIONS
08/14/2013 TM 00616
C
C-001
ADDED (4) 5530022 AND (4) 5535357, UPDATED
BOM REVISIONS
UPDATED NEXT ASSEMBLY
09/18/2015
03/22/2018
JM
TM
00726
00923
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
C
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5215592
LR-5T LIFT PAD BASE
ASSEMBLY, 100mm
04/16/2103
DO NOT SCALE DRAWING
1:4
SCALE:
THIRD ANGLE PROJECTION
CA
4/12/2018
ADHERE RUBBER PAD AFTER PAINTING USING 5580007 ADHESIVE 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
2
1
3
4
NEXT ASSEMBLY
5250074
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5620580 LR-5T LIFT PAD EXTENSION WELDMENT 1 C
2 5716188 LR-5T RUBBER LIFT PAD, 100mm EXTENSION 1 C
3 5530022 BPHS M6 x 1 x 20 ZPL 4 -
4 5535357 NUT M6 x 1.0 NL 4 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE 04/16/2013 TM 00597
B
WAS BOLT ON NOW ADHESIVE STICKER,
REMOVED 5545012, 5530002, AND 5535357,
UPDATED BOM REVISIONS
08/14/2013 TM 00616
C
C-001
ADDED (4) 5530022 AND (4) 5535357, UPDATED
BOM REVISION
UPDATED NEXT ASSEMBLY
09/18/2015
03/22/2018
JM
TM
00726
00923
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
C
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5215593
LR-5T LIFT PAD
EXTENSION
ASSEMBLY, 100mm
04/16/2103
DO NOT SCALE DRAWING
1:3
SCALE:
THIRD ANGLE PROJECTION
CA
4/12/2018
ADHERE RUBBER PAD AFTER PAINTING USING 5580007 ADHESIVE 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
A
B
C
3
1
7
2
8
10
9
11
14
DETAIL A
SCALE 1 : 6
4
5
6
DETAIL B
SCALE 1 : 4
13 17
12
DETAIL C
SCALE 1 : 4
15
16
NEXT ASSEMBLY
5260184
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5601241 LR-5T LIFT WELDMENT 1 A
2 5600754 LR-5T SAFETY BAR WELDMENT 1 B
3 5716185 LR-5T RUBBER PAD, REAR 4 C
4 5746323 LR-5T SAFETY CLEVIS PIN 1 A
5 5540114 C RING 7/8" ID TRUARC 5103-87 4 --
6 5540006 SNAP RING TRUARC 5103-100 2 --
7 5540004 C RING Ø19mm OD DIN M1800 0190 4 --
8 5715107 LR-5T PLASTIC TRAY 4 A
9 5600001 POWER UNIT STAND WELDMENT 1 A
10 5502525 CYLINDER ASSEMBLY Ø2.0 x 17.75 2 D
11 5601052 LR-5T SAFETY LOCKOUT BAR WELDMENT 1 A
12 5737062 LR-5T SAFETY RELEASE CAM 1 A
13 5530341 HHB M10 x 1.5 x 80 1 --
14 5535013 NUT M10 x 1.5 NL 1 --
15 5530100 BHSK M5 x 0.8 x 60 1 A
16 5535142 NUT M5 x 0.8 NL 1 --
17 5535357 NUT M6 x 1.0 NL 1 --
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5245172 02/07/2018 TM 00923
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5245046
LR-5T LIFT
SUPERSTRUCTURE
02/06/2018
DO NOT SCALE DRAWING
1:25
SCALE:
THIRD ANGLE PROJECTION
CA 4/12/2018
ADHERE RUBBER PAD AFTER WELDING AND PAINTING 1.
USING 5580007 ADHESIVE.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
A
B
5
6
4
1
7
8
9
10
11
12
16
17
DETAIL A
SCALE 1 : 4
3
2
DETAIL B
SCALE 1 : 2
13
14
15
NEXT ASSEMBLY
5260184
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5530456 AB 3/4" x 4 - 3/4" 10 -
2 5550103 FTG ELB -04 JIC -06 ORB 1 -
3 5550086 FTG ELB -04 NPT x -04 JIC 2 -
4 5570210 LR-5T HYDRAULIC HOSE ASSEMBLY Ø6.4 x 3777mm DS 1 C
5 5570209 LR-5T HYDRAULIC HOSE ASSY Ø6.4 x 625mm DS 2 E
6 5550310 FTG TEE -04JIC -04JIC -04JIC 1 -
7 5215592 LR-5T LIFT PAD BASE ASSEMBLY, 100mm 4 C
8 5215593 LR-5T LIFT PAD EXTENSION ASSEMBLY, 100mm 4 C
9 5535001 NUT M8 x 1.25 NL 4 -
10 5545012 WASHER, M8x16x1.6mm FLAT 4 -
11 5530304 HHB M8 x 1.25 x 20 4 -
12 5505049 SPRING PIN M6 x 30 2 -
13 5530790 SSS M6 x 1 x 10 NL 1 -
14 5535357 NUT M6 x 1.0 NL 1 -
15 5601242 LR-5T SAFETY RELEASE WELDMENT, FRONT 1 A
16 5715001 PLASTIC SAFETY HANDLE COVER 1 B
17 5900945 LR-5T INSTALLATION MANUAL 1 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5250119 02/21/2018 TM 00923
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5250074
LR-5T PARTS BOX
02/21/2018
DO NOT SCALE DRAWING
1:10
SCALE:
THIRD ANGLE PROJECTION
CA
4/12/2018
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.

PART SPECIFICATION FORM
ACP
BENDPAK Number:
5570129
MRP Description:
¼” HYDRAULIC HOSE 31 CL-0400X
Date:
04/11/2018
ECO :
00939
1. Engineering Specification
Application:
¼” HYDRAULIC HOSE
Detailed Description:
ONE or TWO BRAID STEEL WIRE HYDRAULIC HOSE
SIZE: 1/4” / 6mm I.D. MIN
0.53” / 13.4mm O.D. MAX
SPECS: 5800PSI OR 400 BAR WORKING PRESSURE
17400PSI OR 1200 BAR MINIMUM BURST PRESSURE
3” / 80mm MIN BEND RADIUS
COLOR: BLACK
ADDITIONAL CONTACT INFORMATION:
Xin Yurong
Shandong Ningjin High Energy Hose Co., Ltd.
Tel: [phone]
No. 7, Taishan Rd., Industrial Park, Ningjin County, Shandong, China
Approved Vendor
Vendor Part #
Contact #
AUTHORIZED
COMPONENT PROVIDER
1) Ningjin Hydraulic Hose
Co.
5570129
[phone]
X
2)
OR BENDPAK ENGINEERING APPROVED EQUIVALENT
2. Vendor Information (Or for Reference)

625
1 2
NEXT ASSEMBLY
5250026
5250074
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5570129 Ø6.4 ID HYDRAULIC HOSE 559mm* -
2 5550325 FTG NPL Ø1/4 CRIMP x -04 JIC 2 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
C REPLACED 5570110 WITH 5570129 09/21/2015 JM 00726
D
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLY
03/17/2017 TM 00815
E
E-001
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLY
UPDATED NEXT ASSEMBLY
05/31/2017
03/22/2018
TS
TM
00837
00923
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
TM
5570209
LR-5T HYDRAULIC HOSE
ASSY Ø6.4 x 625mm DS
04/17/2013
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
CA 4/12/2018
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±1.0
0.00 = ±0.25
0.000 = ±0.13
ANGULAR: MACH 2
°
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
(*)ITEM 1 QTY FOR REFERENCE ONLY 2.

3777
1 2
NEXT ASSEMBLY
5250074
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5570129 Ø6.4 ID HYDRAULIC HOSE 3711mm* -
2 5550325 FTG NPL Ø1/4 CRIMP x -04 JIC 2 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5570044 04/17/2013 TM 00597
B REPLACED 5570110 WITH 5517129 09/21/2015 JM 00726
C
C-001
WAS 3700 NOW 3777, UPDATED BOM
UPDATED NEXT ASSEMBLY
10/04/2016
03/22/2018
TS
TM
00781
00923
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
C
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
TM
5570210
LR-5T HYDRAULIC
HOSE ASSEMBLY
Ø6.4 x 3777mm DS
04/17/2013
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
CA 4/12/2018
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±1.0
0.00 = ±0.25
0.000 = ±0.13
ANGULAR: MACH 2
°
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
(*)ITEM 1 QTY FOR REFERENCE ONLY 2.

6
7
4
5
2
1
3
NEXT ASSEMBLY
5245046
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5620624 LR-5T CYLINDER CLEVIS AND SAFETY WELDMENT 1 A
2 5620626 LR-5T BASE WELDMENT, R.H. 1 A
3 5620625 LR-5T BASE WELDMENT, L.H. 1 A
4 5620574 LR-5T HINGE ARM WELDMENT 2 A
5 5620572 LR-5T HINGE ARM SUBWELDMENT 2 A
6 5620575 LR-5T RAMP WELDMENT 1 C
7 5700321 LR-5T HINGE HOLDER 16 B
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE 02/06/2018 TM 00923
SHEET 1 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED.
TM
5601241
LR-5T LIFT WELDMENT
02/06/2018
DO NOT SCALE DRAWING
1:25
SCALE:
THIRD ANGLE PROJECTION
CA 4/12/2018
BREAK AND DEBURR ALL SHARP EDGES 0.3mm 1.
REMOVE ALL WELD SPLATTER 2.
5620572 AND 5620574 MUST SWING FREELY 3.
DIMENSIONS SHOWN ARE AFTER PAINTING 4.
PAINT BENDPAK GRAY (RAL-7024) 5.
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
ANGULAR: 0. =
2
°
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED

4
9
3
13
12
1
11
2
6
8
5
10
7
14
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5620577 02/21/2018 TM 00923
NEXT ASSEMBLY
5601241
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5721027 LR-5T INTERIOR BASE ANGLE L.H. 1 A
2 5721029 LR-5T EXTERIOR BASE ANGLE L.H. 1 A
3 5735486 LR-5T BASE HINGE ARM STOP BAR 2 A
4 5701492 LR-5T BASE SIDE APPROACH RAMP, L.H. 1 A
5 5701256 LR-5T BASE APPROACH RAMP, L.H. 1 A
6 5737061 LR-5T BASE APPROACH RAMP GUSSET 1 A
7 5736671 LR-5T BASE APPROACH RAMP GUSSET, LONG 1 A
8 5737060 LR-5T BASE APPROACH RAMP SUPPORT 2 A
9 5736668 LR-5T BASE APPROACH RAMP SUPPORT, LONG 2 A
10 5736670 LR-5T ANCHOR PLATE 2 A
11 5701498 LR-5T BASE SIDE TROUGH 1 A
12 5735489 LR-5T BASE APPROACH RAMP SPACER 1 A
13 5735648 LR-5T BASE APPROACH RAMP SPACER, SHORT 1 A
14 5737063 LR-5T ANCHOR PLATE, LARGE 1 A
SHEET 1 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED.
TM
5620625
LR-5T BASE WELDMENT, L.H.
02/19/2018
DO NOT SCALE DRAWING
1:15
SCALE:
THIRD ANGLE PROJECTION
CA 4/12/2018
BREAK AND DEBURR ALL SHARP EDGES 0.3mm 1.
REMOVE ALL WELD SPLATTER 2.
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
ANGULAR: 0. =
2
°
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED

4
9
3
13
11
1
12
2
6
8
7
5
10
14
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5620578 02/21/2018 TM 00923
NEXT ASSEMBLY
5601241
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5721030 LR-5T EXTERIOR BASE ANGLE R.H. 1 A
2 5721028 LR-5T INTERIOR BASE ANGLE R.H. 1 A
3 5735486 LR-5T BASE HINGE ARM STOP BAR 2 A
4 5701595 LR-5T BASE SIDE APPROACH RAMP, R.H. 1 A
5 5701257 LR-5T BASE APPROACH RAMP, R.H. 1 A
6 5737061 LR-5T BASE APPROACH RAMP GUSSET 1 A
7 5736671 LR-5T BASE APPROACH RAMP GUSSET, LONG 1 A
8 5737060 LR-5T BASE APPROACH RAMP SUPPORT 2 A
9 5736668 LR-5T BASE APPROACH RAMP SUPPORT, LONG 2 A
10 5736670 LR-5T ANCHOR PLATE 2 A
11 5735489 LR-5T BASE APPROACH RAMP SPACER 1 A
12 5701498 LR-5T BASE SIDE TROUGH 1 A
13 5735648 LR-5T BASE APPROACH RAMP SPACER, SHORT 1 A
14 5737063 LR-5T ANCHOR PLATE, LARGE 1 A
SHEET 1 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED.
TM
5620626
LR-5T BASE WELDMENT, R.H.
02/19/2018
DO NOT SCALE DRAWING
1:15
SCALE:
THIRD ANGLE PROJECTION
CA 4/12/2018
BREAK AND DEBURR ALL SHARP EDGES 0.3mm 1.
REMOVE ALL WELD SPLATTER 2.
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
ANGULAR: 0. =
2
°
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED

PART SPECIFICATION FORM
BENDPAK Number
:
5900945
MRP Description
:
LR-5T INSTALLATION MANUAL
Date: 02/16/2018
ECO :
00910
1. Engineering Specification
Application:
INSTALLATION MANUAL
Detailed Description:
Approved Vendor Vendor Part # Contact # Preferred Vendor
1)
2. Vendor Information

PART SPECIFICATION FORM
BENDPAK Number:
5905135
MRP Description:
CAUTION ALI/WL 300CSW
Date:
12/28/2010
ECO :
00431
1. Engineering Specification
Application:
ALI SCISSOR LIFT STICKER
Detailed Description:
Approved Vendor Vendor Part # Contact # Preferred Vendor
1)
2. Vendor Information

PART SPECIFICATION FORM
BENDPAK Number:
5905176
MRP Description:
WARNING TO PROLONG LIFE
Date:
10/24/2014
ECO :
00654
1. Engineering Specification
Application:
SCISSOR CYLINDER WARNING
Detailed Description:
SIZE: 3” L x 3” W (76mm x 76mm)
Material: White Vinyl Pressure Sensitive Adhesive
Thickness: 4 Mil
Ink: U.V. protected CMYK 2/C Process
Finish: Polished
Print Process: Offset Lithography - 200 line-screen or 300 p.p.i.
for digital
Lamination: Clear-gloss over-laminate for abrasion,
chemical, and ultra violet protection
Approved Vendor
Vendor Part #
Contact #
Preferred Vendor
1)
2. Vendor Information

PART SPECIFICATION FORM
BENDPAK Number:
5905204
MRP Description:
BENDPAK LABEL
Date:
09/16/2015
ECO :
00715
1. Engineering Specification
Application:
BENDPAK LABEL
Detailed Description:
Material: Clear Adhesive PET
Size: 16”W x 3”H
Thickness: 4 Mil
Finish: Polished
Ink: U.V. protected, Opaque White
Print Process: Silk Screen, 85 line-screen (YELLOW color in file represents what should be clear PET material and SHOULD
NOT print as YELLOW ink. White area in file represents Opaque White ink.)
Lamination: Clear-gloss over-laminate for abrasion, chemical, and ultra violet protection
Approved Vendor
Vendor Part #
Contact #
Preferred Vendor
1)
2. Vendor Information

PART SPECIFICATION FORM
BENDPAK Number
:
5905285
MRP Description
:
SERIALTAG EXTERIOR PEEL OFF INVENTORY
LABEL
Date:
04/20/2016
ECO :
00739
1. Engineering Specification
Application:
DATA SERIAL TAG
Detailed Description:
SIZE: 3” L x 3” W (76mm x 76mm)
Approved Vendor Vendor Part # Contact # Preferred Vendor
1)
2. Vendor Information

PART SPECIFICATION FORM
BENDPAK Number:
5905465
MRP Description:
MANUFACTURER LABEL
Date:
05/07/2013
ECO :
00593
1. Engineering Specification
Application:
MANUFACTURER LABEL
Detailed Description:
SIZE: 5.125” L x 5.125” W (130mm x 130mm)
Approved Vendor Vendor Part # Contact # Preferred Vendor
1)
2. Vendor Information
