Stamina Active Aging EasyRow User manual

CAUTION:
Weight on this product should not exceed 300 lbs.
Owner's
Manual
Product May Vary Slightly From Pictured.
Exercise can present a
health risk. Consult a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
discontinue use of this
equipment. Serious bodily
injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
!WARNING
STAMINA PRODUCTS
MADE IN CHINA
© 2020 Stamina Products, Inc.
2020, 01
When calling for parts or
service, please specify
the following numbers:
Model#: 35-1315
S/N: _____________
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springeld, MO 65803
Customer Care
1 [phone]
www.staminaproducts.com

EasyRow

3
TABLE OF CONTENTS
SAFETY INSTRUCTIONS
1. Save these instructions and ensure that other exercisers read this manual prior to using the Stamina®
Active Aging EasyRow for the rst time.
2. Read all warnings and cautions posted on the Stamina® Active Aging EasyRow.
3. The Stamina® Active Aging EasyRow should only be used after a thorough review of the Owner’s
Manual.
Make sure that it is properly assembled and tightened before use.
4. We recommend that two people be available for assembly of this product.
5. Keep children away from the Stamina® Active Aging EasyRow. Do not allow children to use or play
on the Stamina® Active Aging EasyRow. Keep children and pets away from the Stamina® Active
Aging EasyRow when it is in use.
6. It is recommended that you place this exercise equipment on an equipment mat.
7. Set up and operate the Stamina® Active Aging EasyRow on a solid level surface. Do not position the
Stamina® Active Aging EasyRow on loose rugs or uneven surfaces.
8. Make sure that adequate space is available for access to and around the Stamina® Active Aging
EasyRow.
9. Before using, inspect the Stamina® Active Aging EasyRow for worn or loose components, and
securely tighten or replace any worn or loose components prior to use.
10. Shock on rower get HOT during use. To avoid burns, do not touch the shock until it has time to
cool.
11. Consult a physician prior to commencing an exercise program and follow his/her recommendations in
developing your tness program. If at any time during exercise you feel faint, dizzy, or experience pain,
stop and consult your physician.
12. Always choose the workout which best ts your physical strength and exibility level. Know your limits
and train within them. Always use common sense when exercising.
13. Do not wear loose or dangling clothing while using the Stamina® Active Aging EasyRow.
14. Never exercise in bare feet or socks; always wear proper footwear such as running, walking, or cross
training shoes that t well, provide foot support, and feature non-skid rubber soles.
15. Be careful to maintain your balance while using, mounting, dismounting, or assembling the Stamina®
Active Aging EasyRow, loss of balance may result in a fall and bodily injury.
16. Do not use the SEAT(46) to move the Stamina® Active Aging EasyRow.The SEAT(46) will move
and the SEAT CARRIAGE(42) may pinch your hand or ngers.
17. The Stamina® Active Aging EasyRow should not be used by persons weighing over 300 pounds.
18. The Stamina® Active Aging EasyRow should be used by only one person at a time.
19. The Stamina® Active Aging EasyRow is for consumer use only. It is not for use in public or
semipublic facilities.
!WARNING Cancer and Reproductive Harm www.P65Warnings.ca.gov
Consult your physician before starting this or any exercise program. This is
especially important if you are over the age of 35, have never exercised before,
are pregnant, or su󰀨er from any health problem. This product is for home use
only. Do not use in institutional or commercial applications. Failure to follow all
warnings and instructions could result in serious injury or death.
To reduce the risk of serious injury, read the following Safety Instructions
before using the
Stamina® Active Aging EasyRow .
!WARNING
!WARNING
Safety Instructions ...................................... 3
Before You Begin ........................................ 5
Equipment Warning, Caution & Notice Labels ... 6
Hardware Identication Chart .................... 7
Assembly Instructions ................................ 8
Operational Instructions ........................... 12
Storage ....................................................... 14
Maintenance ............................................... 14
Conditioning Guidelines ........................... 15
Warm-Up and Cool-Down ......................... 16
Warranty ..................................................... 17
Product Parts Drawing .............................. 18
Parts List .................................................... 19
Notes ........................................................... 21
Fax/Mail Ordering Form ............................ 22

NEED HELP?
CONTACT US FIRST
1 [phone]
[e-mail]
Hi! From all of us here at Stamina Products, thank you for your purchase. We
know that you have big fitness goals in mind and we are here to help you along.
Call us, email us, or send us a message on Facebook. Be sure to contact us if you
have any questions on your new product. We look forward to hearing from you!
With your body in mind,
Stamina Customer Care
To enact your extended warranty and to help us better
serve you, please go onlineand register your new product.
register.staminaproducts.com
ONLINE
[e-mail]
www.staminaproducts.com
TELEPHONE
1 [phone]
FAX
[phone]
MAIL
Stamina Products, Inc.
ATTN: Customer Care
2040 N Alliance Ave
Springfield, MO 65803
facebook.com/StaminaProducts
facebook.com/AeroPilates
CUSTOMER CARE HOURS:
Monday-Thursday, 7:30 AM-5:00 PM, Central Time
Friday, 8:00 AM-3:00 PM, Central Time
It is quick and easy to register online, but if you’re a little old school or just need a
reason to raise that little flag on your mailbox, fill out the info on the last page of this
manual and mail it in.

BEFORE YOU BEGIN
5
Rear Frame
Leveling
Endcap
Seat
Pedal
Handlebar
Foam Pad
Caution Label
Meter
Pedal
Pedal Strap
Pivoting Arm
Seat Frame
Pedal Strap
Rear Stabilizer
Seat Carriage
Wheel Endcap
Front Frame
Thank you for choosing the Stamina® Active
Aging EasyRow. We take great pride in this
quality product and hope it will provide many hours
of quality exercise to make you feel better, look
better, and enjoy life to its fullest.
It's a proven fact that a regular exercise program
can improve your physical and mental health.
Too often, our busy lifestyles limit our time and
opportunity to exercise. The Stamina® Active
Aging EasyRow provides a convenient and simple
method to begin your journey of getting your body
in shape and achieving a happier and healthier
lifestyle.
Before reading further, please review the
drawing below and familiarize yourself with the
parts that are labeled. Locate the serial decal on
the product and write the serial number on the
cover of the manual in the space provided. See
page 6 for an image of the serial decal. Model
number and serial number are required when
calling for assistance.
Read this manual carefully before using the
Stamina® Active Aging EasyRow.
Providing you with a quality product is Stamina's
top priority. However, sometimes there could be a
missing or incorrectly sized part. If you have any
questions or problems with the parts included with
your Stamina® Active Aging EasyRow, please
do not return the product. Contact us FIRST!
If a part is missing or defective, please contact
Customer Care for assistance. Call us toll free
at 1-800-375-7520 (in the U.S.) or live chat on
staminaproducts.com. Our Customer Care Sta󰀨 is
available to assist you from 7:30 A.M. to 5:00 P.M.
(Central Time) Monday through Thursday and 8:00
A.M. to 3:00 P.M. (Central Time) on Friday.
Be sure to have the name and model number of
the product available when you contact us.
Allen Wrench (4mm)
Wrench
Allen Wrench (6mm) (2 Pieces)
THE FOLLOWING TOOLS ARE INCLUDED FOR ASSEMBLY:
Front Stabilizer
Serial Decal
Front Stabilizer
Shock

6
This chart is provided to help identify the warning, caution, and notice labels on the Stamina® Active
Aging EasyRow. Please take a moment to familiarize yourself with all of the warning, caution, and
notice labels.
EQUIPMENT WARNING, CAUTION & NOTICE LABELS
CAUTION LABEL(54)
To best serve you, our Customer Care Representatives will
need your serial number. For quick access, write in your
serial number on the cover of the manual.
SERIAL DECAL(55)

Part Number and Description Qty
7
24 Washer (M8) 4
27 Washer (M10) 2
3 Bolt, Button Head (M6 x 1 x 13mm) 6
9 Bolt, Button Head (M8 x 1.25 x 16mm) 4
length
length
mm.
in.
INCHES
This chart is provided to help identify the fasteners used in the assembly process. Place the washers or
the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to
check the length of the bolts and screws.
NOTICE: The length of all bolts and screws, except those with flat
heads, is measured from below the head to the end of the bolt
or screw. Flat head bolts and screws are measured from the
top of the head to the end of the bolt or screw.
After unpacking the unit, open the hardware bag and make sure that you have all the following
fasteners. Some fasteners may be already attached to the parts.
MILLIMETERS
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1/2 1 1/2 2 1/2 3 1/2 4 1/2 5 1/2 6
6 8 10 12
3/16" 1/4" 5/16" 3/8" 1/2"
HARDWARE IDENTIFICATION CHART
17 Arc Washer (M10) 4
25 Bolt, Button Head (M10 x 1.5 x 120mm) 2
26 Bolt, Button Head (M10 x 1.5 x 135mm) 1
34 Bolt, Button Head (M8 x 1.25 x 90mm) 2
15 Carriage Bolt (M10 x 1.5 x 70mm) 4
18 Acorn Nut (M10) 4
30 Nylock Nut (M10 x 1.5) 1
35 Nylock Nut (M8 x 1.25) 3
33 Bolt, Button Head w/ Washers (M8x1.25x16mm) 2
36 Bolt, Button Head (M8 x 1.25 x 39mm) 1
43 Bolt, Button Head (M8 x 1.25 x 30mm) 2

8
STEP 1
Position the wheels in the WHEEL ENDCAPS(14) to face to the front, then attach the FRONT
STABILIZER(13) to the FRONT FRAME(19) with CARRIAGE BOLTS(M10x1.5x70mm)(15), ARC
WASHERS(M10)(17), and ACORN NUTS(M10)(18).
STEP 2
Attach the REAR FRAME(32) to the FRONT FRAME(19) with BUTTON HEAD BOLTS w/ WASHERS
(M8x1.25x16mm)(33), BUTTON HEAD BOLTS(M8x1.25x90mm)(34), WASHERS(M8)(24), and
NYLOCK NUTS(M8)(35).
STEP 3
Attach the REAR STABILIZER(39) to the REAR FRAME(32) with CARRIAGE BOLTS(M10x1.5x70mm)
(15), ARC WASHERS(M10)(17), and ACORN NUTS(M10)(18). Turn the LEVELING ENDCAPS(40) on
the REAR STABILIZER(39) as needed until the rower is steady and not rocking.
ASSEMBLY INSTRUCTIONS
Place all parts from the box in a cleared area and position them on the oor in front of you. Remove
all packing materials from your area and place them back into the box. Do not dispose of the packing
materials until assembly is completed. Read each step carefully before beginning. If you are missing
a part, please go to staminaproducts.com under the Customer Care section and order the part
needed, e-mail us at customer[email protected], or call us toll free at 1-800-375-7520
(in the U.S.). Our Customer Care Sta󰀨 is available to assist you from 7:30 A.M. to 5:00 P.M. (Central
Time) Monday through Thursday and 8:00 A.M. to 3:00 P.M. (Central Time) on Friday.
Some product parts are t tested at the factory to ensure proper t and alignment. Marks in
the paint may be noticeable, but are not an indication of damage.
17
18
17
18
39
15
40
40
33
34
24
35
14
14
15
17 18
13
17 18
19
32
FRONT
BACK

ASSEMBLY INSTRUCTIONS
9
10
19
26
27
27
30
12
35
36
10
A.
STEP 4
Place the PIVOTING ARM(10) into the FRONT FRAME(19) and secure with BUTTON HEAD BOLT
(M10x1.5x135mm)(26), WASHERS(M10)(27), and NYLOCK NUT(M10)(30).
STEP 5
Refer to illustration A. Attach the SHOCK(12) to the U bracket on the Pivoting Arm(10) with BUTTON
HEAD BOLT(M8x1.25x39mm)(36) and NYLOCK NUT(M8)(35).

ASSEMBLY INSTRUCTIONS
10
STEP 6
Screw the BUTTON HEAD BOLTS(M10x1.5x120mm)(25) into both sides of the FRONT FRAME(19).
Insert the PEDAL SHAFT(21) through hole on the FRONT FRAME(19). Place a PEDAL(22) onto each end
of the PEDAL SHAFT(21) and slide them toward the FRONT FRAME(19). Then secure the PEDALS(22)
with BUTTON HEAD BOLTS(M8x1.25x16mm)(9) and WASHERS(M8)(24) at both ends of the PEDAL
SHAFT(21). You need to use two Allen Wrenches to tighten the BUTTON HEAD BOLTS(M8x1.25x16mm)
(9) at both ends of the PEDAL SHAFT(21) at the same time.
STEP 7
Insert the HANDLEBAR CONNECTOR(8) through the hole on the top of the PIVOTING ARM(10). Attach
the HANDLEBARS(5) to both ends of the HANDLEBAR CONNECTOR(8) with BUTTON HEAD BOLTS
(M8x1.25x16mm)(9).
STEP 8
Attach the METER BRACKET(2) to the PIVOTING ARM(10) with BUTTON HEAD BOLTS(M6x1x13mm)
(3). Install two AAA batteries into the METER(1), the batteries are not included. See page 13 for detailed
battery installation instructions. Insert the METER(1) onto the METER BRACKET(2).
1
2
3
10
19
23
22
25
21
23 24
9
25
22
24
9
9
8
5
5
9

ASSEMBLY INSTRUCTIONS
STEP 9
Attach the SEAT FRAME(41) to the SEAT CARRIAGE(42) with BUTTON HEAD BOLTS(M8x1.25x30mm)
(43).
STEP 10
Attach the SEAT(46) to the SEAT FRAME(41) with BUTTON HEAD BOLTS(M6x1x13mm)(3). Press the
FOAM PADS(44) onto both sides of the SEAT FRAME(41).
11
46
44
43
41
3
44
42

OPERATIONAL INSTRUCTIONS
12
In the STOP mode, press to set target values. Press the
button and hold it down for three seconds, the meter
will continue to add the values even without pressing
the SET button. Press any button to stop.
USING THE FITNESS METER
POWER OFF: Automatically shuts off after 4 minutes of
inactivity.
POWER ON:
FUNCTIONS:
FUNCTION BUTTONS :
MODE : In the STOP mode, press and release to select each
function for preset target values for TIME, COUNT, and
CALORIES.
Press and release to select functions for display for
TIME, COUNT, TOTAL COUNT, RPM, and CALORIES.
In the STOP mode, press the button to reset the setting values to zero.
Press the button and hold it down for three seconds to reset all functions to zero.
RESET :
Move the handlebar or press any button.
PRESET VALUES OPERATION:
You can pull on the HANDLEBARS(5) to power on the meter and workout with the meter directly. Or, you
can preset the function values for counting down. Press the MODE button to make the SCAN function stop
working. Stop rowing for four seconds, the meter will enter the STOP mode. The meter will go through the
input items as follows and allow you to set the function values. Use the SET and RESET buttons to input
the values, and press the MODE button to conrm. Or, just press the MODE button to skip the setting and
move on to the next function. After all the desired settings are chosen, begin pulling on the HANDLEBARS(5)
to start the workout.
Time (1:00 to 99:00) Count (10 to 9999 rows) Calories (1.0 to 999 Kcal)
NOTE:
1. You may preset values for several functions. The preset function values will start to count down. When
you complete one of the preset functions, then the value of this completed function will start to count
up, while the other preset functions will continue to count down.
2. The Meter will shut o󰀨 automatically after 4 minutes of inactivity. All function values will be kept. You
can continue to workout with these function values, or press the RESET button and hold it down for
three seconds to reset all functions to zero.
SET :
Automatically scans each function of TIME, COUNT, TOTAL COUNT, RPM,and
CALORIES in sequence changing every six seconds. Press and release the MODE
button until the arrow appears on the display and points to the SCAN.
Displays the time from 1 sec. up to 99:59 minutes. Counts down from preset value.
Displays the total number of rows you have taken from zero to 9999 rows. Counts down
from preset value.
Displays the total accumulated number of rows you have taken, from zero to 9999 rows.
The TOTAL COUNT value is retained when the meter is turned o󰀨, until the batteries
are removed.
Displays the rowing speed from zero to 9999 strokes per minute.
Displays the calories burned from zero to 999.9 Kcal. Counts down from preset value.
The calorie readout is an estimate for an average user. It should be used only as a
comparison between workouts on this unit.
SCAN:
TIME:
COUNT:
TOTAL COUNT :
RPM:
CALORIES:
TIME
COUNT
T.COUNT
CALORIES
RPM
SCAN
SET
MODE
RESET

OPERATIONAL INSTRUCTIONS
AAA Batteries
HOW TO INSTALL AND REPLACE BATTERIES:
1. Open the Battery Door on the back of the meter.
2. The meter operates with two AAA batteries (1.5V each), the
batteries are not included. Refer to the illustration to install or
replace the batteries.
1. Do not mix a new battery with an old battery.
2. Use the same type of battery. Do not mix an alkaline
battery with another type of battery.
3. Rechargeable batteries are not recommended.
4. Ultimate disposal of battery should be handled
according to all state and federal laws and regulations.
5. Do not dispose of batteries in re.
NOTE:
LOAD ADJUSTMENT
The resistance of the shock can be adjusted by twisting the adjustment
knob at the top of the shock. There are settings from 1 to 12. Setting #1
will provide the lowest resistance. Setting #12 will provide the highest
resistance.
CAUTION: The shock gets HOT after a few minutes of use.
Adjustment
Knob
Mark
13

14
1. To store the
Stamina® Active Aging EasyRow ,simply keep it in a clean dry place.
2. Move the
Stamina® Active Aging EasyRow
with the wheels in the WHEEL ENDCAPS(14) on the
FRONT STABILIZER(13). Lift the REAR STABILIZER(39) to move the
Stamina® Active Aging
EasyRow
.Do not use the SEAT(46) to move the Stamina® Active Aging EasyRow .The SEAT(46)
will move and the SEAT CARRIAGE(42) may pinch your hand or ngers.
3. To avoid damage to the meter, remove the batteries before storing the Stamina® Active Aging
EasyRow
for one year or more.
The safety and integrity designed into the
Stamina® Active Aging EasyRow
can only be maintained
when the
Stamina® Active Aging EasyRow
is regularly examined for damage and wear. Special
attention should be given to the following:
MAINTENANCE
STORAGE
1. Pull on the HANDLEBARS(5) and verify that the SHOCK(12) provides tension and the seat travel is
smooth and stable.
2. Clean the roller track on the rail in the REAR FRAME(32) with an absorbent cloth.
3. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts.
Tighten loose nuts and bolts.
4. Verify that the CAUTION LABEL(54) is in place and easy to read. Call Stamina Products immediately
at 1-800-375-7520 for a replacement CAUTION LABEL(54) if it is missing or damaged.
5. It is the sole responsibility of the user/owner to ensure that regular maintenance is performed.
6. Worn or damaged components must be replaced immediately or the
Stamina® Active Aging
EasyRow
removed from service until repair is made.
7. Only Stamina Products supplied components should be used to maintain/repair the
Stamina® Active
Aging EasyRow .
8. Keep your Stamina® Active Aging EasyRow clean by wiping it o󰀨 with an absorbent cloth after use.

15
How you begin your exercise program depends on your physical condition. If you have been inactive for
several years or are severely overweight, start slowly and increase your workout time gradually. Increase
your workout intensity gradually by monitoring your heart rate while you exercise.
Initially you may only be able to exercise within your target zone for a few minutes; however, your aerobic
capacity will improve over the next six to eight weeks. It is important to pace yourself while you exercise
so you don't tire too quickly.
Measure your heart rate periodically during your workout by stopping the
exercise but continuing to move your legs or walk around. Place two or
three ngers on your wrist and take a six second heartbeat count. Multiply
the results by ten to nd your heart rate. For example, if your six second
heartbeat count is 14, your heart rate is 140 beats per minute. A six second
count is used because your heart rate will drop rapidly when you stop
exercising. Adjust the intensity of your exercise until your heart rate is at the
proper level.
wrist pulse
Remember to follow these essentials:
Have your doctor review your training and diet programs.
Begin your training program slowly with realistic goals that have been set by you and your physician.
Warm up before you exercise and cool down after you work out.
Take your pulse periodically during your workout and strive to stay within a range of 60% (lower
intensity) to 90% (higher intensity) of your maximum heart rate zone. Start at the lower intensity, and
build up to higher intensity as you become more aerobically t.
If you feel dizzy or lightheaded you should slow down or stop exercising.
To determine if you are working out at the correct intensity, use a heart rate monitor or use the table
below. For effective aerobic exercise, your heart rate should be maintained at a level between 60%
and 90% of your maximum heart rate. If just starting an exercise program, work out at the low end of
your target heart rate zone. As your aerobic capacity improves, gradually increase the intensity of your
workout by increasing your heart rate.
CONDITIONING GUIDELINES
Target Heart Rate Zone Estimated by Age*
* For cardiorespiratory training benefits, the American College of Sports Medicine recommends
working out within a heart rate range of 55% to 90% of maximum heart rate. To predict the
maximum heart rate, the following formula was used: 220 - Age = predicted maximum heart rate
20 years
25 years
30 years
35 years
40 years
45 years
50 years
55 years
60 years
65 years
70 years
Average Maximum
Heart Rate 100%
Age
110-180 beats per minute
107-175 beats per minute
105-171 beats per minute
102-166 beats per minute
99-162 beats per minute
97-157 beats per minute
94-153 beats per minute
91-148 beats per minute
88-144 beats per minute
85-139 beats per minute
83-135 beats per minute
200 beats per minute
195 beats per minute
190 beats per minute
185 beats per minute
180 beats per minute
175 beats per minute
170 beats per minute
165 beats per minute
160 beats per minute
155 beats per minute
150 beats per minute
Target Heart Rate Zone
(55%-90% of Maximum Heart Rate)

16
WARM-UP and COOL-DOWN
Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries.
Warm up for two to ve minutes before strength training or aerobic exercising. Perform activities that
raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging,
jumping jacks, jump rope, and running in place.
Stretching Stretching while your muscles are warm after a proper warm-up and again after your
strength or aerobic training session is very important. Muscles stretch more easily at these times
because of their elevated temperature, which greatly reduces the risk of injury. Stretches should be held
for 15 to 30 seconds. Do not bounce.
Suggested Stretching Exercises
Remember to always check with your physician before starting any exercise program.
Cool-Down The purpose of cooling down is to return the body to its normal, or near normal, resting
state at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows
blood to return to the heart. Your cool-down should include the stretches listed above and should be
completed after each strength training session.
Lower Body Stretch
Place feet shoulder-width
apart and lean forward.
Keep this position for 30
seconds using the body as a
natural weight to stretch the
backs of the legs.
DO NOT BOUNCE!
When the pull on the back of
the legs lessens, gradually
try a lower position.
Floor Stretch
While sitting on the oor,
open the legs as wide as
possible. Stretch the upper
body toward the knee on the
right leg by using your arms
to pull your chest to your
thighs. Hold this stretch 10
to 30 seconds.
DO NOT BOUNCE!
Do this stretch 10 times.
Repeat the stretch with the
left leg.
Bent Over Leg Stretch
Stand with feet shoulder-
width apart and lean forward
as illustrated. Using the
arms, gently pull the upper
body towards the right leg.
Let the head hang down.
DO NOT BOUNCE!
Hold the position a minimum
of 10 seconds. Repeat
pulling the upper body to
the left leg. Do this stretch
several times slowly.
Bent Torso Pulls
While sitting on the oor,
have legs apart, one leg
straight and one knee bent.
Pull the chest down to touch
the thigh on the leg that is
bent, and twist at the waist.
Hold this position at least 10
seconds. Repeat 10 times
on each side.

LIMITED WARRANTY
MODEL 35-1315
17
WARRANTY
Stamina Products, Inc. (“Stamina”) warrants to the original purchaser that this product will be free from
defects in materials and workmanship that arise under normal use, service, proper assembly and proper
operation in accordance with product warnings/instructions for a period of 90 days on the parts and three
years on the frame from the date of the original purchase from an authorized retailer. THIS WARRANTY
SHALL NOT APPLY TO ANY PRODUCT WHICH HAS BEEN SUBJECT TO COMMERCIAL USE,
ABUSE, MISUSE, ALTERATION OF ANY KIND OR TO ANY DEFECT OR CHANGE CAUSED BY
IMPROPER ASSEMBLY, REPAIR, REPLACEMENT, SUBSTITUTION OR USE WITH PARTS NOT
PROVIDED BY STAMINA. Commercial use includes use of product in athletic clubs, health clubs, spas,
gyms, and all other public or semipublic facilities whether or not the product’s use is in furtherance of a
prot making enterprise, and all other use which is not for personal purposes.
To implement this limited warranty, send a written notice stating your name, date, and place of purchase
and a brief description of the defect along with your receipt to Stamina Products, Inc. 2040 N Alliance
Ave, Springeld, Missouri, USA, MO 65803, or email us at customer[email protected], or call
us at 1-800-375-7520. If the defect is covered under this limited warranty, you will be requested to return
the product or part to us for free repair or replacement at our option.
NO ACTION FOR BREACH OF THIS LIMITED WARRANTY MAY BE COMMENCED MORE
THAN ONE (1) YEAR AFTER THE DATE THE ALLEGED BREACH WAS OR SHOULD HAVE
BEEN DISCOVERED. NO ACTION FOR BREACH OF ANY IMPLIED WARRANTY (INCLUDING
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE) MAY BE COMMENCED
MORE THAN ONE (1) YEAR AFTER DELIVERY OF THE PRODUCT TO THE PURCHASER. These
warranties are not transferable. IF ANY PART OF THE PRODUCT IS NOT IN COMPLIANCE
WITH THIS LIMITED WARRANTY OR ANY IMPLIED WARRANTY, THE REMEDY OF REPAIR OR
REPLACEMENT IS THE EXCLUSIVE REMEDY. If any claim is made under this limited warranty or any
implied warranty, Stamina reserves the right to require the product to be returned for inspection, at the
purchaser’s expense, to Stamina’s premises in Springeld, Missouri. Return of the enclosed warranty
registration card is not required for warranty coverage, but is merely a way of establishing the date and
place of purchase.
Stamina SHALL NOT BE LIABLE FOR THE LOSS OF USE OF ANY PRODUCT, LOSS OF TIME,
INCONVENIENCE, COMMERCIAL LOSS OR ANY OTHER INDIRECT, CONSEQUENTIAL, SPECIAL
OR INCIDENTAL DAMAGES DUE TO BREACH OF THE ABOVE WARRANTY OR ANY IMPLIED
WARRANTY.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS WARRANTY. NO ORAL OR WRITTEN
INFORMATION GIVEN BY STAMINA, ITS AGENTS OR EMPLOYEES, SHALL CREATE A WARRANTY
OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY. This warranty gives you specic legal
rights, and you may also have other legal rights which vary from state to state. ANY OTHER RIGHT
WHICH YOU MAY HAVE, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
The laws in some states a󰀨ect the disclaimer or limitation of implied warranties and consequential and
incidental damages. If any such law is found applicable, the foregoing disclaimers and limitations of and
on implied warranties and consequential and incidental damages shall be deemed to be modied to the
extent necessary to comply with applicable law.

1
2
3
10
9
4
8
6
5
7
4
5
6
7
14
14
15
16
16
54
17
18
11
20
19
23
22
24
9
25
26
27
28
29
28
27
30
21 23
24
9
25
35
36
12
34
33
24
35
31
31
32
37 38
46
44
7
45
43
41
3
44
7
53 42
47
35
51
52
51
48
49
50
17
17
18
18
39 40
40
15
35
36
11
11
13
55
22
51
52
51
35
51
52
51
48
49
50
15
PRODUCT PARTS DRAWING
18
FRONT
BACK

PARTS LIST
19
PART# PART NAME QTY
1 Meter 1
2 Meter Bracket 1
3 Bolt, Button Head (M6 x 1 x 13mm) 6
4 Handlebar Bushing 2
5 Handlebar 2
6 Foam Grip (ø23 x ø33 x 205mm) 2
7 Round Plug (25mm) 4
8 Handlebar Connector 1
9 Bolt, Button Head (M8 x 1.25 x 16mm) 4
10 Pivoting Arm 1
11 Rectangular Plug (20mm x 40mm) 6
12 Shock 1
13 Front Stabilizer 1
14 Wheel Endcap (ø60mm) 2
15 Carriage Bolt (M10 x 1.5 x 70mm) 4
16 Screw, Round Head (M4 x 10mm) 2
17 Arc Washer (M10) 4
18 Acorn Nut (M10 x 1.5) 4
19 Front Frame 1
20 Bumper 1
21 Pedal Shaft 1
22 Pedal 2
23 Pedal Strap 2
24 Washer (M8) 4
25 Bolt, Button Head (M10 x 1.5 x 120mm) 2
26 Bolt, Button Head (M10 x 1.5 x 135mm) 1
27 Washer (M10) 2
28 Pivoting Bushing 2
29 Frame Bushing 2
30 Nylock Nut (M10 x 1.5) 1
31 Rectangular Plug (40mm x 80mm) 2
32 Rear Frame 1
33 Bolt, Button Head w/ Washers (M8 x 1.25 x 16mm) 2
34 Bolt, Button Head (M8 x 1.25 x 90mm) 2
35 Nylock Nut (M8 x 1.25) 7
36 Bolt, Button Head (M8 x 1.25 x 39mm) 2
37 Seat Bumper 1
38 Bolt, Round Head (M6 x 1 x 15mm) 1
39 Rear Stabilizer 1
40 Leveling Endcap (ø60mm) 2
41 Seat Frame 1
42 Seat Carriage 1
43 Bolt, Button Head (M8 x 1.25 x 30mm) 2
44 Foam Pad 2
45 Rectangular Plug (20mm x 40mm) 1
46 Seat 1
47 Bolt, Button Head (M8 x 1.25 x 118mm) 1

PARTS LIST
20
PART# PART NAME QTY
48 Eye Bolt (M6 x 1 X 55MM) 2
49 Tension Bracket 2
50 Nylock Nut (M6 x 1) 2
51 Ball Bearing (608ZZ) 6
52 Roller 3
53 Bolt, Button Head (M8 x 1.25 x 110mm) 2
54 Caution Label 1
55 Serial Decal 1
56 Allen Wrench (6mm) 2
57 Allen Wrench (4mm) 1
58 Wrench 1
59 Manual 1
