Standart SDS-UL Installation instructions

SDS - UL/FM
Instruction for
Operation and Maintenance
Double Suction Split Case Centrifugal Fire Pumps

05.2019
Revision 1
Instructions for Installation, Operation and Maintenance
Standart Pompa ve Makina San. Tic. A.Ş.
All rights reserved. Can not be copied or reproduced for any purpose without permission.
Subject in the manual can be changed without any prior notice.

Contents
1. GENERAL
1.1 Safety Signs
1.2 General Instructions
1.3 Safety Instructions
1.3.1 CE signs and approvals
1.3.2 Personnel qualification and training
1.4 Recycling
2. GENERAL PUMP DESCRIPTION
2.1 Pump Description
2.2 Application Areas
2.3 Pump Designation
2.4 Pump Nameplate
2.5 Technical Information
3. UNPACKING, HANDLING and STRAGE
3.1 Unpacking
3.2 Handling
3.2.1 General warnings
3.2.2 Lifting operation
3.3 Storage
4. INSTALLATION SITE
4.1 Bare Shaft Pump
4.2 Preparation for Installation
4.3 Installation Site
4.3.1 General characteristics of the pump foundation (baseplate)
4.3.2 Placement of the Pump Group
4.4 Installation of the Piping System
4.4.1 General Warning
4.4.2 Suction Pipe
4.4.3 Delivery Pipe
4.4.4 Auxiliary pipe connections and accessories
4.5 Coupling Adjustment
4.6 Electrical Connections
4.7 Final Controls
01
01
01
01
02
02
02
03
03
03
03
03
03
04
04
04
04
04
05
05
05
05
05
06
06
07
07
09
09
09
10
11
12

Contents
13
13
13
13
13
13
14
14
14
15
15
15
15
16
16
16
17
18
19
20
20
5. START UP / SHUT DOWN
5.1 Preparation
5.1.1 Lubrication Control
5.1.2 Venting and priming
5.1.3 Checking the direction of rotation
5.2 Start Up The Pump
5.3 Checks to be Made While The Pump is Running
6. LUBRICATION
6.1 Application of Grease on the Bearing
7. DISASEMBLY AND REASSEMBLY
7.1 Disassembly
7.2 Reassembly
7.3 Tightening Torques
7.4 Shaft Seal
7.4.1 Pump with soft packing gland
8. SPARE PART
9. FAULTS, CAUSES AND REMEDIES
10. EXPECTED NOISE VALUES
11. SECTIONAL DRAWING
12. PART LIST
13. COUPLING GUARD AND SAFETY GUARD

01
General Risk
Signifies safety precautions which if not applied may cause vital.
Electrical Risk
Warnings about the electrical current
Warning
Safety instructions that if not applied may cause damage to the machine or operation.
This manual should be made available at a safety place easily accessible by personnel
responsible for safe operation and maintenance of the pump the qualified
1. GENERAL
The objective of this manual is to:
• Instruct the users on installation, dismounting, maintenance and repair of the pump, and
• Describe methods of start-up, operation and stop of the pump.
1.1 Safety Signs
1.2 General Instructions
• The authorized personnel should be experienced and well - informed about the related standards.
• The instructions given in this manual should be carefully read and applied at any phase of the
installation and operating process of the pump.
• The user is responsible to ensure that the inspection and installation are performed by the
authorized and qualified personnel, who read this manual thoroughly.
• The pump should never be operated beyond the operating conditions set forth in the purchase
order. The reason is that the operating conditions set forth in the purchase order have been taken
into consideration in the selection of the pump material and trial of the pump.
• If the pump is required to be operated apart from the conditions set forth in the purchase order,
please contact with STANDART POMPA. Standart Pompa does not assume any responsibility for
any damages that may arise from operation of the pump beyond the specified conditions without
written consent.
• If the pump will not be installed at its place immediately after delivery, it should be stored at a
clean and dry place where the ambient temperature does not change excessively. If the proper pre
cautions are not taken, excessively low or high temperatures may cause serious damages to the
pump.
•
Standart Pompa does not accept any responsibility under warranty for any repair or replacement
performed by the user or any other unauthorized persons.
• This manual does not include safety rules applicable at the place of use.
1.3 Safety Instructions
• Operate the pump only under the specified pump.
• Any tension, contraction and strain on the piping system should never transfer to the pump.
• Electric wiring of the engine and auxiliary components should definitely comply with the local rules
and be performed by the authorized personnel.
• Never perform any work on the pump before the pump set is stopped completely.
ATTENTION
Always observe the following instructions to prevent any physical and/or property
damages.

02
• Any work on the pump should always be performed by at least two workers.
• Clothing of the personnel to work on the pump should always be suitable for the works they will
perform and/or the personnel should use necessary safety equipment.
• The user personnel should take necessary warning precautions (e.g. warning signs, barricades,
etc.).
• When the pump and pipes connected to the pump are under pressure, do not perform any work on
the pump definitely.
• Once the work on the pump is over, put in place all safety shields previously removed.
• Never operate the pump in reverse direction.
• Never insert pour hands and fingers into any hole or openings of the pump.
• Do not trace on the pump and/or pipes connected to the pump.
1.3.1 CE signs and approvals
It is a legal requirement that machinery and equipment put into service within certain regions of the
world shall conform with the applicable CE Marking Directives covering Machinery and, where
applicable, Low Voltage Equipment, Electromagnetic Compatibility (EMC), Pressure Equipment
Directive (PED).
Where applicable, the Directives and any additional Approvals, cover important safety aspects
relating to machinery and equipment and the satisfactory provision of technical documents and
safety instructions. Where applicable this document incorporates information relevant to these
Directives and Approvals. To confirm the Approvals applying and if the product is CE marked, check
the serial number plate markings and the Certification, see the last page of this document.
1.3.2 Personnel qualification and training
All personnel involved in the operation, installation, inspection and maintenance of the unit must
be qualified to carry out the work involved. If the personnel in question do not already possess the
necessary knowledge and skill, appropriate training and instruction must be provided. If required
the operator may commission the manufacturer / supplier to provide applicable training.
Always co-ordinate repair activity with operations and health and safety personnel, and follow all
plant safety requirements and applicable safety and health laws and regulations.
1.4 Recycling
For products and arts which will not be used and scraped, use the local or private waste collection
services. If it is not possible, consult the nearest authorized service centre of STANDART POMPA.
Always disconnect power connection with the engine before you perform any work on the
pump and make sure that no connection is made accidentally.

03
SDS PUMPS
2- GENERAL PUMP DESCRIPTION
2.1- Pump Description
• SDS series pumps are fire pumps which is designed in accordance with UL 448 and FM Class 1311 standards.
2.2- Application Areas
SDS series pumps are suitable for clean or slightly contaminated (max. 20 mg/dm3) liquids with low viscosities.
2.3- Pump Designation
Pump Type
Discharge nozzle (DN-mm)
Nominal impeller diameter (mm)
SDS 100 - 250
WWW.STANDARTPOMPA.COM
@
MAX. NET PRESSURE DEVELOPED
NET PRESSURE AT %150 CAPACITY
MAX. BHP
MAX. POSITIVE SUCTION PRESSURE
: PSI
: PSI
: HP
: PSI
...
...
...
...
CENTRIFUGAL FIRE PUMP
SPLIT CASE
TYPE
SDS ... - ...
DRIVER MAN.
AND SERIAL NO.
.......... - ..........
CONTROLLER MAN.
AND SERIAL NO.
.......... - ..........
NO. STAGES
...
SERIAL NO
....
D
..... MM
N (RATED)
..... RPM
H (RATED)
.... PSI
Q (RATED)
.... GPM
@
MAX. NET PRESSURE DEVELOPED
NET PRESSURE AT %150 CAPACITY
MAX. BHP
MAX. POSITIVE SUCTION PRESSURE
: PSI
: PSI
: HP
: PSI
...
...
...
...
TYPE
SDS ... - ...
NO. STAGES
...
SERIAL NO
....
D
..... MM
N (RATED)
..... RPM
H (RATED)
.... PSI
Q (RATED)
.... GPM
WWW.STANDARTPOMPA.COM
3TP5
CENTRIFUGAL FIRE PUMP
- SPLIT CASE
2.4 Pump Nameplate
2.5- Technical Information
Suction and Discharge Flanges : ANSI B16.42 Class 150/300
Speed : up to 3000 rpm
Ambient Temperature (max) : 40 º C
Permissible Liquids : See Section 2.2
The service life of this product as determined and announced by the Ministry is 10 years.
(*) Note: Contact our company for more detail.

04
3- UNPACKING, HANDLING and STORAGE
3.1- Unpacking
• Check whether the package has been damaged during transportation.
• Remove unpackaged pump and accessories (if any) carefully. Check whether they have been damaged
during transportation.
• If any damage has occurred during transportation, notify SERVICE DEPARTMENT, STANDART
POMPA and SHIPPING COMPANY about it immediately.
• Check whether all materials in the shipping list have been delivered. If there is any missing article,
advise SERVICE DEPARTMENT, STANDART POMPA.
• Remove the liquid inside the pump, for preventing corrosion due to transportation.
3.2- Handling
3.2.1- General warnings
• Follow the rules at work to prevent occurrence of any accidents.
• Wear gloves, steel-tooled shoes and helmet during handling.
• You may use forklift, crane or hoisting ropes to lower wooden crates, packages, pallets
or boxes depending on volume, weight and construction of them.
3.2.2- Lifting operation
- Total weight and centre of gravity, - The largest outer dimensions, and
- Location of the lifting points.
• The load lifting capacity should comply with the weight of the pump or pump group.
• The pump or pump group should always be lifted and handled horizontally.
• Never stand under or near the load being lifted.
• Do not keep the load lifted longer than necessary.
• Accelerating and braking operations during the hoisting should not be performed in such a way that
may be dangerous for the working personnel.
The pump or pump group should be hoisted as shown in the Figure 1a or Figure 1b in order to avoid
from any deformation. (When the group is hoisted as a whole, never use the suspension hook of the
electric motor.
ATTENTION
• Determine the following points prior to lifting and handling the pump or pump and
motor group on the joint frame.
Fig 1b. Pump and motorFig 1a. Bare shaft pump

05
3.3- Storage
• If the pump will not be installed in place immediately, it should be stored at a clean and dry place
free of any frost hazard without excessive change in the ambient temperature.
• If the pump bearings are of grease-applied ones, extra grease should be applied to the bearings to
prevent moisture ingress around the shaft.
• Necessary precautions should be taken to protect the pump against humidity, dust, dirt and foreign
materials.
• The pump should be rotated manually by some turns occasionally (e.g. once in a week) to prevent
pitting on the bearing surfaces and sticking of the pump.
4- INSTALLATION ON SITE
Installation of the pump on site and levelling and adjustments of it should be performed only by
qualified personnel. Improper installation or pump base (foundation) may cause failure. Such situations
are excluded from warranty.
Installation on site should be performed as per NFPA 20 standard.
4.1- Bare Shaft Pump
• If the pump is purchased as bare shaft pump, then first a proper baseplate should be constructed
to connect the pump and motor group. The baseplate should be designed and manufactured in such
a way that it will have resistance to prevent vibration and deformation.
• If the pump is supplied without motor, proper motor and coupling should be selected before the
group is installed.
• Following points should be taken into consideration when selecting motor:
- Maximum power drawn by the pump along the entire operating range,
- Running speed of the pump,
- Applicable power supply (frequence, voltage, etc.),
- Motor type (IEC, NEMA),
- Motor connection form (pedestal, flanged, horizontal, vertical, etc.), and
• Rated motor power, rpm and type of drive should be taken into consideration when selecting coupling.
4.2- Preparation for Installation
Prior to installation of the pump in place:
• Suction and delivery flanges should be cleaned thoroughly.
• Protective film on the pump shaft should be removed.
• If the pump has been stored temporarily, the liquid oil in the bearings should be drained completely
(in case of pumps manufactured with liquid oil) and the bearings should be cleaned by a proper
cleaning agent and then oiled again. This operation is not required for the pumps lubricated by grease
and for the pumps using enclosed type of ball bearing.
ATTENTION
• The pump should be installed at a well-ventilated place free of freezing and explosion risk.
•There should be sucient space around the pump being installed to allow easy access for
maintenance of the pump as well as sucient space above the pump to hoist it when required.
• Suction pipe of the pump should be short as far as possible.
4.3- Installation Site
ATTENTION

06
4.3.1- General characteristics of the pump foundation (baseplate)
You should work carefully for preparation of the pump base and installation of the pump
group in place. Improper and careless installation may cause excessive vibration and premature
wear of the pump equipment as well as pump failure.
ATTENTION
Figure 2. Foundation, baseplate and anchor bolt
Concrete
Anchor Bolt
20 - 40 mm
Shim
Baseplate
Sleeve
• Sizes of the foundation concrete should be determined on basis of minimum 10% excess of the
frame dimensions.
• Pump foundation should be independent of other foundation and platforms.
• Pump foundation should be capable to absorb vibrations and bear the loads to apply on the pump
unit during operation.
• Place and dimension of the anchor bolts should be determined according to the hole dimensions
of the pump unit.
• Washer should be used to prevent tension and distortion when tightening the foundation bolts.
• In order that the foundation bolts should align with the connection holes of the frame exactly and
to allow for minor adjustments, the bolts are inserted into the bushings. The bushings should be
place in such a way that they will not exceed top surface of the foundation concrete.
4.3.2- Placement of the Pump Group
•Preparation and pour of the foundation concrete mass.
-The concrete mass is formed according to its dimensions.
-The locations of the anchor bolts are measured and marked carefully and Styrofoam is
cut tothe dimension, placed and fixed.
-The concrete is poured
Volume ratio: Cement 1: sand 2: gravel 4
Concrete hardens within 7 days (hardening may be shortened by use of special cement).
-Upon hardening of the concrete, the Styrofoam is burned and removed. Locations of anchor
bolts appear in the concrete.
-Top surface of the concrete and holes of the anchor bolts are cleaned.
•Placement of the frame on the foundation concrete mass. (first adjustment)
-Anchor bolts are mounted on the frame.
-The frame is placed on the flattening chocks and the anchor bolts remain suspended
in the holes. Make sure that the anchor bolts remain vertical.
-Levelness of the frame is controlled in both directions from the pump and engine
placement location by use of precise spirit level 0,25 ÷ 0,40 mm/m is acceptable.
- Anchor holes are fileed with concrete. Anchor bolts are thus fixed.

07
• Never use the pump as a point of support or bearer for the piping system.
ATTENTION
Volume ratio: Cement 1 : sand 1.5: gravel 3
Concrete hardens within 7 days (hardening time may be shortened by use of special cement).
•Fixing of the frame on the foundation concrete mass exactly by adjustment.
-The area about 30mm between the foundation concrete mass and frame is formed and
concrete is poured through the holes in the frame.
Volume ratio: Cement 1: sand 2
Concrete hardens within 2 days.
-Frame remains adjusted and fixed on the foundation concrete.
4.4- Installation of the Piping System
4.4.1- General Warning
• The piping system should be supported at points near to the pump. For this purpose, after completion
of the installation of the piping system, loosen the bolts of the suction and delivery flanges and
control whether the piping system applies any tension on the pump. The maximum allowable forces
and moments on the flanges are given in Table 1.
• Rated diameter of the suction and delivery flanges of the pump are not indicator of the correct
sizes of the suction and delivery pipes at all. The rated diameter of the pipes and accessories used
should be equal to or larger than the inlet diameters of the pump at least. Never use pipes and
accessories having smaller diameter than the inlet diameters of the pump. Especıally components
such as, strainer, dirt-retaining filter and check valves with larger free passage area should be preferred.
• Pipe connections should be made with the flanges. Flange bolts should be made of proper material
and in proper size. The flange bolts should be inserted between the flange bolts and centred in such
way that it would not impair flow section.
• In case of excessive vibrations, expansion parts should be used in order that any extra forces that
may arise from thermal expansion are not transferred to the pump.
• Materials such as welding burrs, metal particles, sand and oakum arising from production of fhe
piping system may remain in the pump and give damage to the pump. The suction and delivery
flanges should be sealed blind washers in order to prevent such materials from entering into the
pump during the assembly operations. After assembly, all pipe parts should be removed, cleaned,
painted and reassembled. If dirt-retainer is used on the suction side of the pump, the dirt-retainer
should be cleaned after working for several days.

08
Fig 3. Suction Head
Isolating Valve
Piping Support
Long Radius Elbow
Allowable Forces and Moments on Flange
65-250
80-250
80-315
100-250
125-315
150-315
DN
100
125
150
200
200
Fx
[N]
1690
2080
2600
3510
3510
Fy
[N]
1560
1820
2340
3120
3120
Fz
[N]
1430
1690
2080
2860
2860
∑F
[N]
2730
3250
4030
5460
5460
Mx
[Nm]
690
820
980
1280
1280
My
[Nm]
500
590
690
900
900
Mz
[Nm]
570
740
810
1040
1040
∑M
[Nm]
1020
1200
1430
1820
1820
Suction Flange Dischage Flange
Pump
Type DN
65
80
100
125
150
Fx
[N]
1100
1300
1690
2080
2600
Fy
[N]
960
1170
1560
1820
2340
Fz
[N]
880
1070
1430
1690
2080
∑F
[N]
1690
2080
2730
3250
4030
Mx
[Nm]
590
620
690
820
980
My
[Nm]
430
460
500
590
690
Mz
[Nm]
470
510
570
740
810
∑M
[Nm]
860
920
1020
1200
1430
Table 1
F
y
F
x
F
z

09
4.4.2- Suction pipe
• The suction pipe should be definitely watertight and should not be arranged in a way to cause
formation of air pockets. Figure 3
• In order to keep the loss from friction, sharp elbows should not be used; and abrupt change of
direction and section should be avoided and suction pipe should be made short as far as possible. If
it is required to make change of section on a horizontal suction pipe, an eccentric conical spacer with
its flat side on the top should be used.
4.4.3- Delivery pipe
•A flow control valve should be connected on the delivery pipe, near the pump as far as possible in
order to adjust the flow rate and delivery head. Figure 4
• An insulation valve should be
used to keep the axis on the suction pipe horizontally. This valve should always be open
when the pump operates and it should never be used as flow rate adjusting valve
(Caution: Throttle of the valve may cause the pump to operate with cavitation).
ATTENTION
Fig 4. Suction Head
Isolation Valve
Eccentric Reducer
Non Return Valve
Flow Control Valve
After installation of piping system, coupling allignment should be checked and if necessary
it should be adjusted again.
4.4.4- Auxiliary pipe connections and accessories
•Depending on the application auxiliary pipe connections (for cooling, sealing and flushing of seal,
drainage etc. necessary for the pumping system) and/or accessories to check operating conditions
(pressure gauges, temperature gauges etc.) may be made up and lail.
•Pressure and vacuum gauges must be properly anchored and connected at the measuring points
located on the pump flanges by means of or on the pipes close to the flanges. For safety purposes
isolating and vent valves should be fitted before the gauges.
•Cooling, sealing and flushing of seal piping must be connected only to the designated connections
located on the pump.
ATTENTION

10
4.5- Coupling Adjustment
After installation of the baseplate and system
connections, the coupling adjustment should be controlled
finally. The reason that proper adjustment of the entire
system is responsibility of the purchaser.
“Coupling Adjustment” is to ensure that the
rotation axes of the motor and pump should be on the same
plane. SDS type pumps are ordered with motor and
baseplate, they are delivered with the coupling adjustments
made at the factory. However, this adjustment may be easily
impaired during transportation, handling, installation on
site and installation of the system. For this reason, the
coupling adjustment should be performed again after
installation of the group on site, disregarding the adjustment
made at the factory.
• The most important factor for problem-free operation of
the pump group is correct coupling adjustment. The basic
reason of a number of problems such as vibration, noise,
bearing heating and overload is a coupling unadjusted or
improperly adjusted. For this reason, coupling adjustment
should be performed very well and controlled frequently.
• Elastic coupling should not be regarded as a component to
correct an improper adjustment. Elastic coupling does not
correct a poor axial adjustment between the pump and motor
and does not remove excessively poor adjustments.
• A metal part (steel ruler or gauge, etc.) and a precise caliper
are required to perform coupling adjustment (special
equipment should be used for very fine and precise
adjustment). Axial run-out of the coupling (see Figure 5)
should not exceed 0.1 mm.
• There may be two types of adjusting mistakes on the
coupling:
a) Angular mistake
b) Parallel displacement mistake
• In order to control the angular mistake, the distance
between two parts of the coupling should be measured
mutually on horizontal and vertical planes. The clearances
measures at these four points should be equal (Figure 6a,6b).
ATTENTION
ATTENTION
a
Fig 5. Alligning a flexible coupling
Fig 6a. Angle error in horizontal plane
and adjustment
Fig 6b. Angle error in vertical plane and
adjustment
Fig 6c. Parallel sliding error in
horizontal plane and adjustment.
Fig 6d. Parallel sliding error in vertical
plane and adjustment.

11
• In order to control the parallelism mistake, a gauge with straight edge is pressed on a part of the
coupling in parallel to the axis and the position of the gauge related to other part is observed. The
gauge should contact with both two parts simultaneously and along its entire edge. This process
should be performed at two opposite places on the horizontal and vertical plane (Figure 6c, 6d).
• Adjustment mistakes may be on the horizontal and/or vertical plane. Mistakes on the vertical plane
may be made by putting thin metal sheets under the pump or motor mounts and the mistakes on
the horizontal plane by benefiting from the gaps in the connection holes or sliding the engine on the
horizontal plane. Manner and order of the coupling adjustment is shown inthe Figures 6a, 6b, 6c
and 6d, respectively.
4.6- Electrical Connections
• Electirical connection should be done by a qualified electrician. Current national regulation and
motor manufacturer’s instructions must be observed.
• Take all safety precautions listed in “Safety instructions”. Disconnect all power supplies prior to
doing any work.
• The supply cable must be laid in such a way that it never touches the pipework, pump and motor
casing.
• Check voltage, phase and frequency on motor nameplate with the mains.
• The electric motor must be protected against overloading by means of circuit breakers and/or fuses.
Circuit breakers and fuses must be selected in accordance with full load amperage of the motor
appearing on the motor rating plate.
• Prior to connection the electrical wiring rotate the pump shaft by hand to make sure rotor rotates
easily.
• Connect the electrical wiring in accordance with local electrical codes and make sure to ground the
motor.
• The connection diagram can be found in the terminal box of the motor or in the instruction manual.
• The mains connection on the terminal box depends on the nominal power of the motor, the power
supply and the type of connection. The necessary coneccton of the bridges in the terminal box is
shown in the following (Table 2 ve Figure 7a, 7b, 7c).

12
W
2
U
2
V
2
U
1
V
1
W
1
L
1
L
2
L
3
W
1
V
2
L
1
V
1
U
2
U
1
L
2
W
2
L
3
W
1
V
2
L
1
V
1
U
2
U
1
L
2
W
2
L
3
Figure 7a. ∆ - connection Figure 7b. Y – connection Figure 7c. Y / ∆ - connection
Type of switch
Motor Power
P
N
≤ 4 kW Motor Power
P
N
> 4 kW
Power Supply
3 ~ 400 V Power Supply
3 ~ 400 V
direct Y – connection (11b) ∆ – connection (11a)
Y / ∆ - start Impossible Remove connection
bridges (11c)
Table 2
Motor Power Y - set time
≤ 30 kW
> 30 kW < 3 second
> 5 second
Table 3
In the case of three-phase induction motors with Y - ∆connection it must be ensurred that
the change-over points between star and delta follow on from one another very quickly.
Longer change-over times may result in pump damage (Table 3).
4.7- Final Controls
• After all operations given above are completed, the coupling adjustment should be controlled once
more in accordance with the section 4.5. And if it is incorrect, it should be corrected.
• The pump rotor should be rotated several times manually to make sure it rotates easily.
• All security guards should be put in place.
• And the pump group should be operated and you should allow until the operating and heating
conditions are reached.
• At the end of this term, the pump is stopped and thin metal sheets are put under the motor mounts
only to perform coupling adjustment for the last time.
• Final coupling adjustment is especially recommended to be performed at the operating temperature.
• The pump should never be operated before the safety guards are put in place. This is a
security and safety rule at workplace which should be definitely observed.
ATTENTION

13
5- START UP / SHUT DOWN
5.1- Preparation
5.1.1- Lubrication control
• The bearings of SDS type pump are always lifetime grease lubricated. Lifetime grease lubricated
bearings are maintenance-free.
5.1.2- Venting and priming
• Make sure that the pump and suction pipes are completely filled up with water. There is no problem
for the pumps which have positive suction head. If there is a valve on suction line, it must be opened
and air taps are loosened to enable the water replaces air in the pump, until it is completely full with
water.
Make sure the pump never runs dry.
5.1.3- Checking the direction of rotation
• SDS type pumps rotate in clockwise when it is looked from coupling to the pump. This direction is
already indicated on the pump by an arrow. Check this by switching the pump on, then o again
immediately. Fit the coupling guard back in place if you took it out.
5.2- Start Up The Pump
• Check if the shut o valve in the suction line is open.
• Switch on the circuit breaker and run the motor.
• Wait until the motor reaches the full speed (on star-delta running motors wait until it switches on
delta).
• Pump doesn’t deliver any water,
• Pump doesn’t deliver enough water,
• Flow is going down,
• Discharge pressure is not enough,
• Driver overloaded,
• Vibration on pump,
• High noise level,
• Bearing overheating.
ATTENTION
The pump should be shut down at once and the trouble should be corrected if the pump
is running at its rated speed and found any of the following faults:
ATTENTION

14
5.3- Checks to be Made While The Pump is Running
• The bearing temperature may exceed the ambient temperature by up to 50 ºC. But must never rise
above 80 ºC.
• The valves in the auxiliary lines must remain open while the pump is runing.
• The pump has soft packing type stung boxes. These should drip during operation. The gland nuts
should only be lightly tightened. In case of excessive leakage from the stung box tighten the gland
nuts slowly and evenly until the leakage is reduced to the dripping state. Check the stung box for
overheating by hand. If the gland nuts can not be tightened any further remove the old packing rings.
Make sure that each packing ring is cut of correct size. The joint in successive ring should be oset
to each other.
• The flexible coupling elements should be regularly checked and replaced as soon as they are shown
signs of wear.
• Occasionally check the motor current. Stop motor if the amperage is higher than usual; there may
be jamming or friction in the pump. Make the necessary mechanical and electrical checks.
• Stand-By pumps should be run for a short time at least once a week to ensure they are in constant
readiness for operation. Check the integrity of auxiliary connections.
6- LUBRICATION
• Bearing of SDS type pumps have grease lubricated ball bearings.
• Life-time grease lubricated bearings are maintenance free.
• See the attached Table 4 for bearings type and size.
6.1- Application of Grease on the Bearing
High quality NLGI 2 or NLGI 3 grease must be used in bearings.
The grease must be replaced in every 12-14 months or at the end of each 3000 working hours.
More frequent grease replacement may cause overheating and shortening of the bearing life.
The bearings of the pumps demounted for repair must be inspected and replaced, if necessary.
It must be ensured that the greasing equipment and the reservoir are clean before adding grease to
the bearings.
Grease in suitable amounts must be added to the bearings.
The temperatures of the bearings may increase in the case of adding excessive amount of grease.
The temperatures of the bearings will decrease to the normal operating temperature when excessive
grease is removed.
• The pump must never run dry.
• Never run the pump for along period against a closed discharge valve (at zero flow)
ATTENTION
Pump Dimension
Group
Shaft end
Dimension ø
A
B
C
35
42
55
Bearing Type
6308 C3
6310 C3
6312 C3
Table 4
The bearing temperature must never exceed the ambient temperature by maximum 50 °C.
Also, it must not exceed 80 °C under no circumstances.
ATTENTION

15
7- DISASEMBLY AND REASSEMBLY
• Follow the safety precaution measures outlined in “safety instructions”.
7.1- Disassembly
•Close all valves in the suction and discharge lines, and drain the pump by opening the drain plug and the air
plug.
• Disconnect the stung boxes flushing pipes.
• Remove coupling guard and other safety guards (see section safety guard).
• Remove all casing main joint nuts and dowel pins.
•Separate the casing halves, lifting o the upper half casing. This reveals the pump internals (impeller, wear
rings) for inspection.
• Unscrew the bolts which are connecting the bearing housings to the bottom half casing.
• Remove bearing covers and bearing end covers.
• Pull the bearing housing o the bearings.
• Unscrew the shaft nuts and lock washers.
• Pull the bearing o the shaft and remove.
•Remove in sequence bearing covers, throwers, spacer sleeves, stung boxes, shaft protecting sleeves, wear
rings, impeller and impeller key.
• Clean all the parts, replace damaged or worn-out ones.
7.2- Reassembly
•Reassembly proceeds in reverse sequence to dismantling as described in (section 7.1). You may find the attached
drawing useful. the following points should be noted more particularly.
• Never use old o-rings and make sure the new o-rings are the same size as the old ones.
•Before mountling the shaft protecting sleeves inspect the condition of their rubbing faces. Use new sleeves if
the old ones are badly worn, scored or rough.
•the joint faces of the casing halves are sealed with liquid sealing compund. The joint faces should be thoroughly
cleaned before reassembly and coated over again with sealing compund. NEVER USE A PAPER GASKET BETWEEN
THE TWO FACES.
The following tightening torques must be taken into consideration when tightening
the bolts and nuts during installation.
7.3- Tightening Torques
ATTENTION
Table 5 Table 5 (continue)
Tightening
Torques (Nm)
Tightening
Torques (Nm)
Thread
Diameter
7
20
40
65
100
M6
M8
M10
M12
M14
M16
M18
M20
M22
M24
Thread
Diameter
130
140
140
140
200

16
7.4- Shaft Seal
7.4.1- Pump with soft packing gland
•While starting to change soft packing thoroughly clean the stung box and shaft (or shaft sleeve,
if used).
•Cut enough number of pieces suitable lenght diagonally from suitable size of soft packing. Roll it
up over the shaft (or shaft sleeve, if used) and see the ends are in full contact.
• Insert the first packing ring as the joint will place up, and press home using the gland cover.
•Place the second ring as joint will place down. Insert all the packing rings in the same way. If there
is a lantern ring put into place too.
•Place the gland and fully tighten, thus the packing rings will take the shape of stung box, the
loosen it. Slightly tighten by turning the shaft and stop tightening when it slightly brakes the shaft.
•After starting operation, it is necessary that water drips from the packing. This dripping shouldn’t
be less than 10 cm³/min and more than 20 cm³/min. Adjust dripping by uniformly tightening or
untightening the gland nuts slighly.
•Check the temperature of soft packing after two hours operation after gland adjustment to avoid
overheating.
12x12
12x12
16x16
35
42
55
A
B
C
Pump Dimension
Group
Shaft End
Diameter
ø
Yumuşak
Salmastra Kesiti
□
Table 6
8- SPARE PART
•STANDART POMPA guarantees to supply the spare parts for SDS type pumps for 10 years. You can
provide any spare parts easily.
• Lets us know the following details on the name-plate, when you order spare parts.
Pump Type : (SDS 125-315)
Serial No : (...... – ...............)
Q (Rated) / H (Rated) : (1500 gpm - 150 psi)
•If you prefer to have spare parts in your stock, we recommed you to have the following quantities
for two years operation depending on the number of same of pumps (Table 7).
Part
No Part Name Number of pumps in the system
2 3 4 5 6-7 8-9 10+
Table 7
60
50
20
200
70
400
420
1
1
4
2
4
8
4
1
1
4
2
4
8
6
2
1
4
4
4
12
8
2
2
6
4
6
12
8
2
2
6
6
6
12
9
3
3
8
8
8
16
12
30%
30%
50%
50%
50%
40%
150%
Shaft (incl. keys) (piece)
Impeller
Wear Ring
Ball Bearings
Shaft Sleeve
Soft Packing (set)
Casing O-Ring
