Stanley FATMAX SFMCPH845 User manual

SFMCPH845
Final page size: A5 (148mm x 210mm)

B
Copyright STANLEYFATMAX
English (original instructions) 3

1
Fig. A
11
12 3
46789
10 5
11
12
Fig.C
61112
Fig.B
3
13
Fig. D

2
Fig. F
Fig. H
Fig. E
Fig. G
14
4

ENGLISH
3
Battery
Cat #
Output
Voltage
Charger
SFMCB12
SFMCB202 18 X
SFMCB204 18 X
SFMCB206 18 X
“X” Indicates that the battery pack is compatible with that
specific charger. Read the instruction manual for more
specificinformation.
EC-Declaration of Conformity
Machinery Directive
Hedge Trimmer
SFMCPH845
STANLEYFATMAX declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841-1:2015, EN ISO 10517:2019.
2000/14/EC, Annex V
DEKRA Certification B.V.
Meander 1051 / P.O. box 5185
6525 MJ ARNHEM / 6802 ED
ARNHEM, Netherlands
LPA (measured sound pressure) 75.5 dB(A)
uncertainty (K) = 2.5 dB (A)
LWA (guaranteed sound power) 92 dB(A)
These products also comply with Directive 2014/30/EU
and 2011/65/EU. For more information, please contact
STANLEYFATMAX at the following address or refer to the back
of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofSTANLEYFATMAX.
A. P. Smith
Technical Director
STANLEYFATMAX Europe, Egide Walschaertsstraat14-18,
2800 Mechelen, Belgium
28.10.2019
WARNING: To reduce the risk of injury, read the
instruction manual.
Congratulations!
You have chosen a STANLEYFATMAX tool. Years of experience,
thorough product development and innovation make
STANLEYFATMAX one of the most reliable partners for
professional power toolusers.
Technical Data
Batteries & Chargers sold separately
SFMCPH845
Voltage VDC 18
UK & Ireland VDC 18
Type 1
Blade length mm 450
Blade gap mm 19
Blade strokes spm 1400 min-1
Cutting Swath Size mm 457
Weight (without battery pack) kg 3.6
Noise values and vibration values (triax vector sum) according to
EN62841-2-15:
LPA (emission sound pressure level) dB(A) 75.5
LWA (sound power level) dB(A) 90.0
K (uncertainty for the given sound
level)
dB(A) 2.2
Vibration emission value a
h
=
m/s2<2.5
Uncertainty K =
m/s21.5
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN62841 and may be used to compare one tool with another. It
may be used for a preliminary assessment ofexposure.
WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure
level over the total workingperiod.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation of
workpatterns.
English (original instructions)
HEDGE TRIMMER
SFMCPH845

4
ENGLISH
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
General Power Tool Safety Warnings
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
powertool.
1) Work area safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of a second.
4) Power tool use and care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.

5
ENGLISH
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the
risk of starting the power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.,
in accordance with these instructions taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations
5) Battery tool use and care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury andfire.
c ) When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation orburns.
e ) Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
of injury.
f ) Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130 ° C may cause explosion.
g ) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified range
may damage the battery and increase the risk of fire.
6) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers
Additional Safety Instructions for Hedge
Trimmers
WARNING: Cutting elements continue to rotate after the
motor is switchedoff.
• Keep all parts of the body away from the blade. Do not
remove cut material or hold material to be cut when
blades are moving. Blades continue to move after the switch
is turned off. A moment of inattention while operating the
hedge trimmer may result in serious personalinjury.
• Carry the hedge trimmer by the handle with the blade
stopped and taking care not to operate any power
switch. Proper carrying of the hedge trimmer will decrease the
risk of inadvertent starting and resultant personal injury from
theblades.
• When transporting or storing the hedge trimmer, always
fit the blade cover. Proper handling of the hedge trimmer
will decrease the risk of personal injury from theblades.
• When clearing jammed material or servicing the unit,
make sure all power switches are off and the battery
pack is removed or disconnected. Unexpected actuation
of the hedge trimmer while clearing jammed material or
servicing may result in serious personalinjury.
• Hold the hedge trimmer by insulated gripping surfaces
only, because the blade may contact hidden wiring.
Blades contacting a "live" wire may make exposed metal parts
of the hedge trimmer "live" and could give the operator an
electricshock.
• Keep all power cords and cables away from cutting area.
Power cords or cables may be hidden in hedges or bushes and
can be accidentally cut by theblade.
• Do not use the hedge trimmer in bad weather
conditions, especially when there is a risk of lightning.
This decreases the risk of being struck bylightning.
• To reduce the risk of electrocution, never use the
extended-reach hedge trimmer near any electrical
power lines. Contact with or use near power lines may cause
serious injury or electric shock resulting indeath.

6
ENGLISH
• Always use two hands when operating the extended-
reach hedge trimmer. Hold the extended-reach hedge
trimmer with both hands to avoid loss ofcontrol.
• Always use head protection when operating the
extended-reach hedge trimmer overhead. Falling debris
can result in serious personalinjury.
• Check the hedge for foreign objects, e.g. wirefences.
• The hedge trimmer is intended to be used by the operator
at ground level and not on ladders or any other unstable
support; before operating the hedge trimmer, the user should
make sure the locking device(s) of any moving elements (e.g.
the extended shaft and pivoting element), if any, are in the
lockedposition
• The intended use is described in this instruction manual. The
use of any accessory or attachment or performance of any
operation with this tool other than those recommended in this
instruction manual can present a risk of personal injury and/or
damage toproperty.
• Do not carry the tool with your hands on the front
handle, switch or the trigger switch unless the battery has
beenremoved.
• If you have not used a hedge trimmer before, preferably seek
practical instruction by an experienced user in addition to
studying thismanual.
• Never touch the blades while the tool isrunning.
• Never attempt to force the blades to come to a standstill.
• Do not put the tool down until the blades have come to a
completestandstill.
• Regularly check the blades for damage and wear. Do not use
the tool when the blades aredamaged.
• Take care to avoid hard objects (e.g. metal wire, railings)
when trimming. Should you accidentally hit any such object,
immediately switch the tool off and check for anydamage.
• Should the tool start to vibrate abnormally, immediately switch it off
and remove the battery then check for anydamage.
• If the tool stalls, immediately switch it off. Remove the battery
before attempting to remove anyobstructions.
• After use, place the blade sheath supplied over the blades. Store
the tool, making sure that the blade is notexposed.
• Always ensure that all guards are fitted when using the
tool. Never attempt to use an incomplete tool or a tool with
unauthorisedmodifications.
• Never allow children to use thetool.
• Be aware of falling debris when cutting the higher sides of
ahedge.
• Always hold the tool with both hands and by the
handlesprovided.
Safety Instructions for Extended-Reach
Hedge Trimmers
• Do not use the extended-reach hedge trimmer in bad
weather conditions, especially when there is a risk of
lightning. This decreases the risk of being struck bylightning.
• To reduce the risk of electrocution, never use near any
electrical power lines. Contact with or use near power lines
may cause serious injury or electric shock resulting indeath.
• Always use two hands when operating the extended-
reach hedge trimmer. Hold the extended-reach hedge
trimmer with both hands to avoid loss ofcontrol.
• Always use head protection when operating the
extended-reach hedge trimmer overhead. Falling debris
can result in serious personalinjury. Use a hard hat compliant
with ANSI Z89.1 (CAN/CSA Z94.1).
CAUTION: Do not expose torain.
Important Safety Rules
WARNING: Read and understand all instructions.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious personalinjury.
SAVE THESE INSTRUCTIONS
Before Operating Pole Hedge Trimmer
CAUTION: The unit has not been designed to provide
protection from electric shock in the event of contact with
overhead electric lines, Consult local regulations for safe
distances from overhead electric power lines and ensure
that the operating position is safe and secure before
operating the extended reach hedgetrimmer.
• For safe operation, read and understand all instructions before
using the Pole Hedge Trimmer. Follow all safety instructions.
Failure to follow all safety instructions listed below, can result
in serious personalinjury.
• Watch what you are doing. Use common sense. Do not
operate Pole Hedge Trimmer when you aretired.
• Only well-instructed adults should operate Pole Hedge
Trimmer. Never allow children tooperate.
• Do not use Pole Hedge Trimmer for any job except that for
which it isintended.
• Do not allow children or untrained individuals to use thisunit.
• Wear the following safety gear when operating Pole Hedge
Trimmer:
- heavy-duty gloves
- substantial footwear
- safety glasses, goggles or face screen that are marked to
comply with ANSI Z87.1
- face or dust mask (if working in dusty areas)
• Do not wear loose fitting clothing, or jewelry of any kind that
could get caught in the moving blades or parts of the Pole
HedgeTrimmer.
• Secure long hair so it is above shoulder level to prevent
entanglement in any movingparts.
While Operating Pole Hedge Trimmer
• Stay alert. Use common sense while operating theunit.
• Keep work area clean. Cluttered areas inviteinjuries.

7
ENGLISH
• Keep children, animals and bystanders at a safe distance away
from Pole Hedge Trimmer. Only Pole Hedge Trimmer user
should be in workarea.
• Grip Pole Hedge Trimmer securely - one hand on the foam
gripper, the other on the mainhandle.
• Keep finger off trigger until ready touse.
• Before starting Pole Hedge Trimmer, make sure blades are not
touchinganything.
• Keep all parts of body away from blades when Pole Hedge
Trimmer isrunning.
• Carry Pole Hedge Trimmer from one place to another
- with battery removed
- by holding pole at balance point
- with blades to rear
• Do not operate in poorlighting.
• During operation, rest periodically and change working
positions to reducefatigue.
• Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance or exposure to
sharpsurfaces.
• Do not, under any circumstance, use any attachment or
accessory on this product, which was not provided with the
product, or identified as appropriate for use with this product
in this InstructionManual.
Do Not Operate Pole Hedge Trimmer
• While under the influence of alcohol, medication, or drugs in
rain or in damp or wet areas
• Where highly flammable liquids or gases are present
• If Pole Hedge Trimmer is damaged, adjusted wrong, or not fully
and securely assembled
• If trigger does not turn Pole Hedge Trimmer on and off. Blades
must stop moving when you release trigger. Have faulty switch
replaced by authorized service center. SeeRepairs.
• While in a hurry
• While in tree or on a ladder
• While on aerial booms, buckets or platforms
• During high wind or storming weather
General Safety Rules
WARNING: Shock Hazard. To protect yourself from
electrocution, do not operate within 10 feet (3 m) of
overhead electrical lines. Consult local regulations for safe
distances from overhead electric power lines and ensure
that the operating position is safe and secure before
operating the extended reach hedge trimmer. Failure to do
this could result in severe personalinjury.
• Keep the handles dry, clean, and free ofoil.
• Make sure cutting blades have stopped before setting
unitdown.
DANGER: RISK OF CUT. Keep hands away from blades.
Keep both hands on handles when Pole Hedge Trimmer
ison.
• DO NOT ATTEMPT to remove cut material or hold material
to be cut when blades are moving. Remove battery when
clearing jammed material from blades. Do not grasp the
exposed cutting blades or cutting edges when picking up or
holding the Pole HedgeTrimmer.
CAUTION: Blades coast after turnoff.
• DON’T FORCE POLE HEDGE TRIMMER - It will do the job
better and with less likelihood of a risk of injury at the rate for
which it wasdesigned.
• DISCONNECT BATTERY from the Pole Hedge Trimmer when
not in use or when servicing orcleaning.
• STORE IDLE POLE HEDGE TRIMMER INDOORS - When not
in use, Pole Hedge Trimmer should be stored indoors in a dry
and high or locked-up place out of reach ofchildren.
• MAINTAIN POLE HEDGE TRIMMER WITH CARE - Keep
cutting blades sharp and clean for best performance and to
reduce the risk of injury. Keep handles dry, clean and free from
oil andgrease.
• CHECK DAMAGED PARTS - Before further use of the Pole
Hedge Trimmer, a guard or other part that is damaged should
be carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting and any other condition that may affect its
operation. A guard or other part that is damaged should be
properly repaired or replaced by an authorized service center
unless otherwise indicated elsewhere in thismanual.
Service
• Tool service must be performed only by qualified repair
personnel. Service or maintenance performed by unqualified
personnel could result in a risk of injury. SeeRepairs.
• When servicing a tool, use only identical replacement
parts. Follow instructions in the Maintenance section of
this manual. Use of unauthorized parts or failure to follow
Maintenance Instructions may create a risk of electric shock
orinjury.
Specific Safety Rules
• Hold tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring. Contact with a “live” wire will make
exposed metal parts of the tool “live” and shock theoperator.
Residual Risks
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations and
the implementation of safety devices, certain residual risks can
not be avoided. These include:
• Injuries caused by touching any rotating/moving parts.
• Injuries caused when changing any parts, blades or
accessories.

8
ENGLISH
•Injuries caused by prolonged use of a tool. When using any
tool for prolonged periods ensure you take regular breaks.
•Impairment of hearing.
•Health hazards caused by breathing dust developed when
using your tool (example: working with wood, especially oak,
beech and MDF.)
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of yourmains.
Your STANLEYFATMAX charger is double insulated
in accordance with EN60335; therefore no earth wire
isrequired.
WARNING: 115 V units have to be operated via a fail-safe
isolating transformer with an earth screen between the
primary and secondary winding.
If the supply cord is damaged, it must be replaced by a specially
prepared cord available through the STANLEYFATMAX
serviceorganisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
•Safely dispose of the oldplug.
•Connect the brown lead to the live terminal in theplug.
•Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 3A.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1mm2; the maximum length
is30m.
When using a cable reel, always unwind the cablecompletely.
SAVE THESE INSTRUCTIONS
Chargers
STANLEYFATMAX chargers require no adjustment and are
designed to be as easy as possible tooperate.
Important Safety Instructions for All
Battery Chargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for compatible battery
chargers (refer to TechnicalData).
•Before using charger, read all instructions and cautionary
markings on charger, battery pack, and product using
batterypack.
WARNING: Shock hazard. Do not allow any liquid to get
inside charger. Electric shock mayresult.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only STANLEYFATMAX rechargeable batteries.
Other types of batteries may burst causing personal injury
anddamage.
CAUTION: Children should be supervised to ensure that
they do not play with theappliance.
NOTICE: Under certain conditions, with the charger
plugged into the power supply, the exposed charging
contacts inside the charger can be shorted by foreign
material. Foreign materials of a conductive nature such
as, but not limited to, steel wool, aluminum foil or any
buildup of metallic particles should be kept away from
charger cavities. Always unplug the charger from the
power supply when there is no battery pack in the cavity.
Unplug charger before attempting to clean
•DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger
and battery pack are specifically designed to worktogether.
•These chargers are not intended for any uses other
than charging STANLEYFATMAX rechargeable batteries.
Any other uses may result in risk of fire, electric shock
orelectrocution.
•Do not expose charger to rain orsnow.
•Pull by plug rather than cord when disconnecting
charger. This will reduce risk ofdamage to electric plug
andcord.
•Make sure that cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage orstress.
•Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk
of fire,electric shock, orelectrocution.
•Do not place any object on top of charger or place
the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat.
Place the charger in a position away from any heat source. The
charger is ventilated through slots in the top and the bottom
of thehousing.
•Do not operate charger with damaged cord or plug—
have them replacedimmediately.
•Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. Take it
to an authorised servicecentre.
•Do not disassemble charger; take it to an authorised
service centre when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution
orfire.
•In case of damaged power supply cord the supply cord must
be replaced immediately by the manufacturer, its service agent
or similar qualified person to prevent anyhazard.
•Disconnect the charger from the outlet before
attempting any cleaning. This will reduce the risk of

9
ENGLISH
electric shock. Removing the battery pack will not reduce
thisrisk.
•NEVER attempt to connect two chargerstogether.
•The charger is designed to operate on standard
230V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
Charging a Battery (Fig. B)
1. Plug the charger into an appropriate outlet before inserting
battery pack.
2. Insert the battery pack9 into the charger, making sure the
battery pack is fully seated in the charger. The red (charging)
light will blink repeatedly indicating that the charging
process has started.
3. The completion of charge will be indicated by the red light
remaining ON continuously. The battery pack is fully charged
and may be used at this time or left in the charger. To
remove the battery pack from the charger, push the battery
release button10 on the battery pack.
NOTE: To ensure maximum performance and life of lithium-ion
battery packs, charge the battery pack fully before first use.
Charger Operation
Refer to the indicators below for the charge status of the battery
pack.
Charge Indicators
Charging
Fully Charged
Hot/Cold Pack Delay*
This charger is designed to detect certain problems that can
arise. Problems are indicated by the red light flashing at a fast
rate. If this occurs, remove and then reinsert the battery pack
into the charger. If the problem persists, try a different battery
pack to determine if the charger is working properly. If the new
pack charges correctly, then the original pack is defective and
should be returned to a service center or other collection site
for recycling. If the new battery pack elicits the same trouble
indication as the original, have the charger and the battery pack
tested at an authorized service center.
The compatible charger(s) will not charge a faulty battery pack.
The charger will indicate faulty battery by refusing to light or by
displaying problem pack or charger blink pattern.
NOTE: This could also mean a problem with a charger.
If the charger indicates a problem, take the charger and battery
pack to be tested at an authorised service centre.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too
cold, it automatically starts a Hot/Cold Pack Delay, suspending
charging until the battery pack has reached an appropriate
temperature. The charger then automatically switches to the
pack charging mode. This feature ensures maximum battery
pack life.
A cold battery pack will charge at a slower rate than a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to
maximum charge rate even if the battery pack warms.
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using a
cloth or soft non-metallic brush. Do not use water or any
cleaning solutions. Never let any liquid get inside the tool;
never immerse any part of the tool into a liquid.
Battery Packs
Important Safety Instructions for All
Battery Packs
When ordering replacement battery packs, be sure to include
catalog number and voltage.
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
below. Then follow charging procedures outlined.
READ ALL INSTRUCTIONS
•Do not charge or use battery in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Inserting or removing the battery from the charger may
ignite the dust or fumes.
•Never force battery pack into charger. Do not modify
battery pack in any way to fit into a non-compatible
charger as battery pack may rupture causing serious
personal injury.
•Charge the battery packs only in STANLEYFATMAX chargers.
•DO NOT splash or immerse in water or other liquids.
•Do not store or use the tool and battery pack in
locations where the temperature may reach or exceed
40 ˚C (104 ˚F) (such as outside sheds or metal buildings
in summer).
•Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium-ion battery packs are burned.
•If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open eye
for 15 minutes or until irritation ceases. If medical attention
is needed, the battery electrolyte is composed of a mixture of
liquid organic carbonates and lithium salts.
•Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persists, seek medical
attention.
WARNING: Burn hazard. Battery liquid may be flammable
if exposed to spark or flame.
WARNING: Never attempt to open the battery pack for
any reason. If battery pack case is cracked or damaged,
do not insert into charger. Do not crush, drop or damage
battery pack. Do not use a battery pack or charger that

10
ENGLISH
has received a sharp blow, been dropped, run over or
damaged in any way (i.e., pierced with a nail, hit with
a hammer, stepped on). Electric shock or electrocution
may result. Damaged battery packs should be returned to
service centre for recycling.
WARNING: Fire hazard. Do not store or carry the
battery pack so that metal objects can contact
exposed battery terminals. For example, do not place
the battery pack in aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails, screws, keys, etc.
CAUTION: When not in use, place tool on its side on
a stable surface where it will not cause a tripping
or falling hazard. Some tools with large battery packs
will stand upright on the battery pack but may be easily
knocked over.
Transportation
WARNING: Fire hazard. Transporting batteries can
possibly cause fire if the battery terminals inadvertently
come in contact with conductive materials. When
transporting batteries, make sure that the battery
terminals are protected and well insulated from materials
that could contact them and cause a short circuit.
STANLEYFATMAX batteries comply with all applicable shipping
regulations as prescribed by industry and legal standards which
include UN Recommendations on the Transport of Dangerous
Goods; International Air Transport Association (IATA) Dangerous
Goods Regulations, International Maritime Dangerous Goods
(IMDG) Regulations, and the European Agreement Concerning
The International Carriage of Dangerous Goods by Road (ADR).
Lithium-ion cells and batteries have been tested to section 38.3
of the UN Recommendations on the Transport of Dangerous
Goods Manual of Tests and Criteria.
In most instances, shipping a STANLEYFATMAX battery pack
will be excepted from being classified as a fully regulated Class
9 Hazardous Material. In general, only shipments containing a
lithium-ion battery with an energy rating greater than 100 Watt
Hours (Wh) will require being shipped as fully regulated Class
9. All lithium-ion batteries have the Watt Hour rating marked
on the pack. Furthermore, due to regulation complexities,
STANLEYFATMAX does not recommend air shipping lithium-ion
battery packs alone regardless of Watt Hour rating. Shipments of
tools with batteries (combo kits) can be air shipped as excepted
if the Watt Hour rating of the battery pack is no greater than
100 Whr.
Regardless of whether a shipment is considered excepted
or fully regulated, it is the shipper's responsibility to consult
the latest regulations for packaging, labeling/marking and
documentation requirements.
The information provided in this section of the manual is
provided in good faith and believed to be accurate at the
time the document was created. However, no warranty,
expressed or implied, is given. It is the buyer’s responsibility
to ensure that its activities comply with the applicable
Recommendations
1. The best storage place is one that is cool and dry away
from direct sunlight and excess heat or cold. For optimum
battery performance and life, store battery packs at room
temperature when not in use.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool, dry place out of the charger for
optimal results.
NOTE: Battery packs should not be stored completely depleted
of charge. The battery pack will need to be recharged before
use.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the labels
on the charger and the battery pack may show the following
pictographs:
Read instruction manual before use.
See Technical Data for charging time.
Do not probe with conductive objects.
Do not charge damaged battery packs.
Do not expose to water.
Have defective cords replaced immediately.
Charge only between 4 ˚C and 40 ˚C.
Only for indoor use.
Discard the battery pack with due care for the
environment.
Charge STANLEYFATMAX battery packs only
with designated STANLEYFATMAX chargers.
Charging battery packs other than the
designated STANLEYFATMAX batteries with a
STANLEYFATMAX charger may make them burst or
lead to other dangerous situations.
Do not incinerate the battery pack.
Battery Type
The SFMCPH845 operates on a 18 volt battery pack.
These battery packs may be used: SFMCB202, SFMCB204,
SFMCB206. Refer to Technical Data for moreinformation.

11
ENGLISH
Package Contents
The package contains:
1 Hedge Trimmer
1 Sheath
1 Battery
1 Charger
1 Instruction manual
•Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
•Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Wear headprotection.
Wear slip-resistantfootwear.
Beware of fallingobjects.
Do not expose the tool to rain or high
humidity or leave outdoors while it israining.
Switch the tool off. Before performing any
maintenance on the tool, remove the battery
from thetool.
Keep bystandersaway.
Keep hands away fromblade.
Electrocution hazard. Keep at least 10 m away
from overheadlines.
92
Directive 2000/14/EC guaranteed
soundpower.
Date Code Position (Fig. Q)
The date code29, which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Trigger switch
2 Lock button
3 Battery
4 Foam gripper
5 Threaded pole
6 Threaded sleeve
7 Locking latch
8 Hand guard
9 Five position head
10 Trimmer blade
11 Handle module
12 Trimmer head module
Intended Use
Your STANLEYFATMAX, SFMCPH845 hedge trimmer has been
designed for professional landscapingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This pole hedge trimmer is a professional power tool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
•Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
WARNING: Use only STANLEYFATMAX battery packs
andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. B, C)
NOTE: Make sure your battery pack9 is fullycharged.
To Install the Battery Pack into the Tool
Handle
1. Align the battery pack9 with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.

12
ENGLISH
To Remove the Battery Pack from the Tool
1. Press the release button10 and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. C)
Some STANLEYFATMAX battery packs include a fuel gauge
which consists of three green LED lights that indicate the level
of charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button11. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Joining Trimmer Head Module to Handle
Module (Fig. A, D)
Combining the handle module 11 to the trimmer head module
12 creates a pole trimmer that is approximately 6' (1.8 m).
1. Align the groove on the outside of the coupling end of the
handle module 11 with the tongue on the inside of the
coupling end of the trimmer head module 12.
2. Slide the threaded sleeve 6 on the trimmer head module
down as far as possible and rotate the sleeve clockwise until
it stops and completely covers the orangethreads.
WARNING: Always check to make sure that the sleeve is
completely threaded on and that the threads are no longer
visible. Not threading the sleeve completely on could
result in the modules becoming disconnected creating a
hazardous condition. Periodically check the connections
to insure that no threads arevisible.
Detaching Trimmer Head Module (Fig. D)
WARNING: Sharp moving blade. To prevent accidental
operation, insure that battery is disconnected from the
handle before performing the following operations.
Failure to do this could result in serious personal injury.
When detaching the modules rest the handle module 11 on
the ground and grasp the center of the trimmer head module
12 with one hand. Use your other hand to loosen the threaded
sleeve and then pull the two halves apart.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Proper Hand Position (Fig. D)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Always hold the trimmer, as shown in the illustrations in this
manual, with one hand on the switch handle 14 and one hand
on the foam gripper 4 ( .
Pivoting the Trimmer Head (Fig. A, E)
The trimmer head pivots 180° and can be locked into 5
different positions within that range. To avoid being pinched,
weargloves.
1. Press in on the locking latch 7 and raise the trimmerhead.
2. Lock the trimmer head into any of the 5 positions. Check
to make sure that trimmer head is locked into position by
trying to move the motor housing. If it is not locked, rotate it
to the closest lockposition.
Switch (Fig. A)
To turn the tool ON pull the lock button 1 back with your
thumb and then squeeze the trigger 2 . (Once the tool is
running you can release the lock button.) To turn the tool OFF,
release the trigger.
Trimming Instructions (Fig.A, F, G)
DANGER: KEEP HANDS AWAY FROMBLADES.
WARNING: To guard against injury, observe the
following:
•READ INSTRUCTION MANUAL BEFORE USING. SAVE
INSTRUCTIONMANUAL.
•Check the hedge for foreign objects such as wires or
fences before eachuse.
•KEEP HANDS ON HANDLES. DON’TOVERREACH.
•DO NOT USE UNDER WETCONDITIONS.
CAUTION: BLADE MAY COAST AFTER TURNOFF.
NOTE: Jamming the blade on large branches can
causedamage.

13
ENGLISH
WORKING POSITIONS (Fig.D, F, G) – Maintain proper footing
and balance and do not overreach. Wear safety goggles, non-
skid footwear and gloves when trimming. Hold the tool firmly
in both hands and turn the tool ON. Always hold the trimmer, as
shown in the illustrations in this manual, with one hand on the
switch handle 14 and one hand on the foam gripper 4 ( . Never
hold the tool by the handguard.
TRIMMING NEW GROWTH – Using a wide, sweeping motion,
feeding the blade teeth through the twigs, is most effective.
A slight downward tilt of the blade in the direction of motion
gives the bestcutting.
LEVEL HEDGES – To obtain exceptionally level hedges a piece
of string can be stretched along the length of the hedge as
aguide.
SIDE TRIMMING HEDGES (Fig.G) – Orient the trimmer as
shown and begin at the bottom and sweepup.
Guidelines for trimming (UK & Ireland)
• Trim hedges and shrubs with seasonal leaves (new leaves
every year) in June andOctober.
• Trim evergreens in April andAugust.
• Trim conifers and other fast growing shrubs every six weeks
from May untilOctober.
Guidelines for trimming (Australia & New
Zealand)
• Trim hedges and shrubs with seasonal leaves (new leaves
every year) in December andMarch.
• Trim evergreens in September andFebruary.
• Trim conifers and other fast growing shrubs every six weeks
from October untilMarch.
MAINTENANCE
Your STANLEYFATMAX power tool has been designed
to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon
proper tool care and regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
1. After use, carefully clean the blades with a resin solvent.
2. After cleaning, apply a light film of lubrication to the
exposedblade.
3. Turn the trimmer vertical with the blades toward the ground
and run the trimmer for a few seconds to fully disperse
thelubrication.
Transporting the Pole Hedge Trimmer
Always remove the battery from the tool when transporting the
Pole Hedge Trimmer. Hold pole at balance point with blades
towards therear.
Storing the Pole Hedge Trimmer
1. Disconnect battery fromtool.
2. The best storage place is one that is cool and dry away from
direct sunlight and excess heat orcold.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered by
STANLEYFATMAX, have not been tested with this product,
use of such accessories with this tool could be hazardous.
To reduce the risk of injury, only STANLEYFATMAX
recommended accessories should be used with
thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
household waste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
our environment:
• Run the battery pack down completely, then remove it from
the tool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed of properly.

ENGLISH
Australia & New Zealand
Stanley Black & Decker
Stanley Fat Max
www.stanleytools.com.au
Tel.[phone] (Aust) or Tel. [phone] (NZ)
810 Whitehorse Road Box Hill VIC 3128, Australia
N72683711/19
