Star Trac eSpinner 7140 Operating instructions

Troubleshooting
STAR TRAC FITNESS
1 of 8
637-1419 Rev: A
Possible Display Issues
eSpinner Models 7140 and 7200
A. Touch Screen related issues
Symptom: The touch screen does not recognize a touch on the screen or the touch points are out of alignment.
Troubleshooting:
I. Clean the surface of the screen with a damp cloth (do not use a cleaning agent that contains ammonium
and do not spray directly onto the display) to get rid of any kind of settlement. Also pay attention if there is
anything stuck between the plastic front cover and the actual touch screen.
II. If you can access the service menu using the touch screen, select the button that says “recalibrate” while
in the “Calibration and Setup” menu (Fig.1) to start the touch screen calibration process.
Fig. 1
III. If you can NOT access the service menu using the touch screen follow the instructions in document
number 637-1004 and try to recalibrate the touch screen this way. It might take some tries before this
works. Be patient and use a stopwatch for this procedure. You have to be very precise.

Troubleshooting
STAR TRAC FITNESS
2 of 8
637-1419 Rev: A
B. Power related issues (black screen).
Symptom: The complete screen does not turn on and stays black (Fig. 2).
Troubleshooting:
I. Remove the display and post and disconnect the power connector. Measure if you get 12V out of the red
and black cable that routs through the neck.
II. If you do not get 12V check the cabling for damage and see if the green light on the power supply (hidden
in the base of the front section of the frame) is lit.
III. Check the cable that routes into the display (black and red) and plugs into the mother board if there is any
damage and check for continuity.
IV. Verify that the connector inside the neck itself is making a solid connection. Bend the pins inside the
connector if needed to ensure a solid connection and proper power flow. Perform a vibration test (snap
your finger a couple of times onto the connector while the unit is turned on) to see if the connection is
solid and won’t fail later on when the unit is reassembled again.
Parts reference: 740-6971 Main Power Cable (red and black cable that connects to the mother board on one end
and to the power cable that comes up from the power supply in the base of the unit).
740-6985 Internal Power Supply (the red and black cable inside the neck that connects to the
power cable coming out of the display is hard wired into the internal power supply).
Fig. 2

Troubleshooting
STAR TRAC FITNESS
3 of 8
637-1419 Rev: A
C. RPM related issues (Cadence)
Symptom: The unit goes over into the cool down mode after three minutes because it does not recognize
any movement on the pedals. Also see document number 635-4149.
Troubleshooting:
I. Align the sensor and check if it points in the right direction and/or bring it closer to the flywheel (Fig. 3).
II. Check the continuity on the sensor and extension cable (opens and closes the circuit when the
magnet comes by).
III. Check if you get RPMs on the display (go into the video model/Instructor mode on the screen,
disconnect the sensor connection inside the neck and quickly tap/shorten the two pins inside the
connector a couple of times to simulate a signal).
Parts reference: 740-6987 RPM Sensor, 740-6986 RPM Extension Cable (connects to the RPM sensor on one
end and to the RPM cable that comes out of the display), 740-6964 Display RPM cable
(connects to the RPM extension cable on one end and to the display mother board).
Fig. 3

Troubleshooting
STAR TRAC FITNESS
4 of 8
637-1419 Rev: A
D. Video related issues (Instructor Mode / Spinning Videos)
Symptom: BLACK screen when in “Instructor
Mode” (Fig. 4).
Troubleshooting:
I. Turn the unit off and carefully re-seat
the SD card. See also document
number 620-7895 for further
information for this procedure.
II. Recycle the power.
III. Use a new/different SD card, probably
taken out of a working unit.
IV. Check if the audio settings are correct.
See document number 637-1328 for
further information for the correct audio
settings.
Symptom: GREEN screen when in “Instructor
Mode” (Fig. 5).
Troubleshooting:
I. Turn the unit off and carefully re-seat
the SD card. See also document
number 620-7895 for further
information for this procedure.
II. Recycle the power.
III. Use a new/different SD card, probably
taken out of a working unit.
IV. Check if the audio settings are correct.
See document number 637-1328 for
further information for the correct audio
settings.
Fig. 4
Fig. 5

Troubleshooting
STAR TRAC FITNESS
5 of 8
637-1419 Rev: A
E. Audio related issues
Symptom: The user plugs in the headphones but there is no audio/sound.
Troubleshooting:
I. Try at least one different set of headphones to verify the issue is not caused by the headphones.
II. Check the audio settings. See document 637-1328 for further information.
III. Try a different Pigtail Headphone cable (Fig. 6) or swap with a unit close by.
IV. Check if the connection of the INTERNAL headphone cable into the mother board and to the
pigtail headphone cable is solid. Unplug and plug back in again. Also check for cable damage.
Swap/replace cables if needed.
Parts reference: 740-7523 Pigtail Headphone Cable (this is the cable/connector where the user plugs in the
headphones), 740-6972 Internal Headphone Cable (plugs into the mother board and connects
to the actual Pigtail Headphone Cable on the other end).
Fig. 6

Troubleshooting
STAR TRAC FITNESS
6 of 8
637-1419 Rev: A
F. Heart Rate related issues
Symptom: No or erratic HR reading and/or BPM value to high (coded Polar heart rate strap only).
Troubleshooting:
I. Check current software and update it if the version is not 1.08 or higher. See document number
637-1315 for uploading instructions.
II. Verify if the unit is equipped with the updated HR board. See document number 620-7900 for further
information.
III. Verify if the routing of the HR board cable is correct (Fig. 7) and it was installed in the right position as
seen in Fig. 8.
Parts reference: 740-7008 Heart Rate Board (see document number 620-7900 for installation instructions).
Fig. 7
Fig. 8

Troubleshooting
STAR TRAC FITNESS
7 of 8
637-1419 Rev: A
G. TV related issues
1) Symptom: No TV icon when in TV mode (Fig. 9).
Troubleshooting:
I. Verify that the TV blocking feature is set to “enable blocking”. Also see document number
637-1335 for further information.
Fig. 9
Fig. 10

Troubleshooting
STAR TRAC FITNESS
8 of 8
637-1419 Rev: A
2) Symptom: No or only bad TV picture.
Troubleshooting:
I. Perform a channel scan and change parameter if you are not sure which specific setting applies
to this site (e.g. digital, analog, air, cable…).
II. Verify you have sufficient signal strength coming out of the coax cable (see document number
637-1415 for requirements). Swap cables with a close by unit if possible.
III. Check all connections of the coax cable and bypass the coax cable that routs through the neck
by plugging it directly into the head.
Parts reference: 740-6976 Display Coax Cable (this is the coax cable that connects internally to the tuner card and
on the other end to the coax cable that comes up from the base of the unit inside the neck).
3) Symptom: No channel scan possible / no channel scan option (“Tuner Version Invalid”, Fig. 11).
Troubleshooting:
I. Verify the tuner version by going into the settings (“calibration and setup”).
II. If it says “Tuner Version Invalid” (Fig. 11) replace the tuner card. See document number 637-
1349 for replacement instructions.
Parts reference: 740-6955 Tuner Card ATSC/NTSC
Note: This issue is only known to happen in North America (ATSC/NTSC based countries). Therefore the
PAL/SECAM tuner card is NOT a spare part we supply separately.
Fig. 11
